CADILLAC CT6 2018 1.G Owners Manual

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-11292458) -
2018 - crc - 2/14/17
400 SERVICE AND MAINTENANCE
UsageFluid/Lubricant
Transfer Case (All-Wheel Drive) Transfer Case Fluid (GM Part No. 19331044, in Canada 19331045). Weatherstrip Conditioning Weatherstrip Lubricant (GM Part No. 3634770, in Canada 10953518) or Dielectric Silicone Grease (GM Part No. 12345579, in Canada 10953481).
Windshield Washer Automotive windshield washer fluid that meets regional freeze protection
requirements.
Maintenance Replacement Parts
Replacement parts identified below by name, part number, or specification can be obtained from your dealer.
Part GM Part Number ACDelco Part Number
Engine Air Cleaner/Filter 2.0L L4 Engine 23418368 A3219C
3.0L V6 Engine (Driver Side) 23441383 A3207C
3.0L V6 Engine (Passenger Side) 23450879 A3206C
3.6L V6 Engine 23458700 A3204C
Engine Oil Filter
2.0L L4 Engine 12640445 PF64
3.0L V6 Engine 19330000 PF63E
3.6L V6 Engine 19330000 PF63E

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-11292458) -
2018 - crc - 2/14/17
SERVICE AND MAINTENANCE 401
PartGM Part Number ACDelco Part Number
Passenger Compartment Air Filter Particulate 13508023CF185
Carbon 13356914CF184
Spark Plugs 2.0L L4 Engine 1264782741-125
3.0L V6 Engine 1265028341-131
3.6L V6 Engine 1264678041-130
Wiper Blades Driver Side –60 cm (23.62 in) 23368186—
Passenger Side –45 cm (17.72 in) 23353587—

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-11292458) -
2018 - crc - 2/14/17
402 SERVICE AND MAINTENANCE
Maintenance Records
After the scheduled services are performed, record the date, odometer reading, who performed the service, and the type of
services performed in the boxes provided. Retain all maintenance receipts.Date Odometer
Reading Serviced By Maintenance Stamp Services Performed

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-11292458) -
2018 - crc - 2/14/17
TECHNICAL DATA 403
Technical Data
Vehicle Identification
Vehicle IdentificationNumber (VIN) . . . . . . . . . . . . . . . . . . . 403
Service Parts Identification Label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 403
Vehicle Data
Capacities and Specifications . . . . 404
Engine Drive Belt Routing . . . . . . . 406
Vehicle Identification
Vehicle Identification
Number (VIN)
This legal identifier is in the front
corner of the instrument panel, on the
driver side of the vehicle. It can be
seen through the windshield from
outside. The Vehicle Identification
Number (VIN) also appears on the
Vehicle Certification and Service Parts
labels and certificates of title and
registration.
Engine Identification
The eighth character in the VIN is the
engine code. This code identifies the
vehicle's engine, specifications, and
replacement parts. See “Engine
Specifications” underCapacities and
Specifications 0404 for the vehicle's
engine code.
Service Parts Identification
Label
There may be a label on the inside of
the trunk that contains the following
information:
. Vehicle Identification
Number (VIN)
. Model designation
. Paint information
. Production options and special
equipment
If there is no label, there is a barcode
on the certification label on the
center (B) pillar to scan for this same
information.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-11292458) -
2018 - crc - 2/14/17
404 TECHNICAL DATA
Vehicle Data
Capacities and Specifications
The following approximate capacities are given in metric and English conversions. SeeRecommended Fluids and Lubricants
0 399 for more information.
Application Capacities
Metric English
Air Conditioning Refrigerant For the air conditioning system refrigerant type and charge amount, see the refrigerant label under thehood. See your dealer for more information.
Brake Fluid 0.4 L 0.4 qt
Cooling System –Engine
2.0L L4 Engine 8.6 L 9.1 qt
2.0L L4 Engine with Rear A/C 10.3 L 10.9 qt
2.0L L4 PLUG–IN Engine 9.8 L 10.4 qt
2.0L L4 PLUG–IN Engine –Power Electronics 4.0 L 4.2 qt
2.0L L4 PLUG–IN Engine –RESS 3.1 L 3.3 qt
3.0L V6 Engine 10.6 L 11.2 qt
3.0L V6 Engine with Rear A/C 12.3 L 13.0 qt
3.0L V6 Engine with Rear A/C and Auxiliary Radiator 13.2 L 13.9 qt
3.0L V6 Engine with Auxiliary Radiator 11.5 L 12.2 qt

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-11292458) -
2018 - crc - 2/14/17
TECHNICAL DATA 405
ApplicationCapacities
Metric English
3.0L V6 Engine Intercoolers 3.2 L 3.4 qt
3.6L V6 Engine 9.8 L 10.4 qt
3.6L V6 Engine with Rear A/C 11.4 L 12.0 qt
Engine Oil with Filter
2.0L L4 Engine 4.7 L 5.0 qt
3.0L V6 Engine 5.7 L 6.0 qt
3.6L V6 Engine 5.7 L 6.0 qt
Front Axle 0.5 L 0.53 qt
Rear Axle 0.5 L 0.53 qt
Rear Axle - PLUG–IN 1.1 L 1.16 qt
Fuel Tank Gasoline Only 72.7 L 19.2 gal
PLUG–IN 58.0 L 15.3 gal
Transfer Case –AWD 0.8 L 0.85 qt
Wheel Nut Torque 150 Y110 lb ft
All capacities are approximate. When adding, be sure to fill to the approximate level, as recommended in this manual.
Recheck fluid level after filling.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-11292458) -
2018 - crc - 2/14/17
406 TECHNICAL DATA
Engine Specifications
EngineVIN CodeTransmission Spark Plug Gap
2.0L L4 Engine XAutomatic0.75–0.90 mm (0.030–0.035 in)
3.0L V6 Engine 6Automatic 0.65–0.75 mm (0.26–0.030 in)
3.6L V6 Engine SAutomatic0.80–0.90 mm (0.031–0.035 in)
Engine Drive Belt Routing
2.0L L4 Engine (PLUG-IN)
2.0L L4 Engine (Gasoline Only)3.0L V6 Engine

