Vehicle Care 327
8. Make sure the metal tube iscentered at the striker. Push
the tube toward the front of the
vehicle.
9. Close the liftgate and make sure it is fully latched.
The compact spare is for temporary
use only. Replace the compact
spare tire with a full-size tire as
soon as you can.
Storing the Compact Spare
Tire and Tools
To store the spare tire and tools: 1. Open the liftgate. See Liftgate
0 42. 2. Lift the load floor.
3. Remove the cargo
management system.
4. Put back the spare tire and all tools as they were stored in the
rear storage compartment.
5. Install the cargo management system and load floor.
The compact spare is for temporary
use only. Replace the compact
spare tire with a full-size tire as
soon as you can.
Compact Spare Tire
{Warning
Driving with more than one
compact spare tire at a time could
result in loss of braking and
handling. This could lead to a
crash and you or others could be
injured. Use only one compact
spare tire at a time. If this vehicle has a compact spare
tire, it was fully inflated when new;
however, it can lose air over time.
Check the inflation pressure
regularly. It should be 420 kPa
(60 psi).
Stop as soon as possible and check
that the spare tire is correctly
inflated after being installed on the
vehicle. The compact spare tire is
designed for temporary use only.
The vehicle will perform differently
with the spare tire installed and it is
recommended that the vehicle
speed be limited to 80 km/h (50
mph). To conserve the tread of the
spare tire, have the standard tire
repaired or replaced as soon as
convenient and return the spare tire
to the storage area.
When using a compact spare tire,
the ABS and Traction Control
systems may engage until the spare
tire is recognized by the vehicle,
especially on slippery roads. Adjust
driving to reduce possible
wheel slip.

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12146155) - 2019 - crc - 9/10/18
328 Vehicle Care
Performance of the All-Wheel
Drive (AWD) system will be
automatically reduced to protect the
system when using the compact
spare. To restore the AWD and
prevent excessive wear on the
clutch in the AWD, replace the
compact spare tire with a full-size
tire as soon as possible.
Caution
When the compact spare is
installed, do not take the vehicle
through an automatic car wash
with guide rails. The compact
spare can get caught on the rails
which can damage the tire, wheel,
and other parts of the vehicle.Do not use the compact spare on
other vehicles.
Do not mix the compact spare tire or
wheel with other wheels or tires.
They will not fit. Keep the spare tire
and its wheel together.
Caution
Tire chains will not fit the compact
spare. Using them can damage
the vehicle and the chains. Do not
use tire chains on the compact
spare.
Jump Starting
Jump Starting - North
America
For more information about the
vehicle battery, see
Battery - North
America 0284.
If the battery has run down, try to
use another vehicle and some
jumper cables to start your vehicle.
Be sure to use the following steps to
do it safely.
{Warning
WARNING: Battery posts,
terminals, and related
accessories contain lead and lead
compounds, chemicals known to
the State of California to cause
cancer and birth defects or other
reproductive harm. Batteries also
contain other chemicals known to
the State of California to cause
cancer. WASH HANDS AFTER
(Continued)

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12146155) - 2019 - crc - 9/10/18
Vehicle Care 329
Warning (Continued)
HANDLING.For more information
go to www.P65Warnings.ca.gov/
passenger-vehicle.
See California Proposition
65 Warning 0268 and the back
cover.
{Warning
Batteries can hurt you. They can
be dangerous because:
. They contain acid that can
burn you.
. They contain gas that can
explode or ignite.
. They contain enough
electricity to burn you.
If you do not follow these steps
exactly, some or all of these
things can hurt you.
Caution
Ignoring these steps could result
in costly damage to the vehicle
that would not be covered by the
vehicle warranty. Trying to start
the vehicle by pushing or pulling it
will not work, and it could damage
the vehicle.
1. Discharged Battery Positive (+) Terminal
2. Discharged Battery Remote Negative (-) Terminal 3. Good Battery Negative (-)
Terminal
4. Good Battery Positive (+) Terminal
The jump start positive (+)
Terminal (1) and the negative
remote negative terminal (2) for the
discharged battery are on the driver
side of the vehicle.
