2-85 DIC Warnings and Messages
Other messages or warnings may appear in the DIC
display. For Canadian drivers, in addition to the DIC
message your DIC will display EXP with a number after
it which reflects the following messages:
EXP (Export ID) Warning Message
20 TURN SIGNAL STILL ON?. . . . . . . . . . . . . . . .
24 TRUNK AJAR. . . . . . . . . . . . . . . . . . . . . . . . . . .
25 WINDSHIELD WASHER FLUID LOW. . . . . . .
27 BATTERY SAVER ACTIVE. . . . . . . . . . . . . . . .
36 ENGINE OIL LOW
- CHECK LEVEL . . . . . . . .
40 THEFT ATTEMPT DETECTED. . . . . . . . . . . . .
54 SERVICE STABILITY SYSTEM. . . . . . . . . . . .
55 STABILITY SYSTEM ACTIVE. . . . . . . . . . . . .
61 GAS CAP LOOSE
- CHECK CAP . . . . . . . . . . .
81 CHANGE ENGINE OIL SOON. . . . . . . . . . . . .
91 TRACTION CONTROL SYSTEM ACTIVE. . .
102 CHECK CHARGE SYSTEM. . . . . . . . . . . . . . .
139 DOOR AJAR. . . . . . . . . . . . . . . . . . . . . . . . . . .
144 CHECK TIRE PRESSURES. . . . . . . . . . . . . . . The EXP codes are used to make translation from
English to other languages easier.
Pressing any of the DIC control buttons will remove
the messages or warnings from the DIC display.
SERVICE STABILITY SYSTEM
- 54 : If you ever
see the SERVICE STABILITY SYSTEM message,
it means there may be a problem with your stability
enhancement system. If you see this message, try to
reset the system (stop; turn off the engine; then start the
engine again). If the SERVICE STABILITY SYSTEM
message still comes on, it means there is a problem.
You should see your dealer for service. Reduce your
speed and drive accordingly.
STABILITY SYSTEM ACTIVE
- 55 : You may see
the STABILITY SYSTEM ACTIVE message on the
Driver Information Center. It means that an advanced,
computer
-controlled system has come on to help your
vehicle continue to go in the direction in which you're
steering. This stability enhancement system activates
when the computer senses that your vehicle is just
starting to spin, as it might if you hit a patch of ice or
other slippery spot on the road. When the system is on,
you may hear a noise or feel a vibration in the brake
pedal. This is normal.

2-86
When the STABILITY SYSTEM ACTIVE message is
on, you should continue to steer in the direction you
want to go. The system is designed to help you in bad
weather or other difficult driving situations by making
the most of whatever road conditions will permit. If the
STABILITY SYSTEM ACTIVE message comes on,
you'll know that something has caused your vehicle to
start to spin, so you should consider slowing down.
DIC Personal Choice Programming
The DIC can be used to program the following personal
choice features available with your vehicle:

Automatic Door Locks

Window Lockout

Security Feedback

Delayed Locking

Perimeter Lighting

Memory Seats (If Equipped)

Tilt Mirrors (If Equipped)

Driver ID ON/OFF

Language SelectionFor vehicles not equipped with a DIC, see ªPersonal
Choice Programmingº in the Index.
The personal choice settings displayed on the DIC are
determined by the transmitter used to enter the vehicle.
Each remote keyless entry transmitter was
pre
-programmed to belong to DRIVER 1 or DRIVER 2
and is numbered on the back. After the button with the
unlock symbol on a remote keyless entry transmitter is
pressed and the ignition is in RUN, the DIC will display
the identified driver and recall the settings previously
programmed for that driver. The settings can also be
recalled by briefly pressing one of the MEMORY
buttons located on the driver's door.
If you unlock the vehicle using your door key instead of
your transmitter, the DIC will not change drivers and
will recall the information from the last transmitter used
or the last driver using the memory seat controls. If this
happens and you were not the last driver of the vehicle,
simply press your correct driver number on the memory
seat controls or press the button with the unlock symbol
on your remote keyless entry transmitter.

