on page 93. The symbol + is embossed on
the cover.
1.Open the cover of the BMW auxiliary
terminal for jump-starting, refer to
arrow 1
2.Connect one terminal clamp of the pos-
itive/+ jumper cable to the positive ter-
minal of the battery or a auxiliary termi-
nal of the vehicle providing starting
assistance
3.Connect the second terminal clamp of
the positive/+ jumper cable to the posi-
tive terminal of the battery or to a auxil-
iary terminal of the vehicle to be started.
On your BMW, there is a special nut as
body ground or negative terminal on the
suspension strut dome, refer to arrow 2
4.Attach one end of the jumper cable
minus/Ð to the negative terminal of the
battery or to an engine or body ground
of the vehicle providing assistance
5.Connect the second terminal clamp of
the negative/Ð jumper cable to the neg-
ative terminal of the battery or to the
engine or body ground of the vehicle to
be started.
Starting the engine
1.Start the support vehicle's engine and
let it run at an increased idling speed for
a few minutes
2.Start the engine on the other vehicle in
the usual way.
If the first start attempt is not success-
ful, wait a few minutes before another
attempt in order to allow the discharged
battery to recharge
3.Allow the engines to run for several
minutes
4.Disconnect the jumper cables by
reversing the connection sequence.
If necessary, have the battery checked and
recharged at a BMW Sports Activity Vehi-
cle Center.
Never use spray fluids to start the
engine.<
Towing
Always observe all applicable towing
laws and regulations. Do not tow the
BMW X3 with the axle raised, as otherwise
the transfer case can be damaged.<
Towing with a commercial tow truck
>Use only a flatbed carrier
>Do not tow with sling-type equipment
>Do not use a wheel lift.
Never allow passengers to ride on a
towed vehicle for any reasons.<
Tow fitting
The threaded tow fitting is stored in the tool
kit mounted on the inside of the compart-
ment and should always remain in the vehi-
cle. This fitting is designed for installation in
the tow sockets located at the front and
rear of the vehicle.
Access to tow sockets
Front
Use a screwdriver to lever out the cover
upward at the recess.
Giving and receiving assistance
110
Rear
Use a screwdriver to lever out the cover
upward at the recess.
Only use the tow fitting that comes
with the vehicle and screw it in as far
as it will go. Only use the tow fitting to tow
on the roadway. Adhere to these specifica-
tions, as otherwise the tow fitting can be
torn out and damage the vehicle.
Never attempt to tow or tie down the vehi-
cle using suspension components, as this
could lead to damage that might ultimately
result in an accident.<
Technical data
114
Technical data
Engine specifications
An engine performance test is authorized only on an appropriate chassis dynamometer.
BMW X3 2.5iBMW X3 3.0i
Displacement
Number of cylinderscu in/cmm152.2/2,494
6181.8/2,979
6
Maximum output
at engine speedhp
rpm184
6,000225
5,900
Maximum torque
at engine speedlb ft/Nm
rpm175/237
3,500214/290
3,500
Compression ratioe10.5 10.2
Stroke
Borein/mm
in/mm2.95/75
3.31/843.53/89.6
3.31/84
Fuel-injection system Digital electronic engine-management system DME
Technical data
116
Weights
Never exceed either the approved axle loads or the gross vehicle weight.
BMW X3 2.5iBMW X3 3.0i
Curb weight
with manual transmission
with automatic transmissionlbs/kg
lbs/kg4,001/1,815
4,045/1,8354,023/1,825
4,067/1,845
Approved gross vehicle weight
with manual transmission
with automatic transmissionlbs/kg
lbs/kg4,993/2,265
5,049/2,2905,049/2,290
5,104/2,315
Load
with manual transmission
with automatic transmissionlbs/kg
lbs/kg992/450
1,003/4551,025/465
1,036/470
Approved front axle load lbs/kg 2,425/1,100 2,425/1,100
Approved rear axle load lbs/kg 2,756/1,250 2,778/1,260
Approved roof load capacity lbs/kg 165/75 165/75
Cargo area capacity cu ft/l 71/2,010 71/2,010
Reference
At a glance
Controls
Driving tips
Mobility
117
Capacities
Notes
Fuel tank
Reserve gal./liters
gal./litersapprox. 17.7/67
approx. 2/8Fuel specification:
page 85
Windshield / Headlamp washer
systemquarts/liters approx. 6.9/6.5 For details: page 94
Cooling system including heater quarts/liters 10.6/10.0 for
manual
transmission
10.8/10.2 for
automatic
transmissionFor details: page 95
Engine oil and filter change quarts/liters approx. 6.6/6.2 For details: page 94
Manual, automatic transmission
and differentialÐ Lifetime fluid, no fluid
change required