The jump start positive (+)
terminal (4) and negative (-)
terminal (3) are on the battery of the
vehicle providing the jump start.
The positive jump start connection
for the discharged battery is under a
cover. Remove the cover to expose
the terminal.
1. Check the other vehicle. It must have a 12-volt battery
with a negative ground system.
Caution
If the other vehicle does not have
a 12-volt system with a negative
ground, both vehicles can be
(Continued)

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12146155) - 2019 - crc - 9/10/18
330 Vehicle Care
Caution (Continued)
damaged. Only use a vehicle that
has a 12-volt system with a
negative ground for jump starting.
2. Position the two vehicles so that they are not touching.
3. Set the parking brake firmly and put the shift lever in
P (Park) with an automatic
transmission, or Neutral with a
manual transmission. See
Shifting Into Park 0207.
Caution
If any accessories are left on or
plugged in during the jump
starting procedure, they could be
damaged. The repairs would not
be covered by the vehicle
warranty. Whenever possible, turn
off or unplug all accessories on
either vehicle when jump starting. 4. Turn the ignition off. Turn off all
lights and accessories in both
vehicles, except the hazard
warning flashers if needed.
{Warning
An electric fan can start up even
when the engine is not running
and can injure you. Keep hands,
clothing, and tools away from any
underhood electric fan.
{Warning
Using a match near a battery can
cause battery gas to explode.
People have been hurt doing this,
and some have been blinded.
Use a flashlight if you need more
light.
Battery fluid contains acid that
can burn you. Do not get it on
you. If you accidentally get it in
your eyes or on your skin, flush
the place with water and get
medical help immediately.
{Warning
Fans or other moving engine
parts can injure you badly. Keep
your hands away from moving
parts once the engine is running.
5. Connect one end of the red positive (+) cable to the
positive (+) terminal on the
discharged battery.
6. Connect the other end of the red positive (+) cable to the
positive (+) terminal of the good
battery.
7. Connect one end of the black negative (–) cable to the
negative (–) terminal of the
good battery.
8. Connect the other end of the black negative (–) cable to the
remote negative (–) terminal for
the discharged battery.
9. Start the engine in the vehicle with the good battery and run
the engine at idle speed for at
least four minutes.

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12146155) - 2019 - crc - 9/10/18
342 Vehicle Care
Cargo Cover and
Convenience Net
Wash with warm water and mild
detergent. Do not use chlorine
bleach. Rinse with cold water, and
then dry completely.
Care of Seat Belts
Keep belts clean and dry.
{Warning
Do not bleach or dye seat belt
webbing. It may severely weaken
the webbing. In a crash, they
might not be able to provide
adequate protection. Clean and
rinse seat belt webbing only with
mild soap and lukewarm water.
Allow the webbing to dry.
Floor Mats
{Warning
If a floor mat is the wrong size or
is not properly installed, it can
interfere with the pedals.
Interference with the pedals can
cause unintended acceleration
and/or increased stopping
distance which can cause a crash
and injury. Make sure the floor
mat does not interfere with the
pedals.
Use the following guidelines for
proper floor mat usage.
. The original equipment floor
mats were designed for your
vehicle. If the floor mats need
replacing, it is recommended
that GM certified floor mats be
purchased. Non-GM floor mats
may not fit properly and may
interfere with the accelerator or
brake pedal. Always check that
the floor mats do not interfere
with the pedals. .
Do not use a floor mat if the
vehicle is not equipped with a
floor mat retainer on the driver
side floor.
. Use the floor mat with the
correct side up. Do not turn
it over.
. Do not place anything on top of
the driver side floor mat.
. Use only a single floor mat on
the driver side.
. Do not place one floor mat on
top of another.
Button Retainer

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12146155) - 2019 - crc - 9/10/18
Service and Maintenance 345
The Tire Rotation and Required
Services are the responsibility of the
vehicle owner. It is recommended to
have your dealer perform these
services every 12 000 km/7,500 mi.
