Page 179 of 354
Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-MidEast-9369309) -
2016 - crc - 7/30/15
178 Driving and Operating
Driving and
Operating
Driving Information
Distracted Driving . . . . . . . . . . . . 179
Defensive Driving . . . . . . . . . . . . . 180
Control of a Vehicle . . . . . . . . . . . 180
Braking . . . . . . . . . . . . . . . . . . . . . . . 180
Steering . . . . . . . . . . . . . . . . . . . . . . 180
Off-Road Recovery . . . . . . . . . . . 181
Loss of Control . . . . . . . . . . . . . . . 182
Track Events and CompetitiveDriving . . . . . . . . . . . . . . . . . . . . . . 182
Driving on Wet Roads . . . . . . . . 186
Hill and Mountain Roads . . . . . 187
Winter Driving . . . . . . . . . . . . . . . . 187
If the Vehicle Is Stuck . . . . . . . . 189
Vehicle Load Limits . . . . . . . . . . . 189
Starting and Operating
New Vehicle Break-In . . . . . . . . . 193
Carbon Fiber . . . . . . . . . . . . . . . . . 193
Ignition Positions . . . . . . . . . . . . . 193
Starting the Engine . . . . . . . . . . . 195
Retained Accessory Power (RAP) . . . . . . . . . . . . . . . . 197
Shifting Into Park . . . . . . . . . . . . . 197
Shifting out of Park . . . . . . . . . . . 198 Parking over Things
That Burn . . . . . . . . . . . . . . . . . . . 199
Engine Exhaust
Engine Exhaust . . . . . . . . . . . . . . 199
Running the Vehicle WhileParked . . . . . . . . . . . . . . . . . . . . . . 199
Automatic Transmission
Automatic Transmission . . . . . . 200
Manual Mode . . . . . . . . . . . . . . . . . 202
Drive Systems
All-Wheel Drive . . . . . . . . . . . . . . . 203
Brakes
Antilock BrakeSystem (ABS) . . . . . . . . . . . . . . . 203
Electric Parking Brake . . . . . . . . 204
Brake Assist . . . . . . . . . . . . . . . . . . 206
Ride Control Systems
Traction Control/Electronic Stability Control . . . . . . . . . . . . . 206
Driver Mode Control . . . . . . . . . . 208
Competitive Driving Mode (V-Series Only) . . . . . . . . . . . . . . 211
Limited-Slip Differential (Except V-Series) . . . . . . . . . . . 214
Limited-Slip Differential (V-Series Only) . . . . . . . . . . . . . . 214
Cruise Control
Cruise Control . . . . . . . . . . . . . . . . 214
Adaptive Cruise Control . . . . . . 217
Driver Assistance Systems
Driver Assistance Systems . . . 224
Assistance Systems forParking or Backing . . . . . . . . . . 225
Assistance Systems for Driving . . . . . . . . . . . . . . . . . . . . . . 231
Forward Collision Alert (FCA) System . . . . . . . . . . . . . . . . . . . . . . 232
Front Automatic Braking (FAB) System . . . . . . . . . . . . . . . . . . . . . . 234
Side Blind Zone Alert (SBZA) . . . . . . . . . . . . . . . . 236
Lane Change Alert (LCA) . . . . . 236
Lane Departure Warning (LDW) . . . . . . . . . . . . . 238
Lane Keep Assist (LKA) . . . . . . 238
Fuel
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . 240
Fuel Additives . . . . . . . . . . . . . . . . 241
Filling the Tank . . . . . . . . . . . . . . . 241
Filling a Portable Fuel Container . . . . . . . . . . . . . . . . . . . 242
Trailer Towing
General TowingInformation . . . . . . . . . . . . . . . . . . 243
Page 212 of 354
Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-MidEast-9369309) -
2016 - crc - 7/30/15
Driving and Operating 211
.Snow/Ice –The transmission will
use 2 (Second) gear instead of
1 (First) gear when accelerating
from a stop. The vehicle will
upshift normally when the
vehicle is moving. The
transmission will also shift
differently to assist in
maintaining traction.
Steering (Assist Effort)
Adjusts from a lighter steering feel
in Tour mode to reduced assist in
Sport and Track mode for more
steering feel.
Magnetic Ride Control (if
equipped)
Adjusts the shock dampening
firmness from a comfort tune in Tour
mode to an optimized
responsiveness tune in Sport and
Track.
Launch Control
Available only in Track mode for
maximum “off-the-line” acceleration
when in Competitive Driving Mode
or PTM. Stability Control
.
Competitive mode allows less
computer control to permit some
slide and drift and is selected
with the button –only available
in Track mode.
