Page 101 of 360

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9159225) - 2016 - crc - 7/31/15
100 Instruments and Controls
Instruments and
Controls
Controls
Steering Wheel Adjustment . . . 101
Steering Wheel Controls . . . . . . 102
Horn . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Windshield Wiper/Washer . . . . 102
Rear Window Wiper/Washer . . . . . . . . . . . . . . . . . . . . . 103
Compass . . . . . . . . . . . . . . . . . . . . . 103
Clock . . . . . . . . . . . . . . . . . . . . . . . . . 105
Power Outlets . . . . . . . . . . . . . . . . 106
Warning Lights, Gauges, and
Indicators
Warning Lights, Gauges, and Indicators . . . . . . . . . . . . . . . . . . . 107
Instrument Cluster . . . . . . . . . . . . 108
Speedometer . . . . . . . . . . . . . . . . . 109
Odometer . . . . . . . . . . . . . . . . . . . . . 109
Tachometer . . . . . . . . . . . . . . . . . . . 109
Fuel Gauge . . . . . . . . . . . . . . . . . . . 109
Engine Coolant Temperature Gauge . . . . . . . . . . . . . . . . . . . . . . 110
Voltmeter Gauge . . . . . . . . . . . . . . 110
Safety Belt Reminders . . . . . . . . 111
Airbag Readiness Light . . . . . . . 112 Passenger Airbag Status
Indicator . . . . . . . . . . . . . . . . . . . . . 112
Charging System Light . . . . . . . 113
Malfunction Indicator Lamp (Check Engine Light) . . . . . . . . 113
Brake System Warning Light . . . . . . . . . . . . . . . . . . . . . . . . 115
Antilock Brake System (ABS) Warning Light . . . . . . . . . . . . . . . 116
Tow/Haul Mode Light . . . . . . . . . 116
Lane Departure Warning (LDW) Light . . . . . . . . . . . . . . . . . 117
Vehicle Ahead Indicator . . . . . . . 117
StabiliTrak
®Indicator Light . . . 117
Engine Coolant Temperature Warning Light . . . . . . . . . . . . . . . 117
Tire Pressure Light . . . . . . . . . . . 118
Engine Oil Pressure Light . . . . . 118
Security Light . . . . . . . . . . . . . . . . . 119
High-Beam On Light . . . . . . . . . . 119
Cruise Control Light . . . . . . . . . . 119
Information Displays
Driver Information Center (DIC) . . . . . . . . . . . . . . . . 120
Vehicle Messages
Vehicle Messages . . . . . . . . . . . . 124
Battery Voltage and ChargingMessages . . . . . . . . . . . . . . . . . . . 125
Brake System Messages . . . . . 125 Cruise Control Messages . . . . . 125
Door Ajar Messages . . . . . . . . . . 125
Engine Cooling System
Messages . . . . . . . . . . . . . . . . . . . 126
Engine Oil Messages . . . . . . . . . 127
Engine Power Messages . . . . . 127
Fuel System Messages . . . . . . . 127
Key and Lock Messages . . . . . 128
Lamp Messages . . . . . . . . . . . . . . 128
Object Detection System
Messages . . . . . . . . . . . . . . . . . . . 128
Ride Control System Messages . . . . . . . . . . . . . . . . . . . 130
Airbag System Messages . . . . 130
Security Messages . . . . . . . . . . . 130
Service Vehicle Messages . . . . 131
Tire Messages . . . . . . . . . . . . . . . . 131
Transmission Messages . . . . . . 132
Vehicle Reminder Messages . . . . . . . . . . . . . . . . . . . 133
Vehicle Speed Messages . . . . . 133
Washer Fluid Messages . . . . . . 133
Vehicle Personalization
Vehicle Personalization . . . . . . . 133
Page 110 of 360

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9159225) - 2016 - crc - 7/31/15
Instruments and Controls 109
Speedometer
The speedometer shows the vehicle
speed in kilometers per hour (km/h)
and miles per hour (mph).
Odometer
The odometer shows how far the
vehicle has been driven, in either
kilometers or miles.
Tachometer
The tachometer displays the engine
speed in revolutions per
minute (rpm).