3-2
Comfort Controls
This section describes how to operate your climate
control system. With this system, you can control the
heating, cooling and ventilation in your vehicle.
Your vehicle also has a flow
-through ventilation system
described later in this section.
Electronic Touch Climate Control
Fan Lever
The FAN lever is used to select the speed of the fan.
Moving the lever between LOW and HIGH will
decrease or increase the fan speed. The fan will be
off when the system is off.Temperature Lever
This lever is used to adjust the temperature of the air
coming through the system. Move the TEMPERATURE
lever between COOL and WARM to change the
temperature of the air coming through your outlets.
Mode Controls
The buttons on your system allow you to choose settings
to deliver air through the floor ducts, instrument panel
outlets or windshield outlets.
RECIRC (Recirculation): Press this button to limit the
amount of outside air entering your vehicle. This is
helpful when you are trying to cool the interior of the
vehicle quickly, or limit the amount of outside air
entering your vehicle. To turn off RECIRC, press the
button again. If you select FRONT defrost or BLEND
while RECIRC is selected, the system will automatically
turn off RECIRC to prevent fogging. If you select
RECIRC while in FRONT defrost, the RECIRC light
will flash three times to let you know this is not allowed.

3-7
Sun and temperature sensors automatically adjust the air
temperature, the airflow direction and the fan speed to
maintain your temperature setting. The system may
supply cooler air to the side of the vehicle toward the
sun. Be careful not to put anything over the sensor on
top of the dash.
The display will show fan speed, temperature level
setting and airflow direction for a few seconds whenever
AUTO is selected, and then it will display the outside
temperature. The outside temperature reading is most
accurate when the vehicle is moving. During stops, the
display shows the previous temperature for best
accuracy and system control.
To find your preferred temperature setting, start with the
system in AUTO mode and the TEMP button adjusted
to 75
F (24
C), give the vehicle about 20 minutes to
stabilize, and adjust your temperature setting if
necessary, by using the TEMP button. The display will
show the temperature setting for a few seconds and then
it will display the outside temperature. If you want to
see your current automatic fan speed, airflow direction
and temperature setting, press the AUTO button.In cold weather, the system will delay turning on the fan,
to avoid blowing cold air. During this delay the system
will be in FRONT defrost mode and the light in the button
will come on and stay on as long as the display is showing
the current mode, set TEMP and FAN speed. This light
will go off when the display returns to the outside
temperature. The length of the delay depends on the
engine coolant temperature and the outside temperature.
Pushing the FAN, AIR FLOW or FRONT buttons will
override this delay, turn off the AUTO setting and return
the system to manual operation.
Personal Choice Comfort Controls
(If Equipped)
This feature enables up to two drivers to store and recall
comfort control settings for the temperature, fan speed
and the direction of the airflow.
The memory buttons (1 or 2) for this feature are located
on the driver's door panel and correspond to the
numbers (1 or 2) found on the back of each keyless
entry transmitter.
To recall comfort settings, press the unlock button on the
remote keyless entry transmitter and put the ignition in
ACCESSORY or RUN. The climate control setting last
chosen by the identified driver (1 or 2) will be recalled.

3-8
To program a personal choice climate control setting,
do the following:
1. Choose a temperature setting for the driver and if
desired, for the passenger. See ªDual Automatic
ComforTemp

Climate Controlº and ªPassenger
Climate Controlº earlier in this section.
2. Adjust the fan speed and the direction of the airflow.
3. Locate the memory buttons on the driver's
door panel.
4. Press a memory button (1 or 2) until you hear two
beeps. The beeps confirm that your selection has
been saved and can now be recalled.
Follow these steps each time you want to change the
stored settings. For more information on the memory
feature, see ªMemory Seat and Mirrorsº in the Index.
Air Conditioning
On hot days, open the windows long enough to let hot
inside air escape. This reduces the time it takes for your
vehicle to cool down. Then keep your windows closed
for the air conditioner to work its best.
If you have the electronic touch system, for quick
cool
-down on very hot days, use maximum air
conditioning with the temperature and fan speed
adjusted to COOL and HIGH. If this setting is used
for long periods of time, the air in your vehicle may
become too cold and dry.
For normal cooling on hot days, use Normal and
adjust the temperature and fan speed for your comfort.
If Recirculation is selected while in the Normal air
conditioning mode, the system works like maximum
air conditioning and recirculates the air.

