light BUICK RANDEZVOUS 2007 Owner's Guide

Gate Operator and Canadian
Programming
Canadian radio-frequency laws require transmitter
signals to time out or quit after several seconds
of transmission. This may not be long enough
for Universal Home Remote to pick up the signal
during programming. Similarly, some U.S. gate
operators are manufactured to time out in
the same manner.
If you live in Canada, or you are having difficulty
programming a gate operator or garage door
opener by using the “Programming Universal
Home Remote” procedures, regardless of where
you live, replace Step 3 under “Programming
Universal Home Remote” with the following:
Continue to press and hold the Universal Home
Remote button while you press and release every
two seconds (cycle) the hand-held transmitter
button until the frequency signal has been
successfully accepted by the Universal Home
Remote. The Universal Home Remote indicator
light will ash slowly at rst and then rapidly.
Proceed with Step 4 under “Programming
Universal Home Remote” to complete.
Using Universal Home Remote
Press and hold the appropriate Universal Home
Remote button for at least half of a second.
The indicator light will come on while the signal is
being transmitted.
Erasing Universal Home Remote
Buttons
To erase programming from the three Universal
Home Remote buttons do the following:
1. Press and hold down the two outside buttons
until the indicator light begins to ash, after
20 seconds. Do not hold the two outside
buttons for longer than 30 seconds.
2. Release both buttons.
The Universal Home Remote is now in the training
(learning) mode and can be programmed at any
time beginning with Step 2 under “Programming
Universal Home Remote” shown earlier in
this section.
Individual buttons cannot be erased, but they can
be reprogrammed. See “Reprogramming a
Single Universal Home Remote Button” following
this section.
157

Reprogramming a Single Universal
Home Remote Button
To program a device to Universal Home Remote
using a Universal Home Remote button
previously trained, follow these steps:
1. Press and hold the desired Universal Home
Remote button. Do not release the button.
2. The indicator light will begin to ash after
20 seconds. While still holding the Universal
Home Remote button, proceed with Step 2
under “Programming Universal Home Remote”
shown earlier in this section.
For additional information on Universal Home
Remote, seeCustomer Assistance Offices
on page 496.
Storage Areas
Glove Box
If the glove box has a lock, put your key into the
lock and turn the key counterclockwise. To
open the glove box, pull the latch release.
The glove box door has a set position that
prevents the door from lowering too far. Open the
glove box until the door is partway open, then
pull the door down if you need it fully opened.
To close the glove box, the door must be pushed up
past the set position. To lock the glove box, put your
key into the lock and turn the key clockwise.
Cupholder(s)
There are two cupholders located in the oor
console.
The cupholders have liners that remove for larger
beverage items. Remove the liners by lifting
them out.
158

Floor Console Storage Area
The oor console storage area contains two
cupholders, an ashtray, and a cellular phone
storage compartment with a cigarette
lighter/accessory power outlet.
Below the oor console storage, there is another
storage area with two integrated convenience nets.
Front Armrest Storage Area
Your vehicle has a front armrest storage
compartment which contains two storage
compartments.
To unlock the front armrest storage compartment,
put your key into the lock and turn the key
counterclockwise. To open the armrest, squeeze
the lever while lifting the top to open it.
To close the armrest, push the lid down until you
hear a click. To lock the armrest, put your key
into the lock and turn the key clockwise.
Rear Storage Area
There are four small storage compartments in the
rear of your vehicle. One is on the passenger’s
side, two are on the driver’s side and one is on the
oor by the tailgate. To remove the covers, lift
up on the tabs. If your vehicle has the 10-speaker
system, the compartment on the passenger’s
side and the long compartment on the driver’s side
will be equipped with speakers.
160

Instrument Panel Overview........................ 174
Hazard Warning Flashers.......................... 176
Other Warning Devices............................. 176
Horn.......................................................... 176
Tilt Wheel.................................................. 177
Turn Signal/Multifunction Lever.................. 177
Turn and Lane-Change Signals................. 178
Headlamp High/Low-Beam Changer.......... 179
Flash-to-Pass............................................ 179
Windshield Wipers..................................... 179
Windshield Washer.................................... 180
Rear Window Wiper/Washer...................... 180
Cruise Control........................................... 181
Exterior Lamps.......................................... 185
Daytime Running Lamps (DRL)................. 186
Automatic Headlamp System..................... 187
Fog Lamps................................................ 187
Interior Lamps........................................... 188
Instrument Panel Brightness...................... 188
Interior Lamps Control............................... 188
Headlamp Exit Delay................................. 189
Entry Lighting............................................ 189
Delayed Lighting........................................ 190
Exit Lighting.............................................. 190
Perimeter Lighting..................................... 191Front Reading Lamps................................ 191
Rear Reading Lamps................................ 191
Cargo Lamp.............................................. 192
Battery Run-Down Protection..................... 192
Instrument Panel Switchbank..................... 192
Head-Up Display (HUD)............................ 193
Ultrasonic Rear Parking Assist (URPA)...... 196
Accessory Power Outlet(s)........................ 199
Ashtray(s) and Cigarette Lighter................ 200
Climate Controls......................................... 200
Climate Control System............................. 200
Dual Climate Control System..................... 203
Dual Automatic Climate Control System.... 206
Outlet Adjustment...................................... 210
Warning Lights, Gages, and Indicators..... 211
Instrument Panel Cluster........................... 212
Speedometer and Odometer...................... 213
Trip Odometer........................................... 213
Tachometer............................................... 214
Safety Belt Reminder Light........................ 215
Airbag Readiness Light............................. 215
Passenger Airbag Status Indicator............. 217
Brake System Warning Light..................... 219
Anti-Lock Brake System Warning Light...... 220
Section 3 Instrument Panel
171

