Vehicle Care/Appearance Materials
See your GM dealer for more information on purchasing
the following products.
Description Usage
Polishing Cloth
Wax-TreatedInterior and exterior
polishing cloth.
Tar and Road
Oil RemoverRemoves tar, road oil,
and asphalt.
Chrome Cleaner
and PolishUse on chrome or
stainless steel.
White Sidewall
Tire CleanerRemoves soil and black
marks from whitewalls.
Vinyl CleanerCleans vinyl tops,
upholstery, and
convertible tops.
Glass CleanerRemoves dirt, grime,
smoke and ngerprints.
Chrome and Wire
Wheel CleanerRemoves dirt and grime
from chrome wheels and
wire wheel covers.
Finish EnhancerRemoves dust,
ngerprints, and surface
contaminants. Spray on
and wipe off.
Description Usage
Swirl Remover PolishRemoves swirl marks, ne
scratches, and other light
surface contamination.
Cleaner WaxRemoves light scratches
and protects nish.
Foaming Tire Shine
Low GlossCleans, shines, and
protects in one step.
No wiping necessary.
Wash Wax ConcentrateMedium foaming
shampoo. Cleans and
lightly waxes.
Biodegradable and
phosphate free.
Spot LifterQuickly removes spots
and stains from carpets,
vinyl, and cloth
upholstery.
Odor EliminatorOdorless spray odor
eliminator used on fabrics,
vinyl, leather and carpet.
See your General Motors parts department for these
products. SeeRecommended Fluids and Lubricants
on page 6-13.
5-98

Fuses Usage
RT PARKPassenger’s Side Taillamp
Assembly, Front Sidemarker and
Front Parking Lamp Assembly
HORN Dual Horn Assembly
LT HI BEAM Driver’s Side High-Beam Headlamp
LT LOW BEAM Driver’s Side Low-Beam Headlamp
RT LOW BEAMPassenger’s Side Low-Beam
Headlamp
RT HI BEAMPassenger’s Side High-Beam
Headlamp
SPARE Not Used
SPARE Not Used
THEFTECM (Electronic Control Module),
TCM (Transmission Control Module),
PASS-Key
®III+ Module
LT PARKDriver’s Side Taillamp Assembly,
Front Sidemarker and Front Parking
Lamp Assembly
DIMMINGRear License Plate Assembly,
Dash Integrated Module (DIM)
DIM/ALDLDIM, ALDL (Assembly Line
Data Link)
Fuses Usage
FLASHER Turn Signal/Hazard Flasher Module
ECM Electronic Control Module
STRG CTLSSteering Wheel Control Pad,
Headlamp Switch
HTR VLV/
CLTCHHeater Valve, Clutch Switch
(Normal Closed), Clutch Switch
(Normal Open), Jumper to Start
Relay Coil for Automatic
Transmission
WASH NOZDriver’s and Passenger’s Side
Heated Washer Nozzles
PRE O2/CAMDriver’s & Passenger’s Side Oxygen
Sensors, Transmission Output
Speed Sensor, CAM Phaser
TCM/IPCTCM, ECM and IPC
(Instrument Panel Cluster)
SPARE Not Used
IGN MOD/MAF Front Bank Ignition Modules
ELEC PRNDL Electronic PRNDL
SPARE Not Used
SPARE Not Used
5-103

Capacities and Specications
The following approximate capacities are given in English and metric conversions. SeeRecommended Fluids and
Lubricants on page 6-13for more information.
ApplicationCapacities
English Metric
Air Conditioning Refrigerant R134a
Use Refrigerant Oil, R134a Systems1.3 lbs 0.59 kg
Cooling System
3.2L V6
3.6L HFV6
5.7L V810.4 quarts
9.7 quarts
13.2 quarts9.8 L
9.2 L
12.5 L
Engine Oil with Filter
3.2L V6
3.6L HFV6
5.7L V85.0 quarts
5.6 quarts
6.0 quarts4.8 L
5.3 L
5.7 L
Fuel Tank 17.5 gallons 66.2 L
Transmission
Automatic
5-Speed Manual
6-Speed Manual9.0 quarts
1.3 quarts
3.7 quarts8.5 L
1.2 L
3.5 L
Wheel Nut Torque 100 ft lb (140Y)
All capacities are approximate. When adding, be sure to ll to the approximate level, as recommended in this
manual. Recheck uid level after lling.
5-111