. StabiliTrak can be turned off by
pressing and holding the button
for five seconds.
PTM (Performance Traction
Management) (if equipped)
. Available in Track Mode.
. There are five selectable
settings.
Competitive Driving Mode
(V-Series Only)
To select this optional handling
mode, press the
Ybutton quickly
two times and the DIC will display
the appropriate message. While in
the Competitive Driving Mode, the
traction off light
iand StabiliTrak
OFF light
gwill come on in the
instrument cluster. TCS does not
limit wheel spin, the Electronic Limited-Slip Differential (ELSD)
allows increased vehicle agility, and
more effort is required to turn the
steering wheel. See
“Limited-Slip
Differential (V-Series Only)” later in
this section. Adjust your driving
accordingly.
Press the
Ybutton again, or turn
the ignition to ACC/ACCESSORY
and restart the vehicle, to turn TCS
back on. The traction off light
iand
StabiliTrak OFF light
gwill go out in
the instrument cluster.
Caution
When traction control is turned
off, or Competitive Driving Mode
is active, it is possible to lose
traction.
Performance Traction
Management (V-Series Only)
Performance Traction Management
(PTM) integrates the Traction
Control, StabiliTrak, and Selective
Ride Control systems to provide
improved and consistent
Page 215 of 354
Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-MidEast-9369309) -
2016 - crc - 7/30/15
214 Driving and Operating
Limited-Slip Differential
(Except V-Series)
If equipped, the mechanical
limited-slip differential can give more
traction on snow, mud, ice, sand,
or gravel. It works like a standard
axle most of the time, but when
traction is low, this feature allows
the drive wheel with the most
traction to move the vehicle. For
vehicles with limited slip differential,
driven under severe conditions, the
rear axle fluid should be changed.
SeeCompetitive Driving Mode
(V-Series Only) 0211 and
Maintenance Schedule 0329.
Limited-Slip Differential
(V-Series Only)
If equipped, the Electronic
Limited-Slip Differential (ELSD) is
automatically activated. ELSD
actively monitors vehicle sensors
and driver inputs to determine the
amount of change for the
conditions. With ELSD, the
vehicle has:
.
Enhanced high-speed control. .
Improved traction through
corners, allowing more
acceleration.
. More precise steering.
. Increased vehicle agility.
. Integration with StabiliTrak.
For vehicles with ELSD, driven
under severe conditions, the rear
axle fluid should be changed. See
Competitive Driving Mode (V-Series
Only) 0211 and Maintenance
Schedule 0329.
Cruise Control
{Warning
Cruise control can be dangerous
where you cannot drive safely at
a steady speed. Do not use
cruise control on winding roads or
in heavy traffic.
Cruise control can be dangerous
on slippery roads. On such roads,
fast changes in tire traction can
cause excessive wheel slip, and
you could lose control. Do not use
cruise control on slippery roads.
With cruise control, a speed of
about 40 km/h (25 mph) or more can
be maintained without keeping your
foot on the accelerator. Cruise
control does not work at speeds
below about 40 km/h (25 mph).
If the StabiliTrak
®system begins to
limit wheel spin while using cruise
control, the cruise control
automatically disengages. See
Traction Control/Electronic Stability
Control 0206. If a collision alert
Page 289 of 354
Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-MidEast-9369309) -
2016 - crc - 7/30/15
288 Vehicle Care
Number Usage*1 Electronic limited slip differential/DC
DC transformer
2 Left window
3 Body control module 8
*4 A/C inverter 5 Passive entry passive start
battery 1
6 Body control module 4
7 Heated mirrors
8 Amplifier
9 Rear window defogger
10 Glass break
*11 Trailer connector 12 OnStar (if equipped)
13 Right window
14 Electric parking brake
15 Not used Number Usage
16 Trunk release
*17 Run relay
*18 Logistics relay
*19 Logistics fuse 20 Rear window defogger relay
21 Mirror window module
22 Pedestrian protection
23 Canister vent
24 Body control module 2
*25 Rear vision camera
*26 Front ventilated seats
*27 SBZA/LDW/EOCM
*28 Trailer/Sunshade
*29 Rear heated seats
*30 Semi-active damping system Number Usage
*31 Transfer case control module/
Electronic limited
slip differential
32 Theft module/ Universal garage
door opener/Rain
sensor
*33 UPA
*34 Radio, DVD
35 Spare
*36 Trailer 37 Fuel pump, fuel system control
module
38 Not used
39 Not used
40 Not used
41 Not used
*42 Memory seat module
43 Body control module 3
Page 334 of 354
Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-MidEast-9369309) -
2016 - crc - 7/30/15
Service and Maintenance 333
Recommended Fluids, Lubricants, and Parts
Recommended Fluids and Lubricants
UsageFluid/Lubricant
Engine Oil Engine oil meeting the dexos1™ specification of the proper SAE viscosity
grade. AC Delco dexos1 Synthetic Blend is recommended. See Engine Oil
0 259.
