fuse BMW X5 4.4I 2000 Owners Manual

Contents

Operation, care and maintenance
Owner service procedures
Advanced technology

Under the hood:

Hood133
Engine compartment134
Washer fluid136
Washer nozzles136
Engine oil137
Coolant140
Brake fluid141
Vehicle Identification No.141

Care and maintenance:

The BMW Maintenance
System142
Caring for your vehicle143
Airbags148
Vehicle storage148

Laws and regulations:

Technical modifications149
OBD interface socket150

Replacement procedures:

Onboard tool kit154
Wiper blades154
Lamps and bulbs155
Changing a wheel160
Battery165
Fuses167

In case of electrical
malfunction:

Fuel filler door168
Sliding/Tilt sunroof168
Liftgate168
Tailgate169

Assistance, giving and
receiving:

Jump-starting170
Towing the vehicle171Airbags176
Adaptive Transmission Control
(ATC)176
Four-wheel drive177
Dynamic Stability Control
(DSC)177
Radio reception178
Safety belt tensioner178
DSP sound system179
Rearview mirrors with automatic
dimmer179
Rain sensor180
Integrated rear suspension180
Level control system181
Xenon lamps181

IndexDataTechnologyRepairsCar careControlsOverview
Overview
Controls and features
Operation, care
and maintenance
Owner service procedures
Technical data
Index Advanced technology
153n
Replacement procedures:
Onboard tool kit154
Wiper blades154
Lamps and bulbs155
Changing a wheel161
Battery165
Fuses167
In case of electrical
malfunction:
Fuel filler door168
Sliding/Tilt sunroof168
Liftgate168
Tailgate169
Assistance, giving and
receiving:
Jump-starting170
Towing the vehicle171
Repairs

IndexDataTechnologyRepairsCar careControlsOverview
167n
Fuses When an electrical accessory fails to
operate, switch it off and inspect the
fuse. In the glove compartment 1 Open the glove compartment and
turn the two quick-release knobs to
the left. Spare fuses and plastic
tweezers are located on the fuse
holder.
2 Use the plastic tweezers to remove
the fuse for the accessory or equip-
ment that has stopped working.
3 If the fuse is burned through (the
metal strip will have melted and sep-
arated), replace it with a new fuse of
the same ampere rating (color code). 530us121
A list of the fuses, their respective
ampere ratings and the equipment in
their circuits is provided below the fuse
holder.
Close the fuse holder by holding the top
of the cover in place and screwing the
two quick-release knobs to the right.
Additional fuses are provided in the
cargo area.
The fuse for continuous positive current
is located in a separate fuse box in front
of the spare wheel. If this fuse is defec-
tive, refer the problem to your BMW
center for repair.
Do not attempt to repair a burned
fuse or replace it with a fuse hav-
ing a different color or amperage rating.
To do this could cause a fire in the vehi-
cle resulting from a circuit overload.<
If the fuse continues to burn through,
have the problem corrected by a BMW
center.
In the cargo area Open the right cover by pulling the han-
dle.
A list of the fuses, their respective am-
pere ratings and the equipment in their
circuits is provided on the rear of the
cover. 530us122

Everything from A to ZFuel filler door release after
electrical fault168
Fuel gauge75
Fuel quality30
Fuel tank capacity187
Fuses167GGarage-door opener98
Gasoline30
General driving notes118
Glasses compartment102
Glove compartment101
Glove compartment lamp,
bulb replacement159
Gross vehicle weight186
Ground clearance117HHandbrake65
Handsfree system102
Hazard warning flashers28
Hazard warning triangle28
HDC (Hill Descent
Control)84
Head restraints49
Headlamp covers,
care143, 155
Headlamp flasher69
Headlamp washer
system136Headlamp washers70
Heated steering wheel96
Heating and ventilation90
Heating while stopped94
Heavy cargo112
Height185
Height adjustment, seats48
Height adjustment, steering
wheel51
HiFi system179
High beams25, 87
Bulb replacement155
Hill Descent Control
(HDC)84
Hood release133
Horn26, 27
Hydraulic Brake Assistant
refer to DBC24, 120
IIce warning74
Identification number141
Identification, tires130
Ignition key34
Ignition lock63
Independent ventilation97
Indicator lamps22
Inflation pressure31, 127
INSPECTION76
Instrument cluster18, 20
Instrument lighting86Instrument panel20
Instruments18
Integrated rear axle180
Interference indicators77
Interference, cellular
phone126
Interior and exterior rearview
mirrors, automatic
dimming feature53
Interior lamps87
Bulb replacement158
Remote control38
Interior mirror53
Interior motion sensor44
Interior rearview mirror,
automatic dimming
feature179
Interlock63
Intermittent switch69
JJump-starting170KKey Memory55
Keys34
Keys with radio remote
control34
Kickdown67
LLashing eyes42, 112
Leather care147
Length185
Level control
system24, 125, 181
License plate lamp, bulb
replacement158
Liftgate42, 168
Light switch86
Light-alloy wheel132
Lighter103
Lights-on warning86
Load-securing devices112
Louvers90
Low beams86
Bulb replacement155
Low-fuel warning lamp75
Lug bolts163
Lug wrench160
Luggage net42
Luggage space42
Luggage straps42
Lumbar support49MM+S tires131
Maintenance76, 142
Manual operation
Doors36
Liftgate168
Sliding/Tilt sunroof168
Tailgate169

Owner service procedures
199n
IndexDataTechnologyRepairsCar careControlsOverview
Removal aid for the spare
wheel161
Removing condensation
from the windows93
Replacement key34
Replacing bulbs155
Replacing fuses167
Replacing windshield wiper
blades154
Reservoir, washer
system136SSide lamps, bulb
replacement156
Sliding/Tilt sunroof
Closing following an
electrical malfunction168
Power loss47
Snow chains131
Spare key34
Spare tire161
Spare wheel
removal aid161
Starting assistance170
Starting problems
64, 118, 170, 171
TTailgate
Release following an
electrical malfunction169
Tire damage127
Tire inflation
pressure30, 127
Tools154
Tow fittings171
Towing171
Tow-starting172
Turn signal indicator, bulb
replacement156, 157UUse antifreeze, radiator140WWarning lamps22
Warning messages77
Wiper blade
replacement154
Work in the engine
compartment133
