mirror controls BUICK CASCADA 2019 Owner's Manual

Buick Cascada Owner Manual (GMNA-Localizing-U.S.-12461774) - 2019 -
CRC - 3/26/18
In Brief 5
In Brief
Instrument Panel
Instrument Panel Overview . . . . . . 6
Initial Drive Information
Initial Drive Information . . . . . . . . . . 8
Remote Keyless Entry (RKE)System . . . . . . . . . . . . . . . . . . . . . . . . 8
Remote Vehicle Start . . . . . . . . . . . 8
Door Locks . . . . . . . . . . . . . . . . . . . . . 9
Trunk Release . . . . . . . . . . . . . . . . . . 9
Windows . . . . . . . . . . . . . . . . . . . . . . . 10
Seat Adjustment . . . . . . . . . . . . . . . 10
Heated Seats . . . . . . . . . . . . . . . . . . 11
Head Restraint Adjustment . . . . 11
Seat Belts . . . . . . . . . . . . . . . . . . . . . 12
Passenger Sensing System . . . 12
Mirror Adjustment . . . . . . . . . . . . . . 12
Steering Wheel Adjustment . . . . 13
Interior Lighting . . . . . . . . . . . . . . . . 13
Exterior Lighting . . . . . . . . . . . . . . . 14
Windshield Wiper/Washer . . . . . . 14
Climate Controls . . . . . . . . . . . . . . . 15
Transmission . . . . . . . . . . . . . . . . . . 15
Vehicle Features
Infotainment System . . . . . . . . . . . 16
Steering Wheel Controls . . . . . . . 16 Cruise Control . . . . . . . . . . . . . . . . . 16
Driver Information
Center (DIC) . . . . . . . . . . . . . . . . . 16
Forward Collision Alert (FCA) System . . . . . . . . . . . . . . . . . . . . . . . 17
Lane Departure Warning (LDW) . . . . . . . . . . . . . . . 17
Rear Vision Camera (RVC) . . . . 17
Park Assist . . . . . . . . . . . . . . . . . . . . 17
Power Outlets . . . . . . . . . . . . . . . . . 18
Convertible . . . . . . . . . . . . . . . . . . . . 18
Performance and Maintenance
Traction Control/Electronic Stability Control . . . . . . . . . . . . . . 18
Tire Pressure Monitor . . . . . . . . . . 18
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
E85 or FlexFuel . . . . . . . . . . . . . . . . 19
Engine Oil Life System . . . . . . . . 19
Driving for Better Fuel Economy . . . . . . . . . . . . . . . . . . . . . 20
Roadside Assistance Program . . . . . . . . . . . . . . . . . . . . . . 20

Buick Cascada Owner Manual (GMNA-Localizing-U.S.-12461774) - 2019 -
CRC - 3/26/18
In Brief 13
Exterior Mirrors
1. Turn the selector switch to L(Left) or R (Right) to choose
the driver or passenger mirror.
2. Move the control to adjust the mirror.
3. Turn the selector switch to
9
to deselect the mirror.
The vehicle has manual folding
mirrors. See Folding Mirrors 034.
Steering Wheel
Adjustment
To adjust the steering wheel:
1. Pull the lever down.
2. Move the steering wheel up or down.
3. Pull or push the steering wheel closer or away from you.
4. Lift the lever up to lock the steering wheel in place.
Do not adjust the steering wheel
while driving.
Interior Lighting
Dome Lamps
The interior lamps control in the
overhead console controls both the
front and rear interior lamps.
(: Press to turn the lamps off,
even when a door is open.
H: Press to turn the lamps on
automatically when a door is
opened.
': Press to turn on the dome
lamps.

