CADILLAC CT6 2016 Owners Manual

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-9235592) -
2016 - crc - 11/6/15
260 Driving and Operating Safety Chains Always attach chains between the
vehicle and the trailer. Cross the
safety chains under the tongue of
the trailer to help prevent the tongue
from contacting the road if it
becomes separated from the hitch.
Leave enough slack so the rig can
turn. Never allow safety chains to
drag on the ground.
Trailer Brakes Does the trailer have its own
brakes? Be sure to read and follow
the instructions for the trailer brakes
so they are installed, adjusted, and
maintained properly.
Because the vehicle has antilock
brakes, do not tap into the vehicle's
brake system. If this is done, both
brake systems will not work well or
at all. Conversions and
Add-Ons Add-On Electrical
Equipment
{ WarningThe Data Link Connector (DLC) is
used for vehicle service and
Emission Inspection/Maintenance
testing. See Malfunction Indicator
Lamp (Check Engine Light)
0 132 . A device connected to the
DLC — such as an aftermarket
fleet or driver-behavior tracking
device — may interfere with
vehicle systems. This could affect
vehicle operation and cause a
crash. Such devices may also
access information stored in the
vehicle ’ s systems. CautionSome electrical equipment can
damage the vehicle or cause
components to not work and
would not be covered by the
vehicle warranty. Always check
with your dealer before adding
electrical equipment.
Add-on equipment can drain the
vehicle's 12-volt battery, even if the
vehicle is not operating.
The vehicle has an airbag system.
Before attempting to add anything
electrical to the vehicle, see
Servicing the Airbag-Equipped
Vehicle 0 86
and Adding Equipment to the
Airbag-Equipped Vehicle 0 86 .

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-9235592) -
2016 - crc - 11/6/15
Vehicle Care 261
Vehicle Care General Information General Information . . . . . . . . . . 262
California Proposition
65 Warning . . . . . . . . . . . . . . . . . 262
California Perchlorate
Materials Requirements . . . . . 262
Accessories and
Modifications . . . . . . . . . . . . . . . . 262
Vehicle Checks Doing Your Own
Service Work . . . . . . . . . . . . . . . 263
Hood . . . . . . . . . . . . . . . . . . . . . . . . . 264
Engine Compartment
Overview . . . . . . . . . . . . . . . . . . . . 265
Engine Oil . . . . . . . . . . . . . . . . . . . . 270
Engine Oil Life System . . . . . . . 272
Automatic Transmission
Fluid . . . . . . . . . . . . . . . . . . . . . . . . 273
Engine Air Cleaner/Filter . . . . . . 273
Cooling System . . . . . . . . . . . . . . 275
Engine Coolant . . . . . . . . . . . . . . . 277
Engine Overheating . . . . . . . . . . 280
Washer Fluid . . . . . . . . . . . . . . . . . 281
Brakes . . . . . . . . . . . . . . . . . . . . . . . 282
Brake Fluid . . . . . . . . . . . . . . . . . . . 283
Battery - North America . . . . . . 284
All-Wheel Drive . . . . . . . . . . . . . . . 284 Starter Switch Check . . . . . . . . . 285
Automatic Transmission Shift
Lock Control Function
Check . . . . . . . . . . . . . . . . . . . . . . . 285
Park Brake and P (Park)
Mechanism Check . . . . . . . . . . 286
Wiper Blade Replacement . . . . 286
Windshield Replacement . . . . . 287
Headlamp Aiming Headlamp Aiming . . . . . . . . . . . . 287
Bulb Replacement Bulb Replacement . . . . . . . . . . . . 288
LED Lighting . . . . . . . . . . . . . . . . . 288
License Plate Lamp . . . . . . . . . . 288
Replacement Bulbs . . . . . . . . . . . 289
Electrical System Electrical System Overload . . . 289
Fuses and Circuit Breakers . . . 290
Engine Compartment Fuse
Block . . . . . . . . . . . . . . . . . . . . . . . . 290
Instrument Panel Fuse
Block . . . . . . . . . . . . . . . . . . . . . . . . 293
Rear Compartment Fuse
Block . . . . . . . . . . . . . . . . . . . . . . . . 295
Wheels and Tires
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . 299
All-Season Tires . . . . . . . . . . . . . . 300
Winter Tires . . . . . . . . . . . . . . . . . . 300 Low-Profile Tires . . . . . . . . . . . . . 300
Summer Tires . . . . . . . . . . . . . . . . 301
Tire Sidewall Labeling . . . . . . . . 301
Tire Designations . . . . . . . . . . . . . 303
Tire Terminology and
Definitions . . . . . . . . . . . . . . . . . . 304
Tire Pressure . . . . . . . . . . . . . . . . . 306
Tire Pressure for High-Speed
Operation . . . . . . . . . . . . . . . . . . . 308
Tire Pressure Monitor
System . . . . . . . . . . . . . . . . . . . . . . 308
Tire Pressure Monitor
Operation . . . . . . . . . . . . . . . . . . . 309
Tire Inspection . . . . . . . . . . . . . . . . 312
Tire Rotation . . . . . . . . . . . . . . . . . 313
When It Is Time for New
Tires . . . . . . . . . . . . . . . . . . . . . . . . 314
Buying New Tires . . . . . . . . . . . . . 315
Different Size Tires and
Wheels . . . . . . . . . . . . . . . . . . . . . . 316
Uniform Tire Quality
Grading . . . . . . . . . . . . . . . . . . . . . 316
Wheel Alignment and Tire
Balance . . . . . . . . . . . . . . . . . . . . . 318
Wheel Replacement . . . . . . . . . . 318
Tire Chains . . . . . . . . . . . . . . . . . . . 319
If a Tire Goes Flat . . . . . . . . . . . . 320
Tire Changing . . . . . . . . . . . . . . . . 321
Compact Spare Tire . . . . . . . . . . 326

