windshield wipers BUICK CENTURY 1998 Owner's Manual

yellowblue
2-35
Turn Signal/Multifunction Lever
The lever on the left side of the steering column
includes your:

Turn and Lane Change Signals

Headlamp High/Low Beam Changer

Flash
-To-Pass Feature

Windshield Wipers and Washer

Cruise Control
Turn and Lane Change Signals
The turn signal has two upward (for right) and two
downward (for left) positions. These positions allow you
to signal a turn or a lane change.
To signal a turn, move the lever all the way up or
down. When the turn is finished, the lever will
return automatically.
An arrow on the instrument
panel will flash in the
direction of the turn or
lane change.
To signal a lane change, just raise or lower the lever
until the arrow starts to flash. Hold it there until you
complete your lane change. The lever will return by
itself when you release it.
As you signal a turn or a lane change, if the arrows don't
flash but just stay on, a signal bulb may be burned out
and other drivers won't see your turn signal.

yellowblue
2-36
If a bulb is burned out, replace it to help avoid an
accident. If the arrows don't go on at all when you
signal a turn, check the fuse and check for burned
-out
bulbs. See ªFuses and Circuit Breakersº in the Index.
Turn Signal Reminder
If your turn signal is left on for more than 3/4 of a mile,
a chime will sound. To turn off the chime, move the turn
signal lever to the off position.
Headlamp High/Low Beam Changer
To change the headlamps from low beam to high or high
to low, pull the turn signal lever toward you until you
hear a click. Then release it.
When the high beams are
on, this light on the
instrument panel will also
be on.
Flash-To-Pass Feature
This feature lets you use your high-beam headlamps to
signal a driver in front of you that you want to pass.
To use it, pull the turn signal lever toward you a little,
but not so far that you hear a click.
Your high
-beam headlamps will stay on as long as you
hold the lever toward you. The high
-beam indicator on
the dash will also come on. Release the lever to turn the
high
-beam headlamps off.
Windshield Wipers

yellowblue
2-37
You control the windshield wipers by turning the band
marked WIPER DELAY.
For a single wiping cycle, turn the band to MIST. Hold
it there until the wipers start, then let go. The wipers will
stop after one cycle. If you want more cycles, hold the
band on MIST longer.
You can set the wiper speed for a long or short delay
between wipes. This can be very useful in light rain or
snow. Turn the band to choose the delay time. The
closer to LO, the shorter the delay.
For steady wiping at low speed, turn the band away
from you to the LO position. For high
-speed wiping,
turn the band further, to HI. To stop the wipers, turn the
band to OFF.
Remember that damaged wiper blades may prevent you
from seeing well enough to drive safely. To avoid
damage, be sure to clear ice and snow from the wiper
blades before using them. If they're frozen to the
windshield, carefully loosen or thaw them. If your
blades do become damaged, get new blades or
blade inserts.
Heavy snow or ice can overload your wiper motor. A
circuit breaker will stop the motor until it cools. Clear
away snow or ice to prevent an overload.
Windshield Washer
At the top of the turn signal lever there's a paddle with
the word PUSH on it. To spray washer fluid on the
windshield, just push the paddle briefly. The washer will
spray several times, then stop. Unless they are already
turned on, the wipers will operate at low speed for
several sweeps, then turn off.
CAUTION:
In freezing weather, don't use your washer until
the windshield is warmed. Otherwise the washer
fluid can form ice on the windshield, blocking
your vision.
To get more fluid on the windshield, push and hold
the paddle. Spraying will continue as long as the paddle
is held.

yellowblue
6-57
Electrical System
Add-On Electrical Equipment
NOTICE:
Don't add anything electrical to your vehicle
unless you check with your dealer first. Some
electrical equipment can damage your vehicle
and the damage wouldn't be covered by your
warranty. Some add
-on electrical equipment can
keep other components from working as
they should.
Your vehicle has an air bag system. Before attempting to
add anything electrical to your vehicle, see ªServicing
Your Air Bag
-Equipped Vehicleº in the Index.
Headlamp Wiring
The headlamp wiring is protected by a circuit breaker.
An electrical overload will cause the lamps to go on and
off, or in some cases to remain off. If this happens, have
your headlamp wiring checked right away.
Windshield Wiper Fuses
The windshield wiper motor is protected by a circuit
breaker and a fuse. If the motor overheats due to heavy
snow or ice, the wipers will stop until the motor cools. If
the overload is caused by some electrical problem and
not snow or ice, be sure to get it fixed.
Power Windows and Other Power Options
Circuit breakers in the fuse panel protect the power
windows and other power accessories. When the current
load is too heavy, the circuit breaker opens and closes,
protecting the circuit until the problem is fixed or
goes away.

yellowblue
6-60
Fuse Usage
18 Not Used
19 Radio
20 Cooling Fan
21 Not Used
22 Not Used
23 Windshield Wipers
24 Flat Pack Motor
25 PCM
26 Cigarette Lighter
27 Crank
28 HVAC BlowerEngine Compartment Fuse Block

yellowblue
9-12
Underbody Flushing Service 7-34 . . . . . . . . . . . . . . . . . . . . .
Underbody Maintenance 6-54 . . . . . . . . . . . . . . . . . . . . . . . . .
Universal Theft-Deterrent System 2-15 . . . . . . . . . . . . . . . . . .
Universal Transmitter 2-60 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vehicle
Control 4-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Damage Warnings iv. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dimensions 6
-67 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Identification Number 6-56 . . . . . . . . . . . . . . . . . . . . . . . . .
Loading 4-29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage 6-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vehicle Care/Appearance Materials 6-55 . . . . . . . . . . . . . . . . .
Ventilation System 3-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Visor Vanity Mirrors, Illuminated 2-58 . . . . . . . . . . . . . . . . . .
Visors, Sun 2-58 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warning Devices 5-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warranty Information 8-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Washer Fluid Low Light 2-38 . . . . . . . . . . . . . . . . . . . . . . . . .
Washer Fluid, Windshield 6-25 . . . . . . . . . . . . . . . . . . . . . . . .
Washing Your Vehicle 6-51 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Weatherstrips 6-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Wheel
Alignment 6
-45 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Nut Torque 5-24, 6-66 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacement 6-45 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wrench 5-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windows 2-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Express-Down 2-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power 2-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield Washer 2-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid 2-37, 6-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid Level Check 7-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid Low Light 2-38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield Wipers 2-36 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Blade Check 7-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Blade Replacement 6-39, 6-67 . . . . . . . . . . . . . . . . . . . . . .
Cleaning the Blade 6-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuses 6-57 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Winter Driving 4-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiper Blades, Cleaning 6-51 . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiper Blades, Replacement 6-51 . . . . . . . . . . . . . . . . . . . . . . .
Wiring, Headlamp 6-57 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wood Panels, Cleaning 6-50 . . . . . . . . . . . . . . . . . . . . . . . . . .
Wrecker Towing 5-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wrench, Wheel 5-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
