BMW M3 CONVERTIBLE 2002 E46 Owner's Guide
Manufacturer: BMW, Model Year: 2002, Model line: M3 CONVERTIBLE, Model: BMW M3 CONVERTIBLE 2002 E46Pages: 159, PDF Size: 2.19 MB
Page 31 of 159
31n
OverviewControlsMaintenanceRepairsDataIndex
Opening and closing Ð via the remote controlTo releasePress button to unlock the driver's door
only.
Press the button twice in order to
unlock the entire vehicle.
If you want, you can have this
special feature set as key-depen-
dent.
again.To deactivate the tilt alarm
sensor
* and interior motion
sensor*
Press button a second time immedi-
ately after locking.
For additional information: refer to
page 38.
To open the luggage
compartment lidPress button.
The lid will open slightly, no matter
whether it was locked or unlocked.
Before and after a trip, be sure
that the luggage compartment lid
has not been opened unintentionally.< Panic mode (trigger alarm)By pressing button for more than
2 seconds, the alarm can be sounded
in the event of danger, if it is armed.
To switch off the alarm:
Press button.
Page 32 of 159
32n
Opening and closing Ð via the remote controlExternal systemsLocal systems or devices in the area
may interference with remote control
function.
If this should occur, you can still open
and close the vehicle using the master
key in both the door and luggage
compartment locks.
For US owners onlyThe transmitter and receiver units
comply with part 15 of the FCC (Federal
Communication Commission) regula-
tions. Operation is governed by the
following:
FCC ID: LX8EWS
LX8FZVS
LX8FZVE
Compliance statement:
This device complies with part 15 of the
FCC Rules. Operation is subject to the
following two conditions:
>This device may not cause harmful
interference, and
>this device must accept any interfer-
ence received, including interference
that may cause undesired operation.
Any unauthorized modifications to
these devices could void the
user's authority to operate the equip-
ment.<
Page 33 of 159
33n
OverviewControlsMaintenanceRepairsDataIndex
Opening and closing Ð from the inside With this button you operate the central
locking system whenever the doors are
closed. The doors and luggage
compartment lid are unlocked or locked
only. The anti-theft alarm system is not
activated.
If only the driver's door was
unlocked from the outside and
you press the button, then, with the
driver's door still open, the passenger's
door, the luggage compartment lid, the
fuel filler door and the glove compart-
ment will unlock, too.
If the driver's door is closed, it will be
locked.<
The central locking system locks
automatically as soon as you
begin to drive if you desire. You may
also have this adjusted so that it is
specific to keys.<
To unlock and open the doors>Either unlock the doors together with
the button for the central locking
system and then pull each of the
release handles above the armrests
or
>pull the release handle for each door
twice: the first pull unlocks the door,
and the second one opens it.
To engage locks>Either use the central locking button
to lock all doors at once, or
>press the individual door lock buttons
down. As an added design feature to
prevent the driver from being inad-
vertently locked out of the vehicle,
the driver's door lock button will not
engage as long as the door is open.
Since passengers or animals
remaining in the vehicle might be
able to lock the doors from the inside,
take the vehicle's keys with you so that
the vehicle can be opened again from
the outside at any time.<
Page 34 of 159
34n
Luggage compartment lidThe lock Only the master keys (refer to page 28)
fit in the lock of the luggage compart-
ment lid.Secure separatelyLock the glove compartment using the
master key.
This also locks the luggage compart-
ment lid and disconnects it from the
central locking system. If you surrender
only the door key (refer to page 28), this
will prevent unauthorized access via the
luggage compartment lid, which is an
advantage for valet parking, for
instance.
To open from outsidePress the button in the handle recess
(arrow): the luggage compartment lid
opens slightly.
The luggage compartment is lighted
when the luggage compartment lid is
opened. Manual operation(in the event of electrical malfunction)
Turn the master key to the right as far
as it will go, the luggage compartment
lid will open slightly.
The luggage compartment lid is locked
again as soon as you close the lid.