Traction Control System (TCS) Warning
Light...................................................... 220
Engine Coolant Temperature Gage............ 221
Malfunction Indicator Lamp........................ 222
Fuel Gage................................................. 225
Message Center.......................................... 225
Passenger Seatbelt Reminder Message..... 226
Service Traction System Warning
Message................................................ 226
Traction Active Message........................... 227
Engine Coolant Temperature Warning
Message................................................ 227
Charging System Indicator Message.......... 228
Reduced Engine Power Message.............. 228
Low Oil Pressure Message........................ 229
Change Engine Oil Message..................... 230
Door Ajar Warning Message...................... 230
Rear Hatch Ajar Warning Message............ 230
Check Gas Cap Message......................... 231
PASS-Key
®III Security Message............... 231
Low Washer Fluid Warning Message......... 231
Low Fuel Warning Message...................... 232
Low Brake Fluid Warning Message........... 232
Service Vehicle Soon Message................. 233Program Mode Message........................... 233
Remote Keyless Entry Transmitter Battery
Low Warning Message........................... 234
Parking Lamp Warning Message............... 234
Highbeam Out Warning Message.............. 235
Driver Information Center (DIC).................. 235
DIC Controls and Displays........................ 236
DIC Compass............................................ 238
DIC Vehicle Personalization....................... 240
Audio System(s)......................................... 250
Setting the Time........................................ 252
Radio with CD........................................... 252
Radio with Six-Disc CD............................. 262
XM Radio Messages................................. 276
Navigation/Radio System........................... 277
Rear Seat Entertainment System............... 277
Rear Seat Audio (RSA)............................. 293
Theft-Deterrent Feature............................. 296
Audio Steering Wheel Controls.................. 296
Radio Reception........................................ 297
Care of Your CDs and DVDs.................... 298
Care of the CD and DVD Player............... 298
Fixed Mast Antenna.................................. 299
XM™ Satellite Radio Antenna System....... 299
Section 3 Instrument Panel
172

The main components of the instrument panel are the following:
A. Exterior/Interior Lamps Control. SeeExterior
Lamps on page 185andInterior Lamps
on page 188.
B. Turn Signal/Multifunction Lever. SeeTurn
Signal/Multifunction Lever on page 177.
C. Hazard Warning Flasher Button. SeeHazard
Warning Flashers on page 176.
D. Instrument Panel Cluster. SeeInstrument
Panel Cluster on page 212.
E. Shift Lever. SeeAutomatic Transaxle Operation
on page 132.
F. Instrument Panel Outlets. SeeOutlet
Adjustment on page 210.
G. Audio System. SeeAudio System(s) on
page 250.
H. Audio Steering Wheel Controls. SeeAudio
Steering Wheel Controls on page 296.
I. Head-Up Display Switch and Driver Information
Center (DIC) Controls (If Equipped). See
Head-Up Display (HUD) on page 193andDIC
Controls and Displays on page 236.J. Hood Release. SeeHood Release on
page 363.
K. Ignition Switch. SeeIgnition Positions on
page 128.
L. Climate Controls. SeeClimate Control System
on page 200,Dual Climate Control System
on page 203orDual Automatic Climate Control
System on page 206.
M. Instrument Panel Switchbank. SeeInstrument
Panel Switchbank on page 192.
N. Front Armrest Storage. SeeFront Armrest
Storage Area on page 160.
O. Ashtray/Cigarette Lighter/Accessory Power
Outlet/Cell Phone Storage/Cupholders.
SeeAshtray(s) and Cigarette Lighter on
page 200,Accessory Power Outlet(s) on
page 199,Cell Phone Storage Area on
page 159,Floor Console Storage Area on
page 160andCupholder(s) on page 158.
P. Floor Console Fuse Block. SeeFloor Console
Fuse Block on page 463.
Q. Glove Box. SeeGlove Box on page 158.
175

