BMW X5 3.0I 2001 Owner's Manual

Index
Data
Technology
Repairs
Car care
Controls
Overview

21n

Instrument cluster

*
There are two versions, depending on
the equipment on your vehicle. 1 Fuel gauge with indicator lamp for fuel reserve 77
2 Indicator lamp for turn signals 25
3 Speedometer
4 Indicator lamp for high beams 25
5 Tachometer and Energy Control 77
6 Engine coolant temperature gauge 78
7 Indicator and warning lamps (clockwise) for:

>

Parking brake 23

>

Brake hydraulic system/Dynamic
Brake Control (DBC) 22, 24

>

Antilock Brake System (ABS) 23

>

Airbags23

>

Please fasten safety belts 23

>

Cruise control25
8 CHECK button 79
9 Selector lever and program display for automatic transmission

*
68 10 Outside temperature display
76
11 Indicator lamp for Dynamic Stability Control (DSC) 24
12 Trip odometer 76
13 Indicator for Check Control

*
79
14 Odometer 76
15 Service Interval Display 78
16 Reset button for trip odometer 76
17 Indicator and warning lamps (clockwise) for:

>

Fog lamps 25

>

Battery charge current 22

>

Engine oil pressure22

>

Service Engine Soon 24

22n

Indicator and warning lamps

Technology that monitors itself

Many of the systems of your BMW
monitor themselves automatically, both
during engine starts and while you are
driving. Indicator and warning lamps
that are identified by " l" are tested for
proper functioning whenever the igni-
tion key is turned. They each light up
once for different periods of time.
If a fault should occur in one of these
systems, the corresponding lamp does
not go out after the engine is started or
it lights up while the vehicle is moving.
You will see how to react to this below.
Red: stop immediately
Battery charge current l
The battery is no longer being
charged. There is a malfunction
of the alternator V-belt or in the
charging circuit of the alternator. Please
contact the nearest BMW center.
If the V-belt is defective, do not
continue driving. The engine could
be damaged due to overheating. If the
V-belt is defective, increased steering
effort is also required. <
Engine oil pressure l
Stop the vehicle immediately
and switch off the engine.
Check the engine oil level; top up as
required. If the oil level is correct:
please contact the nearest BMW
center.
Do not continue driving. The
engine could be damaged
because of inadequate lubrication. <
Parking brake*/
Brake hydraulic system l
Comes on when you engage the
parking brake. For additional informa-
tion: refer to page 66.
Comes on although the parking brake
is released: have the brake fluid level
checked. Before continuing your
journey, be sure to read the notes on
pages 141 and 161.
Also comes on in the Check Control
with the message "CHECK BRAKE
LININGS." Parking brake warning lamp
*/
Brake hydraulic system warning
lamp for Canadian models.

Index
Data
Technology
Repairs
Car care
Controls
Overview
23nIndicator and warning lamps
Red or yellow: continue to drive;
drive cautiously
If the brake warning lamp
comes on red together with the
yellow warning lamps for ABS
and DSC:
ABS, CBC, DSC, DBC, EBV and
HDC have failed. Continue to
drive; drive cautiously and
defensively and avoid full brake
applications.
Have the system checked by the
nearest BMW center.
For additional information: refer to
pages 94 and 139.
If all three warning lamps come on
yellow:
ABS, CBC, DSC, DBC and HDC have
failed. Continue to drive; drive
cautiously and defensively and avoid
full brake applications.
Have the system checked by your BMW
center as soon as possible. Warning lamps for Canadian
models.
Red: an important reminder
Parking brake*
Comes on when you engage the
parking brake.
For additional information: refer to
page 66.
Parking brake warning lamp
* for
Canadian models.
Please fasten safety belts l
Together with an acoustic signal
or a message
* in the Check
Control. Comes on until the safety belts
are fastened. For additional information
on safety belts: refer to page 57.
Airbags l
Please have the system
inspected by your BMW center.
For additional information: refer to
page 58.

