Convertible switch BUICK CASCADA 2019 Owner's Manual

Buick Cascada Owner Manual (GMNA-Localizing-U.S.-12461774) - 2019 -
CRC - 3/26/18
In Brief 7
1.Air Vents 0133.
2. Headlamp High/Low-Beam
Changer 0122.
Turn Signal Lever. See Turn
and Lane-Change Signals
0 124.
Driver Information Center (DIC)
Buttons. See Driver Information
Center (DIC) 0112.
3. Cruise Control 0160.
Forward Collision Alert (FCA)
System 0167 (If Equipped).
4. Instrument Cluster 0100.
5. Driver Information Center (DIC)
0112.
6. Steering Wheel Controls 096.
7. Windshield Wiper/Washer 096.
8. Central Locking Switch. See Power Door Locks 028.
Hazard Warning Flashers
0 124.
Passenger Airbag Status
Indicator 0103. 9. AM-FM Radio. See the
infotainment manual.
10. Anti-Theft Alarm System Indicator Light. See Vehicle
Alarm System 031.
11. Traction Control/Electronic
Stability Control 0158.
Lane Departure Warning
(LDW) 0168.
Assistance Systems for
Parking or Backing 0164.
12. Dual Automatic Climate Control
System 0130.
Heated Front Seats 051 (If
Equipped).
Heated Steering Wheel 096 (If
Equipped).
13. USB Port. See the infotainment manual.
Input Jack. See the
infotainment manual.
14. Convertible Top 037.
All Window Switch. See Power
Windows 035.
15. Electric Parking Brake 0156. 16. Shift Lever. See
Automatic
Transmission 0152.
17. Power Outlets 098.
18. Ignition Switch. See Ignition
Positions 0146.
19. Horn 096.
20. Steering Wheel Adjustment
096 (Out of View).
21. Instrument Panel Storage 092.
Instrument Panel Fuse Block
0 207.
22. Hood Release. See Hood
0 178.
23. Exterior Lamp Controls 0121.
Fog Lamps 0125 (If
Equipped).
Instrument Panel Illumination
Control 0125.
24. Data Link Connector (DLC) (Out of View). See Malfunction
Indicator Lamp (Check Engine
Light) 0104.

Buick Cascada Owner Manual (GMNA-Localizing-U.S.-12461774) - 2019 -
CRC - 3/26/18
10 In Brief
Windows
Power windows work when the
ignition is on, in ACC/ACCESSORY,
or when Retained Accessory Power
(RAP) is active. SeeRetained
Accessory Power (RAP) 0149.
Using the window switch, press to
open or pull to close the window.
The windows may be temporarily
disabled if they are used repeatedly
within a short time.
All Window Switch
Press to express open or pull to
express close all windows.
Window Operation with
Convertible Top
Windows will automatically lower
fully when the convertible top is
lowered or raised. See Convertible
Top 037.
Seat Adjustment
Power Driver Seat Adjustment
To adjust a power driver seat,
if equipped:
.
Move the seat forward or
rearward by sliding the control
forward or rearward. .
Raise or lower the front part of
the seat cushion by moving the
front of the control up or down.
. Raise or lower the entire seat by
moving the rear of the control up
or down.
See Power Seat Adjustment 048.
To adjust the power seatback:
.
Tilt the top of the control
rearward to recline.
. Tilt the top of the control forward
to raise.
See Reclining Seatbacks 049.