Opening from the insideIf the luggage compartment lid has not
been locked separately, you can open it
with this button in the footwell on the
driver's side when the vehicle is
stationary.
Page 35 of 159
35n
OverviewControlsMaintenanceRepairsDataIndex
Luggage compartment lidTo closeThe handle recesses (arrows) in the
interior trim panel of the luggage
compartment lid make it easier to pull
the lid down.
To avoid injuries, be sure that the
travel path of the luggage
compartment lid is clear when it is
closed, as with all closing procedures.
Do not drive with the luggage compart-
ment lid open, since exhaust fumes
could penetrate the interior of the
vehicle. Nevertheless, should it be
absolutely necessary to operate the
vehicle with the luggage compartment
lid open (with closed convertible top):
>Close all windows
>Increase the air supply for the air
conditioner or automatic climate
control to a high level, refer to
pages 89, 92.<
Emergency releaseThis lever releases the luggage
compartment lid from the luggage
compartment's interior.
Page 36 of 159
36n
Luggage compartment To secure your luggage, use the
luggage nets
* or flexible straps that you
can attach to the fittings at the inner
corners of the luggage compartment.
Refer also to "Cargo loading" on
page 101.
Raise floor plate and hook in1. Grab it by the handle and pull up
2. Press the button (arrow) to release
the hanger from the handle
3. Hook in the hanger on the rubber
seal of the water gutter (arrow).
Carefully replace the hanger in its
holder when lowering the floor
panel back into place.<
Page 37 of 159
37n
OverviewControlsMaintenanceRepairsDataIndex
Luggage compartment Alarm system
*
Enlarging luggage compartmentWith the convertible top closed, you
can enlarge the luggage compartment.
To do this, flip the handle outward and
press it down and toward the front of
the vehicle (arrow). The convertible top
compartment panel is now raised and
secured.Fold down convertible top
compartment panelTo open the convertible top, the convert-
ible top compartment panel must be
lowered. To do this, fold out the handle
and pull opposite the direction of travel.
When opening the convertible top,
refer to page 40, make sure that the
luggage compartment is set up for this,
otherwise you may damage something.<
The conceptThe vehicle alarm system responds:
>When a door, the hood or the
luggage compartment lid are opened
>To movement inside the vehicle (inte-
rior motion sensor)
>Altering the vehicle tilt, e. g. as would
occur while attempting to steal the
wheels or tow the vehicle (Tilt alarm
sensor system)
>To interruption of battery voltage.
The system responds to unauthorized
vehicle entry and attempted theft by
simultaneously activating the following:
>Sounding an acoustical alarm for
30 seconds
>Activating the hazard warning
flashers for approx. five minutes
>Flashing the high beams on and off in
rhythm with the hazard warning
flashers.
To arm and disarm the
alarm systemWhen the vehicle is locked or unlocked
by using a key or with the remote
control, the alarm system is also simul-
taneously armed or disarmed.
You can have a signal set as
acknowledgment for both arming
and disarming the alarm.<
You can also open the luggage
compartment lid when the system is
armed by pressing the button of the
remote control (refer to page 31). When
it is closed, the lid is once again
secured.
Page 38 of 159
38n
Alarm system
*
Indicator lamp displays>The indicator lamp below the interior
rearview mirror flashes continuously:
The system is armed
>The indicator lamp flashes when it is
armed: the door(s), the hood or
luggage compartment lid are not
completely closed. Even if you do not
close the alerted area, the remaining
areas are deadlocked, and the indi-
cator lamp flashes continuously after
10 seconds. However, the interior
motion sensor is not activated
>If the indicator lamp goes out when
the system is disarmed: no manipula-
tion or attempted intrusions have
been detected in the period since the
system was armed
>If the indicator lamp flashes for
10 seconds when the system is
disarmed: an attempted entry has
been detected in the period since the
system was armed.
