The following only applies to vehicles owned and operated in the US.

REPORTING SAFETY DEFECTS

If you believe that your vehicle has a defect which could cause a crash \
or could cause injury or death, you should
immediately inform the National Highway Traffic Safety Administration (\
NHTSA) in addition to notifying BMW of
North America, LLC, P.O. Box 1227, Westwood, New Jersey 07675-1227, Tele\
phone (201) 307-4000.
If NHTSA receives similar complaints, it may open an investigation, and \
if it finds that a safety defect exists in
a group of vehicles, it may order a recall and remedy campaign. However,\
NHTSA cannot become involved in indi-
vidual problems between you, your dealer, or BMW of North America, LLC.
To contact NHTSA, you may either call the Auto Safety Hotline toll-free \
at 1-800-424-9393 (or 366-0123 in
Washington, D.C. area) or write to: NHTSA, U.S. Department of Transport\
ation, Washington, D.C. 20590. You can
also obtain other information about engine vehicle safety from the Hotli\
ne.

12n

13n

OverviewControlsMaintenanceRepairsDataIndex

Overview
Controls and features
Operation, maintenance
Owner service procedures
Index Technical data

Overview

14n
1 Parking lamps/Low beams85
2

>

Turn signal indicators70

>

Standing lamps86

>

High beams86

>

Headlamp flasher70

>

Computer783 Washer/Wiper system/Rain
sensor71
4 Hazard warning flashers
5 Shift lever63
6 Rear window defroster89, 937 Central locking system28
8 Steering wheel50
9 Horn: the entire surface
10 Fog lamps86

Cockpit

15n

OverviewControlsMaintenanceRepairsDataIndex

Instrument cluster

1 Fuel gauge76
2 Turn signal indicator20
3 Speedometer
4 Indicator and warning
lamps17 to 205 Tachometer and
Engine oil temperature75
6 Engine coolant temperature
gauge76
7 Indicator and warning
lamps17 to 208 Clock reset

>

Clock77

>

Unit of measure of outside temper-
ature display78
9 Display for sequential M gearbox

*

SMG II66

16n

Instrument cluster

10 Indicator lamp for Dynamic Stability
Control (DSC)19
11 Display for

>

Odometer75

>

Trip odometer75

>

Clock77

>

Service Interval76Display for computer, operation
using the turn signal lever, refer to
page 78:

>

Clock

>

Outside temperature

>

Average fuel consumption

>

Range

>

Average speed12 Display for Check Control77
13 Trip odometer, reset to zero75
14 Indicator and warning
lamps17 to 20

17n

OverviewControlsMaintenanceRepairsDataIndex

Indicator and warning lamps

Technology that monitors itself

Indicator and warning lamps that are
identified by "

l

," are tested for proper
functioning whenever the ignition key is
turned. They each light up once for
different periods of time.
If a fault should occur in one of these
systems, the corresponding lamp does
not go out after the engine is started or
it lights up while the vehicle is moving.
You will see how to react to this below.

Red: stop immediately

Battery charge current

l

The battery is no longer being
charged. There is a malfunction
of the alternator drive belt or in the
charging circuit of the alternator. Please
contact the nearest BMW center.
If the drive belt is defective, do not
continue driving. The engine could
be damaged due to overheating. If the
drive belt is defective, increased
steering effort is also required.

<


Engine oil pressure

l

Stop vehicle immediately and
switch off engine. Check the
engine oil level and top up as required.
Please contact the nearest BMW
center.
Do not continue driving, other-
wise, the engine could be
damaged because of inadequate lubri-
cation.

<



Flat Tire Monitor
l
In addition, an acoustic signal is
sounded: a tire failure has
occurred. To come to an immediate
stop, reduce speed, while avoiding any
sudden, jerky braking or steering
maneuvers.
For additional information: refer to
page 82
Brake warning lamp
l
If the lamp comes on when the
parking brake is not engaged:
check the brake fluid level. Before
driving further, be sure to read the
notes on pages 105 and 119.
Brake warning lamp for Cana-
dian models.

