buttons BUICK LESABRE 2002 Owner's Manual

1-6 Heated Seats (Option)
Press this button to turn on the heating element in the seat.
The heated seat buttons
are located on the driver's
and front passenger's
door panel.
When the heated seat button is first pressed, the high
setting is activated. Press the button again for the low
setting. The third press of the button turns the feature off.
The low setting warms the seatback and cushion until
the seat nears body temperature. The high setting heats
the seat to a slightly higher temperature.
The heated seats can only be used when the ignition is
turned on. When the ignition is turned off, the heating
element is also turned off.
Reclining Front Seatbacks
If your vehicle has
power seats, the vertical
control described previously
in this section reclines the
front seatbacks.
If your vehicle has the manual recliner, lift the lever on
the outboard side of the seat and move the seatback to
the desired position. Release the lever to lock the
seatback. Pull up on the lever without pushing on the
seatback and the seatback will go to an upright position.

2-43
Using Cruise Control on Hills
How well your cruise control will work on hills depends
upon your speed, load and the steepness of the hills.
When going up steep hills, you may have to step on the
accelerator pedal to maintain your speed. When going
downhill, you may have to brake or shift to a lower gear
to keep your speed down. Applying the brake or shifting
into a lower gear will take your vehicle out of cruise
control. If you need to apply the brake or shift to
a lower gear due to the grade of the downhill slope,
you may not want to attempt to use your cruise
control feature.
Ending Cruise Control
There are two ways to turn off the cruise control:

Step lightly on the brake pedal; or

press ON/OFF.
Erasing Speed Memory
When you turn off the cruise control or the ignition,
your cruise control set speed memory is erased.Exterior Lamps
The exterior lamp control
buttons are located to the
left of the steering column.
(Parking Lamps): Pressing the button with this
symbol turns on the parking lamps, together with the
following:

Sidemarker Lamps

Taillamps

License Plate Lamps

Instrument Panel Lights
(Headlamps): Pressing the button with this symbol
turns on the headlamps, together with the previously
listed lamps and lights.

2-44
Wiper-Activated Headlamps
This feature turns on the low
-beam headlamps,
instrument panel cluster backlighting and taillamps
when the Twilight Sentinel

is in day mode and after
the windshield wipers have been in use for
approximately six seconds.
To operate the wiper
-activated headlamps, the Twilight
Sentinel must be on. If the wiper
-activated headlamps
are on and the ignition switch is turned to RUN, the
wiper
-activated headlamps will continue. When you
turn the key to OFF, the wiper
-activated headlamps
will immediately turn off. The wiper
-activated
headlamps will also turn off if you turn off the
Twilight Sentinel or the windshield wipers.
Lamps On Reminder
If you leave the exterior lamp buttons for the headlamps
or parking lamps on, remove the key from the ignition
and open the driver's door, you will hear a continuous
warning chime. The chime will turn off when the lamps
are turned off.
Daytime Running Lamps (DRL)
Daytime Running Lamps (DRL) can make it easier
for others to see the front of your vehicle during the
day. DRL can be helpful in many different driving
conditions, but they can be especially helpful in the
short periods after dawn and before sunset. Fully
functional daytime running lamps are required on all
vehicles first sold in Canada.
A light sensor on top of the instrument panel monitors
the exterior light level for the operation of DRL and
Twilight Sentinel, so be sure it isn't covered.
The DRL system will make your high
-beam headlamps
turn on at reduced brightness in daylight when the
following conditions are met:

The ignition is on,

the exterior lamp button for the headlamps is off and

the transaxle is not in PARK (P).

2-49
To turn the feature on, do the following:
1. Close all the doors and turn the ignition on. Keep all
doors closed throughout this procedure.
2. Press and hold LOCK on the power door lock switch
throughout this procedure. All the doors will lock.
3. Press the instant alarm on the transmitter. Perimeter
lighting now remains off at this time and the horn
will chirp one time.
4. Press the instant alarm on the transmitter again.
Perimeter lighting is now enabled and the horn will
chirp two times.
5. Release the door lock switch. The perimeter lighting
feature is now on.
This procedure only changes the mode for the
transmitter used to change this setting. The procedure
will need to be repeated for the second transmitter.Front Reading Lamps
The front reading lamps, located on the headliner, are
turned on or off by pressing one of the buttons located
near each lamp.
Inadvertent Power Battery Saver
This feature is designed to protect your vehicle's battery
against drainage from the interior lamps, trunk lamp, glove
box lamp, cigarette lighters or garage door opener. When
the ignition is turned off, the power to these features will
automatically turn off after 10 minutes. Power will be
restored for an additional 10 minutes if any door is
opened, the trunk is opened or the courtesy lamp switch is
turned on. To restore power back to the cigarette lighters
the ignition must be turned back to RUN.

