display BUICK LESABRE 2001 Owner's Manual

Table of Contents
Windows
Keys and Door Locks
Remote Keyless Entry System
Trunk Release
Automatic Transaxle
Parking Brake
Tilt Wheel
Turn Signal/Multifunction Lever
Windshield Wipers
Cruise Control
Exterior and Interior LampsMirrors
Storage Compartments
Convenience Net
Auxiliary Power Outlets
OnStar® System (If Equipped)
Sunroof (Option)
HomeLink® Transmitter (If Equipped)
Instrument Panel, Warning Lights and Gages
Driver Information Center (If Equipped)
Personal Choice Features
Head-Up Display (If Equipped) Seats and Seat Controls
Safety BeltsAir Bag Systems
Restraint Systems for Children
Section
1
Section
2
Seats and Restraint Systems
Features and Controls
ii

2-
2-1
Section 2 Features and Controls
Here you can learn about the many standard and optional features on your vehicle, and information on starting,
shifting and braking. Also explained are the instrument panel and the warning systems that tell you if everything is
working properly
-- and what to do if you have a problem.
2
-2 Windows
2
-4 Keys
2
-6 Door Locks
2
-10 Remote Keyless Entry System
2
-16 Trunk
2
-17 Theft
2
-18 Content Theft-Deterrent (If Equipped)
2
-20 PASS-Key
III
2
-22 New Vehicle ªBreak-Inº
2
-22 Ignition Positions
2
-24 Starting Your Engine
2
-25 Engine Coolant Heater (Option)
2
-26 Automatic Transaxle Operation
2
-29 Parking Brake
2
-30 Shifting Into PARK (P)
2
-33 Shifting Out of PARK (P)
2
-33 Parking Over Things That Burn
2
-34 Engine Exhaust2
-34 Running Your Engine While You're Parked
2
-35 Horn
2
-35 Tilt Wheel
2
-36 Turn Signal/Multifunction Lever
2
-43 Exterior Lamps
2
-47 Interior Lamps
2
-50 Mirrors
2
-55 Storage Compartments
2
-56 Ashtrays and Cigarette Lighter
2
-57 Sun Visors
2
-66 The Instrument Panel -- Your
Information System
2
-68 Instrument Panel Clusters
2
-71 Warning Lights, Gages and Indicators
2
-82 Driver Information Center (DIC)
(If Equipped)
2
-91 Head-Up Display (HUD) (If Equipped)

2-7 Central Door Unlocking System
If your vehicle has a theft-deterrent system, all doors
will unlock if the key is held in the outside key cylinder
unlock position for more than two seconds. The doors
will also unlock if the key is turned to the unlock
position twice in three seconds.
Power Door Locks
With power door locks,
you can lock or unlock all
the doors on your vehicle
using the driver's or front
passenger's power door
lock switch.
Door Ajar Reminder (If Equipped)
If your vehicle is equipped with the Driver Information
Center (DIC), and a door is not fully closed, the DIC
will display a DOOR AJAR message. See ªDriver
Information Centerº in the Index.
Automatic Door Locks
Close the doors and turn on the ignition. Every time you
move the shift lever out of PARK (P), all of the doors
will lock. And, every time you stop and move the shift
lever into PARK (P), the doors will unlock. If someone
needs to get out while you're not in PARK (P), have that
person use the manual door lock control or power door
lock switch. When the door is closed again, it will not
lock automatically. Just use the manual door lock
control or power door lock switch to lock the door
again. If you need to lock the doors before shifting out
of PARK (P), just use the manual door lock control or
power door lock switch.
Personal Choice Programming
You can program the automatic door locks feature to
change to the following modes:
Mode 0: No automatic door lock or unlock.
Mode 1: All doors automatically lock when shifted
out of PARK (P). No automatic door unlock.
Mode 2: All doors automatically lock when shifted
out of PARK (P). Only the driver's door automatically
unlocks when shifted into PARK (P).
Mode 3: All doors automatically lock when shifted
out of PARK (P). All doors automatically unlock when
shifted into PARK (P).