Engine Coolant 50/50 mixture of clean, drinkable water and use only DEX-COOL
®Coolant.
See Engine Coolant 0266.
Hydraulic Brake System DOT 3 Hydraulic Brake Fluid (GM Part No. 19299818). Windshield Washer Automotive windshield washer fluid that meets regional freeze protection requirements.
Automatic Transmission DEXRON
®-HP Automatic Transmission Fluid (GM Part No. 19300536).
Transfer Case (All-Wheel Drive) Transfer Case Fluid (GM Part No. 88861950). Front Axle (AWD Only) SAE 75W-90 Synthetic Axle Lubricant (GM Part No. 88863089).
Rear Axle (Non-Limited Slip Differential) SAE 75W-90 Synthetic Axle Lubricant (GM Part No. 88863089).
Rear Axle (Limited-Slip Differential) SAE 75W-90 Synthetic Axle Lubricant (GM Part No. 88862624). Electronic Limited Slip Differential(eLSD) Clutch System Lubricant (CTS-V Only) DEXRON
®-VI Automatic Transmission Fluid.
Page 347 of 354
Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-MidEast-9369309) -
2016 - crc - 7/30/15
346 Index
Coolant (cont'd)Engine Temperature Gauge . . .117
Engine Temperature
Warning Light . . . . . . . . . . . . . . . 126
Cooling System . . . . . . . . . . . . . . . . . 264 Engine Messages . . . . . . . . . . . . 137
Cruise Control . . . . . . . . . . . . . . . . . . 214 Light . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Messages . . . . . . . . . . . . . . . . . . . . 136
Cruise Control, Adaptive . . . . . . . . 217
Cupholders . . . . . . . . . . . . . . . . . . . . . 101
D
Danger, Warning, and Caution . . . . 2
Data Recorder Performance . . . . . . . . . . . . . . . . . . 163
Data Recorders, Event . . . . . . . . . 342
Daytime Running Lamps (DRL) . . . . . . . . . . . . . . . . . . 157
Defensive Driving . . . . . . . . . . . . . . . 180
Delayed Locking . . . . . . . . . . . . . . . . . 37
Differential, Limited-Slip . . . . . . . . 214
Distracted Driving . . . . . . . . . . . . . . . 179
Dome Lamps . . . . . . . . . . . . . . . . . . . 160
Door Ajar Light . . . . . . . . . . . . . . . . . . . . . 129
Ajar Messages . . . . . . . . . . . . . . . 137
Delayed Locking . . . . . . . . . . . . . . . . 37
Locks . . . . . . . . . . . . . . . . . . . . . . . . . . . 35 Door (cont'd)
Power Locks . . . . . . . . . . . . . . . . . . . . 37
Rear Seat Pass-Through . . . . . . . 64
Drive Belt Routing, Engine . . . . . . 341
Drive Systems
All-Wheel Drive . . . . . . . . . . 203, 274
Driver Assistance Systems . . . . . 224
Driver Information Center (DIC) . . . . . . . . . . . . . . . . . . 129
Driver Mode Control . . . . . . . . . . . . 208
Driving Assistance Systems . . . . . . . . . . 231
Characteristics andTowing Tips . . . . . . . . . . . . . . . . . 243
Competitive . . . . . . . . . . . . . . . . . . . .211
Defensive . . . . . . . . . . . . . . . . . . . . . 180
For Better Fuel Economy . . . . . . . 26
Hill and Mountain Roads . . . . . . 187
If the Vehicle is Stuck . . . . . . . . . 189
Loss of Control . . . . . . . . . . . . . . . 182
Off-Road Recovery . . . . . . . . . . . 181
Track Events and Competitive . . . . . . . . . . . . . . . . . 182
Vehicle Load Limits . . . . . . . . . . . 189
Wet Roads . . . . . . . . . . . . . . . . . . . 186
Winter . . . . . . . . . . . . . . . . . . . . . . . . 187
Dual Automatic Climate Control System . . . . . . . . . . . . . . . . 169
E
Electric Parking Brake . . . . . . . . . . 204
Electrical Equipment,
Add-On . . . . . . . . . . . . . . . . . . . . . . . 248
Electrical System
Engine Compartment FuseBlock . . . . . . . . . . . . . . . . . . . . . . . . 281
Fuses and Circuit Breakers . . . 280
Instrument Panel Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 284
Overload . . . . . . . . . . . . . . . . . . . . . 280
Rear Compartment Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 287
Engine
Air Cleaner/Filter . . . . . . . . . . . . . 263
