Buick Verano Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9085356) - 2016 - crc - 10/19/15
Driving and Operating 189
{Warning
Turning off the vehicle while
moving may cause loss of power
assist in the brake and steering
systems and disable the airbags.
While driving, only shut the
vehicle off in an emergency.
If the vehicle cannot be pulled over,
and must be shut off while driving,
turn the ignition to ACC/
ACCESSORY.
1 : This position provides power to
some of the electrical accessories.
To move the key from ACC/
ACCESSORY to LOCK/OFF, push
in the key and then turn it to
LOCK/OFF.
2 : The ignition switch stays in this
position when the engine is running.
This position can be used to operate
the electrical accessories, including
the ventilation fan and 12-volt power
outlet, as well as to display some
warning and indicator lights. This
position can also be used for
service and diagnostics, and to verify the proper operation of the
malfunction indicator lamp as may
be required for emission inspection
purposes. The transmission is also
unlocked in this position.
The battery could be drained if the
key is left in the ACC/ACCESSORY
or ON/RUN position with the engine
off. The vehicle might not start if the
battery is allowed to drain for an
extended period of time.
3 :
This position starts the engine.
When the engine starts, release the
key. The ignition switch will return to
ON/RUN for normal driving.
A warning tone sounds when the
driver door is opened if the ignition
is still in ACC/ACCESSORY and the
key is in the ignition.
If the ignition becomes difficult to
turn, see Keys025.
Key Lock Release
The vehicle is equipped with an
electronic key lock release. The key
lock release is designed to prevent
ignition key removal unless the shift
lever is in P (Park). The key lock release is always
functional except in the case of an
uncharged or low voltage (less than
9-volt) battery. If the vehicle has an
uncharged battery or a battery with
low voltage, try charging or jump
starting the battery. See
Jump
Starting - North America 0290.
If charging or jump starting the
battery does not work, locate the
hole below the ignition lock. Insert a
flat bladed tool or another key from
the key chain into the opening.
When the lever can be felt, actuate
the lever toward the driver, and
remove the key from the ignition.

Buick Verano Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9085356) - 2016 - crc - 10/19/15
218 Driving and Operating
vehicle until the fuel is at one-half
tank or less, then refuel with the
current seasonal fuel.
Prohibited Fuels
Gasolines containing oxygenates
such as ethers and ethanol, as well
as reformulated gasolines, are
available in some cities. If these
gasolines comply with the
previously described specification,
then they are acceptable to use.
However, E85 (85% ethanol) and
other fuels containing more than
15% ethanol must be used only in
FlexFuel vehicles.
Caution
Do not use fuel containing
methanol. It can corrode metal
parts in the fuel system and also
damage plastic and rubber parts.
That damage would not be
covered under the vehicle
warranty.
Some gasolines, mainly high octane
racing gasolines, can contain an
octane-enhancing additive called methylcyclopentadienyl manganese
tricarbonyl (MMT). Do not use
gasolines and/or fuel additives with
MMT as they can reduce spark plug
life and affect emission control
system performance. The
malfunction indicator lamp may turn
on. If this occurs, see your dealer
for service.
California Fuel
Requirements
If the vehicle is certified to meet
California Emissions Standards, it is
designed to operate on fuels that
meet California specifications. See
the underhood emission control
label. If this fuel is not available in
states adopting California Emissions
Standards, the vehicle will operate
satisfactorily on fuels meeting
federal specifications, but emission
control system performance might
be affected. The malfunction
indicator lamp could turn on and the
vehicle may not pass a smog-check
test. See
Malfunction Indicator
Lamp (Check Engine Light) 0106.
If this occurs, return to your
authorized dealer for diagnosis. If it is determined that the condition is
caused by the type of fuel used,
repairs may not be covered by the
vehicle warranty.
Fuels in Foreign
Countries
If planning to drive in countries
outside the U.S. or Canada, the
proper fuel might be hard to find.
Check regional auto club or fuel
retail brand websites for availability
in the country where driving. Never
use leaded gasoline, fuel containing
methanol, manganese, or any other
fuel not recommended. Costly
repairs caused by use of improper
fuel would not be covered by the
vehicle warranty.
Fuel Additives
To keep fuel systems clean, TOP
TIER Detergent Gasoline is
recommended. See
Fuel0217.