2-23
LOCK (B): This is the only position in which you
can remove the key. This position locks your ignition,
steering wheel and transaxle. It's a theft
-deterrent feature.
NOTICE:
If your key seems stuck in LOCK and you can't
turn it, be sure you are using the correct key;
if so, is it all the way in? If it is, then turn the
steering wheel left and right while you turn the
key hard. But turn the key only with your hand.
Using a tool to force it could break the key or the
ignition switch. If none of this works, then your
vehicle needs service.
OFF (C): This position lets you turn off the engine but
still turn the steering wheel. It doesn't lock the steering
wheel like LOCK and it doesn't send any electrical
power to the accessories. The instrument panel cluster
will remain powered in LOCK to illuminate the gear
shift indicator. The cluster will also activate the parking
brake light when the parking brake is set. Use UNLOCK
if you must have your vehicle in motion while the
engine is not running.RUN (D): This is the position the switch returns to after
you start your engine and release the switch. This is also
the position for normal driving. Even when the engine is
not running, you can use RUN to operate your electrical
power accessories and to display some instrument panel
warning lights.
START (E): This position starts your engine. When
the engine starts, release the key. The ignition switch
will return to RUN for normal driving.
Key Reminder Warning
If you leave your key in OFF, you will hear a warning
chime when you open the driver's door.
Always leave your key in LOCK. If you leave it in any
other position, you will drain your battery power.
Retained Accessory Power (RAP)
After you turn the ignition off and remove the key,
you will still have electrical power to such accessories
as the power windows, audio steering wheel controls
(if equipped), clock, sunroof (option) and the radio
for up to 10 minutes. The instrument panel cluster
lights will stay on for a few seconds, then will go out.
Once you open a door, the power will shut off.

2-36
Turn Signal/Multifunction Lever
The lever on the left side of the steering column
includes the following:

Turn Signal and Lane Change Indicator

Headlamp High/Low
-Beam Changer

Flash
-To-Pass

Windshield Wipers and Washer
Turn Signal and Lane Change Indicator
To signal a turn, move the lever on the left side of the
steering wheel all the way up or down. The lever returns
automatically when the turn is complete.
An arrow on the instrument
panel cluster will flash in
the direction of the turn or
lane change.
If your vehicle is equipped with the Head
-Up Display
(HUD), an arrow will also appear in the display area
to indicate the direction of the turn or lane change
(See ªHead
-Up Display (HUD)º in Index for
more information).
Raise or lower the lever until the arrow starts to flash to
signal a lane change. Hold it there until the lane change
is complete. The lever will return by itself when you
release it.
If the arrows flash very fast as you signal a turn or a
lane change, a signal bulb may be burned out and other
drivers won't see your turn signal.

2-37
If a bulb is burned out, replace it to help avoid an
accident. If the arrows don't go on at all when you
signal a turn, check the fuse (see ªFuses and Circuit
Breakersº in the Index) and for burned
-out bulbs.
Turn Signal On Chime
If your turn signal is left on for more than 0.8 miles
(1.3 km), a chime will sound at each flash of the turn
signal. To turn off the chime, move the turn signal lever
to the off position.
Headlamp High/Low-Beam Changer
To change the headlamps from low beam to high beam
or high beam to low beam, pull the turn signal lever
toward you and release it.
When the high beams are
on, this light located on the
instrument panel will also
be on.If your vehicle is equipped with the Head
-Up Display
(HUD), an arrow will also appear in the display area to
indicate the high beams are on (See ªHead
-Up Display
(HUD)º in Index for more information).
Flash-To-Pass
This feature lets you use the high-beam headlamps to
signal the driver in front of you that you want to pass.
It works even if your headlamps are off.
Pull the turn signal lever toward you briefly to
flash
-to-pass.
If the headlamps are off or on low beam, the high
-beam
headlamps will turn on. They'll stay on as long as you
hold the lever toward you and the high
-beam indicator
on the instrument panel cluster will come on. Release
the lever to turn the high
-beam headlamps off.

2-44
Wiper-Activated Headlamps
This feature turns on the low
-beam headlamps
instrument panel cluster backlighting and taillamps
when the Twilight Sentinel

is in day mode and after
the windshield wipers have been in use for
approximately six seconds.
To operate the wiper
-activated headlamps, the Twilight
Sentinel must be on. If the wiper
-activated headlamps
are on and the ignition switch is turned to RUN, the
wiper
-activated headlamps will continue. When you
turn the key to OFF, the wiper
-activated headlamps will
immediately turn off. The wiper
-activated headlamps
will also turn off if you turn off the Twilight Sentinel or
the windshield wipers.
Parking Lamps
Press the park button to turn on the parking lamps.
Press it again to turn them off. (If the parking lamps
were turned on with the park button, they must be
turned off with that button).
When the parking lamps are turned on during the day,
the instrument panel cluster lights and backlighting to the
buttons will turn on. At night, if the ignition key is turned
to RUN, the brightness of this lighting can be adjusted
using the instrument panel intensity/brightness control.
The radio and climate control displays will also be on.
Lamps On Reminder
If you leave the manual headlamp or parking lamp
switch on, remove the key from the ignition and open
the driver's door, you will hear a continuous warning
chime. The chime will turn off when the lamps are
turned off.
Daytime Running Lamps
Daytime Running Lamps (DRL) can make it easier for
others to see the front of your vehicle during the day.
DRL can be helpful in many different driving conditions,
but they can be especially helpful in the short periods
after dawn and before sunset. Fully functional daytime
running lights are required on all vehicles first sold
in Canada.
A light sensor on top of the instrument panel monitors
the exterior light level for the operation of DRL and
Twilight Sentinel, so be sure it isn't covered.
The DRL system will make your high
-beam headlamps
turn on at reduced brightness in daylight when the
following conditions are met:

The ignition is on,

the headlamp switch is off and

the transaxle is not in PARK (P).