Caution
If the engine is operated with the
rpm’s in the warning area at the
high end of the tachometer, the
vehicle could be damaged, and
the damage would not be covered
by the vehicle warranty. Do not
operate the engine with the rpm’s
in the warning area.
Fuel Gauge
Metric
EnglishWhen the ignition is on, the fuel
gauge shows about how much fuel
the vehicle has left in the fuel tank.
An arrow on the fuel gauge
indicates the side of the vehicle the
fuel door is on.
The gauge will first indicate empty
before the vehicle is out of fuel, but
the vehicle's fuel tank should be
filled soon.
When the fuel tank is low on fuel,
the FUEL LEVEL LOW message
appears on the Driver Information
Center (DIC). For more information
see
Fuel System Messages 0127.
Here are some situations that can
occur with the fuel gauge. None of
these indicate a problem with the
fuel gauge.
. At the gas station, the fuel pump
shuts off before the gauge
reads full.
. It takes a little more or less fuel
to fill up than the fuel gauge
indicated. For example, the
gauge may have indicated the
tank was half full, but it actually
Page 121 of 360

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9159225) - 2016 - crc - 7/31/15
120 Instruments and Controls
Information Displays
Driver Information
Center (DIC)
The DIC displays information about
your vehicle. It also displays
warning messages if a system
problem is detected.
All messages will appear in the DIC
display at the top of the instrument
cluster.
The DIC comes on when the ignition
is on. After a short delay, the DIC
will display the information that was
last displayed before the engine
was turned off.
The DIC also displays a shift lever
position indicator on the bottom line
of the display. SeeAutomatic
Transmission 0203.
The outside air temperature and
compass, if equipped, also display
on the DIC when viewing the trip
and fuel information. The outside air
temperature automatically appears
in the top right corner of the DIC
display. If there is a problem with the system that controls the
temperature display, the numbers
will be replaced with dashes. If this
occurs, have the vehicle serviced.
The compass will be shown in the
bottom right corner of the DIC
display. See
Compass0103.
The DIC has different displays,
which can be accessed by pressing
the DIC buttons on the center stack.
The DIC also allows some features
to be customized. See Vehicle
Personalization 0133.
DIC Buttons
The buttons are the set/reset,
customization, vehicle information,
and trip/fuel buttons. The button
functions are detailed in the
following pages.
V(Set/Reset) : Press this button to
set or reset certain functions and to
turn off or acknowledge messages
on the DIC.
U(Customization) : Press this
button to customize the feature
settings on your vehicle. See
Vehicle Personalization 0133.
T(Vehicle Information) : Press
this button to display the oil life,
park assist on vehicles with this
feature, units, tire pressure readings
on vehicles with this feature, and
compass calibration and zone
setting on vehicles with this feature.
3(Trip/Fuel) : Press this button
to display the odometer, trip
odometers, fuel range, average
economy, timer, fuel used, and
average speed.
Page 123 of 360

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9159225) - 2016 - crc - 7/31/15
122 Instruments and Controls
turned on. If you choose OFF, the
system will be turned off. When the
RCTA system is turned off, the DIC
will display the REAR CROSS
TRAFFIC ALERT SYSTEM OFF
message as a reminder that the
system has been turned off. See
Object Detection System Messages
0128 andRear Vision Camera
(RVC) 0213.
UNITS
Press the vehicle information button
until UNITS displays. This display
allows you to select between metric
or English units of measurement.
Once in this display, press the set/
reset button to select between
METRIC or ENGLISH units. All of
the vehicle information will then be
displayed in the unit of
measurement selected.
FRONT TIRES or REAR TIRES
On vehicles with the Tire Pressure
Monitor System (TPMS), the
pressure for each tire can be viewed
in the DIC. The tire pressure will be
shown in either kilopascals (kPa) or
pounds per square inch (psi). Press
the vehicle information button until the DIC displays FRONT
TIRES kPa (PSI) LEFT ##
RIGHT ##. Press the vehicle
information button again until the
DIC displays REAR TIRES kPa
(PSI) LEFT ## RIGHT ##.
