BMW 540I SEDAN 2000 Owners Manual

201n
RepairsIndexOverview Controls Car care Technology Data
Weights Ð sedan
BMW 528i BMW 540i
Curb weight (with one person, ready for operation, full tank of fuel, options not included)
with manual transmission
with automatic transmissionlbs. (kg)
lbs. (kg)3,495 (1,585)
3,549 (1,610)3,748 (1,700)
3,803 (1,725)
Approved gross vehicle weight
with manual transmission
with automatic transmissionlbs. (kg)
lbs. (kg)4,508 (2,045)
4,563 (2,070)4,762 (2,160)
4,817 (2,185)
Approved front axle weight lbs. (kg)
2,138 (970)2,381 (1,080)
Approved rear axle weight lbs. (kg) 2,579 (1,170) 2,635 (1,195)
Approved roof load capacity lbs. (kg) 220 (100) 220 (100)
Permitted axle loads and permitted total vehicle weight may not be exceeded.
Luggage compartment capacity cu ft (l) 16.2 (460) 16.2 (460)

202n
Weights Ð sport wagon
BMW 528i BMW 540i
Curb weight (with one person, ready for operation, full tank of fuel, options not included)
with manual transmission
with automatic transmissionlbs. (kg)
lbs. (kg)3,726 (1,690)
3,781 (1,715)Ð
4,056 (1,840)
Approved gross vehicle weight
with manual transmission
with automatic transmissionlbs. (kg)
lbs. (kg)4,817 (2,185)
4,872 (2,210)Ð
5,093 (2,310)
Approved front axle weight lbs. (kg)
2,160 (980)2,381 (1,080)
Approved rear axle weight lbs. (kg) 2,844 (1,290) 2,910 (1,320)
Approved roof load capacity lbs. (kg) 220 (100) 220 (100)
Permitted axle loads and permitted total vehicle weight may not be exceeded.
Luggage compartment capacity cu ft (l) 14.5 Ð 53.9 (410 Ð1,525) 14.5 Ð 53.9 (410 Ð1,525)

203n
RepairsIndexOverview Controls Car care Technology Data
Capacities

Notes
Fuel tank
Reserve gal. (liters)
gal. (liters)approx. 18.5
approx. 2.1
approx. 2.6 (approx. 70)
(approx. 8)
(approx. 10) Ð BMW 528i
Ð BMW 540iFuel specification: Refer to
page 29
Windshield washer system
with headlamp washer system
Intensive cleaning systemquarts (liters)
quarts (liters)
quarts (liters)approx. 3.7
approx. 6.3
approx. 1.1(approx. 3.5)
(approx. 6.0)
(approx. 1.0)For details: Refer to page 148
Cooling system including
heater circuitquarts (liters) 11.1 (10.5)
12.7 (12.0)Ð BMW 528i
Ð BMW 540iFor details: Refer to page 151
Engine oil filter change quarts (liters) 6.9 (6.5)
7.9 (7.5)Ð BMW 528i
Ð BMW 540i"High Performance Synthetic Oil"
for gasoline engines.
Specifications: Refer to page 150
Manual transmission, automatic
transmission and differentialÐ Ð Lifetime fluid, no fluid change
required

204n
Electrical system Drive beltsBattery 12 V, 90 AhSpark plugsNGK BKR 6 EQUP
Bosch FGR 7 DQP
(not released at this time)
This spark ignition system meets all
requirements of the Canadian Interfer-
ence-Causing Equipment Regulations
(ICES-2).BMW 528i:
Water pump Ð Alternator Ð
Power steering
V-belt 6 K x 1555
A/C compressor
V-belt 5 K x 906
BMW 540i:
Water pump Ð Alternator Ð
Power steering
V-belt 7 K x 1635
A/C compressor
V-belt 5 K x 1004You can obtain Original BMW
Parts and Accessories, as well as
professional advice from your autho-
rized BMW center.<