24nIndicator and warning lamps
Yellow: check as soon as possible
Engine oil level
Comes on while driving:
The oil level is at the absolute
minimum; refill as soon as possible. Do
not drive more than approx. 30 miles
(50 km) until you add oil.
For additional information: refer to
page 157.
Engine oil level
Comes on after the engine has
been shut off: add engine oil at
your earliest opportunity (when you
stop to refuel).
For additional information: refer to
page 157.
Automatic transmission
*
Because of a malfunction, the
automatic transmission shifts
only in the emergency program. Please
consult the nearest BMW center.
For additional information: refer to
page 70.
Brake pads
* l
Have the brake pads checked.
For additional information: refer
to page 141.
Dynamic Brake Control (DBC) l
Fault in the DBC system. Please
have the system inspected by
your BMW center.
For additional information: refer to
page 138.
Dynamic Brake Control (DBC)
warning lamp for Canadian
models
Level control system
* l
The level control system is inac-
tive. Please consult the nearest
BMW center.
For additional information: refer to
page 143.
Dynamic Stability Control
(DSC) l
Indicator lamp flashes:
The system is active and governs drive
and braking force.
The warning lamp comes on and stays
on while driving:
DSC has been switched off with the
button. If, after repeatedly pressing the
DSC button, the warning lamp still does
not go off, then that means that the
DSC, HDC and the vehicle's road-
holding ability are defective.
Please have the system checked by the
nearest BMW center.
For additional information: refer to
pages 94 and 96.
Engine electronics*
There is a fault in the engine's
electronic control system. You
can continue to drive with reduced
engine output or engine speed. Please
have the system inspected by your
BMW center.
Service Engine Soon l
If the indicator lamp comes on
either continuously or intermit-
tently, this indicates a fault in the
emissions-related electronic systems.
Although the vehicle remains opera-
tional, you should have the systems
checked by your BMW center at the
earliest possible opportunity.
For additional information: refer to
page 170.
Service Engine Soon warning
lamp for Canadian models.

Index
Data
Technology
Repairs
Car care
Controls
Overview
25nIndicator and warning lamps
Green: for your information
Turn signal indicator
Flashes when the turn signals
are operated. Rapid flashing
indicates a system malfunction.
For additional information: refer to
page 70.
Cruise control
Comes on when the cruise
control is activated: available for
operation via the multifunction steering
wheel.
For additional information: refer to
page 74.
Fog lamps

Lights up whenever you switch
on the fog lamps.
For additional information: refer to
page 98.
Blue: for your information
High beams
Lights up when the high beams
are on or the headlamp flasher
is actuated.
For additional information: refer to
pages 70 and 98.

26nMultifunction steering wheel
The controls integrated in the multi-
function steering wheel (MFL) are
provided so that you can operate a
number of accessories quickly and
without being distracted from traffic
conditions. You may operate:
>Selected functions of the radio as
well as the CD and cassette modes,
> recirculated air control of the air
conditioner system
or
> the steering wheel heating,
> the cruise control,
> selected cellular phone
* functions
and
> voice recognition
*.
In order to operate a system via
the MFL, the corresponding
system controls must be activated. <
The illustration shows the maximum
possible number of controls, corre-
sponding to a full range of optional
equipment. Refer to the individual
accessory manuals for more detailed
descriptions.
1 Press briefly: Receive a phone call, initiate dialing,
terminate a call.
Press longer:
Turn voice recognition on and off
2 Radio/Telephone: select
3 Radio/Telephone: scan backward or scan station buttons or scroll in the
phone listings.
Reverse scan in the CD mode and
rewind in the cassette operation
4 Radio/Telephone: volume
380de702
5 Radio/Telephone: scan forward or scan station buttons or scroll in the
phone listings
Forward scan in the CD mode and
fast forward in the cassette operation
6 Horn: the entire surface
7 Cruise control: activate stored setting (resume)
8 Cruise control: store and accelerate (+); decelerate
and store (–)
9 Cruise control: activate/interrupt/ deactivate
10 Recirculated air mode and AUC or steering wheel heating: activate and
deactivate

Index
Data
Technology
Repairs
Car care
Controls
Overview
27nSports steering wheel*
The controls integrated in the sports
steering wheel are provided so that you
can operate a number of accessories
quickly and without being distracted
from traffic conditions.
You may operate:
>Selected radio functions as well as
the CD and cassette modes,
> the cruise control,
> selected cellular phone
* functions
and
> voice recognition
*.
In order to operate a system via
the sport steering wheel, the
corresponding system controls must be
activated. <
Refer to the individual accessory
manuals for more detailed descriptions.
1 Radio/Telephone: select
2 Press briefly: Receive a phone call, initiate dialing,
and terminate a call.
Press longer:
Turn voice recognition on and off
3 Radio/Telephone: volume
4 Radio/Telephone: scan backward or scan station buttons or scroll in the
phone listings.
Reverse scan in the CD mode and
rewind in the cassette operation
463de057
5 Radio/Telephone: scan forward or scan station buttons or scroll in the
phone listings
Forward scan in the CD mode and
fast forward in the cassette operation
6 Horn: the entire surface
7 Cruise control: activate stored setting (resume)
8 Cruise control: store and accelerate (+); decelerate
and store (–)
9 Cruise control: activate/interrupt/ deactivate