Proper vehicle maintenance helps to
keep the vehicle in good working
condition, improves fuel economy,
and reduces vehicle emissions.
Because of the way people use
vehicles, maintenance needs vary.
There may need to be more
frequent checks and services. The
Additional Required Services -
Normal are for vehicles that:
.Carry passengers and cargo
within recommended limits on
the Tire and Loading Information
label. See Vehicle Load Limits
0 198.
. Are driven on reasonable road
surfaces within legal driving
limits.
. Use the recommended fuel. See
Recommended Fuel 0251.
Refer to the information in the
Maintenance Schedule Additional
Required Services - Normal chart. The Additional Required Services -
Severe are for vehicles that are:
.
Mainly driven in heavy city traffic
in hot weather.
. Mainly driven in hilly or
mountainous terrain.
. Frequently towing a trailer.
. Used for high speed or
competitive driving.
. Used for taxi, police, or delivery
service.
Refer to the information in the
Maintenance Schedule Additional
Required Services - Severe chart.
{Warning
Performing maintenance work can
be dangerous and can cause
serious injury. Perform
maintenance work only if the
required information, proper tools,
and equipment are available.
If they are not, see your dealer to (Continued)
Warning (Continued)
have a trained technician do the
work. SeeDoing Your Own
Service Work 0269.

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12146155) - 2019 - crc - 9/10/18
386 Index
IndexA
Accessories andModifications . . . . . . . . . . . . . . . . . . 269
Accessory Power . . . . . . . . . . . . . . . 207
Adaptive Cruise Control . . . . . . . . 227
Add-On Electrical Equipment . . . 266
Additional Information OnStar . . . . . . . . . . . . . . . . . . . . . . . 376
Additional Maintenance and Care . . . . . . . . . . . . . . . . . . . . . . 351
Adjustments Lumbar, Front Seats . . . . . . . . . . . . 64
Air Cleaner/Filter, Engine . . . . . . . 276
Air Conditioning . . . . . . . . . . . 178, 182
Air Filter, Passenger Compartment . . . . . . . . . . . . . . . . . 185
Air Vents . . . . . . . . . . . . . . . . . . . . . . . 184
Airbag System Check . . . . . . . . . . . . . . . . . . . . . . . . . . 95
How Does an Airbag
Restrain? . . . . . . . . . . . . . . . . . . . . . 88
Passenger Sensing System . . . . 90
What Makes an Airbag Inflate? . . . . . . . . . . . . . . . . . . . . . . . . 88
What Will You See after an Airbag Inflates? . . . . . . . . . . . . . . . 88
When Should an Airbag Inflate? . . . . . . . . . . . . . . . . . . . . . . . . 87 Airbag System (cont'd)
Where Are the Airbags? . . . . . . . . 85
Airbags Adding Equipment to the
Vehicle . . . . . . . . . . . . . . . . . . . . . . . . 94
Passenger Status Indicator . . . 140
Readiness Light . . . . . . . . . . . . . . 140
Servicing Airbag-Equipped Vehicles . . . . . . . . . . . . . . . . . . . . . . . 94
System Check . . . . . . . . . . . . . . . . . . 83
Alarm Vehicle Security . . . . . . . . . . . . . . . . 50
Alert Lane Change . . . . . . . . . . . . . . . . . 247
Side Blind Zone (SBZA) . . . . . . 246
All-Season Tires . . . . . . . . . . . . . . . . 300
All-Wheel Drive . . . . . . . . . . . . 218, 285
Antilock Brake System (ABS) . . . 218 Warning Light . . . . . . . . . . . . . . . . . 144
Appearance Care Exterior . . . . . . . . . . . . . . . . . . . . . . . 334
Interior . . . . . . . . . . . . . . . . . . . . . . . . 339