If a low tire pressure condition is
detected by the system while
driving, a message advising you to
add air to a specific tire will appear
in the display. See
Tire Pressure
0 271 andTire Messages 0131.
If the tire pressure display shows
dashes instead of a value, there
may be a problem with your vehicle.
If this consistently occurs, see your
dealer for service.
COMPASS ZONE SETTING
This display will be available if the
vehicle has a compass. See
Compass 0103.
COMPASS RECALIBRATION
This display will be available if the
vehicle has a compass. See
Compass 0103.
Blank Display
This display shows no information.Trip/Fuel Menu Items
3(Trip/Fuel) : Press this button
to scroll through the following menu
items:
ODOMETER
Press the trip/fuel button until
ODOMETER displays. This display
shows the distance the vehicle has
been driven in either kilometers (km)
or miles (mi). Pressing the trip
odometer reset stem will also
display the odometer.
To switch between English and
metric measurements, see “UNITS”
earlier in this section.
TRIP A and TRIP B
Press the trip/fuel button until
TRIP A or TRIP B displays. This
display shows the current distance
traveled in either kilometers (km) or
miles (mi) since the last reset for
each trip odometer. Both trip
odometers can be used at the same
time. Pressing the trip odometer
reset stem will also display the trip
odometers.
Page 124 of 360

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9159225) - 2016 - crc - 7/31/15
Instruments and Controls 123
Each trip odometer can be reset to
zero separately by pressing the set/
reset button or the trip odometer
reset stem while the desired trip
odometer is displayed.
The trip odometer has a feature
called retroactive reset. This can be
used to set the trip odometer to the
number of kilometers (miles) driven
since the ignition was last turned on.
This can be used if the trip
odometer is not reset at the
beginning of the trip.
To use the retroactive reset feature,
press and hold the set/reset button
for at least four seconds. The trip
odometer will display the number of
kilometers (km) or miles (mi) driven
since the ignition was last turned on
and the vehicle was moving. Once
the vehicle begins moving, the trip
odometer will accumulate mileage.
For example, if the vehicle was
driven 8 km (5 mi) before it is started
again, and then the retroactive reset
feature is activated, the display will
show 8 km (5 mi). As the vehicle
begins moving, the display will then
increase to 8.2 km (5.1 mi), 8.4 km
(5.2 mi), etc.If the retroactive reset feature is
activated after the vehicle is started,
but before it begins moving, the
display will show the number of
kilometers (km) or miles (mi) driven
during the last ignition cycle.
RANGE
Press the trip/fuel button until
RANGE displays. This display
shows the approximate number of
remaining kilometers (km) or
miles (mi) the vehicle can be driven
without refueling. The display will
show LOW if the fuel level is low.
The fuel range estimate is based on
an average of the vehicle's fuel
economy over recent driving history
and the amount of fuel remaining in
the fuel tank. This estimate will
change if driving conditions change.
For example, if driving in traffic and
making frequent stops, this display
may read one number, but if the
vehicle is driven on a freeway, the
number may change even though
the same amount of fuel is in the
fuel tank. This is because different
driving conditions produce different
fuel economies. Generally, freeway
driving produces better fuel
economy than city driving. Fuel
range cannot be reset.
AVG (Average) ECONOMY
Press the trip/fuel button until AVG
ECONOMY displays. This display
shows the approximate average
liters per 100 kilometers (L/100 km)
or miles per gallon (mpg). This
number reflects only the
approximate average fuel economy
that the vehicle has right now, and
will change as driving conditions
change. This number is calculated
based on the number of L/100 km
(mpg) recorded since the last time
this menu item was reset. To reset
AVG ECONOMY, press and hold the
set/reset button.
TIMER
Press the trip/fuel button until
TIMER displays. This display can be
used as a timer.