2-58
OnStar
System (If Equipped)
OnStar is a vehicle communications system that
offers a variety of services and provides a one
-touch
hands
-free communication link between you and the
OnStar Center. To receive OnStar services, a service
subscription agreement is required and an additional fee
may be required. Services are available 24 hours a day,
7 days a week. For more information, call
1
-888-ONSTAR-7 (1-888-667-8277).
OnStar Services Button: Press this button once to
contact an advisor who will be able to assist you with
these services. If you are not quickly connected, the
system will automatically reset and redial. This ensures
connection to the center; there is no additional action
required. Press the Communication button to cancel the
automatic redial.
Emergency Button: In an emergency situation,
press the emergency service button. Upon receiving the
call, an advisor at the center will locate your vehicle and
assess the situation. If necessary, the advisor will alert
the nearest emergency service provider.
Communication Button: Press this button at
the end of a call. Also press this button to answer a call
from the center, or cancel a call if one of the other
buttons is accidentally pressed. This button is also
used to access OnStar Personal Calling and Virtual
Advisor services. See the OnStar owner package for
more information.
Volume Control: You can control the volume of
the OnStar System using either the volume control
knob on the radio or using the steering wheel volume
control (if equipped).
Telltale Light: This light will indicate the status of
the system. A solid green light will come on when you
start the vehicle to let you know that the system is on
and is ready to make or receive calls.
If the light blinks green it means that an incoming or
outgoing call is in progress. Press the Communication
button if you notice the light blinking and you are not
on a call.

2-63 Programming the HomeLink Transmitter
Do not use the HomeLink Transmitter with any garage
door opener that does not have the ªstop and reverseº
safety feature. This includes any garage door opener
model manufactured before April 1, 1982.
Be sure that people and objects are clear of the garage
door you are programming.
It is recommended that a new battery be installed in
your hand
-held transmitter for quicker and more
accurate transmission of the radio frequency.
Your vehicle's engine should be turned off while
programming the transmitter. Follow these steps to
program up to three channels:
1. Decide which one of the three channels (one of the
three HomeLink buttons) you want to program.
2. Press and hold the desired button on HomeLink
through Step 3.3. When the HomeLink indicator light begins to blink
slowly (this may take up to 30 seconds), hold the
hand
-held transmitter about 1 to 3 inches (3 to 8 cm)
from HomeLink and then press and hold the transmit
button on the hand
-held transmitter. Continue to hold
both buttons until the indicator light on HomeLink
begins to flash rapidly (this may take up to
90 seconds).
If you have trouble programming HomeLink, make sure
that you have followed the directions exactly as
described and that the battery in the hand
-held
transmitter is not weak. If you still cannot program it,
move the hand
-held transmitter to the left or right or
forward or backward or flip it upside down. HomeLink
may not work with older garage door openers that do
not meet current Federal Consumer Safety Standards.
If you cannot program the transmitter after repeated
attempts, refer to ªTraining a Garage Door Opener with
Rolling Codesº later in this section or contact the
manufacturer of HomeLink at 1
-800-355-3515,
or on the internet at www.homelink.com.
Be sure to keep the original hand
-held transmitter in
case you need to erase and reprogram HomeLink.

2-65 Canadian Programming
Canadian Owners: During programming, the
hand
-held transmitter may automatically stop
transmitting after two seconds. In this case, you should
press and hold the HomeLink button (see Steps 2 and 3
under ªProgramming the HomeLink Transmitterº) while
you press and repress (cycle) your hand
-held transmitter
every two seconds until HomeLink is trained.
Operating the HomeLink Transmitter
Press and hold the appropriate button on HomeLink for
at least a half of a second. The indicator light will come
on while the signal is being transmitted.
Erasing Channels
To erase all three programmed channels, hold down the
two outside buttons on HomeLink until the indicator
light begins to flash (approximately 20 seconds).
Release both buttons.
Resetting Defaults
To reset HomeLink to default settings, hold down the
two outside buttons on HomeLink until the indicator
light begins to flash (approximately 20 seconds).
Continue to hold the buttons until the HomeLink
indicator light turns off and then release both buttons.
Accessories
Accessories for HomeLink are available. If you would
like additional information, please contact the
manufacturer of HomeLink at 1
-800-355-3515,
or on the internet at www.homelink.com.