If TOP TIER Detergent Gasoline is
not available, one bottle of Fuel
System Treatment PLUS added to
the fuel tank at every engine oil
change, can help. Fuel System

Buick Verano Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9085356) - 2016 - crc - 10/19/15
226 Driving and Operating
Conversions and
Add-Ons
Add-On Electrical
Equipment
{Warning
The Data Link Connector (DLC) is
used for vehicle service and
Emission Inspection/Maintenance
testing. SeeMalfunction Indicator
Lamp (Check Engine Light)
0 106. A device connected to the
DLC —such as an aftermarket
fleet or driver-behavior tracking
device —may interfere with
vehicle systems. This could affect
vehicle operation and cause a
crash. Such devices may also
access information stored in the
vehicle’s systems.
Caution
Some electrical equipment can
damage the vehicle or cause
components to not work and
would not be covered by the
vehicle warranty. Always check
with your dealer before adding
electrical equipment.
Add-on equipment can drain the
vehicle's 12-volt battery, even if the
vehicle is not operating.
The vehicle has an airbag system.
Before attempting to add anything
electrical to the vehicle, see
Servicing the Airbag-Equipped
Vehicle 072 and Adding Equipment
to the Airbag-Equipped
Vehicle 072.

Buick Verano Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9085356) - 2016 - crc - 10/20/15
246 Vehicle Care
Open the cap with the washer
symbol on it. Add washer fluid until
the tank is full. SeeEngine
Compartment Overview 0232 for
reservoir location.
Caution
. Do not use washer fluid that
contains any type of water
repellent coating. This can
cause the wiper blades to
chatter or skip.
. Do not use engine coolant
(antifreeze) in the
windshield washer. It can
damage the windshield
washer system and paint.
. Do not mix water with
ready-to-use washer fluid.
Water can cause the
solution to freeze and
damage the washer fluid
tank and other parts of the
washer system.
(Continued)
Caution (Continued)
.When using concentrated
washer fluid, follow the
manufacturer instructions for
adding water.
. Fill the washer fluid tank
only three-quarters full when
it is very cold. This allows
for fluid expansion if
freezing occurs, which could
damage the tank if it is
completely full.
Brakes
Disc brake pads have built-in wear
indicators that make a high-pitched
warning sound when the brake pads
are worn and new pads are needed.
The sound can come and go or can
be heard all the time when the
vehicle is moving, except when
applying the brake pedal firmly.
{Warning
The brake wear warning sound
means that soon the brakes will
not work well. That could lead to
a crash. When the brake wear
warning sound is heard, have the
vehicle serviced.
Caution
Continuing to drive with worn-out
brake pads could result in costly
brake repair.
Some driving conditions or climates
can cause a brake squeal when the
brakes are first applied or lightly
applied. This does not mean
something is wrong with the brakes.
Properly torqued wheel nuts are
necessary to help prevent brake
pulsation. When tires are rotated,
inspect brake pads for wear and
evenly tighten wheel nuts in the
proper sequence to torque
specifications. See Capacities and
Specifications 0318.

Buick Verano Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9085356) - 2016 - crc - 10/19/15
Service and Maintenance 313
of leaking, blown seals,
or damage, and can advise
when service is needed.
Tires
Tires need to be properly inflated,
rotated, and balanced. Maintaining
the tires can save money and fuel,
and can reduce the risk of tire
failure.
. Signs that the tires need to be
replaced include three or more
visible treadwear indicators; cord
or fabric showing through the
rubber; cracks or cuts in the
tread or sidewall; or a bulge or
split in the tire.
. Trained dealer technicians can
inspect and recommend the right
tires. Your dealer can also
provide tire/wheel balancing
services to ensure smooth
vehicle operation at all speeds.
Your dealer sells and services
name brand tires.
Vehicle Care
To help keep the vehicle looking like
new, vehicle care products are
available from your dealer. For information on how to clean and
protect the vehicle’s interior and
exterior, see
Interior Care 0300 and
Exterior Care 0295.
Wheel Alignment
Wheel alignment is critical for
ensuring that the tires deliver
optimal wear and performance.
. Signs that the alignment may
need to be adjusted include
pulling, improper vehicle
handling, or unusual tire wear.
. Your dealer has the required
equipment to ensure proper
wheel alignment.