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-9235592) -
2016 - crc - 11/6/15
262 Vehicle Care Jump Starting Jump Starting - North
America . . . . . . . . . . . . . . . . . . . . . 327
Towing the Vehicle Towing the Vehicle . . . . . . . . . . . 330
Recreational Vehicle
Towing . . . . . . . . . . . . . . . . . . . . . . 331
Appearance Care Exterior Care . . . . . . . . . . . . . . . . . 333
Interior Care . . . . . . . . . . . . . . . . . . 338
Floor Mats . . . . . . . . . . . . . . . . . . . . 341
General Information For service and parts needs, visit
your dealer. You will receive
genuine GM parts and GM-trained
and supported service people.
Genuine GM parts have one of
these marks:
California Proposition
65 Warning WARNING: Most motor vehicles,
including this one, contain and/or
emit chemicals known to the State
of California to cause cancer and
birth defects or other reproductive harm. Engine exhaust, many parts
and systems, many fluids, and
some component wear by-products
contain and/or emit these
chemicals.
See Battery - North America 0 284
and Jump Starting - North
America 0 327 .
California Perchlorate
Materials Requirements Certain types of automotive
applications, such as airbag
initiators, safety belt pretensioners,
and lithium batteries contained in
Remote Keyless Entry transmitters,
may contain perchlorate materials.
Special handling may be necessary.
For additional information, see
www.dtsc.ca.gov/hazardouswaste/
perchlorate.
Accessories and
Modifications Adding non-dealer accessories or
making modifications to the vehicle
can affect vehicle performance and
safety, including such things as

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-9235592) -
2016 - crc - 11/6/15
Vehicle Care 263airbags, braking, stability, ride and
handling, emissions systems,
aerodynamics, durability, and
electronic systems like antilock
brakes, traction control, and stability
control. These accessories or
modifications could even cause
malfunction or damage not covered
by the vehicle warranty.
Damage to suspension components
caused by modifying vehicle height
outside of factory settings will not be
covered by the warranty. Damage to vehicle components
resulting from modifications or the
installation or use of non-GM
certified parts, including control
module or software modifications, is
not covered under the terms of the
vehicle warranty and may affect
remaining warranty coverage for
affected parts.
GM Accessories are designed to
complement and function with other
systems on the vehicle. See your
dealer to accessorize the vehicle
using genuine GM Accessories
installed by a dealer technician.
Also, see Adding Equipment to the
Airbag-Equipped Vehicle 0 86 .Vehicle Checks Doing Your Own
Service Work
{ WarningIt can be dangerous to work on
your vehicle if you do not have
the proper knowledge, service
manual, tools, or parts. Always
follow owner manual procedures
and consult the service manual
for your vehicle before doing any
service work.
If doing some of your own service
work, use the proper service
manual. It tells you much more
about how to service the vehicle
than this manual can. To order the
proper service manual, see Service
Publications Ordering
Information 0 370 .
This vehicle has an airbag system.
Before attempting to do your own
service work, see Servicing the
Airbag-Equipped Vehicle 0 86 .

