If this happens, slightly recline the vehicle’s
seatback and adjust the seat cushion if possible.
Also make sure the child restraint is not trapped
under the vehicle head restraint. If this happens,
adjust the head restraint.
If the on indicator is still lit, secure the child in
the child restraint in a rear seat position in
the vehicle and check with your dealer.
The passenger sensing system is designed to
enable (may inate) the right front passenger’s
frontal airbag anytime the system senses
that a person of adult size is sitting properly
in the right front passenger’s seat.When the passenger sensing system has allowed
the airbag to be enabled, the on indicator will
light and stay lit to remind you that the airbag
is active.
For some children who have outgrown child
restraints and for very small adults, the
passenger sensing system may or may not
turn off the right front passenger’s frontal airbag,
depending upon the person’s seating posture
and body build. Everyone in your vehicle who has
outgrown child restraints should wear a safety
belt properly — whether or not there is an
airbag for that person.
85

{CAUTION:
If the airbag readiness light in the
instrument panel cluster ever comes on
and stays on, it means that something
may be wrong with the airbag system.
If this ever happens, have the vehicle
serviced promptly, because an adult-size
person sitting in the right front passenger’s
seat may not have the protection of the
airbag(s). SeeAirbag Readiness Light on
page 201for more on this, including
important safety information.A thick layer of additional material such as a
blanket, or aftermarket equipment such as seat
covers, seat heaters and seat massagers
can affect how well the passenger sensing system
operates. Remove any additional material from
the seat cushion before reinstalling or securing the
child restraint or small occupant. You may want
to consider not using seat covers or other
aftermarket equipment if your vehicle has the
passenger sensing system. SeeAdding Equipment
to Your Airbag-Equipped Vehicle on page 89for
more information about modications that can
affect how the system operates.
87

Restraint System Check
Checking the Restraint Systems
Now and then, make sure the safety belt reminder
light and all your belts, buckles, latch plates,
retractors and anchorages are working properly.
Look for any other loose or damaged safety
belt system parts. If you see anything that might
keep a safety belt system from doing its job,
have it repaired. Keep safety belts clean and dry.
SeeCare of Safety Belts on page 439for more
information.
Torn or frayed safety belts may not protect you
in a crash. They can rip apart under impact
forces. If a belt is torn or frayed, get a new one
right away.Also look for any opened or broken airbag covers,
and have them repaired or replaced. The airbag
system does not need regular maintenance.
Notice:If you damage the covering for the
driver’s or the right front passenger’s airbag,
or the airbag covering on the driver’s and
right front passenger’s seatback, or the side
impact airbag covering on the ceiling near the
side windows, the bag may not work properly.
You may have to replace the airbag module
in the steering wheel, both the airbag module
and the instrument panel for the right front
passenger’s airbag, the airbag module
and seatback for the driver’s and right front
passenger’s seat-mounted side impact airbags,
or side impact airbag module and ceiling
covering for the roof-mounted side impact
airbag. Do not open or break the airbag
coverings.
90

Replacing Restraint System Parts
After a Crash
{CAUTION:
A crash can damage the restraint systems
in your vehicle. A damaged restraint
system may not properly protect the
person using it, resulting in serious injury
or even death in a crash. To help make sure
your restraint systems are working
properly after a crash, have them inspected
and any necessary replacements made as
soon as possible.
If you have had a crash, do you need new belts or
LATCH system parts?
After a very minor collision, nothing may be
necessary. But if the belts were stretched, as they
would be if worn during a more severe crash,
then you need new parts.
If the LATCH system was being used during a
more severe crash, you may need new LATCH
system parts.If belts are cut or damaged, replace them.
Collision damage also may mean you will need to
have LATCH system, safety belt or seat parts
repaired or replaced. New parts and repairs may
be necessary even if the belt or LATCH system
was not being used at the time of the collision.
If an airbag inates, you will need to replace airbag
system parts. See the part on the airbag system
earlier in this section.
If the frontal airbags inate, you will also need to
replace the driver’s and right front passenger’s
safety belt buckle assembly. Be sure to do so.
Then the new buckle assembly will be there to help
protect you in a collision.
After a crash you may need to replace the
driver and front passenger’s safety belt buckle
assemblies, even if the frontal airbags have
not deployed. The driver and front passenger’s
safety belt buckle assemblies contain the
safety belt pretensioners. Have your safety belt
pretensioners checked if your vehicle has been in
a collision, or if your airbag readiness light
stays on after you start your vehicle or while you
are driving. SeeAirbag Readiness Light on
page 201.
91

Rear-Seat Pass Through
If your vehicle has the rear seat-pass through
door, you can access the trunk without opening
the trunk lid. This is especially useful when
transporting long items.
To open the door, pull down the rear seat armrest.
Then pull the lever all the way down to release
the door.
To close the door, push it up and back into place.
Then try to open the door without pulling up on
the lever to make sure it is locked into place.
Emergency Trunk Release Handle
Notice:Do not use the emergency trunk
release handle as a tie-down or anchor point
when securing items in the trunk as it
could damage the handle. The emergency
trunk release handle is only intended to aid a
person trapped in a latched trunk, enabling
them to open the trunk from the inside.
There is a glow-in-the-dark emergency trunk
release handle located on the back wall of the
trunk. This handle will glow following exposure to
light. Pull the release handle toward the front
of the vehicle to open the trunk from the inside.
106