Buick Cascada Owner Manual (GMNA-Localizing-U.S.-12461774) - 2019 -
CRC - 3/26/18
Keys, Doors, and Windows 21
Keys, Doors, and
Windows
Keys and Locks
Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Remote Keyless Entry (RKE)System . . . . . . . . . . . . . . . . . . . . . . . 23
Remote Keyless Entry (RKE) System Operation . . . . . . . . . . . . 23
Remote Vehicle Start . . . . . . . . . . 26
Door Locks . . . . . . . . . . . . . . . . . . . . 27
Power Door Locks . . . . . . . . . . . . . 28
Delayed Locking . . . . . . . . . . . . . . . 28
Automatic Door Locks . . . . . . . . . 29
Lockout Protection . . . . . . . . . . . . . 29
Doors
Trunk . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Vehicle Security
Vehicle Security . . . . . . . . . . . . . . . . 31
Vehicle Alarm System . . . . . . . . . 31
Immobilizer . . . . . . . . . . . . . . . . . . . . 32
Immobilizer Operation . . . . . . . . . 32
Exterior Mirrors
Convex Mirrors . . . . . . . . . . . . . . . . 33
Power Mirrors . . . . . . . . . . . . . . . . . . 33
Folding Mirrors . . . . . . . . . . . . . . . . . 34
Heated Mirrors . . . . . . . . . . . . . . . . . 34
Interior Mirrors
Interior Rearview Mirrors . . . . . . . 34
Automatic Dimming Rearview Mirror . . . . . . . . . . . . . . . . . . . . . . . . . 34
Windows
Windows . . . . . . . . . . . . . . . . . . . . . . . 34
Power Windows . . . . . . . . . . . . . . . 35
Sun Visors . . . . . . . . . . . . . . . . . . . . . 37
Roof
Convertible Top . . . . . . . . . . . . . . . . 37
Keys and Locks
Keys
{Warning
Leaving children in a vehicle with
an ignition key or Remote
Keyless Entry (RKE) transmitter is
dangerous and children or others
could be seriously injured or
killed. They could operate the
power window or other controls or
make the vehicle move. The
windows will function with the key
in the ignition or with the RKE
transmitter in the vehicle, and
children or others could be caught
in the path of a closing window.
Do not leave children in a vehicle
with the ignition key or an RKE
transmitter.

Buick Cascada Owner Manual (GMNA-Localizing-U.S.-12461774) - 2019 -
CRC - 3/26/18
132 Climate Controls
Rear Window Defogger
=:Press to turn the rear window
defogger on or off. An indicator light
on the button comes on to show that
the rear window defogger is on.
The defogger only works when the
ignition is on. The defogger turns off
if the ignition is off or in ACC/
ACCESSORY.
The rear window defogger can be
set to automatic operation. See
“Climate and Air Quality” under
Vehicle Personalization 0116.
When Auto Rear Defog is selected,
the rear window defogger turns on
automatically when the interior
temperature is cold and the outside
temperature is about 4 °C (40 °F)
and below. The auto rear defogger
turns off automatically after about
10 minutes. At higher speeds, the
rear window defogger may stay on
continuously.
If equipped with heated outside
mirrors, they turn on when the rear
window defogger button is on and help to clear fog or frost from the
surface of the mirrors. See
Heated
Mirrors 034.
Caution
Do not try to clear frost or other
material from the inside of the
front windshield and rear window
with a razor blade or anything
else that is sharp. This may
damage the rear window
defogger grid and affect the
radio's ability to pick up stations
clearly. The repairs would not be
covered by the vehicle warranty.
MorL:If equipped, press to turn
the heated seats on or off. See
Heated Front Seats 051.
(:If equipped, press to turn the
heated steering wheel on or off. See
Heated Steering Wheel 096. Remote Start Climate Control
Operation :
The climate control
system may run when the vehicle is
started remotely. The system uses
the driver ’s previous settings to heat
or cool the inside of the vehicle. The
rear defog may come on during
remote start based on cold ambient
conditions. The rear defog indicator
light does not come on during a
remote start. If equipped with front
heated seats, they may come on
during a remote start. The heated
seat indicator lights do not come
on during a remote start.
See Remote Vehicle Start 026 and
Heated Front Seats 051.

