BMW M3 COUPE 2002 E46 Owner's Guide
Manufacturer: BMW, Model Year: 2002, Model line: M3 COUPE, Model: BMW M3 COUPE 2002 E46Pages: 151, PDF Size: 2.14 MB
Page 21 of 151
21n
OverviewControlsMaintenanceRepairsDataIndex
Steering wheel with multifunction buttons
The buttons integrated in the multi-
function steering wheel (MFL) are
provided so that you can operate a
number of accessories quickly and
without being distracted from traffic
conditions. You may operate:
>
selected radio functions
>
the cruise control
>
selected cellular phone functions
*
>the voice entry system
*.
The buttons are active only when
the corresponding systems and
accessories are switched on.<
Press briefly:
Receive a phone call, initiate dialing,
terminate a call.
Extended pressure:
Activate/deactivate voice entry.
Switch between phone and radio,
cassette, CD or MD.
Forward:
>Radio
Press briefly: station search in FM
band
Extended pressure: search function
>CD/MD
Press briefly: jump to next track
Extended pressure: search function
in track
>Cassette
Press briefly: stop jump to next track
or fast forward
Extended pressure: fast forward
>Phone
Scan personal phone book.
Rewind: functions as forward.
Volume
Cruise control: to select a stored
setting.
Cruise control: store and accelerate (+)
or decelerate and store (Ð).
Cruise control: activate/interrupt/deac-
tivate.
Page 22 of 151
22n
Warning triangle
*
First-aid kit
* Refueling
The hazard warning triangle is stored in
a storage compartment on the left-hand
side of the luggage compartment.
Always observe all legal regula-
tions requiring a warning triangle
to be carried in the vehicle.<
The first-aid kit is located under the
front passenger's seat.
To open: pull the handle and fold the
cover down.
To close: fold the cover up.
Several of the items contained in
the first-aid kit have a limited
service life. You should check the expi-
ration dates of each of the items regu-
larly, and replace any with passed
dates. You can acquire replacements in
any drugstore or pharmacy.
Always observe all legal regulations
requiring a first-aid kit to be carried in
the vehicle.<
Fuel filler door
Always switch off the engine
before refueling, as it is not
possible to add fuel with the engine
running, and attempts may also trigger
the Service Engine Soon lamp.<
Press on the rear edge of the fuel filler
door to open and close it.
If an electrical malfunction occurs, you
can unlock the fuel filler door manually:
Pull the knob with the fuel pump symbol
on the right trim panel of the luggage
compartment.
Page 23 of 151
23n
OverviewControlsMaintenanceRepairsDataIndex
Refueling
When handling fuels, comply with
all of the applicable safety precau-
tions and regulations pertaining to
fuels.
Never carry spare fuel containers in
your vehicle. Whether empty or full,
these containers can leak, cause an
explosion, or lead to fire in the event of
a collision.<
Simple and environmentally
friendly
Open the filler cap carefully to
prevent fuel from spraying out.
Fuel spray may cause injury.<
Keep the filler cap in the bracket
attached to the fuel filler door.
When refueling, insert the filler nozzle
completely into the filler pipe. Pulling
the nozzle out of the pipe during refu-
eling
>results in premature pump shutoff
>will reduce the effect of the vapor
recovery system on the pump.
As long as the filler nozzle is used prop-
erly, the fuel tank is full whenever the
nozzle shuts off the first time.
Fuel tank capacity>approx. 16.6 gal. (63 liters), incl.
>a reserve capacity of approx. 2.1 gal.
(8 liters).
Refill early to avoid damaging the
catalytic converter; never attempt
to drive to the last drop of fuel in the
tank.<
Close the fuel cap carefully after
refueling until a "click" is heard.
While closing, be sure not to squeeze
the strap which is fastened to the cap.
A loose or missing cap will activate the
Check Filler Cap lamp
*.<
Page 24 of 151
24n
Fuel specifications Tire inflation pressuresRefuel with lead-freeThe engine uses lead-free gasoline
only.
Required fuel:
>Premium Unleaded Gasoline,
min. 91 AKI
AKI = Anti Knock Index
Never use leaded fuel, as it would
cause permanent and irreversible
damage to the oxygen sensor and the
catalytic converter.<
The specified inflation pressures are
provided on a sticker attached to the
B-pillar and visible with the driver's
door open.Check tire pressuresOn the next page you will find all the tire
pressure and ambient air temperature
specifications stated in the units usually
used in your country (psi; kilopascal).
After correcting the tire inflation pres-
sure, reinitialize the Flat Tire Monitor so
that it can monitor the tire inflation
pressure, refer to page 77.
Check the tire pressures on a
regular basis Ð at least twice a
month Ð and before every extended
journey. Incorrect tire pressure can
otherwise lead to driving instability, tire
damage and accidents.<
Comply with tire approval
specifications The inflation pressures apply to BMW
approved tire sizes and tire manufac-
turers. Your BMW center is familiar with
these pressures. Higher pressures may
be specified for tires made by other
manufacturers.
