The fully automatic convertible top
*
Wind deflector
*
Convenience operation from the
driver's door lock>To open: with the door closed, turn
the key to the "Unlock" position and
hold it
>To close: with the door closed, turn
the key to the "Lock" position and
hold it.
Releasing the key stops the movement.
For safety reasons, to keep the closing
process in view, you cannot use the re-
mote control for convenience operation.
At higher speeds, the lower air
pressure in the passenger com-
partment may create a vacuum and
cause the convertible top to start flut-
tering. Increase the air supply via the
ventilation controls so that a vacuum
does not occur in the vehicle.c
The wind deflector cuts down air turbu-
lence within the passenger area, thus
affording a pleasant ride, even at higher
speeds. It is delivered in a protective
casing, and because of its minimal size,
can easily be stowed in the luggage
compartment.Installation1 Take the wind deflector out of its
protective casing

52n
Wind deflector
*
2 Flip out the side pieces on both sides
and lock them into place (arrow)46cde098
Position the wind deflector so that
the smaller portion points toward
the front.c
3 Guide the mounting pin for the side
part into the opening provided
4 Using the slide, pull the mounting pin
on the other side back, so that it can
be guided into the opening provided
5 Unlock the convertible top compart-
ment lid, refer to page 45 or 50, and
open the convertible top compart-
ment lid
6 Flip the rear half of the wind deflector
back so that the attachments are in
contact with the vehicle
7 Close the convertible top compart-
ment lid. The wind deflector has now
been attached and is theft-proof.
46cde099
To avoid any pinching, move the
convertible top compartment lid
from above only.
With wind deflector in place: never
push the front seat all the way back to
avoid damage to the wind deflector.c
RemovingRemove the wind deflector in the
opposite order of installation.

53n
IndexDataTechnologyRepairsCar careControlsOverview
For your personal safety when adjusting
the seat position, please follow the in-
structions below carefully.
Never try to adjust your seat while
driving the vehicle. The seat could
respond with an unexpected movement,
and the ensuing loss of vehicle control
could lead to an accident.
Be sure that the safety belt remains
firmly against your body at all times. In
the event of a frontal impact, a loose lap
belt could slide over the hips, leading to
abdominal injury. In addition, the safety
belt's restraint effectiveness is reduced
if the belt is worn loosely.
Never ride with the backrest reclined to
an extreme angle (this particularly
applies to the front passenger). If you do
so, there is a risk that you will slide
under the safety belt in an accident,
thus reducing the protection provided
by the safety belt.<
Correct sitting postureTo reduce strain on the spinal column,
sit all the way back in the seat and rest
your back fully against the backrest.
In the ideal sitting posture, your head is
positioned along a straight line in rela-
tionship to your spinal column.
For long-distance driving, you may wish
to increase the backrest tilt-angle
slightly to reduce muscular tension.
You should be able to grasp the steer-
ing wheel at its highest point with your
arms slightly bent.
1 Backward/Forward adjustment
2 Cushion height
3 Backrest angle
Comply with the adjustment in-
structions on this page, otherwise,
personal safety is diminished.<
46cde012
Seat adjustment

54n
Head restraints Front head restraints1 Height
Head restraints reduce the risk
of spinal injury in the event of an
accident.
Adjust the head restraint so that its
center is approximately level with your
ears.
To avoid injury when moving the head
restraint, do not hold on between the
head restraint and the backrest's upper
edge.<46cde029
2 Tilt angle
Manually position the head restraint as
desired. 46cde087
Rear head restraints
Rear head restraints may only be
lowered if there are no passen-
gers in the back seat. Raise lowered
head restraints again before taking on
passengers in the back seat.<
To completely lower the rear head
restraints:
1 Press the button down (arrow) and
keep it pressed
2 Push down on the top of the head
restraint.
46cde100

55n
IndexDataTechnologyRepairsCar careControlsOverview
Head restraints BMW sports seat
*
Raising the head restraintsKeep pulling on the head restraints until
they click into place.
Do not remove the rear head re-
straints, as otherwise they will be
damaged.<
For additional information, please con-
tact your BMW center.
Do not use the rear head re-
straints as a shelf. Always keep
the travel path for the rollover protec-
tion system free and clear. Never attach
any type of protective coverings to the
head restraint (also refer to the labeling
on the head restraints).<
1 Tilt angle
2 Backward/Forward adjustment
3 Cushion height
4 Backrest angle
Comply with the adjustment in-
structions on page 53. Failure to
do so could result in diminished per-
sonal safety.<46cde013
5 Thigh support area:
Pull the lever and adjust the position
of the cushion for thigh support as
desired.46cde040

56n
Entering the rear Lumbar support
*
The seat-integrated safety belt system
ensures easier access to the back seat.
It is not necessary to adjust anything on
the safety belt system. It automatically
adjusts to different body sizes.
1 Pull up the lever (1) and tip the back-
rest forward
2 Press the button (2) in the driving
direction and keep it pressed until
the seat has moved into the desired
position.
The backrest can be locked while
tipped forward. This is practical,
for example, when entering the back
seat on a hill. To do this, press against
the backrest until it clicks into place. It
does not need to be released with the
lever (1) to tip it back into place again.<46cde049
If you tip the backrest back into place
and hold the button (2) pressed oppo-
site the driving direction, the seat
moves back into the previous position.
If the button (2) is released before-
hand, the seat stops in the re-
spective position. It does not need to
be released with the lever (1) to tip it
back into place again.<
Lock both back restraints while
driving, otherwise there is a dan-
ger of an unexpected movement caus-
ing an accident.<
You can adjust the backrest's contour
for additional support in the curvature
of your spine's lumbar region.
The upper hips and spinal column re-
ceive supplementary support to help
you maintain a relaxed, upright posture.
>Press front/rear of switch:
Increase/decrease curvature
>Press the upper/lower end of the
switch:
Increase the upper/lower curvature.46cde011

