BUICK RANDEZVOUS 2005 Owner's Manual

{CAUTION:
Getting under a vehicle when it is jacked up is
dangerous. If the vehicle slips off the jack you
could be badly injured or killed. Never get
under a vehicle when it is supported only
by a jack.
{CAUTION:
Raising your vehicle with the jack improperly
positioned can damage the vehicle and even
make the vehicle fall. To help avoid personal
injury and vehicle damage, be sure to t the
jack lift head into the proper location before
raising the vehicle.4. Attach the folding
wrench to the jack, and
turn the wrench
clockwise to raise the
jack head 3 inches
(7.6 cm).
5. Raise the vehicle by turning the folding wrench
clockwise in the jack. Raise the vehicle far
enough off the ground so that there is enough room
for the spare tire to t under the wheel well.
6. Remove all the wheel nuts and take off the at tire.
5-81

{CAUTION:
Rust or dirt on the wheel, or on the parts to
which it is fastened, can make the wheel nuts
become loose after a time. The wheel could
come off and cause an accident. When you
change a wheel, remove any rust or dirt from
the places where the wheel attaches to the
vehicle. In an emergency, you can use a cloth
or a paper towel to do this; but be sure to use
a scraper or wire brush later, if you need to, to
get all the rust or dirt off.
{CAUTION:
Never use oil or grease on studs or nuts. If
you do, the nuts might come loose. Your wheel
could fall off, causing a serious accident.
7. Remove any rust or dirt
from the wheel bolts,
mounting surfaces
and spare wheel.
5-82

8. Lower the vehicle by attaching the folding wrench to
the jack and turning the wrench counterclockwise.
Lower the jack completely.
{CAUTION:
Incorrect wheel nuts or improperly tightened
wheel nuts can cause the wheel to come loose
and even come off. This could lead to an
accident. Be sure to use the correct wheel
nuts. If you have to replace them, be sure to
get new GM original equipment wheel nuts.
Stop somewhere as soon as you can and have
the nuts tightened with a torque wrench to the
proper torque specication. SeeCapacities
and Specifications on page 5-112for wheel nut
torque specication.
Notice:Improperly tightened wheel nuts can lead
to brake pulsation and rotor damage. To avoid
expensive brake repairs, evenly tighten the wheel
nuts in the proper sequence and to the proper
torque specication. SeeCapacities and
Specifications on page 5-112for the wheel nut
torque specication.
5-83

9. Tighten the wheel nuts
rmly in a crisscross
sequence, as shown.
Notice:Wheel covers will not t on your compact
spare. If you try to put a wheel cover on the compact
spare, you could damage the cover or the spare.
10. Do not try to put a wheel cover on the compact
spare tire. It will not t. Store the wheel cover
securely in the rear of the vehicle until you have the
at tire repaired or replaced.Secondary Latch System
Your vehicle has an underbody mounted tire hoist
assembly equipped with a secondary latch system. It is
designed to stop the compact spare tire from suddenly
falling off your vehicle if the cable holding the spare
tire is damaged. For the secondary latch to work, the tire
must be stowed with the valve stem pointing down.
SeeStoring a Flat or Spare Tire and Tools on page 5-88
for instructions on storing the spare tire correctly.
{CAUTION:
Before beginning this procedure read all the
instructions. Failure to read and follow the
instructions could damage the hoist assembly
and you and others could get hurt. Read and
follow the instructions listed below.
5-84

To release the spare tire from the secondary latch, do
the following:
{CAUTION:
Someone standing too close during the
procedure could be injured by the jack. If the
spare tire does not slide off the jack
completely, make sure no one is behind you or
on either side of you as you pull the jack out
from the spare.
1. If the cable is not visible, start this procedure at
Step 3.
2. Turn the wrench counterclockwise until
approximately 6 inches (15 cm) of cable is exposed.All-wheel-drive Vehicle shown
5-85

3. Attach the folding wrench to the jack and raise the
jack at least 10 turns.
4. Place the jack under the vehicle, ahead of the rear
bumper. Position the center lift point of the jack
under the center of the spare tire.
5. Turn the folding wrench clockwise to raise the jack
until it lifts the secondary latch spring.
6. Keep raising the jack until the spare tire stops
moving upward and is held rmly in place. This
lets you know that the secondary latch has released
and the spare tire is balancing on the jack.7. Lower the jack by turning the folding wrench
counterclockwise. Keep lowering the jack until
the spare tire slides off the jack. Front-wheel-drive Vehicle shown
5-86