To start the timer, press the set/
reset button while TIMER is
displayed. The display will show the
amount of time that has passed
since the timer was last reset, not
Page 283 of 360

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9159225) - 2016 - crc - 7/31/15
282 Vehicle Care
Wheel Alignment and Tire
Balance
The tires and wheels were aligned
and balanced at the factory to
provide the longest tire life and best
overall performance. Adjustments to
wheel alignment and tire balancing
are not necessary on a regular
basis. Consider an alignment check
if there is unusual tire wear or the
vehicle is significantly pulling to one
side or the other. Some slight pull to
the left or right, depending on the
crown of the road and/or other road
surface variations such as troughs
or ruts, is normal. If the vehicle is
vibrating when driving on a smooth
road, the tires and wheels may need
to be rebalanced. See your dealer
for proper diagnosis.
Wheel Replacement
Replace any wheel that is bent,
cracked, or badly rusted or
corroded. If wheel nuts keep coming
loose, the wheel, wheel bolts, and
wheel nuts should be replaced.
If the wheel leaks air, replace it.Some aluminum wheels can be
repaired. See your dealer if any of
these conditions exist.
Your dealer will know the kind of
wheel that is needed.
Each new wheel should have the
same load-carrying capacity,
diameter, width, offset, and be
mounted the same way as the one it
replaces.
Replace wheels, wheel bolts, wheel
nuts, or Tire Pressure Monitor
System (TPMS) sensors with new
GM original equipment parts.
{Warning
Using the wrong replacement
wheels, wheel bolts, or wheel
nuts can be dangerous. It could
affect the braking and handling of
the vehicle. Tires can lose air,
and cause loss of control, causing
a crash. Always use the correct
wheel, wheel bolts, and wheel
nuts for replacement.
Caution
The wrong wheel can also cause
problems with bearing life, brake
cooling, speedometer or
odometer calibration, headlamp
aim, bumper height, vehicle
ground clearance, and tire or tire
chain clearance to the body and
chassis.
Used Replacement Wheels
{Warning
Replacing a wheel with a used
one is dangerous. How it has
been used or how far it has been
driven may be unknown. It could
fail suddenly and cause a crash.
When replacing wheels, use a
new GM original equipment
wheel.
Page 322 of 360

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9159225) - 2016 - crc - 7/31/15
Service and Maintenance 321
Maintenance Records
After the scheduled services are performed, record the date, odometer reading, who performed the service, and the
type of services performed in the boxes provided. Retain all maintenance receipts.Date Odometer
Reading Serviced By Services Performed
Page 330 of 360

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9159225) - 2016 - crc - 7/31/15
Customer Information 329
aftermarket adaptive equipment
required for the vehicle, such as
hand controls or a wheelchair/
scooter lift for the vehicle.
For more information on the limited
offer, visit www.gmmobility.com or
call the GM Mobility Assistance
Center at 1-800-323-9935. Text
Telephone (TTY) users, call
1-800-833-9935.
General Motors of Canada also has
a Mobility Program. Visit www.gm.ca
or call 1-800-GM-DRIVE (463-7483)
for details. TTY users call
1-800-263-3830.
Roadside Assistance
Program
For U.S.-purchased vehicles, call
1-800-252-1112; (Text Telephone
(TTY): 1-888-889-2438).
For Canadian-purchased vehicles,
call 1-800-268-6800.
Service is available 24 hours a day,
365 days a year.
Calling for Assistance
When calling Roadside Assistance,
have the following information
ready:
.Your name, home address, and
home telephone number.
. Telephone number of your
location.
. Location of the vehicle.
. Model, year, color, and license
plate number of the vehicle.
. Odometer reading, Vehicle
Identification Number (VIN), and
delivery date of the vehicle.
. Description of the problem.
Coverage
Services are provided for the
duration of the vehicle’s powertrain
warranty.
In the U.S., anyone driving the
vehicle is covered. In Canada, a
person driving the vehicle without
permission from the owner is not
covered. Roadside Assistance is not a part of
the New Vehicle Limited Warranty.
General Motors North America and
Buick reserve the right to make any
changes or discontinue the
Roadside Assistance program at
any time without notification.
General Motors North America and
Buick reserve the right to limit
services or payment to an owner or
driver if they decide the claims are
made too often, or the same type of
claim is made many times.
Services Provided
.
Emergency Fuel Delivery:
Delivery of enough fuel for the
vehicle to get to the nearest
service station.
