BMW X5 4.4I 2001 Owners Manual

IndexDataTechnologyRepairsCar careControlsOverview
171n

172n

IndexDataTechnologyRepairsCar careControlsOverview
Overview
Controls and features
Operation, care
and maintenance
Owner service procedures
Technical data
Index Advanced technology
173n
Replacement procedures:
Onboard tool kit174
Windshield wiper blades174
Lamps and bulbs175
Changing a wheel181
Battery185
Fuses187
In case of electrical
malfunction:
Fuel filler door188
Sliding/Tilt sunroof188
Liftgate188
Tailgate189
Assistance, giving and
receiving:
Jump-starting190
Towing the vehicle191
Repairs

174n
Under the cargo area floor in a pocket.
530us106
Front 1 Move the wiper to a fold-out position
(refer to page 71).
2 Lift the wiper arm and press the
securing spring (arrow).
3 Pull the wiper blade off toward the
wiper arm.
4 Insert the new blade and snap it into
place.
Fold the wipers back down onto
the windshield before you turn the
ignition key to position 1 or 2 again. If
you do not, they could be damaged.< 360de114
Rear

1 Hold the wiper blade on the window
and remove/unclip the wiper arm at
the articulated joint (arrow).
2 Insert a new wiper blade and press it
on/clip it into the wiper arm.
Use only wiper blades approved
by BMW.< 392de173
Onboard tool kit Windshield wiper blades

IndexDataTechnologyRepairsCar careControlsOverview
175n
Lamps and bulbsThe lamps and bulbs are essential
factors contributing to the safety of your
vehicle. For this reason, follow the
instructions below carefully when
replacing a bulb. If you are not familiar
with any of the procedures, consult
your BMW center.
Do not touch the glass portion of a
new bulb with your bare hands
since even small amounts of impurities
burn into the surface and reduce the
service life of the bulb. Use a clean
cloth, paper napkin, or a similar mate-
rial, or hold the bulb by its metallic
base.<
A replacement bulb set is available from
your BMW center.
Whenever working on the elec-
trical system, switch off the elec-
trical accessory you are working on or
disconnect the cable from the negative
terminal of the battery. Failure to do this
could result in short circuits.
To prevent injuries and damage,
comply with any instructions provided
by the bulb manufacturer.<
The illustration shows the right-hand
engine compartment.
For checking and adjusting head-
lamp aim, please contact your
BMW center.< 1 Low beams H7 bulb, 55 watts
The bulb is pressurized. There-
fore, wear safety glasses and
protective gloves. Failure to comply
with this precaution could lead to injury
if the bulb is accidentally damaged
during replacement.<
1 Turn the bulb holder to the left (arrow)
and remove.
2 Remove and replace the bulb. 530us107
2 High beamsHB3 bulb, 60 watts
The bulb is pressurized. There-
fore, wear safety glasses and
protective gloves. Failure to comply
with this precaution could lead to injury
if the bulb is accidentally damaged
during replacement.<
1 Turn the bulb to the left and remove.
2 Disconnect the plug.
3 Plug the new bulb into the plug
connector. Be sure that it is securely
engaged.
4 Install in the opposite order.
When cleaning the headlamps,
please observe the following:
>Do not wipe dry (scratches). Never
use abrasives or strong solvents to
clean the covers.
>Remove dirt and contamination (such
as insects) by soaking with BMW Car
Shampoo and then rinsing with plenty
of water.
>Always use a deicer spray to remove
accumulated ice and snow – never
use a scraper.<

176n
Lamps and bulbsXenon lamps
*
The operating life of these lamp units is
extremely long and the likelihood of
failure very low, provided that they are
not switched on and off a very great
number of times. If one of these bulbs
should nevertheless fail, it is possible to
continue driving with great caution
using the fog lamps, provided traffic
laws in your area do not prohibit this.
Because of the extremely high
voltages involved, any work on the
xenon lighting system should be carried
out by technically-qualified personnel
only. Failure to comply with this creates
a risk of fatal injury.< Turn signal indicators/Side lamps
(side marker lamps), front Dual-filament bulb, 28/8 watts
Please contact a BMW center in case of
a malfunction.
Side turn signals 5 watt bulb
1 Use finger pressure against the rear
end of the lens (arrow) to press it
forward for removal.
2 Press gently on the bulb and turn it to
the left to remove it.
3 Replace the bulb.530us109
Front fog lamps H1 bulb, 55 watts
The bulb is pressurized. There-
fore, wear safety glasses and
protective gloves. Failure to comply
with this precaution could lead to injury
if the bulb is damaged during replace-
ment.<
1 Pull the cover in front of the foglamp
forward.
2 Loosen the two screws (arrows) and
remove the foglamp.
3 Turn the cover cap on the rear of the
foglamp to the left and remove.
4 Unhook the wire clamp, remove the
contact base and replace the bulb. 530us110