Assistance Program,
Roadside . . . . . . . . . . . . . . . . . . . . . . 364
Assistance Systems for Driving . . . . . . . . . . . . . . . . . . . . . . . . 240
Assistance Systems for Parking and Backing . . . . . . . . . . 237

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12146155) - 2019 - crc - 9/10/18
Index 387
Auto StopStop/Start System . . . . . . . . . . . . 205
Automatic Dimming Mirrors . . . . . . . . . . . . . . . . 53
Door Locks . . . . . . . . . . . . . . . . . . . . . 40
Forward Braking . . . . . . . . . . . . . . 243
Headlamp System . . . . . . . . . . . . 171
Transmission . . . . . . . . . . . . . . . . . 212
Transmission Fluid . . . . . . . . . . . 275
Automatic Transmission Manual Mode . . . . . . . . . . . . . . . . . 217
B
Battery
Exterior Lighting BatterySaver . . . . . . . . . . . . . . . . . . . . . . . 176
Load Management . . . . . . . . . . . . 175
Power Protection . . . . . . . . . . . . . 175
Battery - North America . . . . 284, 328
Blade Replacement, Wiper . . . . . 286
Brake Parking, Electric . . . . . . . . . . . . . . 219
System Warning Light . . . . . . . . 143
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . 282 Antilock . . . . . . . . . . . . . . . . . . . . . . . 218
Assist . . . . . . . . . . . . . . . . . . . . . . . . . 220
Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . 283
Braking . . . . . . . . . . . . . . . . . . . . . . . . . 188 Braking (cont'd)
Automatic Forward . . . . . . . . . . . 243
Braking System Front Pedestrian (FPB) . . . . . . . 244
Break-In, New Vehicle . . . . . . . . . . 202
Bulb Replacement Headlamp Aiming . . . . . . . . . . . . . 289
Headlamps . . . . . . . . . . . . . . . . . . . 289
License Plate Lamps . . . . . . . . . 289
Buying New Tires . . . . . . . . . . . . . . . 315
C
Calibration . . . . . . . . . . . . . . . . . . . . . . 126
California Perchlorate MaterialsRequirements . . . . . . . . . . . . . . . 269
California Proposition
65 Warning . . . . . . . . . .268, 284, 328, Back Cover
Canadian Vehicle Owners . . . . . . . . 2
Capacities and Specifications . . . . . . . . . . . . . . . . . 358
Carbon Monoxide
Engine Exhaust . . . . . . . . . . . . . . . .211
Liftgate . . . . . . . . . . . . . . . . . . . . . . . . . 42
Winter Driving . . . . . . . . . . . . . . . . 196 Cargo
Management System . . . . . . . . . .118
Caution, Danger, and Warning . . . . 2
Center Console Storage . . . . . . . . 118
Chains, Tire . . . . . . . . . . . . . . . . . . . . 319
Charging Wireless . . . . . . . . . . . . . . . . . . . . . . 129
Charging System Light . . . . . . . . . 141
Check Engine Light (MalfunctionIndicator) . . . . . . . . . . . . . . . . . . . . 141
Child Restraints Infants and Young Children . . . . . 97
Lower Anchors and Tethersfor Children . . . . . . . . . . . . . . . . . 103
Older Children . . . . . . . . . . . . . . . . . . 96
Securing . . . . . . . . . . . . . . . . . . 111, 113
Systems . . . . . . . . . . . . . . . . . . . . . . 100
Circuit Breakers . . . . . . . . . . . . . . . . 291
Cleaning Exterior Care . . . . . . . . . . . . . . . . . 334
Interior Care . . . . . . . . . . . . . . . . . . 339
Climate Control Systems Dual Automatic . . . . . . . . . . . . . . . 178
Rear . . . . . . . . . . . . . . . . . . . . . . . . . . 182
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
Cluster, Instrument . . . . . . . . . . . . . 132
Collision Damage Repair . . . . . . . 367