Windshield
For safety, appearance, and the
best viewing, keep the windshield
clean and clear.
. Signs of damage include
scratches, cracks, and chips.
. Trained dealer technicians can
inspect the windshield and
recommend proper replacement
if needed. Wiper Blades
Wiper blades need to be cleaned
and kept in good condition to
provide a clear view.
.
Signs of wear include streaking,
skipping across the windshield,
and worn or split rubber.
. Trained dealer technicians can
check the wiper blades and
replace them when needed.

Buick Verano Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9085356) - 2016 - crc - 10/19/15
348 Index
FusesEngine Compartment Fuse
Block . . . . . . . . . . . . . . . . . . . . . . . . 256
Fuses and Circuit Breakers . . . 255
Instrument Panel Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 258
Rear Compartment Fuse
Block . . . . . . . . . . . . . . . . . . . . . . . . 260
G
Garage Door Opener . . . . . . . . . . . 129Programming . . . . . . . . . . . . . . . . . 129
Gauges Engine CoolantTemperature . . . . . . . . . . . . . . . . 104
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Odometer . . . . . . . . . . . . . . . . . . . . . 103
Speedometer . . . . . . . . . . . . . . . . . 103
Tachometer . . . . . . . . . . . . . . . . . . . 103
Trip Odometer . . . . . . . . . . . . . . . . 103
Warning Lights and Indicators . . . . . . . . . . . . . . . . . . . 101
General Information Service and Maintenance . . . . . 304
Towing . . . . . . . . . . . . . . . . . . . . . . . . 221
Vehicle Care . . . . . . . . . . . . . . . . . . 228
Glove Box . . . . . . . . . . . . . . . . . . . . . . . 93
GM Mobility Reimbursement Program . . . . . . . . . . . . . . . . . . . . . . . 323
H
Halogen Bulbs . . . . . . . . . . . . . . . . . . 251
Hazard Warning Flashers . . . . . . . 134
Head Restraints . . . . . . . . . . . . . . . . . 49
HeadlampsAiming . . . . . . . . . . . . . . . . . . . . . . . . 251
Automatic . . . . . . . . . . . . . . . . . . . . . 133
Bulb Replacement . . . . . . . . . . . . 251
Daytime RunningLamps (DRL) . . . . . . . . . . . . . . . . 133
Flash-to-Pass . . . . . . . . . . . . . . . . . 133
High-Beam On Light . . . . . . . . . . .113
High/Low Beam Changer . . . . . 132
Lamps On Reminder . . . . . . . . . .113
Heated Steering Wheel . . . . . . . . . . . . . . . . . 98
Heated Front Seats . . . . . . . . . . . . . . 53
Heated Mirrors . . . . . . . . . . . . . . . . . . . 43
Heater Engine . . . . . . . . . . . . . . . . . . . . . . . . 191
High-Beam On Light . . . . . . . . . . . . 113
Hill and Mountain Roads . . . . . . . . 180
Hill Start Assist (HSA) . . . . . . . . . . 203
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . 230
Horn . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
How to Wear Safety Belts Properly . . . . . . . . . . . . . . . . . . . . . . . . 57
Hydraulic Clutch . . . . . . . . . . . . . . . . 238
I
Ignition Positions . . . . . . . . . . 186, 188
Ignition Transmission Lock
Check . . . . . . . . . . . . . . . . . . . . . . . . . 249
Immobilizer . . . . . . . . . . . . . . . . . . . . . . 40
Indicator
Vehicle Ahead . . . . . . . . . . . . . . . . .110
Infants and Young Children, Restraints . . . . . . . . . . . . . . . . . . . . . . 75
Infotainment . . . . . . . . . . . . . . . . . . . . 139
Infotainment System . . . . . . . . . . . . 333
Instrument Cluster . . . . . . . . . . . . . . 102
Instrument Panel Storage Area . . . . . . . . . . . . . . . . . . . 93
Instrument Panel Overview . . . . . . . 6
Interior Rearview Mirrors . . . . . . . . . 43
Introduction . . . . . . . . . . . . . . . . . . . . . . . 2
J
Jump Starting - North America . . . . . . . . . . . . . . . . . . . . . . . 290
K
Key and Lock Messages . . . . . . . . 120