28nHazard warning flashers Warning triangle* First-aid kit*
The button flashes intermittently when
the hazard warning flashers are on.
To help you locate the button in an
emergency, the button is also illumi-
nated whenever the vehicle's lamps are
on.
530us004
1 Open the cover on the left in the
cargo area: lift the handle on the
cover.
2 Pull the tab of the retaining strap (arrow) and remove the hazard
warning triangle from the support
bracket.
3 To install: slide the hazard warning triangle into the support bracket and
press on the retaining strap.
Comply with legal requirements
which cover the availability of a
hazard warning triangle in the vehicle. <
530us005
The first-aid kit is located under the
front passenger's seat.
To open: pull the handle and fold the
cover down.
To close: fold the cover up.
Some of the articles in the first-aid
kit may be used within a limited
time only. For this reason, check the
expiration dates of each of the items
regularly, and replace any whose
expiration dates have passed. You can
acquire replacements in any drugstore
or pharmacy.
Comply with laws requiring a first-aid
kit in the vehicle. <
460de003

Index
Data
Technology
Repairs
Car care
Controls
Overview
29nRefueling
Fuel filler door
Before filling the tank, shut off the
engine. If you do not, fuel cannot
be filled into the tank and the Service
Engine Soon lamp may come on. <
To open the filler door, press on the
front edge.
To unlock the fuel filler door if the
central locking system malfunctions,
refer to page 188.
When handling fuels, comply with
all of the applicable safety precau-
tions and regulations pertaining to
fuels. Never carry spare fuel containers
in your vehicle. Whether empty or full,
these containers can leak, cause an
explosion, or lead to fire in the event of
a collision. <
530us007
Simple and environmentally
friendly
Open the filler cap carefully to
prevent fuel from spraying out.
Fuel spray may cause injury.
Do not top off. Topping off may cause
fuel spillage. <
Keep the filler cap in the bracket
attached to the fuel filler door.
530us008
When refueling, insert the filler nozzle
completely into the filler pipe. Pulling
the nozzle out of the pipe during refu-
eling
> results in premature pump shutoff
> and will reduce the effect of the
vapor recovery system on the pump.
If the filler nozzle is used correctly, the
fuel tank is full when it shuts off for the
first time.
Tank capacity: refer to page 209.
Close the filler cap carefully after
refueling until a "click" is heard.
While closing, be sure not to squeeze
the strap which is fastened to the cap.
A loose or missing cap will activate the
message "CHECK FILLER CAP" in the
Check Control
* or the Service Engine
Soon lamp. <

30nFuel specifications Tire inflation pressure
The engine uses lead-free gasoline
only.
Required fuel:
>Premium Unleaded Gasoline,
min. 91 AKI.
AKI = Anti Knock Index
Do not use leaded fuels. The use
of leaded fuels will cause perma-
nent damage to the system's oxygen
sensor and the catalytic converter. <
You will find tire inflation pressures on
the inside door pillar.
Check tire pressures
All pressure specifications are indicated
in psi (kilopascal) for tires at ambient
temperature (refer also to the next
page).
530us009
Check tire inflation pressures
regularly — at least every two
weeks and before beginning a longer
trip. Incorrect tire pressure can other-
wise lead to tire damage and accidents.
Check the tire inflation pressure of the
spare wheel. Inflate the spare tire to
the highest inflation of any tire on your
vehicle. <
Comply with tire approval
specifications
The inflation pressures in the table
apply to tires from BMW-approved
manufacturers. Your BMW center is
familiar with these pressures. Higher
pressures may be specified for tires
from other manufacturers. You will find
a list of approved tires beginning on
page 150.
Your vehicle is equipped with tires that
not only meet US standards, but also
European standards. We recommend
the exclusive use of BMW-approved
tires.