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12146155) - 2019 - crc - 9/10/18
388 Index
Compact Spare Tire . . . . . . . . . . . . 327
CompartmentsStorage . . . . . . . . . . . . . . . . . . . . . . . .117
Compass . . . . . . . . . . . . . . . . . . . . . . . 126
Connected Services Connections . . . . . . . . . . . . . . . . . . 383
Diagnostics . . . . . . . . . . . . . . . . . . . 385
Navigation . . . . . . . . . . . . . . . . . . . . 382
Connections Connected Services . . . . . . . . . . 383
Control
Traction and ElectronicStability . . . . . . . . . . . . . . . . . . . . . 222
Control of a Vehicle . . . . . . . . . . . . . 188
Convex Mirrors . . . . . . . . . . . . . . . . . . 52
Coolant Engine Temperature Gauge . . 138
Cooling . . . . . . . . . . . . . . . . . . . . 178, 182
Cooling System . . . . . . . . . . . . . . . . . 277
Courtesy Lamps . . . . . . . . . . . . . . . . 173
Courtesy Transportation Program . . . . . . . . . . . . . . . . . . . . . . . 366
Cruise Control . . . . . . . . . . . . . . . . . . 225 Light . . . . . . . . . . . . . . . . . . . . . . . . . . 149
Cruise Control, Adaptive . . . . . . . . 227
Cupholders . . . . . . . . . . . . . . . . . . . . . 117
Customer Assistance . . . . . . . . . . . 363
Offices . . . . . . . . . . . . . . . . . . . . . . . . 362 Customer Assistance (cont'd)
Text Telephone (TTY)
Users . . . . . . . . . . . . . . . . . . . . . . . 363
Customer Information
Publications OrderingInformation . . . . . . . . . . . . . . . . . . 369
Customer Satisfaction Procedure . . . . . . . . . . . . . . . . . . . . . 360
D
Damage Repair, Collision . . . . . . . 367
Danger, Warning, and Caution . . . . 2
Data CollectionInfotainment System . . . . . . . . . . 373
OnStar . . . . . . . . . . . . . . . . . . . . . . . 373
Data Recorders, Event . . . . . . . . . 372
Daytime Running Lamps (DRL) . . . . . . . . . . . . . . . . . . 171
Defensive Driving . . . . . . . . . . . . . . . 188
Delayed Locking . . . . . . . . . . . . . . . . . 40
Diagnostics
Connected Services . . . . . . . . . . 385
Distracted Driving . . . . . . . . . . . . . . . 187
Dome Lamps . . . . . . . . . . . . . . . . . . . 173
Door Ajar Light . . . . . . . . . . . . . . . . . . . . . 149
Delayed Locking . . . . . . . . . . . . . . . . 40
Locks . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 Door (cont'd)
Power Locks . . . . . . . . . . . . . . . . . . . . 40
Drive Belt Routing, Engine . . . . . . 359
Drive Systems All-Wheel Drive . . . . . . . . . . 218, 285
Driver Assistance Systems . . . . . 235
Driver Information Center (DIC) . . . . . . . . . . . . . 149, 152
Driver Mode Control . . . . . . . . . . . . 223
Driving
Assistance Systems . . . . . . . . . . 240
Characteristics andTowing Tips . . . . . . . . . . . . . . . . . 254
Defensive . . . . . . . . . . . . . . . . . . . . . 188
Drunk . . . . . . . . . . . . . . . . . . . . . . . . . 188
For Better Fuel Economy . . . . . . . 27
Hill and Mountain Roads . . . . . . 196
If the Vehicle is Stuck . . . . . . . . . 198
Loss of Control . . . . . . . . . . . . . . . 190
Off-Road . . . . . . . . . . . . . . . . . . . . . 190
Off-Road Recovery . . . . . . . . . . . 189
Vehicle Load Limits . . . . . . . . . . . 198
Wet Roads . . . . . . . . . . . . . . . . . . . 195
Winter . . . . . . . . . . . . . . . . . . . . . . . . 196
Dual Automatic Climate Control System . . . . . . . . . . . . . . . . 178