Keyless EntryRemote (RKE) System . . . . . . . . . 27
Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Buick Verano Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9085356) - 2016 - crc - 10/19/15
350 Index
MessagesBattery Voltage and
Charging . . . . . . . . . . . . . . . . . . . . .117
Brake System . . . . . . . . . . . . . . . . .118
Compass . . . . . . . . . . . . . . . . . . . . . .118
Door Ajar . . . . . . . . . . . . . . . . . . . . . .118
Engine Cooling System . . . . . . . .119
Engine Oil . . . . . . . . . . . . . . . . . . . . .119
Engine Power . . . . . . . . . . . . . . . . 120
Fuel System . . . . . . . . . . . . . . . . . . 120
Key and Lock . . . . . . . . . . . . . . . . . 120
Object Detection System . . . . . 120
Ride Control System . . . . . . . . . . 121
Security . . . . . . . . . . . . . . . . . . . . . . 122
Tire . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
Transmission . . . . . . . . . . . . . . . . . 122
Vehicle . . . . . . . . . . . . . . . . . . . . . . . .117
Washer Fluid . . . . . . . . . . . . . . . . . 123
Window . . . . . . . . . . . . . . . . . . . . . . . 123
Mirrors Automatic Dimming
Rearview . . . . . . . . . . . . . . . . . . . . . . 43
Convex . . . . . . . . . . . . . . . . . . . . . . . . . 42
Folding . . . . . . . . . . . . . . . . . . . . . . . . . 42
Heated . . . . . . . . . . . . . . . . . . . . . . . . . 43
Manual Rearview . . . . . . . . . . . . . . . 43
Power . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Mirrors, Interior Rearview . . . . . . . . 43 Monitor System, Tire
Pressure . . . . . . . . . . . . . . . . . . . . . . 270
Multi-band Antenna . . . . . . . . . . . . . 151
N
Navigation OnStar®. . . . . . . . . . . . . . . . . . . . . . 335
New Vehicle Break-In . . . . . . . . . . . 186
O
Object Detection System Messages . . . . . . . . . . . . . . . . . . . . . 120
Odometer . . . . . . . . . . . . . . . . . . . . . . . 103
Trip . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Off-Road Recovery . . . . . . . . . . . . . . . . . . . . . 178
Oil
Engine . . . . . . . . . . . . . . . . . . . . . . . . 235
Engine Oil Life System . . . . . . . 237
Messages . . . . . . . . . . . . . . . . . . . . .119
Pressure Light . . . . . . . . . . . . . . . . .112
Older Children, Restraints . . . . . . . 74
Online Owner Center . . . . . . . . . . . 323
OnStar . . . . . . . . . . . . . . . . . . . . . . . . . 332
OnStar
®Additional
Information . . . . . . . . . . . . . . . . . . . . 338
OnStar
®Connections . . . . . . . . . . . 336
OnStar®Diagnostics . . . . . . . . . . . . 338
OnStar®Emergency . . . . . . . . . . . . 335 OnStar
®Navigation . . . . . . . . . . . . . 335
OnStar®Overview . . . . . . . . . . . . . . 334
OnStar®Security . . . . . . . . . . . . . . . 335
Operation Infotainment System . . . . . . . . . . 142
Ordering Service Publications . . . . . . . . . . 329
Outlets Power . . . . . . . . . . . . . . . . . . . . . . . . 100
Overheating, Engine . . . . . . . . . . . . 244
Overview . . . . . . . . . . . . . . . . . . . . . . . 141
P
Park Shifting Into . . . . . . . . . . . . . . . . . . . 193
Shifting Out of . . . . . . . . . . . . . . . . 194
Parking . . . . . . . . . . . . . . . . . . . . . . . . . 194
Brake . . . . . . . . . . . . . . . . . . . . . . . . . 201
Brake and P (Park)Mechanism Check . . . . . . . . . . 249
Over Things That Burn . . . . . . . 194
Parking Assist . . . . . . . . . . . . . . . . . . 211
Passenger Airbag Status Indicator . . . . . . . . . . . . . . . . . . . . . . 105
Passenger Compartment Air Filter . . . . . . . . . . . . . . . . . . . . . . . . . . 174
Passenger Sensing System . . . . . 68
Perchlorate Materials Requirements, California . . . . . . 228
