BMW Z8 2000 Repair Manual

60n
1 Odometer With the ignition key in position 0, you
can activate the displays shown in the
illustration by pressing the button in the
instrument cluster (arrow).2 Trip odometerTo reset the trip odometer to zero,
press the button (arrow) with the igni-
tion key in position 1.520us004
Avoid engine speeds in the gauge's red
warning zone.
If the needle gets into this range, fuel
supply is interrupted to protect the en-
gine, resulting in a noticeable loss of
power.520de029
When you switch on the ignition, the
indicator lamp lights up briefly to
confirm that the system is operational.
Once the indicator lamp comes on and
stays on, there are approx. 2.6 gallons
(10 liters) of fuel left in the fuel tank.
For fuel tank capacity, refer to
page 157.
Certain operating conditions (such
as those encountered in mountainous
areas) may cause the needle to fluctu-
ate slightly.
Please refuel early, since driving
to the last drop of fuel can result
in damage to the engine or catalytic
converter.<520us005
Odometer Tachometer Fuel gauge

61n
IndexDataTechnologyRepairsCar careControlsOverview
Coolant temperature gauge Service Interval Display BlueThe engine is still cold. Drive at moder-
ate engine and vehicle speeds.RedWhen you switch on the ignition, the
warning lamp comes on briefly to con-
firm that the system is operational.
If the lamp comes on while operating
the vehicle, the engine has overheated.
Turn it off immediately and let it cool
down.520de031
Between the blue and red zonesNormal operating range. It is not un-
usual for the needle to rise as far as
the edge of the red zone in response
to high outside temperatures or severe
operating conditions.
For checking coolant level, refer to
page 111.
Remaining distance before
serviceThe displays shown in the illustration
appear for a few seconds when the
ignition key is in position 1 or after the
engine is started.
The remaining distance in miles before
the next scheduled service will appear
together with the display OILSERVICE
or INSPECTION.
The computer bases its calculations for
the remaining distance on the preced-
ing driving conditions.
A flashing display and a "Ð" in front of
the number indicate that service is past
due by the number of miles displayed.
Please contact your BMW center for an
appointment.520us006

62n
Set the clock From ignition key position 0 on:
To set ahead: turn the button to the
right.
To set back: turn the button to the left.
If you keep holding the knob turned,
you will find the setting faster.520us007
With the Multi-Information Radio, you
can operate the navigation system and
few other cellular phone functions, in
addition to your car radio.
Please refer to the supplementary
Owner's Manual provided with your
sound system for detailed information
on adjusting and operating the Multi-
Information Radio. Outside temperature You can have the outside temperature
shown on the Multi-Information Radio
display. Refer to the supplementary
Owner's Manual.
Clock Multi-Information Radio (MIR)

63n
IndexDataTechnologyRepairsCar careControlsOverview
The conceptDSC maintains vehicle stability even in
critical driving situations. The system
optimizes vehicle stability during accel-
eration and when starting from a full
stop, as well as optimizing traction. In
addition, the system recognizes unsta-
ble vehicle conditions (understeering or
oversteering, for example) and holds
the vehicle on a sure course by inter-
vening via the engine and by braking
intervention at the individual wheels,
within physically feasible limits.
The system starts up automatically
each time you start the engine.Indicator lamp
The indicator lamp in the instru-
ment cluster goes out shortly
after you switch on the ignition.
Refer to page 20.
Indicator lamp flashes:
The system is active and governs drive
force and braking force.
If the indicator lamp does not go out
after the engine is started, or if it comes
on during normal driving and stays on:
There is a system malfunction or the
system was deactivated with the button.
You can continue to drive the vehicle
normally, but without DSC.
Please consult your BMW center for re-
pairs.
To deactivate the systemPress the button, and the indicator
lamp comes on and stays on.
When the DSC is deactivated, you are
operating the vehicle in the conven-
tional drive mode.
In the following rare circumstances, it
may be a good idea to deactivate the
DSC for a short period of time:
>When rocking the vehicle or starting
off in deep snow or on loose surfaces.
To maintain vehicle stability,
always drive with the system
switched on when possible.<520de035
Dynamic Stability Control (DSC)

64n
Dynamic Stability Control Dynamic Driving ControlTo reactivate the systemPress the button again; the indicator
lamp goes out.
The laws of physics cannot be
repealed, even with DSC. An
appropriate driving style remains the
responsibility of the driver. For this rea-
son, do not use the additional safety
margin provided by the system as an
excuse to take risks.
Do not make any modifications to the
DSC system. Service procedures on
the system are to be performed by
authorized technicians only.<
For additional details concerning DSC,
please refer to the chapter "Advanced
technology" on page 149.
Whenever required, the system can be
switched from sporty-comfortable ori-
entation Ð based on what the driver is
demanding in terms of vehicle perfor-
mance via the accelerator pedal Ð to a
purely sports-oriented response. This
means that the switch-over is sponta-
neous and in response to the demands
made on the system through the accel-
erator pedal (detecting the sport mode).Every time the engine is started, the
sporty-comfortable orientation is acti-
vated.520de057
Detecting the Sport ModeActivating
In ignition position 2, press the button.
The indicator lamp will come on.
Deactivating
Whenever the indicator lamp is on, it
will go out if you press the button again.

