Page 98 of 174

98n
Hardtop10. Press the left and right protective
covers onto the hardtop brackets.520de110
InstallingGoes the same way as for taking the
hardtop off, just do it in reverse order.
Attach the protective cloth insert to the
roof brace (arrow) before placing the
convertible top on the hardtop cart.
Whenever the hardtop is in constant
use, the fabric convertible top does not
need to be dismantled, even in winter.
Before storing the fabric convertible top
in the convertible top compartment, it
has to be completely dry to keep any
water or mildew stains from forming.520de165
Two individuals are required for
removal and installation. When
removing and installing the top, always
proceed with utmost caution to avoid
damage to the vehicle's paint and
bodywork or to the hardtop itself.
The hardtop headining fabric must
not contact the hardtop cart.
Otherwise it jams and can lead to
damage.<
Page 116 of 174

116n
The BMW Maintenance System has
been designed as a reliable means of
ensuring that our customers enjoy
optimal vehicle safety and reliability
with only minimum effort and expense.
Please keep in mind that regular service
not only plays a vital role in ensuring
continued vehicle safety, but also plays
a significant role in maintaining your
vehicle's resale value.
520us006
Service Interval DisplayOptimal maintenance intervals are
calculated by using advanced tech-
nology; these then are indicated in the
Service Interval Display. While conven-
tional systems rely on distance traveled
alone to determine when service is due,
the BMW Maintenance System has for
years considered the actual conditions
under which the vehicle operates,
because miles can be traveled in many
different ways:
From the maintenance point of view,
62,000 miles (100,000 km) accumulated
in short-distance urban driving are not
equivalent to the same distance
covered at moderate speeds in long-
distance highway travel.
The BMW Maintenance System, which
is based on operating conditions,
includes the Engine Oil Service and
Inspections I and II.
Determining the maintenance intervals
according to the actual loads on the
vehicle covers every kind of operating
situation. However, even those drivers
who put significantly less than
6,000 miles (10,000 km) on their vehicle
anually should have the engine oil
changed at least every two years since
oil deteriorates over time, regardless of
use.
Service Warranty Information
Booklet (US models)/Warranty
and Service Guide Booklet
(Canadian models)For additional information on mainte-
nance intervals and procedures, please
refer to the Service and Warranty Infor-
mation Booklet (US models) or the
Warranty and Service Guide Booklet
(Canadian models).
Have your BMW center perform
maintenance and repair work.
Your BMW center is always informed on
the latest maintenance work and repair
techniques and equipped with the
required special tools. In addition,
checking parts known from experience
to be subject to wear is a permanent
part of the maintenance specifications.
Be sure that all maintenance work is
confirmed in the Service and Warranty
Information Booklet (US models) or the
Warranty and Service Guide Booklet
(Canadian models).
These entries are your proof of regular
vehicle maintenance and the basis for
warranty claims.<
The BMW Maintenance System
Page 124 of 174

124n
Vehicle storage
If the vehicle is to be stored for
more than three months, ensure
that the following service operations
are carried out first.<
Preparations for storageHave your BMW center perform the
following procedures:
1. Clean and apply a rust proofing
agent or other treatment to the
engine, engine compartment, under-
carriage, axles and major compo-
nents in accordance with approved
repair procedures. Wash the vehicle,
clean the interior and treat painted
and chromed parts. Clean the
weather-stripping around the hood,
luggage compartment and doors
2. Change engine oil and oil filter at
operating temperature. As an addi-
tional corrosion protection measure,
an anticorrosive agent can be added
to the engine in accordance with the
manufacturer's instructions
3. Check the coolant level and concen-
tration and top off if necessary
4. Check the fluid level of the wind-
shield washer fluid reservoir; top off
if necessary
5. Fill the fuel tank completely to
prevent the formation of condensa-
tion
6. Increase the tire inflation pressure to
51 psi (350 kPa).Before parking the vehicle1. Dry the parking brake and footbrake
by brake applications to prevent the
brake discs and drums from
corroding
2. Park the vehicle in a covered, dry,
and well-ventilated area. Place the
transmission in first gear or, if neces-
sary, chock the wheels to prevent the
vehicle from rolling. Do not engage
the parking brake
3. Remove the battery, charge it
completely and store it in a cool (but
frost-free) room
4. Remove the hardtop and store it
separately, refer to page 96
5. Close the convertible top.
During storageRecharge a battery that has been taken
out of the vehicle every six months. If it
is not recharged, it will not be service-
able. Every time the battery is
discharged, especially over extended
periods, its service life is reduced.Removing the vehicle from
storageRecharge the battery if the "Magic Eye"
turns black, refer to page 138.
Then have Inspection I performed by
your BMW center, including a brake
fluid replacement, if necessary. Refer to
the Service and Warranty Information
Booklet (US models) or the Warranty
and Service Guide Booklet (Canadian
models).
Page 160 of 174

