Delayed Exit Lighting
This feature illuminates the interior for a period of time
after the ignition key is removed from the ignition.
When the ignition key is removed, interior illumination
will activate and remain on until one of the following
occurs:
The ignition is in RUN.
The power door locks are activated.
Twenty ve seconds has elapsed.
If during the illumination period a door is opened, the
timed illumination period will be canceled and the interior
lamps will remain on.
Perimeter Lighting
Perimeter lighting provides a period of exterior vehicle
lighting. Perimeter lighting activates when the doors
are closed, the ignition is in OFF and the security
feedback feature is activated in Mode 3 or 4. See
“Security Feedback” underRemote Keyless Entry
System Operation on page 2-4for more information.
The vehicle headlamps and back-up lamps are
then activated for a period of 25 seconds or until the
ignition switch is turned to RUN.Perimeter lighting can be turned on or off when the
driver performs the following sequence with the engine
off and the doors closed:
1. Turn the ignition to RUN.
2. Close all the doors.
3. Apply the brake.
4. Press and hold the LOCK position on the power
door lock switch while pressing and releasing the
remote alarm button on the remote keyless
entry transmitter.
This activates the customization mode. While in the
customization mode, the number of chimes
corresponding to the current mode will sound. One
chime means the feature is turned off. Two chimes
mean that the perimeter lighting feature is turned on.
Each additional press of the power door lock switch will
advance to the next mode. Release the LOCK position
on the power door lock switch to set the mode.
Disconnecting the vehicle’s battery for up to a year will
not change the programmed operation for this feature.
Reading Lamps
The reading lamps are located on the underside of the
rearview mirror. Press the button next to each lamp
to turn it on and off.
3-15

Fuses Usage
CRUISE Cruise Control
Blank Not Used
CLSTR Instrument Panel Cluster
LTR Cigarette Lighter
STOP LAMPS Stoplamps
ONSTAR OnStar
®
PRK/LGHT Parking Lamps
Blank Not Used
CRNK SIG,
BCM, CLSTRCrank Signal, Body Control Module,
Cluster, Powertrain Control Module
HVACIgnition Signal, Heating, Ventilation
and Air Conditioning Control Head
BTSI (REGAL) Shifter Lock Solenoid
AIR BAG Air Bag
BCM PWR Body Control Module
HAZRD Hazard Warning Flashers
Fuses Usage
LH HTD SEAT Driver’s Heated Seat
Blank Not Used
BCM ACCYIgnition Signal: Hot in ACCESSORY
and RUN, Body Control Module
Blank Not Used
LOW BLWER Low Blower
ABS Anti-Lock Brakes
TRN SIG Turn Signals, Cornering Lamps
RADIO, HVAC,
RFA, CLSTR
ALDLRadio; Heating Ventilation, and Air
Conditioning Head; Remote Keyless
Entry, Cluster
HI BLWR High Blower
RH HTD SEAT Passenger’s Heated Seat
STR/WHL
CNTRLAudio Steering Wheel Controls
WPR Windshield Wipers
5-100

Underhood Fuse Block
Some fuses and relays are located in the underhood
fuse block on the passenger’s side of the vehicle in the
engine compartment. SeeEngine Compartment
Overview on page 5-12for more information on location.
Fuses Usage
1 Anti-Lock Brake System
2 Starter Solenoid
3Power Seats, Rear Window
Defogger, Heated Seats
4High Blower, Hazard Flasher,
Stoplamps, Power Mirror, Door
Locks
5Ignition Switch, BTS Shifter Lock
Solenoid, Stoplamps, Anti-Lock
Brake System, Turn Signals,
Cluster, Air Bag, Daytime Running
Lamps Module
6 Cooling Fan
7Retained Accessory Power (RAP),
Remote Keyless Entry, Data Link,
Heating, Ventilation and Air
Conditioning Head, Cluster, Radio,
Cigarette Lighter
8Ignition Switch, Windshield Wipers,
Radio, Steering Wheel Controls,
Body Control Module, Power
Windows, Sunroof; Heating,
Ventilation and Air Conditioning
Controls; Daytime Running Lamps,
Rear Window Defogger Relay
5-101

How to Add Fluid............................................5-26
How to Check........................................5-24, 5-69
How to Check and Add Oil...............................5-22
How to Check Power Steering Fluid..................5-41
How to Use This Manual...................................... ii
How to Wear Safety Belts Properly...................1-11
Hydroplaning..................................................4-20
I
If No Steam Is Coming From Your Engine..........5-31
If Steam Is Coming From Your Engine...............5-30
If the Light Is Flashing.....................................3-36
If the Light Is On Steady.................................3-37
If You Are Caught in a Blizzard.........................4-28
If You Are Stuck in Sand, Mud, Ice or Snow.......4-30
If You Do Decide To Pull A Trailer.....................4-40
Ignition Positions.............................................2-18
Illumination on Remote Activation........................ 2-7
Infants and Young Children, Restraints...............1-29
Ination - Tire Pressure...................................5-68
Instrument Panel
Cluster.......................................................3-27
Overview..................................................... 3-2
Instrument Panel Brightness.............................3-14
Instrument Panel Fuse Block............................5-98
Interior Lamps................................................3-14
J
Jump Starting.................................................5-47
K
Keyless Entry System....................................... 2-3
Keys............................................................... 2-2
L
Lamps
Exterior......................................................3-11
Interior.......................................................3-14
Lap Belt........................................................1-20
Lap-Shoulder Belt...................................1-12, 1-22
LATCH System
Child Restraints...........................................1-38
Securing a Child Restraint Designed
for the LATCH System..............................1-40
Leaving Your Vehicle.......................................2-11
Leaving Your Vehicle With the Engine
Running.....................................................2-26
Light
Air Bag Readiness.......................................3-30
Anti-Lock Brake System Warning...................3-32
7

