key BUICK RANDEZVOUS 2005 User Guide

Remote Keyless Entry System
Operation
With this feature, you can
lock and unlock your doors
from about 3 feet (1 m)
up to 30 feet (9 m)
away using the remote
keyless entry transmitter
supplied with your vehicle.
UNLOCK:Press UNLOCK to unlock only the driver’s
door. If you press UNLOCK again within ve seconds,
the passengers’ doors and the liftgate will unlock.
See “Liftgate Release” underLiftgate on page 2-11for
more information.
The UNLOCK button on the remote keyless entry
transmitter will disarm the content theft-deterrent system.
SeeContent Theft-Deterrent on page 2-15for more
information.If you would like to program the way the headlamps and
parking lamps operate with remote unlock conrmation,
and your vehicle is equipped with the Driver Information
Center (DIC), seeDIC Vehicle Personalization on
page 3-66.
LOCK:To lock all doors, press LOCK.
The LOCK button on the remote keyless entry
transmitter will arm the content theft-deterrent system.
SeeContent Theft-Deterrent on page 2-15for more
information.
If you would like to program the way the headlamps,
parking lamps, horn, and radio operate with remote lock
conrmation, and your vehicle is equipped with the
Driver Information Center (DIC), seeDIC Vehicle
Personalization on page 3-66.
REAR:To unlock the liftgate, press REAR. SeeLiftgate
on page 2-11for more information.
L(Remote Alarm):Press the button with the horn
symbol to make the headlamps and parking lamps ash
and the horn sound. This will allow you to attract
attention, if needed. Press the button with the horn
symbol again to stop the alarm from sounding, or the
alarm will turn off after 90 seconds.
2-6

Matching Transmitter(s) to Your Vehicle
Each remote keyless entry transmitter is coded to prevent
another transmitter from unlocking your vehicle. If a
transmitter is lost or stolen, a replacement can be
purchased through your dealer. Remember to bring any
remaining transmitters with you when you go to your
dealer. When the dealer matches the replacement
transmitter to your vehicle, any remaining transmitters
must also be matched. Once your dealer has coded the
new transmitter, the lost transmitter will not unlock your
vehicle. Each vehicle can have a maximum of four
transmitters matched to it.
See your dealer to match transmitters to another vehicle.
Battery Replacement
Under normal use, the battery in your remote keyless
entry transmitter should last about three years.You can tell the battery is weak if the KEY FOB
BATTERY LOW message appears in the message
center. If you get this message, the battery in the key
fob needs to be replaced.
Notice:When replacing the battery, use care not to
touch any of the circuitry. Static from your body
transferred to these surfaces may damage the
transmitter.
1. Insert a at object, such as a coin, into the slot on
the side of the transmitter and twist to separate the
halves.
2. Gently pry the battery out of the transmitter. Do not
use the metal anges to remove the battery.
3. Replace the battery.
4. Reassemble the transmitter. Make sure the halves
are snapped together tightly so water will not get in.
5. Press and hold the LOCK and UNLOCK buttons for
seven seconds to synchronize the transmitter.
6. Check the transmitter operation.
United States
Canada
2-7

Doors and Locks
Door Locks
{CAUTION:
Unlocked doors can be dangerous.
Passengers — especially children — can
easily open the doors and fall out of a
moving vehicle. When a door is locked, the
handle will not open it. You increase the
chance of being thrown out of the vehicle
in a crash if the doors are not locked. So,
wear safety belts properly and lock the
doors whenever you drive.
Young children who get into unlocked
vehicles may be unable to get out. A child
can be overcome by extreme heat and can
suffer permanent injuries or even death
from heat stroke. Always lock your vehicle
whenever you leave it.
Outsiders can easily enter through an
unlocked door when you slow down or
stop your vehicle. Locking your doors can
help prevent this from happening.There are several ways to lock and unlock your vehicle.
From the outside, use your key or the remote keyless
entry transmitter.
To unlock the driver’s door from the outside with the
key, insert the key and turn it toward the front of
the vehicle. To lock the driver’s door from the outside
with your key, insert the key and turn it toward the rear
of the vehicle.
To unlock either manual
locking front door from the
inside, pull back on the
manual lever. To lock
either front door from the
inside, push the manual
lever forward.
2-8