Express Window Anti-Pinch Override
{CAUTION:
If express override is activated, the
window will not reverse automatically.
You or others could be injured and the
window could be damaged. Before you
use express override, make sure that all
people and obstructions are clear of the
window path.
In an emergency, the anti-pinch feature can be
overridden in a supervised mode. Hold the window
switch all the way down in the express position.
The window will rise for as long as the switch
is held. Once the switch is released, the express
mode is re-activated.
In this mode, the window can still close on an
object in its path. Use care when using the
override mode.
Window Lockout
This feature allows you to disable the passenger
window switches.
The passenger window
lockout button is located
below the power window
switches on the driver’s
door armrest.
Press the button to disable the passenger window
controls. The light on the button will illuminate,
indicating that the feature is in use. The passenger
windows still can be raised or lowered using the
driver’s window switches when the lockout feature
is active.
To restore power to the passenger windows, press
the button again. The light on the button will go out.
You can program this feature to disable all
passenger windows or only the rear passenger
windows. SeeDIC Vehicle Personalization
on page 242for more information.
110

Sun Visors
Swing down the primary visor to block out glare.
It can also be detached from the center mount
and moved to the side to block glare from
that direction.
The driver’s visor may also have buttons for a
built-in garage door opener. SeeUniversal Home
Remote System on page 147for more
information.
Lighted Visor Vanity Mirror
Pull the visor down and lift the cover to access the
mirror. A light comes on when the cover is lifted
and goes out when it is closed.
Theft-Deterrent Systems
Vehicle theft is big business, especially in some
cities. Although your vehicle has a number of
theft-deterrent features, we know that nothing we
put on it can make it impossible to steal.
Theft-Deterrent System
If your vehicle has this
feature, the security
light is located on
the instrument panel
cluster.
If the ignition is off and a door is open, the
security light will ash, reminding you to arm the
theft-deterrent system.
111

To arm the system, do the following:
1. Lock the door using the Remote Keyless
Entry (RKE) transmitter or the power door
lock switch.
2. Close all the doors. The security light
will come on. It should go off within
approximately 30 seconds. Your security
system is now armed.
If a door or a trunk is opened without a key or a
RKE transmitter, the horn will sound and the lamps
will ash for up to 30 seconds.
The theft-deterrent system will not arm if you lock
the doors with a key or use the manual door
lock. It activates only if you use the RKE
transmitter or the power lock on the door.To avoid activating the alarm by accident do the
following:
Lock the door with the key or the manual door
lock after the doors are closed if you do not
want to arm the theft-deterrent system.
Always unlock a door with a key or use the
RKE transmitter. Pressing the unlock button
on the RKE transmitter disables the
theft-deterrent system.
Unlocking a door any other way will activate
the alarm when a door or the trunk is opened.
If you activate the alarm by accident, unlock the
driver’s door with your key. You can also turn
off the alarm by using the unlock button on the
RKE transmitter, or by starting the vehicle with a
valid key.
112

Testing the Alarm
1. Roll down the window, then get out of the
vehicle, keeping the door open.
2. From outside of the vehicle, with the door
open, lock the vehicle using the power door
lock switch or the RKE transmitter and close
the door. Wait approximately 30 seconds
until the security light goes off.
3. Reach in and unlock the door using the
manual lock and open the door. The horn
will sound and the exterior lamps will ash.
The alarm can be turned off by unlocking the
driver’s door with the key, using the unlock button
on the RKE transmitter or by starting the car
with a valid key.
If the alarm does not sound when it should, check
to see if the horn works. The horn fuse may be
blown. To replace the fuse, seeFuses and Circuit
Breakers on page 447. If the fuse does not need
to be replaced, you may need to have your vehicle
serviced.
To reduce the possibility of theft, always arm the
theft-deterrent system when leaving your vehicle.
Immobilizer
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following
two conditions:
1. This device may not cause interference.
2. This device must accept any interference
received, including interference that may
cause undesired operation.
This device complies with RSS-210 of Industry
Canada. Operation is subject to the following
two conditions:
1. This device may not cause interference.
2. This device must accept any interference
received, including interference that may
cause undesired operation of the device.
Changes or modications to this system by other
than an authorized service facility could void
authorization to use this equipment.
113

Immobilizer Operation
Your vehicle has a
passive theft-deterrent
system.
The system works when the key is turned to ON.
The key uses a transponder that matches an
immobilizer control unit in your vehicle. Only the
correct key will start the vehicle. If the key is ever
damaged, you may not be able to start your vehicle.When trying to start the vehicle, if the engine does
not start and the security light comes on, the
key may have a damaged transponder. Turn the
ignition off and try again.
If the engine still does not start, and the key
appears to be undamaged, try another ignition
key. At this time, you may also want to check
the fuse. SeeFuses and Circuit Breakers on
page 447. If the engine still does not start with the
other key, your vehicle needs service. If your
vehicle does start, the rst key may be faulty.
See your dealer who can service the
theft-deterrent system and have a new key made.
It is possible for the theft-deterrent system decoder
to learn the transponder value of a new or
replacement key. Up to 10 additional keys may be
programmed for the vehicle. The following
procedure is for programming additional keys only.
114
