Page 71 of 328
2-4
Anti-Pinch Feature
If a hand, an arm or another object is above the middle
of the window and is in the way of the power window
express
-closing, the window will stop at the obstruction
and express
-open to a preset factory position.
CAUTION:
Pressing and holding the power window control
button will turn off the anti
-pinch feature.
If this happens, a power window won't stop if
something gets in the way. You or others could be
injured, and your window could be damaged. Be
careful not to press and hold the power window
control button.
Rear Window Lockout
Moving this switch to the
left will disable the rear
passenger window controls.
A red indicator light in the
control will illuminate as
a reminder that the rear
passenger window controls
have been disabled.
Moving the switch back to the right to enable the rear
passenger window controls again. A green indicator
light in the control will illuminate to indicate that the
rear passenger window controls are once again active.
Page 72 of 328
2-5
Keys
CAUTION:
Leaving children in a vehicle with the ignition
key is dangerous for many reasons. A child or
others could be badly injured or even killed.
They could operate the power windows or
other controls or even make the vehicle move.
Don't leave the keys in a vehicle with children.
Page 73 of 328
2-6
One key is used for the
ignition, the doors and all
other locks. (There is no
lock cylinder for the trunk
or the passenger's door.)
Your vehicle comes with a spare key. This key does not
have an immobilizer pellet in it; however, it will still
unlock your vehicle's doors. Because of the key's flat
shape, it can be stored in your wallet.
If you've lost your keys or need to have a new one
made, you will have to contact your dealer for the
correct key code.In an emergency, contact the Cadillac Roadside
Assistance Center. See ªRoadside Assistanceº
in the Index.
NOTICE:
Your vehicle has a number of new features that
can help prevent theft. You can have a lot of
trouble getting into your vehicle if you ever
lock your keys inside and you may have to
damage your vehicle to get in. Be sure you
have extra keys.
Page 74 of 328
2-7
Door Locks
CAUTION:
Unlocked doors can be dangerous.
Passengers -- especially children -- can
easily open the doors and fall out of a
moving vehicle. When a door is locked, the
handle won't open it. You increase the
chance of being thrown out of the vehicle in
a crash if the doors aren't locked. So, wear
safety belts properly and lock the doors
whenever you drive.
Young children who get into unlocked
vehicles may be unable to get out. A child
can be overcome by extreme heat and can
suffer permanent injuries or even death
from heat stroke. Always lock your vehicle
whenever you leave it.
Outsiders can easily enter through an
unlocked door when you slow down or stop
your vehicle. Locking your doors can help
prevent this from happening.
There are several ways to lock and unlock your vehicle.
From the outside, use your key or the remote keyless
entry transmitter. This will avoid setting off the optional
theft
-deterrent alarm.
From inside your vehicle,
slide the manual lock lever
down to lock the door. To
unlock the door, slide the
manual lock lever up.
Central Door Unlocking System
When unlocking the driver's door from the outside,
you can also unlock the other doors by holding the
key in a turned position for several seconds (turn the
key counterclockwise).
Pressing the unlock button on the remote keyless entry
transmitter twice in a row will also open the other doors.
Page 75 of 328
2-8 Power Door Locks
Push the side of the power
door lock switch with the
lock symbol to lock all the
doors. Push the side of the
switch with the unlock
symbol to unlock all
the doors.
Automatic Door Locks
Close the doors and turn on the ignition. Every time you
move the shift lever out of PARK (P), all of the doors
will lock. The doors will also unlock every time you
stop the vehicle and move the shift lever into PARK (P).
If someone needs to get out while your vehicle is not in
PARK (P), have that person use the manual or power
door lock. When the door is closed again, it will not lock
automatically. Use the manual or power lock to lock the
door again.
Programmable Automatic Door Locks
Each remote keyless entry transmitter supplied
with your vehicle can be programmed to suit each
driver's door lock preference. The two remote keyless
entry transmitters are identified on the back with
either a ª1º or a ª2º. Each transmitter must be
programmed separately.
The automatic door locks can be programmed (using the
remote keyless entry transmitter) for various lock and
unlock options.
With the ignition on, the transmission in PARK (P)
and the brake pedal pressed down, you are now ready
to begin programming.
To program:
All doors do not unlock when shifting into
PARK (P)
- Press the unlock button on the remote
keyless entry transmitter four times. Each press should
be held for about one second with less than five seconds
in between each press.
All doors unlock when shifting into PARK (P)
- Press
the unlock button on the remote keyless entry
transmitter four times. Each press should be held for
about one second with less than five seconds in between
each press.
The unlock button will toggle between the above
two settings.