205n
RepairsIndexOverview Controls Car care Technology Data

206n

Overview
Controls and features
Operation, care
and maintenance
Owner service procedures
Technical data
Index Advanced technology

207n

RepairsIndexOverview Controls Car care Technology Data

Everything from A to Z 208
Owner service procedures 214

A
ABS (Antilock Brake
System)23, 127
Accessories6
Activated-charcoal
filter103
Active seat53, 190
Adaptive Transmission
Control (ATC)71, 188
Add engine oil149
Add washer fluid148
Adjust backrest52
Adjust seats50
Adjust steering wheel54
Adjust temperature100
Air conditioning control98
Remove condensation
from windshields101
Air distribution100
Air pressure134
Air supply101
Air vent98
Airbags23, 60, 160, 188
Alarm system45
Antenna, Diversity190
Antennas133
Antifreeze151
Antifreeze, radiator130
Antilock Brake System
(ABS)23, 127
Anti-theft protection37
Approved gross vehicle
weight201Aquaplaning134
ASC+T/DSC24, 91, 189
Ashtray110
ATC (Adaptive Transmission
Control)71, 188
Attach vacuum cleaner111
AUC (Automatic recirculated-
air control)101
Automatic car washes155
Automatic climate control98
Automatic cruise control80
Automatic curb monitor56
Automatic dimming, interior
rearview mirror55
Automatic rear window
wiper79
Automatic recirculated-air
control (AUC)101
Automatic Stability Control
plus Traction/Dynamic
Stability Control (ASC+T)/
(DSC)24, 91, 189
Automatic steering wheel
adjustment54
Automatic transmission71
Automatic transmission with
Steptronic74
Automatic transmission, oil
capacities203
Average fuel
consumption88
Average speed88
Axle loads201

B
Backup lamps70
Bulb replacement169
Battery176, 204
Capacity204
Charging177
Discharged182
Removal and
installation178
Belts59
Beverage holder109
Blower101
BMW active seat53, 190
BMW comfort seat51
BMW sports seat52
BMW Universal
Transmitter105
Bore198
Brake system124
Brake faults130
Brake fluid152
Brake lamps, bulb
replacement169
Brake pads23
Breaking-in the
brakes124
Disc brakes124, 128
Parking brake23, 69
Brake-in procedure124
Brakes, refer to Brake
system
Breaking in the vehicle124
Break-resistant security
glass, care158
Bulb replacement167

C
Car jack173
Car keys35
Car Memory58
Car phones and telephones,
refer to the seperate
Owner's Manual
Car radio
reception133, 190
Car telephone109
Car wash155
Care, vehicle exterior156
Care, vehicle interior158
Cargo loading120
Caring for the vehicle
finish157
Catalytic converter126
Cellular phone133
Center (high-mount) brake
lamp, bulb
replacement171
Central locking system,
button40
Changing a tire173
Charging the battery177
Check air pressure30
Check Control85
Check engine oil level149
Child restraint systems59
Child's seat59
Child-safety locks66
Cigarette lighter110

Everything from A to Z

209n

RepairsIndexOverview Controls Car care Technology Data

Everything from A to Z

Clock, refer to the Radio
Owner's Manual
Cockpit16
Cold start68
Comfort seat51
Compartments108
Compression ratio198
Computer, refer to Onboard
computer88
Consumption display83
Convenience operating
mode of windows and
sliding/tilt sunroof36
Coolant130, 151
Antifreeze130
Capacity203
Temperature gauge84
Cover, sun blinds104
Cruise control80
Cruising range88
Cup holder109
Curb weight201