Buick Cascada Owner Manual (GMNA-Localizing-U.S.-12461774) - 2019 -
CRC - 3/26/18
298 Index
Electrical System (cont'd)Fuses and Circuit Breakers . . . 204
Instrument Panel Fuse
Block . . . . . . . . . . . . . . . . . . . . . . . . 207
Overload . . . . . . . . . . . . . . . . . . . . . 203
Rear Compartment Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 209
Emergency OnStar . . . . . . . . . . . . . . . . . . . . . . . 284
Engine Air Cleaner/Filter . . . . . . . . . . . . . 185
Check Light (MalfunctionIndicator) . . . . . . . . . . . . . . . . . . . . 104
Compartment Overview . . . . . . . 180
Coolant Temperature
Gauge . . . . . . . . . . . . . . . . . . . . . . 102
Cooling System . . . . . . . . . . . . . . . 186
Drive Belt Routing . . . . . . . . . . . . 268
Exhaust . . . . . . . . . . . . . . . . . . . . . . 151
Oil Life System . . . . . . . . . . . . . . . 183
Oil Pressure Light . . . . . . . . . . . . .110
Overheating . . . . . . . . . . . . . . . . . . 189
Power Messages . . . . . . . . . . . . . .115
Running While Parked . . . . . . . . 152
Starting . . . . . . . . . . . . . . . . . . . . . . . 148
Entry Lighting . . . . . . . . . . . . . . . . . . . 126
Event Data Recorders . . . . . . . . . . 281
Exit Lighting . . . . . . . . . . . . . . . . . . . . 126 Extender, Seat Belt . . . . . . . . . . . . . . 59
Exterior Lamp Controls . . . . . . . . . 121
Exterior Lighting Battery
Saver . . . . . . . . . . . . . . . . . . . . . . . . . 127
F
Filter,Engine Air Cleaner . . . . . . . . . . . 185
Flash-to-Pass . . . . . . . . . . . . . . . . . . . 122
Flashers, Hazard Warning . . . . . . 124
Flat Tire . . . . . . . . . . . . . . . . . . . . . . . . 230 Changing . . . . . . . . . . . . . . . . . . . . . 232
Floor Mats . . . . . . . . . . . . . . . . . . . . . . 251
Fluid Automatic Transmission . . . . . . 184
Brakes . . . . . . . . . . . . . . . . . . . . . . . . 192
Washer . . . . . . . . . . . . . . . . . . . . . . . 190
Fog Lamps . . . . . . . . . . . . . . . . . . . . . 125 Bulb Replacement . . . . . . . . . . . . 198
Folding Mirrors . . . . . . . . . . . . . . . . . . 34
Forward Collision Alert (FCA) System . . . . . . . . . . . . . . . . . 167
Frequency Statement Radio . . . . . . . . . . . . . . . . . . . . . . . . . 279
Front Fog Lamp Light . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
Front Seats Heated . . . . . . . . . . . . . . . . . . . . . . . . . 51 Front Turn Signal Lamps . . . . . . . 199
Fuel
Additives . . . . . . . . . . . . . . . . . . . . . 171
Economy Driving . . . . . . . . . . . . . . . 20
Filling a Portable FuelContainer . . . . . . . . . . . . . . . . . . . 173
Filling the Tank . . . . . . . . . . . . . . . 171
Foreign Countries . . . . . . . . . . . . 171
Gauge . . . . . . . . . . . . . . . . . . . . . . . . 101
Low Fuel Warning Light . . . . . . . .110
Prohibited Fuels . . . . . . . . . . . . . . 170
Recommended . . . . . . . . . . . . . . . 170
Top Tier . . . . . . . . . . . . . . . . . . . . . . 170
Fuses Engine Compartment FuseBlock . . . . . . . . . . . . . . . . . . . . . . . . 204
Fuses and Circuit Breakers . . . 204
Instrument Panel Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 207
Rear Compartment Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 209
G
Gas Strut(s) . . . . . . . . . . . . . . . . . . . . 195
GaugesEngine Coolant
Temperature . . . . . . . . . . . . . . . . 102
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . 101