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-9235592) -
2016 - crc - 11/13/15
264 Vehicle Care Keep a record with all parts receipts
and list the mileage and the date of
any service work performed. See
Maintenance Records 0 356 .
CautionEven small amounts of
contamination can cause damage
to vehicle systems. Do not allow
contaminants to contact the fluids,
reservoir caps, or dipsticks.
Hood
{ WarningGas struts and other hot metal
components under the hood can
get hot after running the engine.
Do not touch as they can burn
unprotected skin and could cause
serious injury.
Clear any snow from the hood
before opening. To open the hood:
1. Pull the hood release handle.
It is on the lower left side of the
instrument panel between the
door and the steering wheel.
2. Release the handle, then pull
the handle again to fully open
the hood.
3. Go to the front of the vehicle
and lift the hood open. CautionBe sure the hood is completely
closed before driving. Damage
may occur if it is not.
To close the hood:
1. Before closing the hood, be
sure all filler caps are properly
installed.
2. Lower the hood approximately
46 cm (18 in) from the closed
position.
3. Then push the front center of
the hood with a swift, firm
motion.
4. Check to make sure the hood
is closed. If not, release the
hood from inside and repeat
Steps 1 – 3.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-9235592) -
2016 - crc - 11/6/15
Vehicle Care 265
Engine Compartment Overview
2.0L L4 Engine

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-9235592) -
2016 - crc - 11/6/15
266 Vehicle Care 1. Engine Coolant Surge Tank
and Pressure Cap. See
Cooling System 0 275 .
2. Engine Air Cleaner/Filter 0 273 .
3. Engine Oil Fill Cap. See
Engine Oil 0 270 .
4. Engine Cooling Fan (Out of
View). See Cooling
System 0 275 .
5. Engine Oil Dipstick. See
Engine Oil 0 270 .
6. Remote Positive (+) Battery
Terminal. See Jump Starting -
North America 0 327 .
7. Engine Compartment Fuse
Block 0 290 .
8. Brake Fluid Reservoir (Under
Cover). See Brake Fluid 0 283 .
9. Windshield Washer Fluid
Reservoir. See Washer
Fluid 0 281 .
10. Remote Negative (-) Battery
Terminal. See Jump Starting -
North America 0 327 .

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-9235592) -
2016 - crc - 11/6/15
Vehicle Care 267
3.0L V6 Twin Turbo Engine

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-9235592) -
2016 - crc - 11/6/15
268 Vehicle Care 1. Engine Coolant Surge Tank
and Pressure Cap. See
Cooling System 0 275 .
2. Engine Air Cleaner/Filter 0 273 .
3. Engine Cooling Fan (Out of
View). See Cooling
System 0 275 .
4. Engine Oil Fill Cap. See
Engine Oil 0 270 .
5. Engine Oil Dipstick. See
Engine Oil 0 270 .
6. Remote Positive (+) Battery
Terminal. See Jump Starting -
North America 0 327 .
7. Engine Compartment Fuse
Block 0 290 .
8. Brake Fluid Reservoir. See
Brake Fluid 0 283 .
9. Windshield Washer Fluid
Reservoir. See Washer
Fluid 0 281 .
10. Remote Negative (-) Battery
Terminal. See Jump Starting -
North America 0 327 .

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-9235592) -
2016 - crc - 11/6/15
Vehicle Care 269
3.6L V6 Engine
