A. Vehicle Capacity WeightThe Tire and Loading Information label shows the
seating capacity and the total weight your vehicle can
properly carry. This weight is called the vehicle capacity
weight. If your vehicle has the Tire and Loading
Information label, Example 1, the label is attached to
the center pillar, near the driver’s door latch. If your
vehicle has the Tire-Loading Information label, Example
2, the label is on the inside trunk lid.
The Tire and Loading Information label also gives you
the size and recommended in ation pressure for
the factory-installed, original equipment tires on your
vehicle. For more information on tires and in ation see
Tires on page 5-61andIn ation - Tire Pressure on
page 5-68.
There is also important loading information on the
Certi cation label. It tells you the Gross Vehicle Weight
Rating (GVWR) and the Gross Axle Weight Rating
(GAWR) for the front and rear axle; see “Certi cation
Label” later in this section. Example 2
4-34