D
Dashboard16
Data link connector for
Onboard Diagnostics162
Daytime-driving lamp94
DBC (Dynamic Brake
Control)24, 129
Deep water125Defrost windshields101
Digital sound processor192
Dimensions199
Dipstick, engine oil149
Disc brakes124, 128
Disconnect the battery178
Displacement198
Display lighting94
Displays18
Distance warning90
Diversity Antenna
system190
Divided rear-seat
backrest112
Door keys35
Door locks, care130
Doors
Emergency release36
Manual operation36
Unlocking and locking36
Drive belts204
Driving notes125
Driving through water125
DSC (Dynamic Stability
Control)24, 91, 189
Dynamic Brake Control
(DBC)24, 129
Dynamic Stability Control
(DSC)24, 91, 189

E
Electric power seat50
Electric power windows47
Electrical defect
Fuel filler door180
Sliding/Tilt sunroof180
Tailgate181
Electrical heating exterior
mirror55
Electrical steering wheel
adjustment54
Elements of operation16
Emergency operation
Doors36
Fuel filler door180
Luggage compartment lid/
Tailgate41, 181
Sliding/Tilt sunroof180
Energy Control83
Engine
Compartment144
Coolant151
Specifications198
Engine oil
Capacity203
Consumption149
Grades150
Level23
Pressure23
Error indicators85
Exterior finish156
Exterior mirror54
Electrical heating55

F
Failure of an electrical
accessorry180
Failure warnings85
Filler cap cover28
Filling capacities203
First-aid kit27
Fittings, tow-starting and
towing183
Flashlight108
Flat tire134
Footbrake
Footwell lamps96
Forward/Back adjustment,
seat50, 52
Front fog lamps95, 169
bulb replacement169
Front seat adjustment50
Frost protection,
radiator151
Fuel29
Capacity203
Consumption indicator83
Gauge83
Quality29
Reserve203
Fuel filler door release after
electrical fault180
Fuel tank, capacity203
Fuses178

Everything from A to Z

G
Gasoline29
Gasoline gauge83
Glove compartment108
Gross weight201

H
Handbrake23, 69
Handsfree system109
Hazard warning system27
Hazard warning triangle27
Head restraint53
Headlamp cleaning78
Headlamp covers,
care155, 167
Headlamp flasher77
Headlamp washer
system148
Heated seats103
Heated steering wheel103
Heating and ventilation98
Heating while stopped102
Heavy loads120
Height199
Height adjustment
Seats52
Steering wheel54
HiFi system192
High beams24
Bulb replacement167
High Performance Synthetic
Oils150Hood release143
Horn25, 26
Hydraulic Brake Assistant,
refer to DBC24, 129

I
Ice warning82
Identification number of the
vehicle153
Identification, tires137
Ignition key35
Ignition lock67
Independent ventilation104
Indicator77
Indicator lamps22
Inflation pressure30, 134
Monitoring92, 194
INSPECTION84
Instrument cluster18, 20
Instrument lighting94
Instrument panel20
Instrument panel switch77
Instruments18
Integrated rear axle194
Intensive automatic cleaning
unit78
Intensive cleaning
system148
Interaxle tire rotation136
Interference indicators85
Interference with
car phones133Interior lamps96
Remote control38
Interior mirror55
automatic dimming
feature55
Interior motion sensor46
Deactivation46
Interior rearview mirror
with automatic dimming
feature55, 192
Interlock67
Intermittent wiper switch77

J
Jack173
Jump-starting182

K
Key Memory58
Keys35
Kickdown72, 75

L
Lashing eye44, 120
Leather care159
Length199
Level control
system24, 132, 195
Light switch94
Light-alloy wheels138, 140
Lighter110Lights-on warning94
Load-securing devices120
Locking and unlocking the
doors36, 37
Low beams94
Bulb replacement167
Low beams, bulb
replacement167
Low-fuel warning lamp83
Lug bolts174
Lug wrench174
Luggage compartment
Capacity201
Lamps96
Net44
Luggage compartment lid/
Tailgate44
Emergency actuation41
Opening separately41
Remote control39
Luggage space44
Luggage straps44
Lumbar support51

M
M Multifunction steering
wheel (MFL)26
M+S tires138
Magic Eye177
Maintenance84, 154