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12146155) - 2019 - crc - 9/10/18
Index 389
E
Electric Parking Brake . . . . . . . . . . 219
Electric Parking Brake Light . . . . 144
Electrical Equipment,Add-On . . . . . . . . . . . . . . . . . . . . . . . 266
Electrical System Engine Compartment FuseBlock . . . . . . . . . . . . . . . . . . . . . . . . 291
Fuses and Circuit Breakers . . . 291
Instrument Panel Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 294
Overload . . . . . . . . . . . . . . . . . . . . . 290
Rear Compartment Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 296
Emergency OnStar . . . . . . . . . . . . . . . . . . . . . . . 375
Engine Air Cleaner/Filter . . . . . . . . . . . . . 276
Check Light (MalfunctionIndicator) . . . . . . . . . . . . . . . . . . . . 141
Compartment Overview . . . . . . . 271
Coolant Temperature Gauge . . . . . . . . . . . . . . . . . . . . . . 138
Cooling System . . . . . . . . . . . . . . . 277
Drive Belt Routing . . . . . . . . . . . . 359
Exhaust . . . . . . . . . . . . . . . . . . . . . . .211
Heater . . . . . . . . . . . . . . . . . . . . . . . . 206
Oil Life System . . . . . . . . . . . . . . . 274 Engine (cont'd)
Oil Pressure Light . . . . . . . . . . . . 147
Overheating . . . . . . . . . . . . . . . . . . 280
Power Messages . . . . . . . . . . . . . 155
Running While Parked . . . . . . . . 212
Starting . . . . . . . . . . . . . . . . . . . . . . . 204
Engine Oil Temperature Gauge . . . . . . . . . . 137
Entry Lighting . . . . . . . . . . . . . . . . . . . 174
Equipment, Towing . . . . . . . . . . . . . 261
Event Data Recorders . . . . . . . . . . 372
Exit Lighting . . . . . . . . . . . . . . . . . . . . 175
Extended Parking . . . . . . . . . . . . . . . 210
Extender, Seat Belt . . . . . . . . . . . . . . 81
Exterior Lamp Controls . . . . . . . . . 168
Exterior Lamps Off Reminder . . . 170
Exterior Lighting Battery Saver . . . . . . . . . . . . . . . . . . . . . . . . . 176
F
Features
Memory . . . . . . . . . . . . . . . . . . . . . . . . . 11
Filter, Engine Air Cleaner . . . . . . . . . . . 276
Flash-to-Pass . . . . . . . . . . . . . . . . . . . 170
Flashers, Hazard Warning . . . . . . 172
Flat Tire . . . . . . . . . . . . . . . . . . . . . . . . 320 Changing . . . . . . . . . . . . . . . . . . . . . 321 Floor Mats . . . . . . . . . . . . . . . . . . . . . . 342
Fluid
Automatic Transmission . . . . . . 275
Brakes . . . . . . . . . . . . . . . . . . . . . . . . 283
Washer . . . . . . . . . . . . . . . . . . . . . . . 281
Folding Mirrors . . . . . . . . . . . . . . . . . . 52
Forward Automatic Braking . . . . . 243
Forward Collision Alert (FCA) System . . . . . . . . . . . . . . . . . 240
Frequency Statement Radio . . . . . . . . . . . . . . . . . . . . . . . . . 370
Front Pedestrian Braking (FPB) System . . . . . . . . . . . . . . . . . 244
Front Seats Heated and Ventilated . . . . . . . . . . 68
Fuel
Additives . . . . . . . . . . . . . . . . . . . . . 252
Economy Driving . . . . . . . . . . . . . . . 27
Filling a Portable FuelContainer . . . . . . . . . . . . . . . . . . . 253
Filling the Tank . . . . . . . . . . . . . . . 252
Foreign Countries . . . . . . . . . . . . 252
Gauge . . . . . . . . . . . . . . . . . . . . . . . . 136
Low Fuel Warning Light . . . . . . . 148
Prohibited Fuels . . . . . . . . . . . . . . 251
Recommended . . . . . . . . . . . . . . . 251
Top Tier . . . . . . . . . . . . . . . . . . . . . . 251
