fuel fill door release BMW 325i TOURING 2001 E46 Owner's Manual

34n
Central locking system Opening and closing Ð from the outside The conceptThe central locking system is ready for
operation whenever the driver's door is
closed. The system engages and
releases the locks on the
>doors
>tailgate and rear window
>fuel filler door.
The central locking system can be
operated
>from outside via the door lock and
using the remote control
>from inside by pressing a button.
Activating the central locking system
from inside does not lock the fuel filler
door (see page 38). When it is actuated
from the outside, the anti-theft system
is activated simultaneously. Both the
door locks and release handles remain
locked. The alarm system is also armed
or disarmed.
If locked from the inside, the central
locking system unlocks automatically in
the event of an accident. But the system
only unlocks those doors that were not
locked separately using the safety
buttons, refer to page 38. In addition,
the hazard warning flashers and interior
lamps come on.
Using the keyOne turn of the key in the driver's door
lock unlocks the driver's door only.
Turning the key a second time unlocks
all of the remaining doors, the tailgate
and the fuel filler door.
You can have a signal set as an
acknowledgment message that
the vehicle is closed correctly.<460de006
Convenience operationYou can also operate the power
windows and sliding/tilt sunroof via the
door lock.
>To open: if the door is closed, hold
the key firmly in the "Unlock" posi-
tion.
>To close: if the door is closed, hold
the key firmly in the "Lock" position.
Watch during the closing process
to be sure that nobody is inadvert-
ently injured. Releasing the key stops
the operation. Turn the key to the extreme left or right
to unlock/lock the door.

38n
Opening and closing Ð from the inside Use this button to operate the central
locking system when the front doors
are closed. The doors and tailgate are
unlocked or locked only. The anti-theft
alarm system is not activated.
If only the driver's door was
unlocked from the outside and
you press on the button, then all the
other doors, tailgate and rear window
as well as the fuel filler door will unlock
if the driver's door is open.
If the driver's door is closed it will be
locked.<
The central locking system can be
locked automatically as soon as
you begin to drive if you desire. You
may also have this adjusted so that it is
specific to keys.<460us007
To unlock and open the doors>Either unlock the doors together with
the button for the central locking
system and then pull each of the
release handles above the armrests,
or
>pull the release handle for each door
twice: the first pull unlocks the door,
and the second one opens it.To engage locks>Use the central locking button to lock
all of the doors simultaneously, or
>press the individual safety lock
buttons down. The fuel filler door
then remains unlocked. As an added
design feature to prevent the driver
from being inadvertently locked out
of the vehicle, the driver's door safety
lock button will not engage as long as
the door is open.
Children might be able to lock the
doors from the inside. For this
reason, take the vehicle's keys with you
so that the vehicle can be opened again
from the outside at any time.<

166n
Manual release Unlatch the right-side side panel in the
cargo area (arrow 1). Pull the knob with
the fuel pump symbol (arrow 2). 463de056
Manual operation 1 Remove the interior lamp (refer to
page 158), reach into the opening
and push out the panel.
2 Turn the sunroof's steel crank with
the Allen wrench from the onboard
tool kit (refer to page 152) in the
desired direction.460de183
Manual operation1 Fold either the center armrest or the
rear backrest in the back forward.
2 Remove the cover panel under
tailgate 1 (possible by using the igni-
tion key).
3 Press the lever (arrow) to the right.
The luggage compartment is locked
again as soon as you close the tailgate.463de039
Fuel filler door Sliding/tilt sunroof
* Tailgate

Everything from A to ZFolding rear backrest108
Footbrake118
Footwell lamps88
bulb replacement158
Four-wheel drive175
Front fog lamps, bulb
replacement155
Front seat adjustment46
Frost protection,
radiator137
Fuel28
consumption77
consumption display74
gauge74
preparation184
quality28
Fuel filler door
releasing following an
electrical malfunction166
Fuel reserve indicator
lamp74
Fuel tank capacity187
Fuel tank gauge74
Functional status179
Fuses164 G
Gasoline28
Gasoline gauge74
Gasoline quality28
Glove compartment101 Glove compartment lamp,
bulb replacement158
Gross vehicle weight186
H
Handbrake63
Hands-free system103
Hazard warning flashers26
Hazard warning triangle26
Head restraint47
Headlamp covers,
care141,153
Headlamp flasher88
Headlamp washer
system70,134,187
Heated seats100
Heating, rapid94
Heavy loads110
Height185
HiFi system101
High beams23,68,88
bulb replacement153
High Performance Synthetic
Oils136
High-mount brake lamp157
Hood release130
Horn17
Hubcap160
Hydraulic Brake assistant,
refer to DBC118
I
Ice warning76
Icy roads76,121
Identification, tires127
Ignition key32,35
Ignition lock61
Imprint4
Indicator lamps20
Inflation pressure28,124
monitoring85,178
INSPECTION74
Installation child restraint
systems60
Instrument cluster18
Instrument lighting87
Interaxle tire rotation126
Interface socket for Onboard
Diagnostics149
Interference, cellular
phone123
Interior lamps36,88
bulb replacement158
remote control36
Interior motion sensor41
Interior rearview mirror51
automatic dimming
feature52,176
Interlock61
Intermittent wipe68
J
Jack159
Jump-starting167 K
Key32,35
Key Memory52 L
Lamps and bulbs153
Lashing eyes110
LATCH attachment of the
child seat58
Leather care145
Length185
License plate lamp
bulb replacement157
Light switch87
Light-alloy wheels129
Lighter104
Load-securing devices110
Louvers90,96
Low beam headlamps87
bulb replacement153
Lug bolts160
Lug wrench159

Owner service procedures
199n
IndexDataTechnologyRepairsCar careControlsOverview
Luggage compartment
emergency actuation166
Luggage compartment
lamps, bulb
replacement158 M
Maintenance140
Malfunction displays75
Microfilter, change165
Motion sensor, switching
off42 O
Oil
quality136
specifications136
viscosity136
Onboard tool kit152 P
Pressure, tires28 R
Rear hatch lamp
bulb replacement157
Rear lamp156
Release the hood130 Releasing the fuel filler door
after an electrical
defect166
Removing condensation
from the windows94
Replace windshield wiper
blades152
Replacement key32
Replacing lamp bulbs153
Replenish washer
reservoir134
Return used batteries164
S
Side lamps
bulb replacement154
Sliding/tilt sunroof
close in event of electrical
defect166
Space-saver spare tire159
Spare key32
Spare tire159
Spare wheel159
Starting problems115
Switching off tilt alarm/
interior motion sensor42
T
Tail lamps
bulb replacement156
Tailgate lamps
bulb replacement156
Tailgate, emergency lock
operation166
Tilt alarm, switching off42
Tire changing159
Tire damage124
Tools152
Tow fittings168
Tow starting168
Towing168
Turn signals, bulb
replacement154 U
Use antifreeze for
radiator138
Used batteries164
Used engine oil136 V
Vanity mirror lamp, bulb
replacement158
W

Warning lamps20
Warning messages75
Washer fluid, adding134
Washer nozzles,
adjusting134
Washer reservoir, filling134
Wheel changing159
Windshield wiper blades,
replacing152
Working in the engine
compartment130