Parking
Brake........................................................2-24
Over Things That Burn.................................2-28
Parking on Hills..............................................4-44
Passenger Compartment
Air Filter.....................................................3-25
Passenger Control..........................................3-23
Passing.................................................4-14, 4-43
PASS-Key
®II .................................................2-16
Perimeter Lighting...........................................3-15
Plan Ahead When Possible................................ 7-8
Playing a Cassette Tape..................................3-57
Playing a CD.........................................3-50, 3-59
Playing the Radio...................................3-45, 3-52
Power
Accessory Outlets........................................3-16
Door Locks.................................................2-10
Electrical System.........................................5-98
Six-Way Seats.............................................. 1-3
Steering Fluid.............................................5-40
Windows....................................................2-15
Power Steering...............................................4-12
Programmable Automatic
Door Locks.................................................2-10
Q
Questions and Answers About Safety Belts.........1-11
R
Radiator Pressure Cap....................................5-29
Radio Data System (RDS).......................3-48, 3-55
Radio Messages.....................................3-50, 3-57
Radios..........................................................3-44
Care of Your Cassette Tape Player................3-63
Care of Your CD Player...............................3-64
Care of Your CDs........................................3-64
Radio with Cassette and CD.........................3-52
Radio with CD............................................3-45
Setting the Time..........................................3-45
Theft-Deterrent............................................3-61
Understanding Reception..............................3-62
RDS Messages......................................3-49, 3-56
Reading Lamps..............................................3-15
Rear Safety Belt Comfort Guides......................1-24
Rear Seat Outside Passenger Positions.............1-21
Rear Seat Passengers, Safety Belts..................1-21
Rear Window Defogger............................3-19, 3-24
Rearview Mirror, Automatic Dimming..................2-32
Rearview Mirror, Automatic Dimming
with OnStar
®..............................................2-32
Rearview Mirror with OnStar®...........................2-31
Rearview Mirrors.............................................2-31
Reclining Seatbacks.......................................... 1-4
Recommended Fluids and Lubricants.................6-12
Recreational Vehicle Towing.............................4-31
Remote Keyless Entry System............................ 2-3
10

Remote Keyless Entry System Operation............. 2-4
Remote Trunk Release....................................2-12
Removing the Flat Tire and Installing
the Spare Tire.............................................5-82
Removing the Spare Tire and Tools...................5-79
Removing the Wheel Center Caps....................5-81
Removing the Wheel Covers............................5-81
Replacement Bulbs.........................................5-59
Replacing Brake System Parts..........................5-46
Replacing Restraint System Parts
After a Crash..............................................1-55
Reporting Safety Defects
Canadian Government..................................7-11
General Motors...........................................7-11
United States Government............................7-10
Restraint System Check
Checking Your Restraint Systems...................1-54
Replacing Restraint System Parts
After a Crash..........................................1-55
Restraint Systems
Checking....................................................1-54
Replacing Parts...........................................1-55
Resynchronization............................................. 2-8
Retained Accessory Power (RAP)......................2-18
Right Front Passenger Position,
Safety Belts................................................1-20
Roadside
Assistance Program....................................... 7-6
Rocking Your Vehicle To Get It Out...................4-31Routing, Engine Drive Belt...............................6-14
Running Your Engine While You Are Parked.......2-30
SSafety Belt
Reminder Light............................................3-29
Safety Belts
Care of......................................................5-92
Center Passenger Position............................1-20
Driver Position............................................1-12
How to Wear Safety Belts Properly................1-11
Questions and Answers About Safety Belts.....1-11
Rear Safety Belt Comfort Guides for
Children and Small Adults.........................1-24
Rear Seat Passengers.................................1-21
Right Front Passenger Position......................1-20
Safety Belt Extender....................................1-26
Safety Belt Use During Pregnancy.................1-19
Safety Belts Are for Everyone......................... 1-6
Safety Chains.................................................4-42
Safety Warnings and Symbols.............................. iii
Scheduled Maintenance..................................... 6-4
Seats
Head Restraints............................................ 1-5
Heated Seats............................................... 1-3
Manual........................................................ 1-2
Reclining Seatbacks...................................... 1-4
Six-Way Power Seats.................................... 1-3
Split Folding Rear Seat.................................. 1-6
11