2-49
This procedure only changes the mode for the
transmitter used to change this setting. The procedure
will need to be repeated for the second transmitter.
If your vehicle is equipped with the Driver Information
Center (DIC), you must program this feature through
the DIC. See ªDriver Information Centerº in the Index.
Battery Load Management
The battery load management feature is designed to
monitor the vehicle's electrical load and determine when
the battery is in a heavy discharge condition. During
times of high electrical loading, the engine may idle at
a higher rpm setting than normal to make sure the
battery charges. High electrical loads may occur when
several of the following are on: headlamps, high beams,
rear window defogger, high blower fan, heated seats
(if equipped) and engine cooling fans.
If your vehicle's battery remains in a heavy discharge
condition for a long period of time, the blower fan,
rear defogger, heated seats and heated mirrors will be
disabled and the DIC will display BATTERY SAVER
ACTIVE. This can happen either under long periods of
idling or low speed driving with high electrical loading,
or in the event of a charging system fault.
Exterior Lighting Battery Saver
If the manual lamp control has been left on, the exterior
lamps will turn off approximately 10 minutes after the
ignition is turned to LOCK and any door has been
opened. This protects draining the battery in case you
have accidentally left the headlamps or parking lamps
on. If you need to leave the lamps on for more than
10 minutes, use the manual control to turn the lamps
back on after the ignition is turned to LOCK and any
door is opened. To delay the lamps from turning off,
see ªTwilight Sentinel

º in the index.

2-51 Electrochromic Day/Night Rearview Mirror
(If Equipped)
Your vehicle may have an automatic electrochromic
day/night rearview mirror. Your vehicle's mirror may
also contain OnStar

controls.
This is the on/off button for mirrors equipped with
OnStar controls.
When this feature is turned on, the mirror automatically
changes to reduce glare from headlamps behind you.
A photocell on the mirror senses when it is becoming
dark outside. Another photocell built into the mirror
face senses when headlamps are behind you.
At night, when the glare is too high, the mirror will
gradually darken to reduce glare (this change may take a
few seconds). The mirror will return to its clear daytime
state when the glare is reduced.
Mirror Operation
To turn on the automatic dimming feature, press AUTO
(or the on/off button for mirrors equipped with OnStar
controls). To turn off automatic dimming, press OFF
(or the on/off button for mirrors equipped with OnStar
controls). The indicator light will be illuminated when
this feature is active.
Electrochromic Day/Night Rearview Mirror
with Compass (If Equipped)
Your vehicle may have an electrochromic inside
rearview mirror with a compass. Your vehicle's mirror
may also contain OnStar

controls.
This is the on/off button for mirrors equipped with
OnStar controls.
Pressing the MIRROR button (or the on/off button
for mirrors equipped with OnStar controls) located at
the bottom of the mirror, turns the automatic dimming
feature on or off.
The mirror also includes an eight
-point compass
display in the upper right corner of the mirror face.
When on, the compass automatically calibrates as the
vehicle is driven.
When cleaning the mirror, use a paper towel or similar
material dampened with glass cleaner. Do not spray
glass cleaner directly on the mirror as that may cause
the liquid cleaner to enter the mirror housing.

2-52
Mirror Operation
To turn on the automatic dimming feature, press
MIRROR (or press and hold the on/off button for
about three seconds for mirrors equipped with OnStar
controls). To turn off automatic dimming, press
MIRROR (or press and hold the on/off button for
about three seconds for mirrors equipped with OnStar
controls) again. The green indicator light will be
illuminated when this feature is active. The automatic
dimming feature will be active each time the vehicle
is started.
Compass Operation
Press COMPASS (or the on/off button for mirrors
equipped with OnStar controls) once to turn the compass
on or off.
When the ignition and the compass feature are on, the
compass will show two character boxes for approximately
two seconds. After two seconds, the mirror will display the
compass heading.Compass Calibration
If, after two seconds, the display does not show a
compass heading (ªNº for North, for example),
there may be a strong magnetic field interfering with
the compass. Such interference may be caused by a
magnetic antenna mount, magnetic note pad holder
or a similar magnetic item. If the letter ªCº should
ever appear in the compass window, the compass may
need calibration.
The mirror can be calibrated in one of two ways:

Drive the vehicle in circles at 5 mph (8 km/h) or less
until the display reads a direction, or

drive the vehicle on your everyday routine.
Mirrors equipped with OnStar controls can be placed in
calibration mode by pressing and holding the on/off
button until a ªCº is shown in the compass display.
