Page 70 of 328
yellowblue
2-8
This device complies with RSS-210 of Industry Canada.
Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation of
the device.
Changes or modifications to this system by other than an
authorized service facility could void authorization to
use this equipment.
The range of this system is about 10 feet (3 m). At times
you may notice a decrease in range. This is normal for
any remote keyless entry transmitter. If the transmitter
does not work or if you have to stand closer to your
vehicle for the transmitter to work, try this:
Check to determine if battery replacement or
resynchronization is necessary. See the instructions
that follow.
Check the distance. You may be too far from your
vehicle. You may need to stand closer during rainy
or snowy weather.
Check the location. Other vehicles or objects may be
blocking the signal. Take a few steps to the left or
right, hold the transmitter higher, and try again.
If you're still having trouble, see your dealer or a
qualified technician for service.Operation
When you press this symbol to unlock the driver's
door, the parking lamps on your vehicle will blink twice.
The parking lamps and headlamps will remain on for
about 20 seconds. Pressing this button again within five
seconds will unlock the other doors. Pressing this button
will also disarm the optional theft
-deterrent system and
turn on the interior lamps (for approximately 20 seconds).
When you press this symbol to lock the doors
(including the fuel door), the parking lamps will blink
once. This also arms the optional theft
-deterrent system.
Press this symbol to open the trunk.
Press this button to unlock the fuel door.
Matching Transmitter(s) To Your Vehicle
Each remote keyless entry transmitter is coded to
prevent another transmitter from unlocking your vehicle.
If a transmitter is lost or stolen, a replacement can be
purchased through your dealer. Once your dealer has
coded the new transmitter, the lost transmitter will not
unlock your vehicle. Your vehicle may be equipped with
either a two or four fob capability and is only able to
have the same number of transmitters matched to it.
Since all vehicles come with only two fobs, you need to
check with your dealer to see which system you have.
Page 87 of 328
yellowblue
2-25
This feature is for improved traction only when the road
surface is slippery and is not intended for continuous use
or when the vehicle is stuck in sand, mud, ice, snow or
gravel. Drive as usual for normal road conditions.
This feature automatically turns off when any of the
following conditions occur:
When the ignition is turned off.
If the shift lever is placed in PARK (P), THIRD (3),
SECOND (2), or FIRST (1).
If you press and hold the accelerator pedal past its
resistance point for more than two seconds.
When speed falls below 25 mph (40 km/h).
Once the vehicle reaches 67 mph (108 km/h).
To turn this feature off, press the button again.
Whenever you start your vehicle, the transmission is in
the normal mode.Parking Brake
To set the parking brake, hold the regular brake pedal
down with your foot and pull up on the parking brake
lever. If the ignition is on, the brake system warning
light will come on.
Page 320 of 328
yellowblue
8-4
Driving (Continued)
Night 4-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
On Curves 4-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
On Grades While Towing a Trailer 4-36 . . . . . . . . . . . . . . .
On Hill and Mountain Roads 4-23 . . . . . . . . . . . . . . . . . . . .
On Snow or Ice 4-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Through Deep Standing Water 4-19 . . . . . . . . . . . . . . . . . . .
Winter 4-24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
With a Trailer 4-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electrical Equipment, Adding 2-19 . . . . . . . . . . . . . . . . . . . .
Electrical System 6-55 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electrochromic Day/Night Rearview Mirror 2-47 . . . . . . . . . .
Electronic Climate Control (ECC) 3-2 . . . . . . . . . . . . . . . . . . .
Electronic Level Control 4-30 . . . . . . . . . . . . . . . . . . . . . . . . .
Emergency Trunk Release 2-12 . . . . . . . . . . . . . . . . . . . . . . . .
Engine 6-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air Cleaner/Filter 6-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Compartment Relay Center 6-61 . . . . . . . . . . . . . . . . . . . . .
Coolant 6-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant Heater 2-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant Temperature Gage 2-69 . . . . . . . . . . . . . . . . . . . . .
Coolant Temperature Warning Light 2-68 . . . . . . . . . . . . . .
Cooling When Trailer Towing 4-37 . . . . . . . . . . . . . . . . . . .
Exhaust 2-11, 2-30, 2-31, 4-28 . . . . . . . . . . . . . . . . . . . . . .
Identification 6-54 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Overheating 5-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Running While You're Parked 2-31 . . . . . . . . . . . . . . . . . . .