. Lock-Out Service: Service to
unlock the vehicle if you are
locked out. A remote unlock may
be available if you have
OnStar
®. For security reasons,
the driver must present
identification before this service
is given.
Page 354 of 360

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9159225) - 2016 - crc - 7/31/15
Index 353
Fuel (cont'd)Filling a Portable Fuel
Container . . . . . . . . . . . . . . . . . . . 224
Filling the Tank . . . . . . . . . . . . . . . 223
Foreign Countries . . . . . . . . . . . . 222
Gauge . . . . . . . . . . . . . . . . . . . . . . . . 109
Requirements, California . . . . . 222
System Messages . . . . . . . . . . . . 127
Fuses
Engine Compartment FuseBlock . . . . . . . . . . . . . . . . . . . . . . . . 258
Fuses and Circuit Breakers . . . 258
Instrument Panel Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 261
G
Garage Door Opener . . . . . . . . . . . 140
Programming . . . . . . . . . . . . . . . . . 140
Gauges
Engine CoolantTemperature . . . . . . . . . . . . . . . . .110
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Odometer . . . . . . . . . . . . . . . . . . . . . 109
Speedometer . . . . . . . . . . . . . . . . . 109
Tachometer . . . . . . . . . . . . . . . . . . . 109
Voltmeter . . . . . . . . . . . . . . . . . . . . . .110
Warning Lights and Indicators . . . . . . . . . . . . . . . . . . . 107 General Information
Service and Maintenance . . . . . 309
Towing . . . . . . . . . . . . . . . . . . . . . . . . 225
Vehicle Care . . . . . . . . . . . . . . . . . . 234
Glove Box . . . . . . . . . . . . . . . . . . . . . . . 95
GM Mobility Reimbursement Program . . . . . . . . . . . . . . . . . . . . . . . 328
H
Hazard Warning Flashers . . . . . . . 146
Head Restraints . . . . . . . . . . . . . . . . . 46
Headlamps
Adaptive ForwardLighting (AFL) . . . . . . . . . . . . . . . 146
Aiming . . . . . . . . . . . . . . . . . . . . . . . . 255
Bulb Replacement . . . . . . . . . . . . 255
Daytime Running Lamps/ Automatic Headlamp
System . . . . . . . . . . . . . . . . . . . . . . 145
Delayed . . . . . . . . . . . . . . . . . . . . . . 146
Flash-to-Pass . . . . . . . . . . . . . . . . . 145
High Intensity Discharge (HID) Lighting . . . . . . . . . . . . . . . 255
High-Beam On Light . . . . . . . . . . .119
High/Low Beam Changer . . . . . 145
Heated and Cooled Front
Seats . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Heated Mirrors . . . . . . . . . . . . . . . . . . . 40 Heater
Engine . . . . . . . . . . . . . . . . . . . . . . . . 199
High Voltage Devices and Wiring . . . . . . . . . . . . . . . . . . . . . . . . . 257
High-Beam On Light . . . . . . . . . . . . 119
Hill and Mountain Roads . . . . . . . . 190
Hill Start Assist (HSA) . . . . . . . . . . 209
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . 235
Horn . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
How to Wear Safety Belts Properly . . . . . . . . . . . . . . . . . . . . . . . . 57
I
Ignition Positions . . . . . . . . . . . . . . . 196
Ignition Transmission Lock
Check . . . . . . . . . . . . . . . . . . . . . . . . . 253
Immobilizer . . . . . . . . . . . . . . . . . . . . . . 37
Indicator
Vehicle Ahead . . . . . . . . . . . . . . . . .117
Infants and Young Children, Restraints . . . . . . . . . . . . . . . . . . . . . . 77
Infotainment . . . . . . . . . . . . . . . . . . . . 151
Infotainment System . . . . . . . . . . . . 338
Instrument Cluster . . . . . . . . . . . . . . 108
Instrument Panel Storage Area . . . . . . . . . . . . . . . . . . . 95
Interior Rearview Mirrors . . . . . . . . . 41
Introduction . . . . . . . . . . . . . . . . . . . . . . . 2