2-67
The main components of your instrument panel are the following:
A. Air Outlets
B. Driver Information Center Buttons (If Equipped)
C. Turn Signal/Multifunction Lever
D. Steering Wheel Controls (If Equipped)
E. Hazard Warning Flashers
F. Instrument Panel Cluster
G. Traction Control Button (If Equipped)
H. Exterior Lamp ButtonsI. Head
-Up Display (HUD) Controls (If Equipped)
J. Hood Release
K. Parking Brake
L. Cruise Controls
M. Audio System
N. Climate Controls
O. Glove Box

2-82
Driver Information Center (DIC)
(If Equipped)
Your vehicle may be equipped with a Driver
Information Center (DIC). The DIC will display
information about how your vehicle is functioning,
as well as warning messages if a system problem is
detected. This feature also allows two different drivers
to store and recall their own personal choice settings.
See ªDIC Personal Choice Programmingº later in
this section.
DIC Displays and Controls
There are two lines in the DIC display. The DIC
displays the driver number identified when entering the
vehicle. You can have your dealer program your name to
appear on this display line. See your dealer for more
information.
When you turn the ignition on, the DIC will display
your DRIVER NUMBER. The system will then perform
a status check and display any messages if a problem
is detected.
If there are no problems detected, the display will return
to the mode selected by that driver the last time the
ignition was turned off.If a problem is detected, a diagnostic message will
appear in the display. The following pages will show
the messages you may see on the DIC display.
The message center is continuously updated with the
vehicle's performance status.
The following buttons are
on the DIC control panel
which is located to the left
of the steering column:
ODO/TRIP (Odometer/Trip): When this button is
pressed, the display will show the total mileage, and
Trip 1 or Trip 2 miles. Trip 1 and Trip 2 will display the
miles traveled since the last reset. To reset the trip
odometer, press the ODO/TRIP button until the
preferred trip number (1 or 2) is shown in the DIC
display, then press the RESET button. The trip odometer
will now accumulate miles until the next reset.

2-84
Press the GAGE INFO button until the display shows
BATTERY STATE. If the voltage is normal the display
will show BATTERY STATE NORMAL. If the voltage
drops below 10.5 volts, the display will show BATTERY
STATE LOW. If the voltage is above 16.2 volts, the
display will show BATTERY STATE HIGH. If the display
shows the high or low message, you need to have your
battery and charging system checked.
Press the GAGE INFO button until OIL LIFE INDEX
appears in the display. The OIL LIFE INDEX
NORMAL display will show an estimate of the oil's
remaining useful life. When the oil life index is less than
10 percent, the display will show OIL LIFE INDEX
CHANGE OIL. When you have the oil changed
according to the maintenance schedule (see
ªMaintenance Scheduleº in the Index), you will have to
reset the oil life monitor. To reset the Oil Life System
(Index), see ªOil Life Systemº or ªEngine Oil, When to
Changeº in the Index.
Press the GAGE INFO button until TIRE PRESSURE
appears in the display. TIRE PRESSURE NORMAL is
displayed when the check tire pressure system believes
your vehicle's tire pressures are normal. If a potential
tire pressure problem is detected, the display will show
CHECK TIRE PRESSURE.If you see the CHECK TIRE PRESSURE message, you
should stop as soon as you can and check all your tires
for damage. (If a tire is flat, see ªIf a Tire Goes Flatº in
the Index.) Also check the tire pressure in all four tires
as soon as you can. See ªInflation
-- Tire Pressureº
and ªCheck Tire Pressure Systemº in the Index.
There are times when you will have to reset (calibrate)
the Check Tire Pressure System. See ªCheck Tire
Pressure Systemº in the Index.
RESET: This button, used along with other buttons, will
reset system functions.
ENG/MET (English/Metric): Use this button to change
the display between English and metric units.
DIC messages can be displayed in one of three languages:
English, French or Spanish. The language of the display
is set by holding the FUEL INFO and RESET buttons
together for five seconds. As the buttons are held, each
language will be displayed for three seconds. Release the
FUEL INFO and RESET buttons when the desired
language is displayed. All DIC messages will now be in
the selected language. Language selection can also be
done through the DIC Personal Choice Programming. See
ªDIC Personal Choice Programmingº later in this section.