Overseas — Customer Assistance
Please contact the local General Motors Business Unit.
Mexico, Central America and
Caribbean Islands/Countries
(Except Puerto Rico and U.S. Virgin
Islands) — Customer Assistance
General Motors de Mexico, S. de R.L. de C.V.
Customer Assistance Center
Paseo de la Reforma # 2740
Col. Lomas de Bezares
C.P. 11910, Mexico, D.F.
01-800-508-0000
Long Distance: 011-52-53 29 0 800
GM Mobility Program for Persons
with Disabilities
This program, available to
qualied applicants, can
reimburse you up to
$1,000 toward eligible
aftermarket driver or
passenger adaptive
equipment that may be
required for your vehicle,
such as hand controls,
wheelchair/scooter
lifts, etc.
This program can also provide you with free resource
information, such as area driver assessment centers and
mobility equipment installers. The offer is available for
a limited period of time from the date of vehicle
purchase/lease. For more details, or to determine your
vehicle’s eligibility, see your GM dealer or call the
GM Mobility Assistance Center at 1-800-323-9935.
Text telephone (TTY) users, call 1-800-833-9935.
GM of Canada also has a Mobility Program.
Call 1-800-GM-DRIVE (463-7483) for details.
All TTY users call 1-800-263-3830.
7-5

A
Accessing the DIC Main Menu
(Base Audio System)...................................3-66
Accessory Power Outlets.................................3-27
Activating Program Type (PTY) Stations
(RDS and XM™).......................................3-116
Adding Washer Fluid.......................................5-41
Additional Program Information........................... 7-9
Additives, Fuel................................................. 5-6
Add-On Electrical Equipment...........................5-100
Adjusting the Speakers (Balance/Fade).............3-113
Air Cleaner/Filter, Engine.................................5-24
Air Conditioning..............................................3-29
Airbag
Readiness Light..........................................3-42
Airbag Sensing and Diagnostic Module (SDM)......... 7-9
Airbag Systems..............................................1-48
Adding Equipment to Your
Airbag-Equipped Vehicle............................1-58
How Does an Airbag Restrain?......................1-55
Servicing Your Airbag-Equipped Vehicle..........1-58
What Makes an Airbag Inate?......................1-55
What Will You See After an Airbag Inates?......1-56
When Should an Airbag Inate?....................1-54
Where Are the Airbags?...............................1-50
AM .............................................................3-125Antenna, Diversity Antenna System..................3-127
Antenna, XM™ Satellite Radio
Antenna System........................................3-127
Anti-lock Brake System (ABS)............................ 4-6
Anti-Lock Brake, System Warning Light..............3-44
Anti-Pinch Feature..................................2-16, 2-53
Appearance Care............................................5-92
Care of Safety Belts....................................5-94
Chemical Paint Spotting...............................5-97
Cleaning the Inside of Your Vehicle................5-92
Cleaning the Outside of Your Vehicle..............5-95
Finish Damage............................................5-97
Sheet Metal Damage...................................5-97
Underbody Maintenance...............................5-97
Vehicle Care/Appearance Materials................5-98
Weatherstrips..............................................5-94
Ashtray.........................................................3-28
Ashtrays........................................................3-28
Assist Handles...............................................2-51
Audio System(s)............................................3-107
Audio Steering Wheel Controls....................3-124
Care of Your CD Player..............................3-126
Care of Your CDs......................................3-126
Diversity Antenna System............................3-127
Navigation/Radio System.............................3-124
Radio with CD...........................................3-108
Setting the Time........................................3-108
1

