Page 261 of 328

CADILLAC CATERA 1999 1.G Owners Manual yellowblue
6-23
CAUTION:
Turning the surge tank pressure cap when the
engine and radiator are hot can allow steam and
scalding liquids to blow out and burn you badly.
Never turn the surge tank pr

Page 262 of 328

CADILLAC CATERA 1999 1.G Owners Manual yellowblue
6-24
Power Steering Fluid
The power steering fluid reservoir is located between
the battery and the brake master cylinder on the drivers
side of the engine.
When to Check Power Steeri

Page 263 of 328

CADILLAC CATERA 1999 1.G Owners Manual yellowblue
6-25
Windshield Washer Fluid
What to Use
When you need windshield washer fluid, be sure to read
the manufacturers instructions before use. If you will be
operating your vehicle in an

Page 264 of 328

CADILLAC CATERA 1999 1.G Owners Manual yellowblue
6-26
Brakes
Brake Fluid
Your brake master cylinder reservoir is on the drivers
side of the engine compartment. It is filled with DOT
-3
brake fluid.There are only two reasons why the

Page 265 of 328

CADILLAC CATERA 1999 1.G Owners Manual yellowblue
6-27
When your brake fluid falls to a low level, your brake
warning light will come on. See ªBrake System Warning
Lightº in the Index.
What to Add
When you do need brake fluid, use o

Page 266 of 328

CADILLAC CATERA 1999 1.G Owners Manual yellowblue
6-28
CAUTION:
The brake pad wear indicator light means that
soon your brakes wont work well. That could
lead to an accident. When the brake pad wear
indicator light comes on and stays

Page 267 of 328

CADILLAC CATERA 1999 1.G Owners Manual yellowblue
6-29 Replacing Brake System Parts
The braking system on a vehicle is complex. Its many
parts have to be of top quality and work well together if
the vehicle is to have really good brak

Page 268 of 328

CADILLAC CATERA 1999 1.G Owners Manual yellowblue
6-30
Bulb Replacement
For any bulb changing procedure not listed in this
section, contact your dealer service department.
For bulb types, see ªReplacement Bulbsº in the Index.
Haloge

Page 269 of 328

CADILLAC CATERA 1999 1.G Owners Manual yellowblue
6-31
2. Remove the black rubber cap that protects the
bulb area.3. Remove the plug connector from the bulb.

Page 270 of 328

CADILLAC CATERA 1999 1.G Owners Manual yellowblue
6-32
4. Squeeze the retaining clip together and then pull
away from the bulb assembly.5. Pull the bulb out and then replace.
