CAUTION: (Continued)

Underinated tires pose the same
danger as overloaded tires. The
resulting accident could cause serious
injury. Check all tires frequently to
maintain the recommended pressure.
Tire pressure should be checked when
your tires are cold. SeeInflation - Tire
Pressure on page 5-66.
Overinated tires are more likely
to be cut, punctured, or broken by
a sudden impact — such as when
you hit a pothole. Keep tires at the
recommended pressure.
Worn, old tires can cause accidents. If
your tread is badly worn, or if your tires
have been damaged, replace them.
SeeHigh-Speed Operation on page 5-68for
ination pressure adjustment for high
speed driving.
Low-Prole Performance Tires
If your vehicle has 235/50ZR18 or P235/50R18
size tires, they are classied as low-prole tires.
These tires are designed for very responsive driving
on wet or dry pavement. You may also notice more
road noise with low-prole performance tires and
that they tend to wear faster.
Notice:If the vehicle has low-prole tires,
they are more susceptible to damage from road
hazards or curb impact than standard prole
tires. Tire and/or wheel assembly damage can
occur when coming into contact with road
hazards like, potholes, or sharp edged objects,
or when sliding into a curb. The vehicle
warranty does not cover this type of damage.
Keep tires set to the correct ination pressure
and, when possible avoid contact with curbs,
potholes, and other road hazards.
Summer Performance Tires
Many General Motors high performance models
come factory-equipped with tires that are optimized
for maximum dry and wet road performance while
still retaining satisfactory tread life, excellent
durability, and low noise levels. In severe winter
climates where snowfall may be signicant, these
tires may be found to provide less traction.
5-59

Outward Facing Sidewall:The side of an
asymmetrical tire that has a particular side that
faces outward when mounted on a vehicle.
The side of the tire that contains a whitewall,
bears white lettering, or bears manufacturer,
brand, and/or model name molding that is higher
or deeper than the same moldings on the other
sidewall of the tire.
Passenger (P-Metric) Tire
:A tire used on
passenger cars and some light duty trucks and
multipurpose vehicles.
Recommended Ination Pressure
:Vehicle
manufacturer’s recommended tire ination pressure
as shown on the tire placard. SeeInflation - Tire
Pressure on page 5-66andLoading the Vehicle
on page 4-22.
Radial Ply Tire
:A pneumatic tire in which the
ply cords that extend to the beads are laid at
90 degrees to the centerline of the tread.
Rim
:A metal support for a tire and upon which
the tire beads are seated.
Sidewall
:The portion of a tire between the tread
and the bead.
Speed Rating
:An alphanumeric code assigned to
a tire indicating the maximum speed at which a
tire can operate.Traction
:The friction between the tire and the
road surface. The amount of grip provided.
Tread
:The portion of a tire that comes into
contact with the road.
Treadwear Indicators
:Narrow bands, sometimes
called wear bars, that show across the tread of
a tire when only 1/16 inch (1.6 mm) of tread
remains. SeeWhen It Is Time for New Tires
on page 5-75.
UTQGS (Uniform Tire Quality Grading
Standards)
:A tire information system that
provides consumers with ratings for a tire’s
traction, temperature, and treadwear. Ratings are
determined by tire manufacturers using government
testing procedures. The ratings are molded into
the sidewall of the tire. SeeUniform Tire Quality
Grading on page 5-78.
Vehicle Capacity Weight
:The number of
designated seating positions multiplied by 150 lbs
(68 kg) plus the rated cargo load. SeeLoading
the Vehicle on page 4-22.
Vehicle Maximum Load on the Tire
:Load on
an individual tire due to curb weight, accessory
weight, occupant weight, and cargo weight.
5-65