Your vehicle is equipped with tires that
not only meet US standards, but also
European standards. We recommend
the exclusive use of BMW approved
tires.
Page 25 of 151
25n
OverviewControlsMaintenanceRepairsDataIndex
Tire inflation pressures Tires
All pressure specifications in
the table are indicated in psi
(kilopascal) with cold tires
(cold = ambient temperature)
225/45 ZR 18 2.3 (230/33) - 2.8 (280/41) -
255/44 ZR 18 - 2.4 (240/35) - 3.3 (330/48)
225/45 ZR 18
225/40 ZR 192.3 (230/33) - 2.8 (280/41) -
255/35 ZR 19 - 2.4 (240/35) - 3.3 (330/48)
225/45 R 17 91 Q/T/H M+S 2.3 (230/33) 2.6 (260/38) 2.5 (250/36) 3.2 (320/46)
Page 26 of 151
26n
Controls
Page 27 of 151
27n
OverviewControlsMaintenanceRepairsDataIndex
Overview
Controls and features
Operation, maintenance
Owner service procedures
Index Technical data
Page 28 of 151
28n
Keys Central locking systemThe key set1 The master keys with remote control
determine the functions of the Key
Memory, refer to page 55.
You can mark individual keys for
subsequent identification by applying
the colored decals that you received
when accepting delivery of your
vehicle
There is an extended-life battery
in every master key that is
charged automatically in the ignition
lock as you drive. For this reason, if you
have a master key that is otherwise not
used, use that key at least once every
year while driving for an extended
period to charge the battery, also refer
to page 30.<
2 Spare master key for storage in a
safe place, such as in your wallet.
This key is not intended for constant
use
3 Door and ignition key
The locks for the luggage compart-
ment lid and the glove compartment
cannot be operated with this key Ð
this is recommended for valet
parking, for instance
The conceptThe central locking system is ready for
operation whenever the driver's door is
closed. The system engages and
releases the locks on the
>doors
>luggage compartment lid
>fuel filler door.
The central locking system can be
operated
>from outside via the door lock and
using the remote control
>from inside by pressing a button.
If it is operated from inside, the fuel
filler door will not be locked, refer to
page 33.
When the system is actuated from
outside the vehicle, the anti-theft
system is simultaneously activated.
Both the door locks and release
handles remain locked. The alarm
system is also armed or disarmed.
Information for your safety: if locked
from inside, the central locking system
unlocks automatically in the event of an
accident. In addition, the hazard
warning flashers and interior lamps
come on.
Page 29 of 151
29n
OverviewControlsMaintenanceRepairsDataIndex
Opening and closing Ð via the door lockWith the keyTurning the key once in the driver's
door will unlock only the driver's door.
Turning the key a second time will
unlock the passenger's door, the
luggage compartment lid and the fuel
filler door.
You can have a signal set to
confirm that the vehicle's locks
have engaged securely.<
Convenience operating modeYou can also operate the windows and
the sliding/tilt sunroof via the door lock.
To open: with the door closed, hold the
key in the "Unlock" position.
To close: with the door closed, turn the
key to the "Lock" position and hold it.
Watch during the closing process
to be sure that no one is inadvert-
ently injured. Releasing the key stops
the operation.
left or right to unlock/lock the driver's
door.
Page 30 of 151
30n
Opening and closing Ð via the remote control The conceptThe remote control gives you an excep-
tionally convenient method for
unlocking and locking your vehicle.
Furthermore, it provides two additional
functions which you can only execute
via the remote control:
>Switch on the interior lamps, refer to
page 31.
With this function, you can also
"search for" your vehicle Ð when
parked in an underground garage, for
instance
>Open the luggage compartment lid,
refer to page 31.
The luggage compartment lid will
open slightly, regardless of whether it
was locked or unlocked.
The anti-theft system is also deacti-
vated/activated simultaneously with the
unlocking or locking of the vehicle, the
alarm system is disarmed/armed, and
the interior lamps are switched on/off.
You can have a signal set to
confirm that the vehicle's locks
have engaged securely.<
1 Unlock, convenience mode opening
and alarm system
2 Lock and secure, switch on interior
lamps, deactivating tilt alarm sensor
and interior motion sensor
3 Open the luggage compartment lid,
panic mode (trigger alarm)
Master key with remote control
Since passengers or animals
remaining in the vehicle might be
able to lock the doors from the inside,
take the vehicle's keys with you so that
the vehicle can be opened again from
the outside at any time.<
Master keys that are used repeat-
edly are always ready for opera-
tion, since the battery in the key is
charged automatically in the ignition
lock as you drive.
If it is no longer possible to unlock the
vehicle via the remote control, the
battery is discharged. Use this key
while driving for an extended period in
order to recharge the battery, refer also
to page 28.
Guard the remote control against unau-
thorized use by only surrendering the
spare key or the door key (refer to
page 28) e.g. for valet parking.
In the event of a system malfunction,
please contact your BMW center. You
can also obtain replacement keys
there.<