Buick Cascada Owner Manual (GMNA-Localizing-U.S.-12461774) - 2019 -
CRC - 3/26/18
36 Keys, Doors, and Windows
Press to express open or pull to
express close all windows.
Window Automatic Reversal
System
The express-close feature will
reverse window movement if it
comes in contact with an object.
Extreme cold or ice could cause the
window to auto-reverse. The
window will operate normally after
the object or condition is removed.
Window Operation with
Convertible Top
Windows will automatically lower
fully when the convertible top is
lowered or raised. SeeConvertible
Top 037.
Automatic Reversal System
Override
{Warning
If automatic reversal system
override is active, the window will
not reverse automatically. You or
(Continued)
Warning (Continued)
others could be injured and the
window could be damaged.
Before using automatic reversal
system override, make sure that
all people and obstructions are
clear of the window path.
When the engine is on, override the
automatic reversal system by pulling
and holding the window switch if
conditions prevent it from closing.
Programming the Power
Windows
If the battery on the vehicle has
been recharged or disconnected,
or is not working, the windows with
the express-up feature will need to
be reprogrammed for the feature to
work. If power is lost, the rear
windows must be reprogrammed
first. Before reprogramming, replace
or recharge the vehicle's battery. To program a window:
1. With the ignition on or in ACC/ ACCESSORY, or when
Retained Accessory Power
(RAP) is active, close all doors.
2. Pull and hold the power window switch until the window
is fully closed. Continue
holding the switch up for
approximately five seconds
after the window is completely
closed.
3. Press the power window switch down until the window is fully
open. Continue holding the
switch down for approximately
five seconds after the window
is completely open.
The window is now reprogrammed.
Repeat the process for the other
windows.

Buick Cascada Owner Manual (GMNA-Localizing-U.S.-12461774) - 2019 -
CRC - 3/26/18
38 Keys, Doors, and Windows
Caution (Continued)
.Remove all objects from the
trunk that may contact the
convertible top when it is
operated.
. Do not leave the vehicle
with the convertible
top open.
. Do not exceed 50 km/h
(31 mph) until the top has
completely closed or
opened.
. Do not open or close the top
while driving in high wind
conditions.
. Do not operate the
convertible top multiple
times in a short period of
time without starting the
engine to avoid draining the
vehicle battery.
(Continued)
Caution (Continued)
.Do not open or store the
convertible top when it is
dirty or wet. This could
result in stains, mildew,
or other damage.
. Only store the vehicle with
the top fully closed.
Opening the Convertible Top 1. Fold out the rear trunk partition into the upright position. See
Rear Storage 092.
2. Close the trunk.
3. Start the vehicle or place it in ACC/ACCESSORY.
4. When possible, operate the convertible top when the
vehicle is stopped. The top can
be operated while driving
below 50 km/h (31 mph) and
will stop if that speed is
exceeded. The top operation
will take approximately 25 seconds. Make sure the top
operation can be completed
before that speed is reached.
5. Pull and hold the front of the
convertible top switch. The
windows will automatically
lower.
6. Continue holding until the convertible top is completely
open. A chime will sound.
Release the switch.
7. Briefly pull the all window switch to close all windows.

Buick Cascada Owner Manual (GMNA-Localizing-U.S.-12461774) - 2019 -
CRC - 3/26/18
Keys, Doors, and Windows 39
If the radio is on, the sound may be
muted for a brief time due to a new
audio system equalization being
loaded.
Closing the Convertible Top1. Make sure the sun visor mirror covers are closed and the sun
visors are stored in the center
mount position.
2. Close the trunk.
3. Start the vehicle or place it in ACC/ACCESSORY.
4. When possible, operate the convertible top when the
vehicle is stopped. The top can
be operated while driving
below 50 km/h (31 mph) and
will stop if that speed is
exceeded. The top operation
will take approximately
25 seconds. Make sure the top
operation can be completed
before that speed is reached.
5. Press and hold the front of the
convertible top switch. The
windows will automatically
lower.
6. After the convertible top is completely closed, a chime will
sound. Release the switch.
7. Briefly pull the all window switch to close all windows.
If the radio is on, the sound may be
muted for a brief time due to a new
audio system equalization being
loaded. Troubleshooting
Check the following if the
convertible top switch is not
operating:
.
The ignition should be on or in
ACC/ACCESSORY, or Retained
Accessory Power (RAP) should
be active.
. The trunk lid should be closed
with the rear trunk partition in
place. A Driver Information
Center (DIC) message will
display.
. If the ONLY MANUAL
OPERATION OF TOP
POSSIBLE message is
displayed on the DIC, see
“Manual Closing of Top” later in
this section.
. At cooler outside temperatures,
the convertible top may not
open. It is possible to close the
top down to temperatures of
about −20 °C (−4 °F). A DIC
message will display if the top
will not open due to low

