BUICK RIVIERA 1999 Owner's Manual

yellowblue
2-59
Assist Handles
An assist handle above each door can be used to help
you get in or out of your vehicle.
Garment Hooks
Rear garment hooks are available for your convenience.
Garment hooks are not designed to support clothing
bars. Use assist handles for this if possible.
Rear License Plate Holder
To use it, open the trunk lid and slide your license plate
into the slot. Always close the trunk to prevent theft of
the plate.
Astroroof (Option)
If your vehicle has the
astroroof option, the switch
is on the roof between the
sun visors. It will open the
astroroof when the ignition
is on, or when retained
accessory power is active.
To fully open the glass panel and sunshade, press the
switch rearward and release. To stop the panel in a
partially open position, press the switch again at the
desired point. To continue to open fully, press the switch
rearward again and release. The sunshade can be
opened manually.
To close the glass panel, press and hold the switch
forward. The sunshade must be closed manually.
Once the astroroof is closed, it can be opened to a vent
position. Press the switch forward to vent. To close,
press the switch rearward.

yellowblue
2-60
Universal Transmitter (Option)
This transmitter allows you to consolidate the functions
of up to three individual hand
-held transmitters. It will
operate garage doors and gates, or other devices
controlled by radio frequency such as home/office
lighting systems.
The transmitter will learn and transmit the frequencies
of most current transmitters and is powered by your
vehicle's battery and charging system.This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause
undesired operation.
This device complies with RSS
-210 of Industry Canada.
Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this
device must accept any interference, including
interference that may cause undesired operation of
the device.
Changes and modifications to this system by other than
an authorized service facility could void authorization to
use this equipment.
Programming the Universal Transmitter
Do not use the Universal Transmitter with any garage
door opener that does not have the ªstop and reverseº
safety feature. This includes any garage door opener
model manufactured before April 1, 1982.
Be sure that people and objects are clear of the garage
door you are programming.

yellowblue
2-61
Your vehicle's engine should be turned off while
programming the transmitter. Follow these steps to
program up to three channels:
1. If you have previously programmed a transmitter
channel, proceed to Step 2. Otherwise, hold down
the two outside buttons on the Universal Transmitter
until the indicator light begins to flash rapidly (after
20 seconds). Then release the buttons. This
procedure initializes the memory and erases any
previous settings for all three channels.
2. Decide which one of the three channels you want to
program. Hold the end of the hand
-held transmitter
about 2 to 5 inches (5 to 13 cm) away from the
surface of the Universal Transmitter so that you can
still see the indicator light.
3. Using both hands, press the hand
-held transmitter
button and the desired button on the Universal
Transmitter. Continue to press both buttons
through Step 4.
4. Hold down both buttons until you see the indicator
light on the Universal Transmitter flash slowly and
then rapidly. The rapid flashing indicates that the
Universal Transmitter has been programmed.
Release both buttons once the indicator light starts to
flash rapidly.If you have trouble programming the Universal
Transmitter, make sure that you have followed the
directions exactly as described. The Universal
Transmitter may not work with older garage door
openers that do not meet current Federal Consumer
Safety Standards. If you cannot program the transmitter
after repeated attempts, refer to ªRolling Codes
Programmingº later in this section or contact the
Universal Transmitter manufacturer at 1
-800-355-3515.
Be sure to keep the original hand
-held transmitter
in case you need to erase and reprogram the
Universal Transmitter.
Note to Canadian Owners: During programming, the
hand
-held transmitter may automatically stop
transmitting after one or two seconds. In this case, you
should press and re
-press the button on the hand-held
transmitter every two seconds without ever releasing the
button on the Universal Transmitter. Release both
buttons when the indicator light on the Universal
Transmitter begins to flash rapidly.

yellowblue
2-62 Operating the Universal Transmitter
Press and release the appropriate button on the Universal
Transmitter. The indicator light comes on while the
signal is being transmitted.
If the hand
-held transmitter appears to program the
Universal Transmitter but does not open your garage
door, and if the garage door opener was manufactured
after 1996, the garage door opener may have a ªrolling
codeº system. A rolling code system changes the code
of the garage door opener every time you open or close
the garage door.
To determine if you have this system, press the button
on the Universal Transmitter that you have programmed
already. If the indicator light on the Universal
Transmitter flashes rapidly for two seconds and then
turns solid, the garage door opener has a rolling code
system. In a rolling code system, the garage door motor
head unit must be trained to the Universal Transmitter.
ªRolling Codeº Programming (If Equipped)
If you have not previously programmed the hand-held
transmitter to the Universal Transmitter, see
ªProgramming the Universal Transmitterº listed
previously. If you have completed this programming
already, you now need to train the garage door opener
motor head unit to recognize the Universal Transmitter.
Refer to your garage door opener owner's manual for
the proper transmitter training procedure for your garage
door opener brand.
1. Find the training button on the garage door opener
motor head unit. The exact location and color of the
button may vary by garage door opener brand. If you
have difficulty finding the training button, refer to
your garage door opener owner's manual.
2. Press the training button on the garage door opener
motor head unit.
Note: Following this step, you have 30 seconds to
start Step 3.