Check and Service EngineSoon Light . . . . . . . . . . . . . . . . . . 121
Compartment Overview . . . . . . . 252
Coolant . . . . . . . . . . . . . . . . . . . . . . . 266
Coolant Temperature Gauge . . . . . . . . . . . . . . . . . . . . . . .117
Coolant Temperature Warning Light . . . . . . . . . . . . . . . 126
Cooling System . . . . . . . . . . . . . . . 264
Cooling System Messages . . . 137
Drive Belt Routing . . . . . . . . . . . . 341
Exhaust . . . . . . . . . . . . . . . . . . . . . . 199
Oil Life System . . . . . . . . . . . . . . . 261
Page 350 of 354
Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-MidEast-9369309) -
2016 - crc - 7/30/15
Index 349
Lights (cont'd)Engine Oil Pressure . . . . . . . . . . 127
Flash-to-Pass . . . . . . . . . . . . . . . . . 157
High-Beam On . . . . . . . . . . . . . . . . 128
High/Low Beam Changer . . . . . 157
Low Fuel Warning . . . . . . . . . . . . 127
Safety Belt Reminders . . . . . . . . .118
Security . . . . . . . . . . . . . . . . . . . . . . 127
Service Electric Parking
Brake . . . . . . . . . . . . . . . . . . . . . . . 123
StabiliTrak
®OFF . . . . . . . . . . . . . 125
Tire Pressure . . . . . . . . . . . . . . . . . 126
Traction Control System (TCS)/StabiliTrak
®. . . . . . . . . . 125
Traction Off . . . . . . . . . . . . . . . . . . . 125
Limited-Slip Differential . . . . . . . . . 214
Locks Automatic Door . . . . . . . . . . . . . . . . . 38
Delayed Locking . . . . . . . . . . . . . . . . 37
Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Lockout Protection . . . . . . . . . . . . . . 38
Power Door . . . . . . . . . . . . . . . . . . . . . 37
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Loss of Control . . . . . . . . . . . . . . . . . 182
Low Fuel Warning Light . . . . . . . . . 127
Low-Profile Tires . . . . . . . . . . . . . . . . 292 Lower Anchors and Tethers
for Children (LATCH
System) . . . . . . . . . . . . . . . . . . . . . . . . 89
Lumbar Adjustment . . . . . . . . . . . . . . 56 Front Seats . . . . . . . . . . . . . . . . . . . . . 56
M
MaintenanceRecords . . . . . . . . . . . . . . . . . . . . . . 336
Maintenance Schedule . . . . . . . . . 329 Recommended Fluids andLubricants . . . . . . . . . . . . . . . . . . . 333
Malfunction Indicator Lamp . . . . . 121
Manual Mode . . . . . . . . . . . . . . . . . . . 202
Memory Features . . . . . . . . . . . . . . . . 13
Memory Seats . . . . . . . . . . . . . . . . . . . 58
Messages Airbag System . . . . . . . . . . . . . . . . 144
Battery Voltage andCharging . . . . . . . . . . . . . . . . . . . . 135
Brake System . . . . . . . . . . . . . . . . 136
Door Ajar . . . . . . . . . . . . . . . . . . . . . 137
Engine Cooling System . . . . . . . 137
Engine Oil . . . . . . . . . . . . . . . . . . . . 138
Engine Power . . . . . . . . . . . . . . . . 138
Fuel System . . . . . . . . . . . . . . . . . . 138
Key and Lock . . . . . . . . . . . . . . . . . 139
Lamp . . . . . . . . . . . . . . . . . . . . . . . . . 139
Object Detection System . . . . . 140 Messages (cont'd)
Ride Control System . . . . . . . . . . 142
Safety Belt . . . . . . . . . . . . . . . . . . . . 145
Security . . . . . . . . . . . . . . . . . . . . . . 145
Service Vehicle . . . . . . . . . . . . . . . 145
Starting the Vehicle . . . . . . . . . . . 145
Tire . . . . . . . . . . . . . . . . . . . . . . . . . . . 146
Transmission . . . . . . . . . . . . . . . . . 146
Vehicle . . . . . . . . . . . . . . . . . . . . . . . 135
Vehicle Reminder . . . . . . . . . . . . . 146
Vehicle Speed . . . . . . . . . . . . . . . . 147
Washer Fluid . . . . . . . . . . . . . . . . . 147
Mirrors Automatic Dimming
Rearview . . . . . . . . . . . . . . . . . . . . . . 45
Convex . . . . . . . . . . . . . . . . . . . . . . . . . 43