Headlamp High/Low-Beam Changer
To change the headlamps from low to high,
push the turn signal lever away from you, then
release it. To change the headlamps from high to
low, pull the lever toward you.
When the high beams
are on, this light on the
instrument panel
cluster and the HUD
display, if the vehicle
has this, will also be on.
Flash-to-Pass
When the headlamps are off, pull the lever toward
you to momentarily turn on the high beams.
This will signal that you are going to pass. When
you release the lever, they will turn off.
Windshield Wipers
WIPERN:Turn the band marked WIPER to
control the windshield wipers.MIST:For a single wiping cycle, turn the band to
MIST. Hold it there until the wipers start, then let go.
The wipers will stop after one cycle. If you want
more cycles, hold the band on MIST longer.
Delay:For delayed wiping cycles, you can set the
wiper speed for a long or short delay between
wipes. This can be very useful in light rain or snow.
Turn the band to choose the delay time. The
closer to LO, the shorter the delay time.
LO:For steady wiping cycles at low speed, turn
the band away from you to the LO position.
HI:For high-speed wiping, turn the band away
from you to the HI position.
OFF:To stop the wipers, turn the band to OFF.
Remember that damaged wiper blades may
prevent you from seeing well enough to drive
safely. To avoid damage, carefully clear ice and
snow from the wiper blades before using them. If
they are frozen to the windshield, carefully
loosen or thaw them. If your blades do become
damaged, get new blades or blade inserts.
Heavy snow or ice can overload your wipers. A
circuit breaker will stop them until the motor cools.
Clear away snow or ice to prevent an overload.
179

Using Cruise Control on Hills
How well your cruise control will work on hills
depends upon your speed, load and the steepness
of the hills. When going up steep hills, you may
have to step on the accelerator pedal to maintain
your speed. When going downhill, you may
have to brake or shift to a lower gear to keep your
speed down. Of course, applying the brake
takes you out of cruise control. Many drivers nd
this to be too much trouble and do not use
cruise control on steep hills.
Ending Cruise Control
There are two ways to turn off the cruise control:
Step lightly on the brake pedal.
Move the cruise control switch to OFF.
Erasing Speed Memory
When you turn off the cruise control or the
ignition, your cruise control set speed memory is
erased.
Exterior Lamps
The control on the left
side of the steering
column operates
the exterior lamps.
The exterior lamp control has three positions:
AUTO (Automatic Headlamp Control/Off):
Turning the control to this position will activate the
automatic headlamps when it is dark enough
outside and turn off all lamps and lights during the
day except for the Daytime Running Lamps (DRL).
185

<(Parking Lamps):Turning the control to this
position turns on the parking lamps together
with the following:
Taillamps
Instrument Panel Lights
5(Headlamps):Turning the control to this
position turns on the headlamps together with the
previously listed lamps and lights.
Lamps on Reminder
If the driver’s door is opened and you turn the
ignition to OFF while leaving the lamps on, you will
hear a warning chime.
Daytime Running Lamps (DRL)
Daytime Running Lamps (DRL) can make it easier
for others to see the front of your vehicle during
the day. DRL can be helpful in many different
driving conditions, but they can be especially
helpful in the short periods after dawn and before
sunset. Fully functional daytime running lamps
are required on all vehicles rst sold in Canada.A light sensor on top of the instrument panel
makes the DRL work, so be sure it is not covered.
The DRL system will make your reduced
intensity low-beam headlamps come on in daylight
when the following conditions are met:
The ignition is on.
The exterior lamps control is in AUTO.
The shift lever is not in PARK (P).
When the DRL are on, only your reduced intensity
high-beam headlamps will be on. Your instrument
panel will not be lit up.
When it is dark enough outside, the exterior lamps
will come on automatically. When it is bright
enough outside, the exterior lamps will go out and
the DRL will turn on. Of course, you may still
turn on the headlamps any time you need to.
As with any vehicle, you should turn on the regular
headlamp system when you need it.
186

Automatic Headlamp System
When the exterior lamp control is turned to AUTO,
and it is dark enough outside, the headlamps
and parking lamps will, automatically, come on.
The lamps will also come on automatically if
the following conditions are met:
The ignition is in ON.
The parking brake is released.
Fog Lamps
The fog lamp button is
located on the exterior
lamp control.Press the FOG PUSH button to turn the fog lamps
on. The FOG light, located next to the fog lamp
button, will come on to indicate when the fog
lamps are on. To turn off the fog lamps, press the
fog lamp button or turn the ignition off.
If you turn on the fog lamps while the DRL are on,
the parking lamps will turn on automatically.
Your fog lamps will go off when you switch to high
beams. When you return to low beam, the fog
lamps will come back on. Using your high beams
in fog is not recommended.
Some localities have laws that require the
headlamps to be on along with the fog lamps.
187