IndexDataTechnologyRepairsCar careControlsOverview
177n
Lamps and bulbsTail lamp assembly Tail lamp 2: 21/5 watt bulb
Remaining bulbs: 21 watts
1 Turn signal
indicator yellow or white
2 Rear lamps/
Side marker lamps red
3 Backup lamps white
4 Brake lamps red
5 Reflector red530de212
Lamps in the side panel:
1 Open the cover in the side panel.
2 Lift the side panel if necessary.
3 Press gently on the lamp holder and
turn it to the left to remove it.
4 Remove the bulb. 530us112
Lamps in the tailgate:
1 Unclip the trim panel in the tailgate
with a screwdriver.
2 Press gently on the lamp holder and
turn it to the left to remove it.
3 Remove the bulb. Center (high-mount) brake lampLED strip in the rear spoiler: please
contact a BMW center in case of a
malfunction. 530us113

178n
Lamps and bulbsLicense plate lamps 5 watt bulb
1 Press the lamp out to the side with a
screwdriver.
2 Remove the lamp and replace the
bulb. 530us114
Interior lamps Front and rear
*
Interior lamp (6 watt bulb) with reading
lamps (2 x 6 watt bulbs)
1 Press the lamp out to the side with a
screwdriver.
2 Turn the bulb holder to the left and
remove.
3 Remove and replace the bulb.
Rear
Interior lamp (2 x 5 watt bulbs)
1 Press the lamp out to the front with a
screwdriver.
2 Take off the lens and pull the lamp
out of the contact tab.530us115
Cargo area lamps Two lamps in the trim panel of the lift-
gate:
6 watt bulbs
1 Apply a screwdriver in the recess to
press the lens out.
2 Replace the bulb. Footwell lamps, front 5 watt bulb
1 Press the lamp out with a screw-
driver.
2 Replace the bulb.Footwell lamps in the rear
passenger area 5 watt bulb
1 Use a screwdriver to press the lens
out to the side.
2 Replace the bulb.

IndexDataTechnologyRepairsCar careControlsOverview
179n
Lamps and bulbsGlove compartment lamp 5 watt bulb
1 Apply a screwdriver in the recess to
press the lamp out.
2 Remove the reflector.
3 Replace the bulb. Lighted vanity mirror10 watt bulb
1 Remove the bulb housing. Use a
screwdriver if necessary.
2 Replace the bulb.
Exit lamps Lamp in the lower door trim panel:
5 watt bulb
1 Press the lamp out with a screw-
driver.
2 Replace the bulb. Front area lighting
*
6 watt xenon bulb
Please contact a BMW center in case of
a malfunction.

180n
Changing a wheel
Safety measures in the event of a
flat tire or wheel change: stop the
vehicle as far as possible from passing
traffic. Park on a firm, flat, surface.
Switch on the hazard warning flashers.
Turn the steering wheel to the straight-
ahead position, remove the key and
engage the steering lock. Shift into 1st or
reverse (selector lever in "Park" with
automatic transmission) and engage the
parking brake. All passengers should be
outside the vehicle and well away from
your immediate working area (behind a
guardrail, for instance). If a warning
triangle or portable hazard warning lamp
is required, set it up on the roadside at
an appropriate distance from the rear of
the vehicle. Comply with all safety guide-
lines and regulations. Change the wheel
only on a level, firm surface which is not
slippery. Avoid jacking the vehicle up on
a soft or slippery surface (snow, ice, very
smooth surfaces, etc.), since it could
slide sideways. Position the jack on a
firm support surface. Do not place
wooden blocks or similar objects under
the jack. If this is done, the jack might not
be able to reach its full support capacity
because of the limited height. Do not lie
under the vehicle or start the engine
when the vehicle is supported by the
jack. Failure to comply with this creates a
risk of fatal injury.<
What you will need In order to avoid rattling noises later,
note the position of the tools when you
remove them and return them to their
original position when you are through
using them.
>Two wedges (wheel chocks)
Open the liftgate and tailgate.
In the cargo area, fold up the floor
cover or pull-out cargo floor (refer to
page 127 or 128).
Take out the wedges (arrow) next to
the spare wheel. 530us117
>Lug wrench
Is located next to the spare wheel. 530us120