8. Disconnect the wrench from the jack and carefully
remove the jack. Use one hand to push against the
spare tire while rmly pulling the jack out from
under the spare tire with the other hand.9. Tilt the retainer and slip it through the wheel
opening when the spare tire has been completely
lowered.
10. Turn the wrench clockwise to raise the cable back
up if the cable is hanging.
Have the hoist assembly inspected as soon as you can.
You will not be able to store a spare tire using the
hoist assembly until it has been repaired or replaced.
5-87

Storing a Flat or Spare Tire and
Tools
Storing the Flat Tire (Vehicles without
Stowable Seat and without Rear
Convenience Center)
A. D-Ring
B. Wing Nut
C. J-HookD. Valve Stem
E. Full-Size Tire1. Flip up the D-ring located in the rear cargo area.
2. Lay the tire in the rear cargo area of the vehicle with
the valve stem up with the center hole of the tire
over the D-ring.
For vehicles with aluminum wheels, remove the
center cap by tapping the back of the cap with the
folding wrench.
3. Remove the J-hook and the wing nut from the back
of the jack access door. Assemble the wing nut and
the J-hook.
4. Install the wing nut and the J-hook to the D-ring
through the center hole of the tire.
5. Tighten the wing nut to secure the tire to the oor.
Push and pull on the tire to make sure the tire is
secure and does not move.
6. Put back all tools as they were stored in the jack
storage compartment and put the compartment
cover back on.
Slip the tabs on the side of the compartment cover
into the cover opening. Push the cover in place
and push down the tabs on the cover so that it rests
in the groove. This secures the cover in place.
5-88

Storing the Flat Tire (Vehicles with a
Rear Convenience Center)
A. D-Ring
B. Rear Convenience
Center
C. Wing Nut
D. J-HookE. Full-Size Tire
F. Cap on Bottom of
Storage
Compartment
1. Open the center storage compartment door of the
rear convenience center.
2. Remove the cap on the bottom of the storage
compartment and ip the D-ring up.3. Lay the tire on top of the center storage
compartment with the valve stem down. Make sure
you can see the D-ring through the center hole
of the tire.
4. Remove the J-hook and the wing nut from the back
of the jack access door. Assemble the wing nut and
the J-hook.
5. Install the wing nut and the J-hook to the D-ring
through the center hole of the tire.
6. Tighten the wing nut to secure the tire to the oor.
Push and pull on the tire to make sure the tire is
secure and does not move.
7. Put back all tools as they were stored in the jack
storage compartment and put the compartment
cover back on.
Slip the tabs on the side of the compartment cover
into the cover opening. Push the cover in place
and push down the tabs on the cover so that it rests
in the groove. This secures the cover in place.
5-89

Storing the Flat Tire (Vehicles with a
Stowable Seat)
A. Rear Convenience
Center
B. Full-Size Tire
C. D-RingD. Stowable Seat Strap
E. Cargo Net Hook
F. J-Hook
G. Wing Nut
1. If the seatback is not in an upright position, move it
to an upright position.
2. There is a strap attached to each side of the
stowable seat. Hook the straps to the cargo
net hook in the rear of the vehicle.3. Flip the D-ring so it is pointing outward.
4. Open the convenience center cover.
5. Stand the full-size tire up, in the tray against the
back of the seat with the valve stem pointing out.
6. Remove the J-hook and the wing nut from the back
of the jack access door. Assemble the wing nut and
the J-hook.
7. Install the wing nut and the J-hook to the D-ring
through the center hole of the tire.
8. Tighten the wing nut to secure the tire to the
seatback.
Push and pull on the tire to make sure the tire is
secure and does not move.
9. Put back all tools as they were stored in the jack
storage compartment and put the compartment
cover back on.
Slip the tabs on the side of the compartment cover
into the cover opening. Push the cover in place
and push down the tabs on the cover so that it rests
in the groove. This secures the cover in place.
5-90