18n

Indicator and warning lamps

Red: an important reminder

Parking brake

l

Comes on when the parking
brake is engaged Ð an additional
acoustic signal sounds when starting
off. For additional information: refer to
page 63
Brake warning lamp for Cana-
dian models.
Lock backrest/Please fasten
safety belts

l

A warning signal will sound at
the same time. Flashes when the back-
rest is not locked. Lights up when a
safety belt is not fastened or until
passengers fasten safety belts.
For details on locking the backrest:
refer to page 47
For additional information on safety
belts: refer to page 48
Airbags

l

Please have the system
inspected immediately at your
BMW center.
For additional information: refer to
page 52

Red and yellow: continue to drive;
drive cautiously

The red brake warning lamp
lights up together with the
yellow indicator lamps for ABS
and DSC:
The entire ABS, CBC and DSC
control system


has failed.
Continue to drive; drive
cautiously and defensively and
avoid full brake applications. Please
have the system checked by your BMW
center as soon as possible.
For additional information: refer to
pages 81, 105
ABS, CBC and DSC indicator
and warning lamps for Canadian
models.

Orange: consult the nearest BMW
center

Sequential M transmission

*

SMG II
If the indicator lamp fails to go
out after the engine has been started,
or if it comes on during normal driving:
this indicates a malfunction in the
system. Please consult the nearest
BMW center.
Indicator lamp flashes: a system over-
load has occurred.
For additional information: refer to
page 69

19n

OverviewControlsMaintenanceRepairsDataIndex

Indicator and warning lamps

Yellow: check as soon as
possible

Antilock Brake System (ABS)

l

In addition, an acoustic signal is
sounded: ABS has been deacti-
vated in response to system malfunc-
tion. Conventional braking efficiency is
available and unrestricted. Please have
the system inspected at your BMW
center.
For additional information: refer to
page 105
ABS warning lamp for Canadian
models.
Engine oil level
Comes on while driving: the
engine oil level has fallen to the
absolute minimum; refill as soon as
possible. Do not drive more than
30 miles (50 km) until you do.
For additional information: refer to
page 116
Engine oil level
Comes on after the engine has
been switched off: add engine
oil at your earliest opportunity (when
you stop to refuel). For additional infor-
mation: refer to page 116

Brake pads

l

Have the brake pads checked.
For additional information: refer
to page 105
Flat Tire Monitor

l

The Flat Tire Monitor has been
deactivated, either at the button
or in response to a system malfunction.
In the event of a malfunction, have the
system checked by your BMW center.
For additional information: refer to
pages 24, 82
Dynamic Stability Control
(DSC)

l

The indicator lamp flashes and
an acoustic signal sounds:
The system is active and governs drive
and braking force.
If the indicator lamp fails to go out after
the engine is started, or if it comes on
during normal driving and stays on:
DSC has been deactivated, either at the
button or in response to a system
malfunction. In the event of a malfunc-
tion, have the system checked by your
nearest BMW center.
For additional information: refer to
page 81

Dynamic Brake Control (DBC)

l

Malfunction in DBC system.
Conventional braking efficiency
is available and unrestricted.
Have the system checked and repaired
at your BMW center as soon as
possible.
For additional information: refer to
page 82
Dynamic Brake Control (DBC)
warning lamp for Canadian
models.
Add washer fluid
The washer fluid is too low. Top
off the fluid at the earliest
opportunity.
For additional information: refer to
page 115
Service Engine Soon

l

If the indicator lamp comes on
either continuously or intermit-
tently, this indicates a fault in the emis-
sions-related electronic systems.
Although the vehicle remains opera-
tional, you should have the systems
checked by your BMW center at the
earliest possible opportunity.
For additional information: refer to
page 122

20n

Indicator and warning lamps

Service Engine Soon warning
lamp for Canadian models.
Engine electronics

l

There is a fault in the electronic
engine-management system.
You can continue to drive with reduced
engine output or engine speed. Please
have the system inspected at your
BMW center.
Add coolant
Coolant level too low, top up as
soon as possible.
For additional information: refer to
page 118
Rollover protection system

l

The rollover protection system is
deactivated due to a malfunc-
tion. Please have the system inspected
immediately at your BMW center.
For additional information: refer to
page 58
Check Filler Cap

*


l

If the indicator lamp comes on
although the fuel filler cap is
secured correctly: this indicates a
malfunction in the fuel system. Have the
system inspected at your BMW center
at the earliest opportunity.
For additional information: refer to
page 23

Green: for your information

Turn signal indicators
Flashes when turn signals are
on. Rapid flashing: indicates a
system malfunction.
For additional information: refer to
page 70
Cruise control
Lights up when the cruise
control is activated. Available for
operation via the multifunction steering
wheel.
For additional information: refer to
page 73
Front fog lamps
Lights up whenever the fog
lamps are on.
For additional information: refer to
page 86

Blue: for your information

High beam
Comes on when the high beams
are on or the headlamp flasher
is actuated.
For additional information: refer to
pages 70, 86