CD Messages...............................................3-122
Cellular Phone Usage....................................3-126
Center Console Storage Area...........................2-51
Center High-Mounted Stoplamp (CHMSL)...........5-53
Chains, Tire...................................................5-78
Change Engine Oil..........................................3-73
Change Trans (Transmission) Fluid
(Automatic Transmission)..............................3-73
Charging System Light....................................3-43
Check
Engine Light...............................................3-47
Engine Oil Pressure Message.......................3-58
Check Brake Fluid..........................................3-74
Check Coolant Level.......................................3-74
Check Engine Light.........................................3-47
Check Gas Cap..............................................3-74
Check Washer Fluid........................................3-75
Checking Coolant............................................5-30
Checking Engine Oil........................................5-18
Checking Things Under the Hood......................5-10
Chemical Paint Spotting...................................5-97
Child Restraints
Child Restraint Systems...............................1-35
Infants and Young Children...........................1-32
Lower Anchorages and Top Tethers for
Children (LATCH System)..........................1-41Child Restraints (cont.)
Older Children.............................................1-29
Securing a Child Restraint Designed for
the LATCH System...................................1-43
Securing a Child Restraint in a Rear
Seat Position...........................................1-43
Securing a Child Restraint in the Right
Front Seat Position...................................1-46
Top Strap...................................................1-39
Top Strap Anchor Location............................1-40
Where to Put the Restraint...........................1-38
Cigarette Lighter.............................................3-28
Cleaning
Inside of Your Vehicle..................................5-92
Outside of Your Vehicle................................5-95
Underbody Maintenance...............................5-97
Weatherstrips..............................................5-94
Cleaning Aluminum or Chrome-Plated Wheels......5-96
Cleaning Exterior Lamps/Lenses.......................5-95
Cleaning Fabric/Carpet....................................5-92
Cleaning Glass Surfaces..................................5-94
Cleaning Interior Plastic Components.................5-93
Cleaning Leather............................................5-93
Cleaning the Mirror.................................2-41, 2-43
Cleaning the Speaker Covers...........................5-94
Cleaning the Top of the Instrument Panel...........5-93
3

Cleaning Tires................................................5-96
Cleaning Vinyl................................................5-93
Cleaning Windshield and Wiper Blades..............5-96
Cleaning Wood Panels....................................5-94
Climate Control System
Air Filter, Passenger Compartment.................3-35
Dual..........................................................3-29
Outlet Adjustment........................................3-34
Steering Wheel Controls...............................3-36
Clutch, Hydraulic.............................................5-28
Compact Spare Tire........................................5-91
Compass Calibration.......................................2-42
Compass Operation.........................................2-42
Compass Variance..........................................2-42
Competitive Driving (CTS-V) .............................3-75
Competitive Driving Mode................................4-10
Congurable Radio Display Keys.....................3-123
Control of a Vehicle.......................................... 4-5
Convenience Net............................................2-52
Coolant
Engine Temperature Gage............................3-46
Engine Temperature Warning Light.................3-45
Heater, Engine............................................2-25
Hot Temperature Warning Message................3-57
Surge Tank Pressure Cap.............................5-31
Cooling System..............................................5-34
Cruise Control................................................3-23
Cruise Control (CTS).......................................3-14Cruise Control (CTS-V) ....................................3-17
Cruise Control Light........................................3-52
CTS-VEngine Data.......................................5-112
Cupholder(s)..................................................2-50
Current and Past Model Order Forms................7-12
Customer Assistance Information
Courtesy Transportation.................................. 7-7
Customer Assistance for Text
Telephone (TTY) Users............................... 7-4
Customer Assistance Offices........................... 7-4
Customer Satisfaction Procedure..................... 7-2
GM Mobility Program for Persons
with Disabilities.......................................... 7-5
Reporting Safety Defects to
General Motors........................................7-11
Reporting Safety Defects to the
Canadian Government..............................7-11
Reporting Safety Defects to the
United States Government.........................7-10
Roadside Service.......................................... 7-6
Service Publications Ordering Information........7-11
D
Daytime Running Lamps..................................3-24
Defensive Driving............................................. 4-2
Defogging and Defrosting.................................3-32
4

N
Navigation/Radio System................................3-124
New Vehicle Break-In......................................2-21
Normal Maintenance Replacement Parts............6-15
O
Odometer......................................................3-40
Off-Road Recovery..........................................4-15
Oil
Engine.......................................................5-18
Pressure Light.............................................3-49
Oil Pressure Low – Stop Engine.......................3-79
Oil Temperatue Warning Message.....................3-58
Older Children, Restraints................................1-29
Online Owner Center........................................ 7-3
OnStar
®Personal Calling.................................2-46
OnStar®Services............................................2-45
OnStar®Steering Wheel Controls (CTS).............2-46
OnStar®System.............................................2-45
OnStar®Virtual Advisor....................................2-46
Other Warning Devices...................................... 3-7
Outlet Adjustment............................................3-34
Outside
Convex Mirror.............................................2-44
Curb View Assist Mirror................................2-44Outside (cont.)
Heated Mirrors............................................2-45
Power Mirrors.............................................2-43
Overheated Engine Protection
Operating Mode..........................................5-31
Overseas — Customer Assistance...................... 7-5
Owner Checks and Services.............................. 6-9
Owners, Canadian............................................... ii
Owner’s Information........................................7-12
P
Panic Brake Assist..........................................4-12
Parade Dimming.............................................3-27
Park (P)
Shifting Into................................................2-36
Shifting Out of............................................2-38
Parking
Brake........................................................2-35
Over Things That Burn.................................2-39
Parking on Hills..............................................4-44
Parking Your Vehicle.......................................2-38
Passenger Compartment Air Filter.....................3-35
Passenger Door Ajar.......................................3-79
Passing.................................................4-15, 4-43
Personalization Features..................................3-90
Personalization Off/Driver Identication
(Navigation System).....................................3-79
11