TPMS Sensor Matching Process
Each TPMS sensor has a unique identication code.
Any time you replace one or more of the TPMS sensors
or rotate your vehicle’s tires, the identication codes
need to be matched to the new tire/wheel position.
The sensors are matched to the tire/wheel positions
in the following order: driver side front tire, passenger
side front tire, passenger side rear tire, and driver
side rear tire using a TPMS diagnostic tool. See your
dealer/retailer for service.
The TPMS sensors can also be matched to each
tire/wheel position by increasing or decreasing the tire’s
air pressure. If increasing the tire’s air pressure, do not
exceed the maximum ination pressure indicated on the
tire’s sidewall. To decrease the tire’s air-pressure use the
pointed end of the valve cap, a pencil-style air pressure
gage, or a key.
You have two minutes to match the rst tire/wheel
position, and ve minutes overall, to match all four
tire/wheel positions. If it takes longer than two minutes,
to match the rst tire and wheel, or more than
ve minutes to match all four tire and wheel positions,
the matching process stops and you need to start over.The TPMS matching process is outlined below:
1. Set the parking brake.
2. Turn the ignition switch to ON/RUN with the
engine off.
3. Press the Remote Keyless Entry (RKE) transmitter’s
lock and unlock buttons at the same time for
approximately ve seconds. The horn sounds twice
to signal the receiver is in relearn mode and Tire
Learning Active message displays on the DIC
screen.
4. Start with the driver side front tire.
5. Remove the valve cap from the valve stem.
Activate the TPMS sensor by increasing or
decreasing the tire’s air pressure for 10 seconds,
or until a horn chirp sounds. The horn chirp, which
can take up to 30 seconds to sound, conrms
that the TPMS sensor identication code has
been matched to this tire position.
6. Proceed to the passenger side front tire, and repeat
the procedure in Step 5.
7. Proceed to the passenger side rear tire, and repeat
the procedure in Step 5.
8. Proceed to the driver side rear tire, and repeat the
procedure in Step 5.
5-73

9. After hearing the conrming horn chirp, for the
driver side rear tire, the horn sounds two more
times to signal the tire learning mode is no longer
active. Turn the ignition switch to LOCK/OFF.
10. Set all four tires to the recommended air pressure
level as indicated on the tire and loading information
label.
11. Put the valve caps back on the valve stems.
Tire Inspection and Rotation
We recommend that you regularly inspect your
vehicle’s tires, including the spare tire, for signs
of wear or damage. SeeWhen It Is Time for New
Tires on page 5-75for more information.
Tires should be rotated every 5,000 to 8,000 miles
(8 000 to 13 000 km). SeeScheduled Maintenance
on page 6-4.
The purpose of a regular tire rotation is to achieve
a uniform wear for all tires on the vehicle. This will
ensure that your vehicle continues to perform most
like it did when the tires were new.
If your vehicle has 235/50ZR18 size tires, GM
recommends rotating these tires at 3,000 mile
(4 800 km) intervals. These tires are optimized fordry traction and handling performance. Tread life
may be 15,000 miles (24 140 km) or less for these
tires, depending on how and where you drive.
Any time you notice unusual wear, rotate your
vehicle’s tires as soon as possible and check
wheel alignment. Also check for damaged tires
or wheels. SeeWhen It Is Time for New Tires on
page 5-75andWheel Replacement on page 5-80
for more information.
When rotating your vehicle’s tires, always use the
correct rotation pattern shown here.
If your vehicle has a compact spare tire, do not
include it in the tire rotation.
5-74

Current and Past Model Order Forms
Technical Service Bulletins and Manuals are available
for current and past model GM vehicles. To request
an order form, specify year and model name of
the vehicle.
ORDER TOLL FREE: 1-800-551-4123
Monday-Friday 8:00 AM - 6:00 PM
Eastern Time
For Credit Card Orders Only
(VISA-MasterCard-Discover), visit Helm, Inc. on
the World Wide Web at: helminc.com
Or you can write to:
Helm, Incorporated
P.O. Box 07130
Detroit, MI 48207
Prices are subject to change without notice and without
incurring obligation. Allow ample time for delivery.
Note to Canadian Customers: All listed prices are
quoted in U.S. funds. Canadian residents are to make
checks payable in U.S. funds.
Vehicle Data Recording and
Privacy
Your GM vehicle has a number of sophisticated
computers that record information about the vehicle’s
performance and how it is driven. For example,
your vehicle uses computer modules to monitor and
control engine and transmission performance, to monitor
the conditions for airbag deployment and deploy
airbags in a crash and, if so equipped, to provide
antilock braking to help the driver control the vehicle.
These modules may store data to help your
dealer/retailer technician service your vehicle.
Some modules may also store data about how you
operate the vehicle, such as rate of fuel consumption
or average speed. These modules may also retain
the owner’s personal preferences, such as radio
pre-sets, seat positions, and temperature settings.
7-18