Page 76 of 328
2-9
All doors do not lock when shifting out
of PARK (P)
- Press the lock button on the remote
keyless entry transmitter four times. Each press should
be held for about one second with less than five seconds
in between each press.
All doors lock when shifting out of PARK (P)
- Press
the lock button on the remote keyless entry four times.
Each press should be held for about one second with less
than five seconds in between each press.
The lock button will toggle between the above
two settings.
Rear Door Security Lock
Your vehicle is equipped
with rear door security
locks that help prevent
passengers from opening
the rear door of your vehicle
from the inside. The lock is
located on the rear edge of
each rear door.To use this lock do the following:
1. Move the lever on the door all the way down into the
ENGAGED position.
2. Close the door.
3. Do the same thing to the other rear door lock.
The rear doors of your vehicle cannot be opened from
the inside when this feature is in use.
When you want to open a rear door when the security
lock is on:
1. Unlock the door from the inside.
2. Then open the door from the outside.
To cancel the rear door lock do the following:
1. Unlock the door from the inside and open the door
from the outside.
2. Move the lever all the way up.
3. Do the same for the other rear door.
The rear door locks will now work normally.
Page 77 of 328
2-10 Anti-Lockout Feature
Leaving your key in the ignition with a door open will
prevent locking of the doors with either the power door
lock switches or the remote keyless entry transmitter.
It is always recommended that you remove the ignition
key when locking your vehicle.
The anti
-lockout feature can be overridden by holding
the power door lock switch for three seconds or longer.
Leaving Your Vehicle
If you are leaving your vehicle, open the door, set the
locks from the inside, get out and close the door.
Remote Keyless Entry System (RKE)
With this feature, you can lock and unlock your doors or
unlock your trunk from about 3 feet (1 m) up to 30 feet
(9 m) away using the remote keyless entry transmitter
supplied with your vehicle.
Your keyless entry system operates on a radio frequency
subject to Federal Communications Commission (FCC)
Rules and with Industry Canada.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
This device complies with RSS
-210 of Industry Canada.
Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation of
the device.
Page 78 of 328
2-11
Changes or modifications to this system by other than an
authorized service facility could void authorization to
use this equipment.
The average range of this system is about 30 feet (9 m).
At times you may notice a decrease in range. This is
normal for any remote keyless entry transmitter. If the
transmitter does not work or if you have to stand closer
to your vehicle for the transmitter to work, try this:
Check the distance. You may be too far from your
vehicle. You may need to stand closer during rainy
or snowy weather.
Check the location. Other vehicles or objects may be
blocking the signal. Take a few steps to the left or
right, hold the transmitter higher, and try again.
Check to determine if battery replacement or
resynchronization is necessary. See the instructions
that follow.
If you're still having trouble, see your dealer or a
qualified technician for service.Operation
When you press
this symbol to unlock
the driver's door, the
parking lamps on your
vehicle will blink
twice. The parking
lamps and headlamps
will remain on for
about 20 seconds.
Pressing this button again within five seconds will
unlock the other doors. Pressing this button will also
disarm the optional theft
-deterrent system and turn on
the interior lamps (for approximately 20 seconds).
When you press this symbol to lock the doors
(including the fuel door), the parking lamps will blink
once. This also arms the optional theft
-deterrent system.
Press this symbol to open the trunk.
Press this button to unlock the fuel door.
Page 79 of 328
2-12 Matching Transmitter(s) to Your Vehicle
Each remote keyless entry transmitter is coded to
prevent another transmitter from unlocking your vehicle.
If a transmitter is lost or stolen, a replacement can be
purchased through your dealer. Remember to bring any
remaining transmitters with you when you go to your
dealer. When the dealer matches the replacement
transmitter to your vehicle, any remaining transmitters
must also be matched. Once your dealer has coded the
new transmitter, the lost transmitter will not unlock your
vehicle. Each vehicle can have only four transmitters
matched to it.
Battery Replacement
Under normal use, the battery in your remote keyless
entry transmitter should last about four years.
You can tell the battery is weak if the transmitter won't
work at the normal range in any location. If you have to
get close to your vehicle before the transmitter works,
it's probably time to change the battery.
NOTICE:
When replacing the battery, use care not to
touch any of the circuitry. Static from your
body transferred to these surfaces may damage
the transmitter.
Page 80 of 328
2-13
1. Use a thin coin to pry open the transmitter.2. Remove the battery and replace it with a CR2032
battery. Using the wrong size battery can damage the
transmitter. Make sure the battery is positioned with
the ªplusº (+) facing down.
3. Align the internal pieces of the transmitter, including
the cover. Snap together to reinstall.
