BMW X5 2000 E53 Xenon Lights Instalation Instruction Manual Xenon-Licht mit automatischer Leuchtweitenregulierung
für BMW X5 (E 53) LHD
Fachkenntnisse sind Voraussetzung.
BMW Parts and Accessories – Installation Instruction
Xenon lights with automatic headl

Page 2 of 38

BMW X5 2000 E53 Xenon Lights Instalation Instruction Manual Inhalt Seite
1 Wichtige Hinweise  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
2 Einbau  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Page 3 of 38

BMW X5 2000 E53 Xenon Lights Instalation Instruction Manual EN/1-3
1. Important information
(Only for use within the BMW dealer organisation.)
Installation time approx. 7.5 hours.
The installation times may differ depending on the condition of the car and the

Page 4 of 38

BMW X5 2000 E53 Xenon Lights Instalation Instruction Manual 1-4/EN
Tools and equipment required
Philips screwdriver
Straight slot screwdriver
Sockets, sizes 8 mm and 10 mm
Ring spanner, size 10 mm
Open-ended spanner, size 9 mm
Torque wrench
1/2 inch reversible

Page 5 of 38

BMW X5 2000 E53 Xenon Lights Instalation Instruction Manual 2. Installation
Contents.................................................................................................................................Pa g e
2.1 Preparation ........................

Page 6 of 38

BMW X5 2000 E53 Xenon Lights Instalation Instruction Manual 2.1 Preparation
Print out the error memory.
Disconnect the battery.
Remove the door sill strips on the right-hand side.
Remove the bottom A pillar trim on the right-hand side.
Remove the glove box.
Re

Page 7 of 38

BMW X5 2000 E53 Xenon Lights Instalation Instruction Manual Fold out folded page 2-33.
All lock nuts are to be replaced. All tightening torque values are to be taken from the current repair
instructions and must be observed at all times.
2.2 To install the lev

Page 8 of 38

BMW X5 2000 E53 Xenon Lights Instalation Instruction Manual Only for cars with an air suspension front axle.
G
Disconnect the connection plug from the level sensor (12).
Undo the nut SW 10 mm (20) and release the control rod (18).
Undo the nut SW 10 mm (16) an

Page 9 of 38

BMW X5 2000 E53 Xenon Lights Instalation Instruction Manual 2-33
32
1
A
4576
B
3 4
8
9
61
C
11 10
D
F 53 0055 EVAF 53 0056 EVA
F 53 0057 EVAF 53 0058 EVA
141312
E
15
10
F
18 14
121619
11
17
20
G
F 53 0059 EVAF 53 0060 EVA
F 53 0061 EVA

Page 10 of 38

BMW X5 2000 E53 Xenon Lights Instalation Instruction Manual 2-36/EN
2.4 Connection overview of the xenon wiring harness (ECE cars only)
Fold out folded page 2-43
Item Description Cable colour Connection location in the car Abbreviation /
Slot
A26-pin plug (Bo