160n
Weights
BMW Z8
Curb weight (with one person, ready for operation, full tank of fuel, without hardtop)
Ibs. (kg) 3,725 (1,690)
Approved gross vehicle weight Ibs. (kg) 4,255 (1,930)
Approved front axle weights Ibs. (kg) 2,028 (920)
Approved rear axle weights Ibs. (kg) 2,359 (1,070)
Approved roof load capacity Ibs. (kg) Ð
Luggage compartment capacity cu ft (litres) 7.2 (203)
Approved axle weights and approved gross vehicle weight may not be exceeded.
Page 170 of 174

Everything from A to ZRestraint systems53
Return used
batteries140t
Reverse17, 58
Roof load capacity160
Rotating the tires101
Rubber parts93SSafety belt tensioners153
Safety belts50
Safety buttons36
Safety tires99
Seat adjustment45
Seat heating77
Securing cargo83
Self-defrosting mirrors48
Service Interval
Display63, 116
Shelves78, 79
Should131t
Side airbags51
Side marker lamps69
bulb
replacment131t, 132t
Skid control94
Slippery roads93
Snow chains93, 103, 104
Socket82
for flashlights82
for power supplies82
for vacuum cleaners82Sound system, refer to the
separate Owner's Manual
Spare key30
Spark plugs162
Speaker81
Specified engine oil112
Speedometer18
Starting56
problems87t, 145
Steel wheels104
Steering94
Steering wheel lock55
Stopping the vehicle57
Storage areas78, 79
Storing your vehicle124
Stroke158
Summer tires102
Switching off the engine57
Switching off the interior
motion sensor39t
Switching off the tilt alarm
sensor39t
Symbols4, 138
TTachometer62
Tail lamps132
bulb replacment132t
Tank capacity161
Technical data158
Technical
modifications6, 125Telephone81
Temperature display
outside temperature64
Temperature gauge
engine coolant63
Temperature
selection74, 75
Tilt alarm34
Tilt alarm sensor39
Tire codes102
Tire damage99t
Tire inflation
pressure26, 99
Tire pressure monitor67
Tire replacement100, 101
Tire rotation101
Tire specifications104
Tire tread99
Tools130t
Torque158
Tow fittings146t
Towing the vehicle146t
Tow-starting146t
Track159
Traction Control System
refer to DSC65
Transmission58
Transmitter key30
Tread depth, tires99
Trip odometer62
Trunk lid, refer to luggage
compartment lid37Turn signal indicator23, 59
Turning circle159
UUniform Tire Quality
Grading101
Unusually high steering
effort20, 94
Use antifreeze114t
radiator114t
Used batteries,
disposal140tVVacuum cleaner82
Vehicle battery138, 162
Vehicle care
exterior119
interior121
Vehicle equipment
options and accessories5
Vehicle Identification
Number (VIN)115
Vehicle immobilizer31
Vehicle painting119
Vehicle storage124
Vehicle weight160
Vehicle, starting56
Vehicle, stopping57
Ventilation72
draft-free75
Vinyl upholstery, care121