Heated . . . . . . . . . . . . . . . . . . . . . . . . . 44
Power . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Tilt in Reverse . . . . . . . . . . . . . . . . . . 44
Mirrors, Interior Rearview . . . . . . . . 45
Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 208 Driver Control . . . . . . . . . . . . . . . . . 208
Monitor System, Tire
Pressure . . . . . . . . . . . . . . . . . . . . . . 294
Page 353 of 354
Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-MidEast-9369309) -
2016 - crc - 7/30/15
352 Index
Steering (cont'd)Wheel Controls . . . . . . . . . . . . . . . 105
Storage Areas Armrest . . . . . . . . . . . . . . . . . . . . . . . 101
Center Console . . . . . . . . . . . . . . . 101
Convenience Net . . . . . . . . . . . . . 102
Glove Box . . . . . . . . . . . . . . . . . . . . 100
Instrument Panel . . . . . . . . . . . . . 100
Storage Compartments . . . . . . . . . 100
Storing the Tire Sealant and
Compressor Kit . . . . . . . . . . . . . . . 312
Stuck Vehicle . . . . . . . . . . . . . . . . . . . 189
Summer Tires . . . . . . . . . . . . . . . . . . 292
Sun Visors . . . . . . . . . . . . . . . . . . . . . . . 48
Sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Sunshade Rear Window . . . . . . . . . . . . . . . . . . . 48
Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . 3
System
Forward CollisionAlert (FCA) . . . . . . . . . . . . . . . . . . 232
Infotainment . . . . . . . . . . . . . 163, 343
Systems
Driver Assistance . . . . . . . . . . . . . 224T
Tachometer . . . . . . . . . . . . . . . . . . . . . 116
Theft-Deterrent Systems . . . . . . . . . 42
Thigh Support Adjustment . . . . . . . 57
Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . 289All-Season . . . . . . . . . . . . . . . . . . . . 290
Buying New Tires . . . . . . . . . . . . . 301
Chains . . . . . . . . . . . . . . . . . . . . . . . . 304
Different Size . . . . . . . . . . . . . . . . . 302
If a Tire Goes Flat . . . . . . . . . . . . 304
Inspection . . . . . . . . . . . . . . . . . . . . 298
Low Profile . . . . . . . . . . . . . . . . . . . 292
Messages . . . . . . . . . . . . . . . . . . . . 146
Pressure . . . . . . . . . . . . . . . . . . . . . . 294
Pressure Light . . . . . . . . . . . . . . . . 126
Pressure Monitor Operation . . 295
Pressure Monitor System . . . . . 294
Rotation . . . . . . . . . . . . . . . . . . . . . . 299
Run-Flat . . . . . . . . . . . . . . . . . . . . . . 291
Sealant andCompressor Kit . . . . . . . . . . . . . 306
Sealant and Compressor Kit, Storing . . . . . . . . . . . . . . . . . . 312
Wheel Alignment and Tire Balance . . . . . . . . . . . . . . . . . . . . . 303
Wheel Replacement . . . . . . . . . . 303 Tires (cont'd)
When It Is Time for New
Tires . . . . . . . . . . . . . . . . . . . . . . . . 300
Winter . . . . . . . . . . . . . . . . . . . . . . . . 290
Towing Driving Characteristics . . . . . . . . 243
Equipment . . . . . . . . . . . . . . . 247, 248
General Information . . . . . . . . . . 243
Recreational Vehicle . . . . . . . . . . 316
Trailer . . . . . . . . . . . . . . . . . . . 246–248
Vehicle . . . . . . . . . . . . . . . . . . . . . . . 315
Track Events and Competitive Driving . . . . . . . . . . . 182
Traction
Control System (TCS)/StabiliTrak
®Light . . . . . . . . . . . . 125
Limited-Slip Differential . . . . . . . 214
Off Light . . . . . . . . . . . . . . . . . . . . . . 125
Traction Control/Electronic Stability Control . . . . . . . . . . . . . . . 206
Trailer Towing . . . . . . . . . . . . . . . . . . . 246–248
Transmission
Automatic . . . . . . . . . . . . . . . . . . . . . 200
Fluid, Automatic . . . . . . . . . . . . . . 262
Messages . . . . . . . . . . . . . . . . . . . . 146
Trip Odometer . . . . . . . . . . . . . . . . . . 116
Trunk . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