Specifications 6-63 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Speed Limiter 2-63 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting Your 2-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Engine Oil 6
-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Additives 6-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking 6-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
What Kind to Use 6-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
What to do with Used 6-14 . . . . . . . . . . . . . . . . . . . . . . . . . .
When to Add 6-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
When to Change 6-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
English/Metric Display 3-3 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ethanol 6-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exhaust, Engine 2-11, 2-30, 2-31, 4-28 . . . . . . . . . . . . . . . . .
Extender, Safety Belts 1-52 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exterior Lamps 2-40 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fan Button, Climate Control System 3-2 . . . . . . . . . . . . . . . .
Features and Controls 2-1 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Filling a Portable Fuel Container 6-8 . . . . . . . . . . . . . . . . . . . .
Filling Your Tank 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Filter, Air 6-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Filter Replacement, Passenger Compartment Air 6-17 . . . . . .
Finish Care 6-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Finish Damage 6-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
FIRST (1) Gear, Automatic Transmission 2-23 . . . . . . . . . . . .
Flashers, Hazard Warning 5-2 . . . . . . . . . . . . . . . . . . . . . . . . .
Flash-To-Pass 2-35 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Flat Tire, Changing 5-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Floor Mats 2-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid
Brake 6
-26 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power Steering 6-24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield Washer 6-25 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fog Lamps 2-44 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Page 326 of 328
yellowblue
8-10
Shoulder Belt Height Adjuster 1-18 . . . . . . . . . . . . . . . . . . . . .
Signaling Turns 2-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Skidding 4-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sound Equipment, Adding (Audio) 3-29 . . . . . . . . . . . . . . . . .
Speaker Covers, Cleaning 6-48 . . . . . . . . . . . . . . . . . . . . . . . .
Specifications and Capacities 6-62 . . . . . . . . . . . . . . . . . . . . . .
Specifications, Engine 6-63 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Speech Impaired, Customer Assistance 7-3 . . . . . . . . . . . . . . .
Speed Limiter, Engine 2-63 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Speedometer 2-63 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sport Mode Button 2-24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting Your Engine 2-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Steam 5-9, 5-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Steering 4-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
In Emergencies 4-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power 4-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Speed Sensitive (SSS) 4-10 . . . . . . . . . . . . . . . . . . . . . . . . .
Tips 4-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheel Controls for Audio System 3-27 . . . . . . . . . . . . . . . .
Wheel, Tilt 2-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage Compartments 2-49 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Stuck: In Sand, Mud, Ice or Snow 5-28 . . . . . . . . . . . . . . . . . .
Sun Visors 2-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sunroof 2-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Anti-Pinch Feature 2-54 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Manual Operation 2-54 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Programming 2-55 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sunshade, Rear 2-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Surge Tank, Coolant 5-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Surge Tank Pressure Cap 6-20 . . . . . . . . . . . . . . . . . . . . . . . . .
Symbols, Vehicle vii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tachometer 2-63 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Taillamp and Rear Turn Signal Lamp 6-35 . . . . . . . . . . . . . . .
Tape Player Care 3-29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Telephone, Cellular 2-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Temperature Display, Outside 3-3 . . . . . . . . . . . . . . . . . . . . . .
Temperature Knobs, Climate Control System 3-2 . . . . . . . . . .
Theft 2-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Theft-Deterrent Feature (Radio) 3-27 . . . . . . . . . . . . . . . . . . .
Theft-Deterrent System 2-13 . . . . . . . . . . . . . . . . . . . . . . . . . .
Theftlock3-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Thermostat 6-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
THIRD (3) Gear, Automatic Transmission 2-23 . . . . . . . . . . .
Third-Gear Start 2-24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tilt Wheel 2-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Time, Setting the 3-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tips About Your Audio System 3-28 . . . . . . . . . . . . . . . . . . . .
Tires 6-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Alignment and Balance 6-44 . . . . . . . . . . . . . . . . . . . . . . . .
Buying New 6-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chains 6-45 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing a Flat 5-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning 6-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inflation Pressure 6-38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inspection and Rotation 6-39 . . . . . . . . . . . . . . . . . . . . . . . .
Loading Information Label 4-29 . . . . . . . . . . . . . . . . . . . . .
Temperature 6-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Traction 6-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Treadwear 6-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Uniform Quality Grading 6-42 . . . . . . . . . . . . . . . . . . . . . . .
Wear Indicators 6-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheel Replacement 6-44 . . . . . . . . . . . . . . . . . . . . . . . . . . .
When It's Time for New 6-41 . . . . . . . . . . . . . . . . . . . . . . .