Engine
Air Cleaner/Filter.........................................5-21
Check and Service Engine Soon Light............3-41
Coolant......................................................5-28
Coolant Heater............................................2-37
Coolant Temperature Gage...........................3-40
Coolant Temperature Warning Light................3-40
Cover........................................................5-21
Drive Belt Routing.......................................6-17
Engine Compartment Overview......................5-14
Exhaust.....................................................2-48
Oil .............................................................5-16
Oil Life System...........................................5-19
Oil Pressure Gage.......................................3-45
Overheated Protection Operating Mode...........5-33
Overheating................................................5-31
Speed Limiter.............................................3-32
Starting......................................................2-35
Entry Lighting.................................................3-20
Event Data Recorders.....................................7-19
Extender, Safety Belt.......................................1-32
Exterior Lighting Battery Saver..........................3-20
F
Filter
Engine Air Cleaner......................................5-21
Finish Damage.............................................5-119
Flashers, Hazard Warning.................................. 3-6Flash-to-Pass................................................... 3-9
Flat Tire........................................................5-82
Flat Tire, Changing........................................5-102
Flat Tire, Storing...........................................5-110
Fluid.............................................................5-26
Automatic Transmission................................5-25
Power Steering...........................................5-39
Windshield Washer......................................5-40
Fog Lamp
Fog ...........................................................3-19
Fog Lamp Light..............................................3-46
Folding Rear Seat...........................................1-11
Fuel............................................................... 5-6
Additives...................................................... 5-8
California Fuel.............................................. 5-7
Filling a Portable Fuel Container....................5-11
Filling the Tank............................................. 5-9
Fuels in Foreign Countries.............................. 5-8
Gage .........................................................3-47
Gasoline Octane........................................... 5-7
Gasoline Specications.................................. 5-7
Running Out of...........................................2-49
Fuses
Fuses and Circuit Breakers.........................5-123
Rear Compartment Fuse Block....................5-126
Underhood Fuse Block...............................5-123
Windshield Wiper.......................................5-122
5

N
Navigation System, Privacy..............................7-20
Navigation/Radio System,
see Navigation Manual...............................3-111
New Vehicle Break-In......................................2-32
O
Odometer......................................................3-32
Odometers, Trip..............................................3-32
Off-Road Recovery..........................................4-12
Oil
Engine.......................................................5-16
Engine Oil Pressure Gage............................3-45
Pressure Light.............................................3-44
Oil, Engine Oil Life System..............................5-19
Older Children, Restraints................................1-32
Online Owner Center........................................ 7-5
OnStar, Privacy..............................................7-20
OnStar
®System, see OnStar®Manual...............2-55
Operation, Universal Home Remote System........2-58
Outlet Adjustment............................................3-28
Outlets
Accessory Power.........................................3-22
Outside
Convex Mirror.............................................2-51
Heated Mirrors............................................2-51
Power Mirrors.............................................2-50Overheated Engine Protection Operating Mode . . . 5-33
Owner Checks and Services.............................6-10
Owners, Canadian.............................................. iii
P
Paint, Damage..............................................5-119
Panic Brake Assist............................................ 4-9
Parade Dimming.............................................3-20
Park
Shifting Into................................................2-45
Shifting Out of............................................2-47
Park Aid........................................................2-52
Park Brake....................................................2-44
Park Tilt Mirrors..............................................2-51
Parking
Assist........................................................2-52
Over Things That Burn.................................2-48
Parking Your Vehicle.......................................2-47
Passenger Airbag Status Indicator.....................3-35
Passenger Compartment Air Filter.....................3-29
Passenger Sensing System..............................1-65
Passing.........................................................4-12
Perchlorate Materials Requirements, California...... 5-5
Phone
Bluetooth
®................................................3-111
Power
Door Locks.................................................2-19
Electrical System.......................................5-122
9