Power Door Locks
The power door lock switch
is located on the driver’s
and front passenger’s
doors next to the door
handle.
Press the front of the switch to lock all doors, or press
the back of the switch to unlock all doors.
The rear doors do not have power door lock switches.
Instead, each rear door has a manual lever that
works only that door’s lock.
If your vehicle has the content theft-deterrent system,
the power door lock switch may cause the system
to arm. SeeContent Theft-Deterrent on page 2-15for
more information.
Delayed Locking
With the delayed locking feature, the doors will not lock
immediately when locking the doors using the power door
lock switch or when LOCK on the remote keyless entry
transmitter is pressed while any door is open. Instead,
three chimes will be heard to indicate that the delayed
locking feature is in operation. Five seconds after all
doors are closed, the doors will lock automatically.
If the ignition is in ON or ACCESSORY, this feature will
not lock the doors.
If your vehicle is equipped with the Driver Information
Center (DIC), seeDIC Vehicle Personalization on
page 3-66to program the delayed locking feature.
2-9

Programmable Automatic Door
Locks
All of the doors will automatically lock when all doors
are closed, the engine is running and the shift lever
is shifted out of PARK (P). All of the doors will
automatically unlock when the shift lever is shifted into
PARK (P).
With the automatic door lock feature, you can still lock
or unlock the doors at any time, either manually, with the
power door lock switches or by pressing LOCK on the
remote keyless entry transmitter. SeeRemote Keyless
Entry System Operation on page 2-6for more
information.
If your vehicle is equipped with the Driver Information
Center (DIC), seeDIC Vehicle Personalization on
page 3-66to program the automatic door lock feature.
Rear Door Security Locks
Your vehicle is equipped with rear door security locks
that help prevent passengers from opening the rear
doors on your vehicle from the inside. To use one
of these locks do the following:
1. Open one of the rear doors.2. On the inside of the rear
door will be a lock.
Push the lever up to
engage the safety lock.
3. Close the door.
4. Repeat Steps 1 through 3 for the other rear
door lock.
The rear doors on your vehicle cannot be opened from
inside the vehicle when this feature is in use. If you
want to open the rear door when the security lock is on,
unlock the door from the inside and then open the
door from the outside.
2-10

Canceling the Rear Door Security
Locks
1. Unlock and open the rear door from the outside.
2. Push the lever down to disengage the safety lock.
3. Close the door.
4. Repeat Steps 1 through 3 for the other rear
door lock.
The rear door locks will now work normally.
Lockout Protection
The lockout protection feature may prevent you from
locking your key in your vehicle. Pressing the power
door lock switch will lock all doors, then unlock
the driver’s door, if the key is in the ignition when a door
is opened.
If you leave the key in your vehicle but not in the
ignition or if you use the manual door lock, you could
still lock the key in the vehicle. Always remember to take
the key with you.
Liftgate
{CAUTION:
It can be dangerous to drive with the liftgate
open because carbon monoxide (CO) gas can
come into your vehicle. You can’t see or smell
CO. It can cause unconsciousness and even
death. If you must drive with the liftgate open
or if electrical wiring or other cable
connections must pass through the seal
between the body and the liftgate:
Make sure all other windows are shut.
Turn the fan on your heating or cooling
system to its highest speed and select the
control setting that will force outside air
into your vehicle. SeeClimate Control
System on page 3-28.
If you have air outlets on or under the
instrument panel, open them all the way.
SeeEngine Exhaust on page 2-29.
2-11

Liftgate Release
Your vehicle is equipped with a liftgate release touchpad,
located on the inner side of the liftgate handle.To open the liftgate using the touchpad, do the following:
1. Put the vehicle in PARK (P).
2. Unlock all of the doors.
3. Lift up on the liftgate handle.
If your vehicle has a remote keyless entry transmitter,
you may unlock the liftgate by pressing the REAR button
on the transmitter, then open the liftgate manually by
lifting up on the liftgate handle. Pressing REAR while the
Content Theft-Deterrent is active allows you to open
the liftgate while all other doors remain locked.
SeeContent Theft-Deterrent on page 2-15
Liftgate Handle
2-12