Buick Cascada Owner Manual (GMNA-Localizing-U.S.-12461774) - 2019 -
CRC - 3/26/18
40 Keys, Doors, and Windows
temperature. If necessary, move
the vehicle to a heated indoor
area to operate the top.
. If the top has recently been
cycled repeatedly or left in an
intermediate state, it will be
temporarily disabled. A DIC
message displays. Normal
operation will be restored within
10 minutes after the system has
cooled.
. If the vehicle battery is low, the
power top operation may be
disabled. Try to start the vehicle.
A DIC message displays.
. If the battery has recently been
reconnected or if the vehicle has
been jump started, the top may
not operate until the power
windows have been
programmed. Complete the
power window programming
procedure. See Power Windows
0 35. Other features may be affected
while operating the convertible top:
.
The trunk can only be opened
when the convertible top is
completely opened or closed.
. The windows cannot close while
the top is moving.
. When driving with the top not
fully secured, chimes can be
heard above 80 km/h (50 mph).
If the vehicle battery has been
disconnected and reconnected,
if the fuses were pulled or replaced,
or if a jump start was performed, the
TOP NOT SECURE message may
display. Press and hold the front of
the convertible top switch to close
the top, or pull and hold the switch
to open the top, until this message
is cleared.
Partial Top Cycling
If the convertible top operation is
stopped before completion, the top
will temporarily hold its position.
If the ignition is on or in ACC/
ACCESSORY, the top will be held
for up to 10 minutes. If the vehicle is moving or off, the amount of time
will vary from a few seconds to
about a minute.
Chimes and DIC messages will be
displayed before the top will move.
When this occurs, immediately finish
the convertible top operation by
pressing the switch again until it
completes.
If the top cannot be secured, keep
clear of the top components. In
some conditions the top may move
quickly.
Do not drive with the convertible top
in an unsecured position. The top
components may move
unexpectedly. In some cases the
top may not be able to be power
operated. If this occurs, follow the
DIC messages displayed.
If the tonneau cover is not secured
and latched, and the vehicle is
moving above 10 km/h (6 mph), the
tonneau cover may automatically
move to a stable position.

Buick Cascada Owner Manual (GMNA-Localizing-U.S.-12461774) - 2019 -
CRC - 3/26/18
Keys, Doors, and Windows 41
Manual Closing of Top
If the DIC displays the ONLY
MANUAL OPERATION OF TOP
POSSIBLE message:1. Press and hold or pull and hold the front of the convertible top
switch to either open or close
the top. Press or pull the switch
in the opposite direction if one
does not work.
2. If the top moves, continue holding the switch in that
direction for at least
five seconds. The top should
then work normally.
If the top does not respond in either
direction, use the following
procedure to manually close the
convertible top and tonneau cover
before servicing if needed. This
requires more than one person.
There is a hex wrench in the glove
box. There is also string in the glove
box for your dealer to manually
secure the top completely if needed. 1. Turn off the ignition.
2. Open the trunk and pull the tonneau cover release lever
downward.
3. Close the trunk. The trunk cannot be opened from this
step forward.4. With an additional person, liftthe tonneau cover from both
sides to approximately the half
raised position.

Buick Cascada Owner Manual (GMNA-Localizing-U.S.-12461774) - 2019 -
CRC - 3/26/18
52 Seats and Restraints
Rear Seats
Either side of the rear seatback can
be folded for more cargo space or to
access the wind deflector bag. See
"Wind Deflectors" underConvertible
Top 037.
{Warning
Take care when operating the
foldable rear seats. The rear
seatback folds forward with
considerable power which can
cause injury, particularly to
children. Ensure that nothing is
attached to the rear seats or on
the seat cushion.
Caution
Folding a rear seat with the seat
belts still fastened may cause
damage to the seat or the seat
belts. Always unbuckle the seat
(Continued)
Caution (Continued)
belts and return them to their
normal stowed position before
folding a rear seat.
To fold the rear seatbacks: 1. Remove the wind deflector if installed.
2. Move the front seats forward or remove the rear head
restraints. See Power Seat
Adjustment 048 orLower
Anchors and Tethers for
Children (LATCH System) 079
for head restraint removal
instructions. Store the head
restraints in the cargo area.
3. Pull the release switch in the
trunk to fold the rear
seatback down.
4. Fold the seatback forward.
5. Repeat Steps 1–4 for the other seatback, if necessary.