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-11292458) -
2018 - crc - 2/14/17
TECHNICAL DATA 407
3.6L V6 Engine

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-11292458) -
2018 - crc - 2/14/17
408 CUSTOMER INFORMATION
Customer
Information
Customer Information
Customer SatisfactionProcedure . . . . . . . . . . . . . . . . . . . . . . . 408
Customer Assistance Offices . . . . 410
Customer Assistance for Text Telephone (TTY) Users . . . . . . . . . 410
Online Owner Center . . . . . . . . . . . . . 411
Roadside Service . . . . . . . . . . . . . . . . . 411
Scheduling Service Appointments . . . . . . . . . . . . . . . . . . . 413
Courtesy Transportation Program . . . . . . . . . . . . . . . . . . . . . . . . . 413
Collision Damage Repair . . . . . . . . . 414
Service Publications Ordering Information . . . . . . . . . . . . . . . . . . . . . 416
Radio Frequency Statement . . . . . 417
Reporting Safety Defects
Reporting Safety Defects to the United States Government . . . . . 418
Reporting Safety Defects to the Canadian Government . . . . . . . . . 418
Reporting Safety Defects to General Motors . . . . . . . . . . . . . . . . . 418
Vehicle Data Recording and
Privacy
Vehicle Data Recording andPrivacy . . . . . . . . . . . . . . . . . . . . . . . . . . . 419
Event Data Recorders . . . . . . . . . . . . 419
OnStar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 420
Infotainment System . . . . . . . . . . . . . 420
Customer Information
Customer Satisfaction
Procedure
Your satisfaction and goodwill are
important to your dealer and to
Cadillac. Normally, any concerns with
the sales transaction or the operation
of the vehicle will be resolved by your
dealer's sales or service departments.
Sometimes, however, despite the best
intentions of all concerned,
misunderstandings can occur. If your
concern has not been resolved to your
satisfaction, the following steps
should be taken:
STEP ONE : Discuss your concern
with a member of dealership
management. Normally, concerns can
be quickly resolved at that level. If the
matter has already been reviewed with
the sales, service or parts manager,
contact the owner of your dealership
or the general manager.
STEP TWO : If after contacting a
member of dealership management, it
appears your concern cannot be
resolved by your dealership without

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-11292458) -
2018 - crc - 2/14/17
CUSTOMER INFORMATION 409
further help, in the U.S., call the
Cadillac Customer Assistance Center
at 1-800–458–8006. In Canada, call
the Canadian Cadillac Customer Care
Centre at 1-888-446-2000.
We encourage you to call the toll-free
number in order to give your inquiry
prompt attention. Have the following
information available to give the
Customer Assistance representative:
.Vehicle Identification
Number (VIN). This is available
from the vehicle registration or
title, or the plate at the top left of
the instrument panel and visible
through the windshield.
. Dealership name and location.
. Vehicle delivery date and present
mileage.
When contacting Cadillac, remember
that your concern will likely be
resolved at a dealer's facility. That is
why we suggest following Step One
first.
STEP THREE —U.S. Owners : Both
General Motors and your dealer are
committed to making sure you are
completely satisfied with the new vehicle. However, if you continue to
remain unsatisfied after following the
procedure outlined in Steps One and
Two, you can file with the Better
Business Bureau (BBB) Auto Line
®
Program to enforce your rights.
The BBB Auto Line Program is an
out-of-court program administered by
the Council of Better Business Bureaus
to settle automotive disputes
regarding vehicle repairs or the
interpretation of the New Vehicle
Limited Warranty. Although you may
be required to resort to this informal
dispute resolution program prior to
filing a court action, use of the
program is free of charge and your
case will generally be heard within
40 days. If you do not agree with the
decision given in your case, you may
reject it and proceed with any other
venue for relief available to you.
You may contact the BBB Auto Line
Program using the toll-free telephone
number or write them at the following
address:
BBB Auto Line Program
Council of Better Business Bureaus,
Inc.
3033 Wilson Boulevard
Suite 600
Arlington, VA 22201
Telephone: 1-800-955-5100
http://www.bbb.org/council/
programs-services/
dispute-handling-and-resolution/
bbb-auto-line
This program is available in all
50 states and the District of Columbia.
Eligibility is limited by vehicle age,
mileage, and other factors. General
Motors reserves the right to change
eligibility limitations and/or
discontinue its participation in this
program.
STEP THREE
—Canadian Owners :
In the event that you do not feel your
concerns have been addressed after
following the procedure outlined in
Steps One and Two, General Motors of
Canada Company wants you to be
aware of its participation in a
no-charge mediation/arbitration
program. General Motors of Canada
Company has committed to binding