Following triggering of an alarm, the
indicator lamp will flash continuously.Avoiding unintentional alarms The tilt alarm sensor and interior motion
sensor may be deactivated at the same
time. Doing this you can prevent any
unwanted alarm, e. g. in parking
garages or when it is being transported
on car trains:
Locking the vehicle twice (= setting the
alarm). Press button 2 on the remote
control twice in succession or lock the
vehicle twice with the key, refer to
page 31.
The indicator lamp lights up briefly and
then flashes continuously. The tilt alarm
sensor and the interior motion sensor
are deactivated as long as the system is
armed. Reset the alarm to reactivate
the tilt alarm sensor and the interior
motion sensor.
Interior motion sensorDeactivate the interior motion sensor
(see previous column) if children or
animals are to remain in the vehicle.For US owners onlyThe transmitter and receiver units
comply with part 15 of the FCC (Federal
Communication Commission) regula-
tions. Operation is governed by the
following:
FCC ID: LTQSDR2G5
Compliance statement:
This device complies with part 15 of the
FCC Rules. Operation is subject to the
following two conditions:
>This device may not cause harmful
interference, and
>this device must accept any interfer-
ence received, including interference
that may cause undesired operation.
Any unauthorized modifications to
these devices could void the
user's authority to operate the equip-
ment.<
Page 39 of 159
39n
OverviewControlsMaintenanceRepairsDataIndex
Electric power windowsTo open and close windowsFrom ignition key position 1:
To open:
>Press the switch until you feel resis-
tance: the window continues to move
as long as you continue to hold the
switch
>Press the switch briefly past the pres-
sure point: the window moves auto-
matically. Touching the switch again
stops the opening cycle.
To close: you can close the windows in
the same manner by pulling the switch.
After the ignition has been switched off:
You can still operate the electric power
windows for up to 15 minutes, provided
that no door has been opened.
When leaving the vehicle, always
remove the ignition key from the
lock and remember to close the doors
to prevent children from operating the
power windows and injuring them-
selves, etc.<
For convenience closing via the door
lock, refer to page 29.
To operate all the side windowsFrom ignition key position 1:
To open:
>Press the switch until you feel resis-
tance:
All of the windows will continue to
lower as long as you continue to
press the switch
>Press the switch briefly past the pres-
sure point:
All windows will move automatically.
Pressing the switch again stops the
opening cycle.
To close: you can close the windows in
the same manner by pulling the switch.
Page 40 of 159
40n
Convertible top The completely automatically operated
convertible top combines assured
protection against the elements
together with simple and easy handling.
So that you will get the most out of
enjoying your convertible, here are a
few tips:
>It is advisable to close the convertible
top when the vehicle is being parked.
The closed convertible top not only
protects the passenger compartment
from unforeseeable damage from the
weather, it also provides a certain
degree of theft protection. In addi-
tion, keep valuables only in the
locked luggage compartment, even
with the convertible top closed
>Never mount a roof-mounted luggage
rack on the convertible top
>At temperatures below 15 7
(Ð10 6) do not operate the convert-
ible top to prevent damage.
Never store the convertible top
while it is wet to avoid permanent
damage from moisture.<
Driving with the opening or
closing operation not completely
ended can lead to damage and/or inju-
ries.
If possible, only operate the convertible
top with the vehicle stopped, as other-
wise the process may be interrupted.
Traffic laws applicable in your area take
precedence when you operate the
convertible top, otherwise you may be
breaking the law.
Before closing the convertible top,
remove any objects from the windshield
frame that could keep the convertible
top from closing properly.
Do not lay objects on the convertible
top, since they would fall off when the
convertible top is operated and cause
damage or injuries.
Do not reach into the convertible top
mechanism during opening and closing.
Keep children away from the moving
parts of the convertible top during oper-
ation.<
To close the electric power
windows while driving, always be
sure to first close either the rear
windows, or all 4 windows at the same
time, otherwise, at high speed, the
windows may not close tightly.<
At higher speeds, the ensuing
vacuum in the passenger
compartment can cause the convertible
top to begin fluttering. Increase the air
supply via the ventilation controls so
that a vacuum does not occur in the
vehicle.<