yellowblue
2-63
3. Return to the Universal Transmitter in your vehicle and
firmly press and release the Universal Transmitter
button you have already programmed for two to three
seconds. Press and release the button again (you may
need to do this step up to three times) to make sure
that the Universal Transmitter has been trained to the
garage door opener motor head unit. Check that the
training was successful.
The garage door opener should now recognize the
Universal Transmitter. You may either use the Universal
Transmitter or the hand
-held transmitter to open the
garage door.
If after following these instructions, you still have
problems training the garage door opener, contact the
Universal Transmitter manufacturer at 1
-800-355-3515.
Erasing Channels
To erase all three programmed channels, hold down the
two outside buttons until the indicator light begins to
flash (after 20 seconds). Release both buttons.
Accessories
Accessories for the Universal Transmitter are available
from the manufacturer of the unit. If you would like
additional information, please call 1
-800-355-3515.

yellowblue
2-64
The Instrument Panel - Your Information System

yellowblue
2-65
The main components of your instrument panel are:
A. Warning Lights
B. Tachometer
C. Fuel Gage
D. Engine Temperature Gage
E. Speedometer
F. Warning Lights
G. Climate Controls
H. Audio System
I. Headlamp/Instrument Panel Intensity
Control/Twilight Sentinel
J. Hood Release
K. Turn Signal/Multifunction LeverL. Steering Wheel Touch Controls for Audio System
M. Tilt Steering Wheel Lever
N. Horn
O. Steering Wheel Touch Controls for Audio/Climate
Control System
P. Traction Control/Trip Reset Button
Q. Ashtray and Cigarette Lighter
R. Dual Cupholder
S. Compact Disc Storage Compartment
T. Gearshift Lever
U. Air Outlets
V. Glove Box

yellowblue
2-66
Instrument Panel Cluster
Your vehicle is equipped with this instrument panel cluster. Your instrument panel cluster is designed to let you know
at a glance how your vehicle is running. It includes indicator warning lights and gages that are explained on the
following pages. You'll know how fast you're going, how much fuel you're using, and many other things you'll need
to know to drive safely and economically.

yellowblue
2-67 Speedometer and Odometer
Your speedometer lets you see your speed in both miles
per hour (mph) and kilometers per hour (km/h). Your
odometer shows how far your vehicle has been driven,
in either miles (used in the United States) or kilometers
(used in Canada).
Trip Odometer
A trip odometer can tell you how many miles you have
driven since you last reset it back to zero.
To reset the trip
odometer, push the
TRIP RESET button.
Tachometer
The tachometer tells you
how fast the engine is
running. It displays engine
speed in revolutions per
minute (rpm).
NOTICE:
Do not operate the engine with the tachometer in
the red area, or engine damage may occur.

yellowblue
2-68
Warning Lights, Gages
and Indicators
This part describes the warning lights and gages that
may be on your vehicle. The pictures will help you
locate them.
Warning lights and gages can signal that something is
wrong before it becomes serious enough to cause an
expensive repair or replacement. Paying attention to
your warning lights and gages could also save you or
others from injury.
Warning lights come on when there may be or is a
problem with one of your vehicle's functions. As you
will see in the details on the next few pages, some
warning lights come on briefly when you start the
engine just to let you know they're working. If you are
familiar with this section, you should not be alarmed
when this happens.
Gages can indicate when there may be or is a problem
with one of your vehicle's functions. Often gages and
warning lights work together to let you know when
there's a problem with your vehicle.When one of the warning lights comes on and stays on
when you are driving, or when one of the gages shows
there may be a problem, check the section that tells you
what to do about it. Please follow this manual's advice.
Waiting to do repairs can be costly
-- and even
dangerous. So please get to know your warning lights
and gages. They're a big help.
Safety Belt Reminder Light
When the key is turned to RUN or START, a chime will
come on for about eight seconds to remind people to
fasten their safety belts.
The safety belt light will
also come on and stay on
for about 70 seconds. If the
driver's belt is already
buckled, neither the chime
nor the light will come on.