3-9
On sunny days, when the air is moderately warm or
cool, use Bi
-Level to deliver warm air to the floor ducts
and cooler air to the instrument panel outlets. On days
like these, the sun may adequately warm your upper
body, but your lower body may not be warm enough.
To warm or cool the air delivered, adjust the
TEMPERATURE lever.
The amount of fresh air entering the vehicle is limited
when Recirculation is selected. This is helpful when you
are trying to cool the air in your vehicle or limit the air
entering the vehicle.
If your vehicle has the Dual Automatic ComforTemp
system and it is set for Automatic Operation, on very hot
days, the system will automatically enter recirculation
mode and the temperature door will be positioned at the
full cold position for maximum cooling. If the system is
not in the automatic mode, recirculation should be
selected to provide maximum cooling. You can choose
the extreme comfort setting of 60
F (16
C), but the
system will not cool any faster as a result.Heating
If your vehicle has the electronic touch system, on cold
days, use HTR with the TEMPERATURE lever toward
WARM and the fan speed toward HIGH.
If your vehicle has the Dual Automatic ComforTemp
system, and on cold days, if the automatic mode is
selected, the system will automatically direct the air
toward the floor and the temperature door will be
positioned at the full hot position. You can choose the
extreme comfort setting of 90
F (32
C) but the
system will not warm up any faster as a result. If the
outside temperature is cold, the fan will be delayed to
avoid blowing cold air. Pushing the FAN, AIR FLOW
or FRONT buttons will override this delay, turn off
the automatic mode and return the system to
manual operation.
With each system, outside air will be brought in and sent
through the floor ducts. The heater works best if you
keep your windows closed while using it.

3-12
Ventilation Tips

Keep the hood and front air inlet free of ice, snow or
any other obstruction such as leaves. The heater and
defroster will work better, reducing the chance of
fogging your windows.

Keep the air path under the front seats clear
of objects. This helps air to circulate throughout
your vehicle.

When the engine idles for a long time, the exterior
temperature sensor may cause the system to blow air
that is too cool. Once the vehicle is moving again,
the system will try to maintain the set temperature
inside your vehicle.

When you start your vehicle and the EXT display
flashes (Dual Automatic ComforTemp system only)
for some time, the system may need repair. See
your dealer.Steering Wheel Controls for Climate
Control (If Equipped)
If your vehicle has this feature, you can control the
temperature function by using the buttons located on
your steering wheel.
Press the TEMP
(Temperature) up arrow
to increase the temperature
and the TEMP
(Temperature) down
arrow to decrease
the temperature.

3-14
Finding a Station
AM FM: Press this button to switch between AM, FM1
and FM2. The display shows your selection.
TUNE: Turn this knob clockwise to tune to the next station.
Turn it counterclockwise to tune to the previous station.
SEEK : Press the right or left arrow to go to the
next or previous station and stay there. The sound will
mute while seeking. The radio will seek to stations with
a strong signal only.
To scan stations, press and hold one of the SEEK arrows
for two seconds and SCN will appear on the display.
The radio will go to a station, play for a few seconds,
then go on to the next station. Press one of the SEEK
arrows again to stop scanning. The sound will mute
while scanning. The radio will seek to stations with a
strong signal only.
To scan preset stations, press and hold one of the SEEK
arrows for more than four seconds until PSCAN and the
preset number appear on the display. You will hear a double
beep. The radio will go to the first preset station stored
on your pushbuttons, play for a few seconds, then go on to
the next preset station. Preset scan will only scan the
six presets that are in the band selected. Press one of the
SEEK arrows again to stop scanning your preset stations.
The radio will seek to stations with a strong signal only.Setting Preset Stations
The six numbered pushbuttons let you return to
your favorite stations. You can set up to 18 stations
(six AM, six FM1 and six FM2) by performing the
following steps:
1. Turn the radio on.
2. Press AM FM to select AM, FM1 or FM2.
3. Tune in the desired station.
4. Press EQ to select the EQ setting. It will be stored
with the preset station.
5. Press and hold one of the six numbered pushbuttons.
When you hear the radio produce one beep, release
the pushbutton. Whenever you press that numbered
pushbutton, the station you set will return.
6. Repeat the steps for each pushbutton.