Once armed, the alarm will go off if someone tries to
enter the vehicle without using the optional remote
keyless entry transmitter or the key, or tries to turn the
ignition on without using the correct key. The horn
will sound and the headlamps and parking lamps will
ash any time the alarm sounds.
When the content theft-deterrent system is armed, the
liftgate may be opened by pressing the REAR button on
the remote keyless entry transmitter. The alarm will
go into standby mode. Once the liftgate is closed, the
alarm will be armed. See “Liftgate Release” under
Liftgate on page 2-11for more information on how to
open the liftgate.
Arming with the Power Lock Switch
The content theft-deterrent alarm system will arm when
you use either power door lock switch to lock the doors
while any door or the liftgate is open and the key is
removed from the ignition. The security light, located on
top of the instrument panel, will start ashing when the
system is armed.
Within ve seconds, after the security light begins to
ash, any door can be manually unlocked and opened,
without sounding the alarm. A door unlocked manually
will remain unlocked until locked again.
Arming with the Remote Keyless Entry
Transmitter
Your alarm system will arm when you press LOCK once
on your remote keyless entry transmitter to lock the
doors. The alarm system light will come on for
30 seconds and then start ashing to let you know the
system is armed.
Within the 30 second delay after the security light
comes on, and an additional ve seconds after the light
begins to ash, any door can be manually unlocked
and opened, without sounding the alarm.
If LOCK is pressed on your remote keyless entry
transmitter twice within ve seconds, any door can be
manually unlocked and opened within ve seconds after
the security light begins to ash, without sounding the
alarm. A door unlocked manually will remain unlocked
until locked again.
2-16

Disarming with Your Key
Your alarm system will disarm when you use your key
to unlock the driver’s door. The security light will
stop ashing to let you know the system is no longer
armed.
Disarming with the Remote Keyless
Entry Transmitter
Your alarm system will disarm when you press UNLOCK
on your remote keyless entry transmitter to unlock the
doors. The security light, on top of the instrument panel,
will stop ashing to let you know the system is no
longer armed.
PASS-Key®III
Your PASS-Key®III system operates on a radio
frequency subject to Federal Communications
Commission (FCC) Rules and with Industry Canada.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received,
including interference that may cause undesired
operation.
This device complies with RSS-210 of Industry Canada.
Operation is subject to the following two conditions:
1. This device may not cause interference.
2. This device must accept any interference received,
including interference that may cause undesired
operation of the device.
Changes or modications to this system by other than
an authorized service facility could void authorization to
use this equipment.
PASS-Key
®III uses a radio frequency transponder in
the key that matches a decoder in your vehicle.
2-17

PASS-Key®III Operation
Your vehicle is equipped
with the PASS-Key®III
(Personalized Automotive
Security System)
theft-deterrent system.
PASS-Key
®III is a passive
theft deterrent system.
This means you don’t have
to do anything different
to arm or disarm the
system. It works when you
insert or remove the key
from the ignition.
When the PASS-Key
®III system senses that someone
is using the wrong key, it shuts down the vehicle’s
starter and fuel systems. The starter will not work and
fuel will stop being delivered to the engine. Anyone
using a trial-and-error method to start the vehicle will be
discouraged because of the high number of electrical
key codes.
If the SECURITY message is shown on the Message
Center when trying to start the vehicle, the key may
have a damaged transponder. SeePASS-Key
®
III Security Message on page 3-57. Turn the ignition off
and try to start the vehicle again.If the engine still does not start, and the key appears to be
undamaged, try another ignition key. At this time, you
may also want to check the fuse. SeeFuses and Circuit
Breakers on page 5-105. If the engine still does not start
with the other key, your vehicle needs service. If your
vehicle does start, the rst key may be faulty. See your
dealer who can service the PASS-Key
®III to have a new
key made.
It is possible for the PASS-Key
®III decoder to program
the transponder value of a new or replacement key. Up to
10 additional keys may be programmed for the vehicle.
This procedure is for programming additional keys only. If
all the currently programmed keys are lost or do not
operate, you must see your dealer or a locksmith who can
service PASS-Key
®III to have keys made and
programmed to the system.
See your dealer who can service PASS-Key
®III to get a
new key blank that is a cut exactly as the ignition key
that operates the system.
Canadian Owners:If you lose or damage your keys,
only a GM dealer can service PASS-Key
®III to
have new keys made. To program additional keys you
will need two current driver’s keys (black in color).
You must add a step to the following procedure. After
Step 3 repeat Steps 1 through 3 with the second current
driver’s key. Then continue with Step 4.
2-18