Page 356 of 360

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9159225) - 2016 - crc - 7/31/15
Index 355
MessagesAirbag System . . . . . . . . . . . . . . . . 130
Battery Voltage and
Charging . . . . . . . . . . . . . . . . . . . . 125
Brake System . . . . . . . . . . . . . . . . 125
Door Ajar . . . . . . . . . . . . . . . . . . . . . 125
Engine Cooling System . . . . . . . 126
Engine Oil . . . . . . . . . . . . . . . . . . . . 127
Engine Power . . . . . . . . . . . . . . . . 127
Fuel System . . . . . . . . . . . . . . . . . . 127
Key and Lock . . . . . . . . . . . . . . . . . 128
Lamp . . . . . . . . . . . . . . . . . . . . . . . . . 128
Object Detection System . . . . . 128
Ride Control System . . . . . . . . . . 130
Security . . . . . . . . . . . . . . . . . . . . . . 130
Service Vehicle . . . . . . . . . . . . . . . 131
Tire . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
Transmission . . . . . . . . . . . . . . . . . 132
Vehicle . . . . . . . . . . . . . . . . . . . . . . . 124
Vehicle Reminder . . . . . . . . . . . . . 133
Vehicle Speed . . . . . . . . . . . . . . . . 133
Washer Fluid . . . . . . . . . . . . . . . . . 133
Mirrors Automatic Dimming . . . . . . . . . . . . . 40
Automatic DimmingRearview . . . . . . . . . . . . . . . . . . . . . . 41
Convex . . . . . . . . . . . . . . . . . . . . . . . . . 39
Folding . . . . . . . . . . . . . . . . . . . . . . . . . 40 Mirrors (cont'd)
Heated . . . . . . . . . . . . . . . . . . . . . . . . . 40
Park Tilt . . . . . . . . . . . . . . . . . . . . . . . . 40
Power . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Mirrors, Interior Rearview . . . . . . . . 41
Monitor System, Tire Pressure . . . . . . . . . . . . . . . . . . . . . . 272
MP3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 162
Multi-band Antenna . . . . . . . . . . . . . 160
N
Navigation OnStar®. . . . . . . . . . . . . . . . . . . . . . 340
Net, Convenience . . . . . . . . . . . . . . . 98
New Vehicle Break-In . . . . . . . . . . . 196
O
Object Detection System
Messages . . . . . . . . . . . . . . . . . . . . . 128
Odometer . . . . . . . . . . . . . . . . . . . . . . . 109
Off-Road
Recovery . . . . . . . . . . . . . . . . . . . . . 188
Oil Engine . . . . . . . . . . . . . . . . . . . . . . . . 238
Engine Oil Life System . . . . . . . 241
Messages . . . . . . . . . . . . . . . . . . . . 127
Pressure Light . . . . . . . . . . . . . . . . .118
Older Children, Restraints . . . . . . . 76
Online Owner Center . . . . . . . . . . . 328 OnStar . . . . . . . . . . . . . . . . . . . . . . . . . 337
OnStar System . . . . . . . . . . . . . . . . . 165
OnStar
®Additional
Information . . . . . . . . . . . . . . . . . . . . 343
OnStar
®Connections . . . . . . . . . . . 341
OnStar®Diagnostics . . . . . . . . . . . . 343
OnStar®Emergency . . . . . . . . . . . . 340
OnStar®Navigation . . . . . . . . . . . . . 340
OnStar®Overview . . . . . . . . . . . . . . 339
OnStar®Security . . . . . . . . . . . . . . . 340
Operating Mode
Overheated EngineProtection . . . . . . . . . . . . . . . . . . . 248
Operation Infotainment System . . . . . . . . . . 153
Ordering
Service Publications . . . . . . . . . . 334
Outlets Power . . . . . . . . . . . . . . . . . . . . . . . . 106
Overheated Engine Protection Operating Mode . . . . 248
Overheating, Engine . . . . . . . . . . . . 247
Overview . . . . . . . . . . . . . . . . . . . . . . . 153
P
Parade Dimming . . . . . . . . . . . . . . . . 149
Park Shifting Into . . . . . . . . . . . . . . . . . . . 200
Shifting Out of . . . . . . . . . . . . . . . . 201