3-20
To scan preset stations, press and hold one of the SEEK
arrows for more than four seconds until PSCAN and the
preset number appear on the display. You will hear a double
beep. The radio will go to the first preset station stored on
your pushbuttons, play for a few seconds, then go on to
the next preset station. Preset scan will only scan the six
presets that are in the band selected. Press one of the SEEK
arrows again to stop scanning your preset stations. The
radio will seek to stations with a strong signal only.
Setting Preset Stations
The six numbered pushbuttons let you return to your
favorite stations. You can set up to 18 stations (six AM,
six FM1 and six FM2) by performing the following steps:
1. Turn the radio on.
2. Press AM FM to select AM, FM1 or FM2.
3. Tune in the desired station.
4. Press EQ to select the EQ setting. It will be stored
with the preset station.
5. Press and hold one of the six numbered pushbuttons.
When you hear the radio produce one beep, release
the pushbutton. Whenever you press that numbered
pushbutton, the station you set will return.
6. Repeat the steps for each pushbutton.Setting the Tone (Bass/Treble)
AUDIO: Push and release AUDIO until BASS appears
on the display. Then turn the AUDIO knob clockwise to
increase bass. BASS and a positive number will appear
on the display. Turn the AUDIO knob counterclockwise
to decrease bass. BASS and a negative number will
appear on the display. BASS and a zero will appear on
the display when the bass level is set to the middle
position. Stop turning the knob when you find the bass
level you want or when the maximum or minimum level
is reached.
Push and release AUDIO until MID appears on the
display. Then turn the AUDIO knob clockwise to
increase treble. MID and a positive number will appear on
the display. Turn the AUDIO knob counterclockwise to
decrease treble. MID and a negative number will appear
on the display. MID and a zero will appear on the display
when the treble level is set to the middle position. Stop
turning the knob when you find the treble level you want
or when the maximum or minimum level is reached.

3-23
Finding a PTY Station
P
-TYP (Program Type): This button is used to turn
on and off Program Type (PTY) select. The P
-TYPE
symbol will appear on the display and the SELECT
LED indicator next to the P
-TYP button will light.
The last selected PTY will appear on the display for five
seconds. Turn the AUDIO knob to select the PTY you
want to listen to. Press the SEEK arrows to find radio
stations of the PTY you want to listen to. The last
PTY selected will be used for seek. If a station with the
selected PTY is not found, NOT FOUND will appear on
the display. If both P
-TYP and TRAF are on, the radio
will search for stations with traffic announcements and
the selected PTY.
To use the PTY interrupt feature, press and hold this
button until you hear a beep on the PTY you want to
interrupt. An asterisk will appear next to the PTY name,
example (CLASSICAL*). When you are listening to a
CD, the last selected RDS FM station will interrupt play
if that selected PTY format is broadcast.AM FM (Alternate Frequency): Alternate frequency
allows the radio to switch to a stronger station with the
same program type. Press and hold AM FM for two
seconds to turn alternate frequency on. AF ON will appear
on the display. The radio may switch to stronger stations.
Press and hold AM FM again for two seconds to turn
alternate frequency off. AF OFF will appear on the
display. The radio will not switch to other stations. When
you turn the ignition off and then on again, the alternate
frequency feature will automatically be turned on.
Setting PTY Preset Stations
The six numbered pushbuttons let you return to your
favorite Program Types (PTYs). These pushbuttons have
factory PTY presets. You can set up to 12 PTYs (six FM1
and six FM2) by performing the following steps:
1. Press AM FM to select FM1 or FM2.
2. Press P
-TYP to activate program type mode.
3. Turn the AUDIO knob to select a PTY.
4. Press and hold one of the six numbered pushbuttons
until you hear a beep. Whenever you press that
numbered pushbutton, the PTY you set will return.
5. Repeat the steps for each pushbutton.