57n
IndexDataTechnologyRepairsCar careControlsOverview
Seat and mirror memory
*
You can store and recall three different
driver's seat and outside mirror posi-
tions. The illustration shows the buttons
on the driver's seat, for making these
position adjustments.
The setting for the head restraint
is stored in memory, but the set-
ting for the lumbar support is not. 1 or 2
2 Set the desired positions for the seat,
head restraint and outside mirror
3 Press the
M
EMORY button: the indi-
cator lamp in the button lights up
4 Press memory button 1, 2 or 3, as
desired. Indicator lamp goes out.
46cde014
To select a stored setting Convenience function:
1 Open the driver's door after unlock-
ing or set the ignition key in posi-
tion 1
2 Briefly press memory button 1, 2 or 3,
as desired.
The adjustment cycle is canceled im-
mediately if you press a seat adjust-
ment switch or one of the memory
buttons.
Security function:
1 With the driver's door closed and the
ignition key either removed or in posi-
tion 0 or 2
2 Maintain pressure on the desired
memory button (1, 2 or 3) until the
adjustment process is completed.
If you press the
M
EMORY button acci-
dentally: press the button again; the
indicator lamp goes out.
Do not select a memory position
while the vehicle is moving. If you
do so, there is a risk of accident from
unexpected seat movement.<
Your BMW center can adjust your
vehicle's systems in such a man-
ner that your personalized settings are
automatically set for the seat, head
restraint and outside mirror positions
when you unlock the vehicle with your
personal remote control.<
If you make use of this method of
adjustment, be sure that the foot-
well behind the driver's seat is unob-
structed before unlocking the vehicle.
If you fail to do so, any persons or ob-
jects behind the seat could be injured
or damaged by a rearward movement
of the seat.<

58n
Seat and mirror memory
*
Adjusting steering wheel Mirrors
Passenger side exterior mirror
tilt function(automatic curb monitor)
*
1 Move the mirror selector switch 1 to
the "driver's mirror" position
2 When the selector lever is placed in
"Reverse", the passenger-side mirror
tilts downward. This allows the driver
to see the area directly adjacent to
the vehicle during parking (curbs,
etc.).
You can deactivate this automatic fea-
ture by setting the mirror selector switch
to the "passenger side" position.463de043
1 Push the locking lever downward
2 Adjust the steering wheel for your
seating position
3 Pull the lever back in to clamp the
steering wheel in the new position.
Do not adjust the steering wheel
while the vehicle is moving. If you
do so, there is a risk of accident from
unexpected movement.<460de073
Exterior mirrors1 Switch for 4-way adjustment
2 Selector switch for changing
between mirrors462us016

59n
IndexDataTechnologyRepairsCar careControlsOverview
MirrorsYou can also adjust the mirrors manu-
ally by pressing against the outer edges
of their lenses.
The mirror on the passenger's
side features a lens with a more
convex surface than the mirror installed
on the driver's side. When estimating
the distance between yourself and
other traffic, bear in mind that the ob-
jects reflected in the mirror are closer
than they appear. Estimating the dis-
tance between you and the traffic be-
hind you is therefore imprecise. ed with the ignition key in position 2.
Interior rearview mirror To reduce glare from behind when
driving at night, turn the knob.Sun visorsThese can be folded down toward the
windshield or swiveled out against the
side windows.46cus034
Inside rearview mirror with
automatic dimming feature
*
By responding to the effects of ambient
light and the glare from following traffic,
this mirror automatically dims through
an infinitely variable range.
The mirror switches to its clear, un-
dimmed mode whenever the trans-
mission is placed in reverse gear
(selector lever in "Reverse").
For proper functioning of the mirror, be
sure that the two photocells are unob-
structed and clean. One of the photo-
cells (arrow) is positioned in the mirror's
glass, while the other is slightly offset
on the opposite side of the mirror.
For an explanation of the electro-chro-
mic technology used in this mirror, refer
to page 175.46cde023

60n
Car Memory, Key Memory How the system functionsYou have probably frequently wished
that you could configure individual
functions of your vehicles to reflect
your own personal requirements. In
engineering your vehicle, BMW has in-
cluded several user-defined functions
in the vehicle's design. Your BMW cen-
ter can make these settings for you in
accordance with your wishes.
There are settings related to the vehicle
("Car Memory") and settings related to
individuals ("Key Memory"). You can
have up to four different basic settings
adjusted for four different persons. The
only requirement is that each person
uses his or her own remote control key. 463de029
When your vehicle is unlocked with the
remote control, the vehicle recognizes
the individual user by means of a data
exchange with the key, and makes ad-
justments accordingly.
In order for you to distinguish between
different keys, colored decals are sup-
plied together with the keys.What the system can doYour BMW center can provide you with
details on the capabilities of the Car
Memory and Key Memory systems.
You will see this symbol through-
out the Owner's Manual. It is to
remind you at appropriate places of the
settings that are available to you.<
An example of Key Memory is the auto-
matic adjustment of the power driver's
seat with stored settings for the indi-
vidual person when the vehicle is un-
locked.