65n
IndexDataTechnologyRepairsCar careControlsOverview
Tire Pressure Warning (RDW)The conceptThe RDW monitors the tire pressure in
all four wheels while driving. The sys-
tem provides an alert whenever the in-
flation pressure drops significantly in
one of the tires.
For RDW to "learn" the correct tire infla-
tion pressure, check the inflation pres-
sure in all tires, comparing them with
the values in the inflation pressure table
(refer to page 25), and make correc-
tions as necessary. Then activate the
system.
This indicator lamp in the instru-
ment cluster will flash to inform
you if the inflation pressure in
one of the tires has dropped signifi-
cantly.
To activate the system 1 Turn the ignition key to position 2
2 Press the switch long enough for the
indicator lamp in the instrument clus-
ter to light up red for a few seconds
3 The RDW undergoes an automatic
"learning" process while you are driv-
ing, and stores this data to aim for op-
timal conditions. This one-time "learn-
ing" process lasts at least 10 minutes,
after which the RDW is able to detect
and report any tire failure.
Repeat this process after any changes
in tire inflation pressure, tire rotation or
replacement.
Once the pressures have been adjusted
to the reference values used in the
"learning" process, do not activate the
system a further time.520de117
Tire failureThe red indicator lamp will flash in the
event of a tire failure.
A supplementary gong is also heard.
Carefully reduce speed to less than
50 mph (80 km/h), avoiding any hard
braking or steering maneuvers while
doing so.
For additional details, refer to page 135.
The RDW cannot alert you to
severe and sudden tire damage
caused by external factors.
Nor can it detect the gradual loss of
pressure at all four tires that normally
occurs over a period of time.<

66n
Tire Pressure Warning (RDW)
Check tire pressure on a regular
basis and correct it if you need to.
Refer to page 24.
Do not carry out any system activation
while driving with snow chains or while
driving on curves. Malfunction warnings
and undetected losses are possible
while driving under these types of
conditions.
In certain circumstances, there could
be a delayed detection of any loss in in-
flation pressure while driving on snow-
covered or slippery road surfaces.
A sporty driving style can also cause
delayed RDW alerts (e. g. slippage in
the drive wheels, high lateral accelera-
tion).<
System interferenceThe red indicator lamp in the instrument
cluster will stay on for as long as there
is a malfunction.
The indicator lamp will come on if the
system malfunctions.
Please contact your BMW center for
additional information.

67n
IndexDataTechnologyRepairsCar careControlsOverview
Side lamps (Side marker lamps)
With the switch in this position,
the front, rear and side vehicle
lighting is switched on. For light-
ing on one side for parking, refer to
page 68.
Low beams
When you switch off the ignition
and the low beams are still on,
only the side lamps (side marker
lamps) remain on.
520de036
"Follow-Me-Home" lamps:
If you actuate the headlamp
flasher after you have parked the vehi-
cle and shut off the engine, the low
beams will remain on for a brief period.
You may also have this function deacti-
vated if you wish.<
"LAMPS ON" warningIf you turn the ignition key in position 0,
an acoustic signal will sound for a few
seconds after the driver's door has
been opened if the low beam head-
lamps have not been switched off.Daytime running lamps switch
*
The headlamps are automatically
switched on for daylight driving when
ignition key is in position 2.
Turn the knob to adjust the lighting
intensity.520us008
Side lamps/Low beams Instrument lighting

68n
High beams/Parking lamps
Rear foglamp Interior lamps
1 High beam (blue indicator lamp)
2 Headlamp flasher (blue indicator
lamp)
3 Parking lampsParking lamp, left or rightWith the ignition key in position 0,
engage the lever in the appropriate
turn signal position.520de025
The yellow indicator lamp in
the instrument cluster lights up
whenever the rear foglamps are
switched on.
Obey the legal stipulations regarding
foglamp use.
520de039
The interior lamps operate automati-
cally.Switching the interior lamps on
and off manuallyTurn the knob.
If you want the interior lamps to remain
turned off, keep the knob turned for
approx. 3 seconds.
Turn the knob again to turn it back on.Footwell lampsThe footwell lamps operate in the same
way as the interior lamps.520de040

69n
IndexDataTechnologyRepairsCar careControlsOverview
Reading lamps

The reading lamps can be switched on
and off using the push button located
next to each lamp.520de041
In order to prevent battery dis-
charge, all of the lamps in the
vehicle are switched off automatically
approx. 15 minutes after the ignition
key has been turned to position 0.<
