BMW X5 4.4I 2002 Owners Manual

121n
OverviewControlsMaintenanceRepairsDataIndex
Ski bag
*
Securing the load
Secure the bag's contents by
tightening down the retaining
strap at the buckle.<
Please be sure that the skis are clean
before loading them into the bag. Be
careful to avoid damage from sharp
edges.
530de284
If the cover is concealed in the
cargo area by the pull-out cargo
floor, do not fold the larger rear back-
rest down. If you do so, it will damage
the cover.<

122n
Cargo areaFold the rear backrests downReach into the recess and pull forward
(arrow).
When you fold back the backrest,
be sure that the catch engages
securely. The red warning indicator
disappears in the recess when the
catch is engaged.
The center safety belt can be retracted
only when the larger backrest is
engaged.< 530de285
Cargo area coverPull the cover out by the handle and
hook it in the rear holders.
You can carry light objects such as
articles of clothing on the cover.
Do not place heavy or hard
objects on the cover. If you do so,
they could pose a danger to vehicle
occupants during braking or evasive
maneuvers.<
Before you slide it back into position,
place the grip in the rear fold of the
cover. 530de286
When the cover is pulled out, it can be
opened behind the rear-seat backrest
to gain access to the cargo area from
the rear seats during a trip, for example.
For removing the cover, refer to the
next page. 530de287

123n
OverviewControlsMaintenanceRepairsDataIndex
Cargo area Removing the cover 1. Use both hands to press the cover
together on both sides and slide it
forward (arrow 1)
2. Lift the cover upward from the rear
on both sides (arrow 2) and remove
it. InstallationSlide the cover into the retainers on
both sides and then press it down at
the rear until it engages. 530de288
Partition net
*
1. Remove the bag with the partition
net from the retainer by releasing the
hooks from the lashing eyes on both
sides
2. Remove the partition net from the
bag and unroll it half way
Note how the bag with the parti-
tion net is secured in the vehicle
and how the partition net is rolled up
and stored in the bag so that you can
return everything to its place after use.
If your vehicle is equiped with a pull-out
cargo floor
* be sure to read the note on
page 126.<
530de028
3. Slide back the covers on the
retainers for the partition net on both
sides of the roof (arrow)
4. Insert the curved ends of the parti-
tion net rod in the retainers on both
sides
5. Now you can slide the covers toward
the front again (arrow) 530de289

124n
Cargo area 6. Attach the hooks on the bottom of
the partition net into the eyes on both
sides 530de030
7. When the rear backrests are folded
down, you can open the Velcro¨
strips, completely unroll the partition
net, insert it in the front retainers on
the roof and attach the three hooks
into the eyes.
The illustration shows securing at the
bottom right as an example. 530de031
Side coversPull the handle to open the side covers.530de290

125n
OverviewControlsMaintenanceRepairsDataIndex
Cargo area Floor cover To access the spare wheel.
To release: press the recess in the
handle (arrow) and raise the cover with
the handle. 530de291
Fold the floor cover upLift up the black retainer on the lower
side of the floor cover and hook it into
the upper frame of the liftgate cutout.
Before you fold the floor cover down,
return the retainer to its original posi-
tion.530us086
Power outlets When you fold the cover cap up, you
have access to additional power
outlets.
You can use the power outlets for flash-
lights, car vacuum cleaners or other
automotive appliances with up to
approx. 200 watts at 12 volts. Avoid
damage to the socket caused by
inserting plugs of a different shape or
size.
Refer also to page 119. 530us084

126n
Cargo area Pull-out cargo floor
*
To release, pull the handle recess
upward. Then pull the floor out.
Do not drive when the cargo floor
is pulled out.
Do not release the cargo floor on steep
grades. If you do, it could extend auto-
matically and cause personal injuries.
A load which is not properly secured
could begin to slide if the floor extends
automatically and then drop to the
ground as a result of the rapid braking
of the cargo floor at the limit stop.< 530de292
When it is extended, you can load the
cargo floor:
>With up to 990 Ibs (450 kg),
distributed evenly across the
entire surface
>With up to 330 Ibs (150 kg) on the
rear edge.
Do not overload the cargo floor
when it is extended. If you do so,
it could cause damage.
When you slide the cargo floor back in,
do not grasp it on the bottom. If you do
so, there is a risk of personal injury.<
Raise the cargo floor For access to the spare wheel or other
stored items:
Swing the cargo floor up and secure it
with the rod (see detail).
If your vehicle has a partition net
*:
Take the bag with the partition net
out of the retainer (refer to page 123),
before you raise the cargo floor panel.
Otherwise, the bag could slide down-
ward.<
530de240

127n
OverviewControlsMaintenanceRepairsDataIndex
Cargo areaStowing cargo When transporting cargo in your BMW:
>Load heavy cargo as far forward as
possible Ð directly behind the back-
rests Ð and as low as possible
>Cover sharp edges and corners
>Do not pile objects higher than the
top edge of the backrest
>Fasten the partition net
* (refer to
page 123) and ensure that carried
items cannot pass through the parti-
tion net
>If you are transporting very heavy
loads when the rear seat is not occu-
pied, secure the outer safety belts in
the opposite buckles.
530de032
Securing the load >Secure smaller, light pieces with the
retaining straps or a luggage net
*, or
use elastic straps, refer to page 38
>For large, heavy pieces, see your
BMW Sports Activity Vehicle center
for load-securing devices
*. The
lashing eyes provided at the corners
of the cargo area serve for mounting
these load-securing devices
>Read and comply with the informa-
tion enclosed with the load-securing
devices.
530us090
Always position and secure the
load correctly. If you do not, it can
endanger the passengers during
braking or evasive maneuvers.
Do not exceed the permissible gross
vehicle weight and the permissible axle
loads, refer to page 172. If you do, the
operating safety of the vehicle is no
longer ensured and you are in violation
of the law.
Do not carry hard or heavy objects
unsecured in the passenger compart-
ment. If you do so, they may be
projected through the air during braking
and evasive maneuvers, thus endan-
gering vehicle occupants.<

128n
Roof-mounted luggage rack
*
A special rack system is available as an
option for your BMW. Please comply
with the precautions included with the
installation instructions.Mounting pointsAccess to the mounting points:
To fold up the cover (arrow), please use
the tool which is provided with the rack
system.530de293
Cargo loading and driving hintsRoof-mounted luggage racks raise the
center of gravity of the vehicle when
they are loaded. For this reason, they
exercise a major effect on the vehicle's
handling and steering response.
You should therefore always remember
not to exceed the approved roof
weight, the approved gross vehicle
weight or the axle loads when loading
the rack.
You will find the specifications under
"Technical Data" on page 172.
Make sure that the load is not too
heavy, and attempt to distribute it
evenly. Always load the heaviest pieces
first (on the bottom). Be sure that
adequate clearance is maintained for
raising the sliding/tilt sunroof, and that
objects do not project into the opening
path of the liftgate. Always ensure that roof-mounted
loads are tightly secured, as loose
loads can shift or even fly off the roof,
posing a serious hazard for following
traffic.<
Drive smoothly. Avoid sudden accelera-
tion and braking maneuvers. Take
corners gently.

129n