Playing the Radio..........................................3-109
Power
Accessory Outlets........................................3-27
Door Locks.................................................. 2-9
Electrical System.......................................5-100
Lumbar Controls........................................... 1-3
Seat............................................................ 1-2
Steering Fluid.............................................5-40
Windows....................................................2-15
Power Steering...............................................4-12
Pretensioners, Safety Belt................................1-28
Programmable Automatic Door Locks.................2-10
Programming the HomeLink
®Transmitter...........2-47
Programming the Power Windows.....................2-16
Q
Questions and Answers About Safety Belts.........1-13
R
Radio Data System (RDS)..............................3-108
Radio Message.............................................3-116
Radios.........................................................3-107
Care of Your CD Player..............................3-126
Care of Your CDs......................................3-126
Navigation/Radio System.............................3-124Radios (cont.)
Radio with CD...........................................3-108
Setting the Time........................................3-108
Theft-Deterrent..........................................3-124
Understanding Reception............................3-125
RDS Messages.............................................3-114
Reaching Roadside Service............................... 7-7
Reading Lamps..............................................3-27
Rear Axle......................................................5-51
Limited-Slip.................................................4-11
Rear Door Security Locks................................2-10
Rear Safety Belt Comfort Guides......................1-26
Rear Seat Passengers, Safety Belts..................1-22
Rear Underseat Fuse Block
(Driver’s Side)...........................................5-107
Rear Underseat Fuse Block
(Passenger’s Side).....................................5-109
Rear Window Defogger....................................3-33
Rear-Seat Pass Through..................................2-13
Rearview Mirror, Automatic Dimming
with OnStar
®..............................................2-41
Rearview Mirror, Automatic Dimming
with OnStar
®and Compass..........................2-41
Reclining Seatbacks.......................................... 1-4
Recommended Fluids and Lubricants.................6-13
Recongurable Steering Wheel Controls............... 3-8
Recreational Vehicle Towing.............................4-33
12

Remote Keyless Entry System............................ 2-4
Remote Keyless Entry System, Operation............ 2-5
Removing the Flat Tire and Installing the
Spare Tire..................................................5-85
Removing the Spare Tire and Tools...................5-82
Removing Wheel Covers and
Wheel Nut Caps..........................................5-84
Replacement Bulbs.........................................5-56
Replacing Brake System Parts..........................5-44
Reporting Safety Defects
Canadian Government..................................7-11
General Motors...........................................7-11
United States Government............................7-10
Reprogramming a Single HomeLink
®Button.......2-50
Resetting Defaults...........................................2-50
Restraint System Check
Checking Your Restraint Systems...................1-59
Replacing Restraint System Parts
After a Crash..........................................1-59
Restraint Systems
Checking....................................................1-59
Replacing Parts...........................................1-59
Retained Accessory Power (RAP)......................2-24
Right Front Passenger Position, Safety Belts.........1-22
Right Rear Door Ajar.......................................3-80
Roadside
Service........................................................ 7-6Roadside Service Availability.............................. 7-7
Roadside Service for the Hearing or
Speech Impaired........................................... 7-7
Rocking Your Vehicle To Get It Out...................4-32
Roof Rack Provisions......................................2-51
Run-Flat Tires................................................5-66
Running Your Engine While You Are Parked.......2-40
S
Safety Belt
Pretensioners..............................................1-28
Reminder Light............................................3-41
Safety Belts
Care of......................................................5-94
Driver Position............................................1-15
How to Wear Safety Belts Properly................1-14
Questions and Answers About Safety Belts........1-13
Rear Safety Belt Comfort Guides for
Children and Small Adults.........................1-26
Rear Seat Passengers.................................1-22
Right Front Passenger Position......................1-22
Safety Belt Extender....................................1-28
Safety Belt Use During Pregnancy.................1-21
Safety Belts Are for Everyone......................... 1-9
Safety Chains.................................................4-42
Safety Warnings and Symbols.............................. iii
13
