Power Lumbar
Your vehicle may have
this feature. The driver’s
and passenger’s
seatback lumbar support
can be adjusted by
moving the control
located on the
outboard side of the
seat cushions.
To increase or decrease support, hold the control
forward or rearward. Keep in mind that as your
seating position changes, as it may during
long trips, so should the position of your lumbar
support. Adjust the seat as needed.
Heated Seats
If your vehicle has
heated front seats,
the buttons are
located on the climate
control panel.
There is one button for the driver and one for the
front passenger. Each button has three settings,
LO, HI and off. The active setting appears on
the climate control panel display. The LO setting
warms the seatback and cushion until the seat
approximates normal body temperature.
The HI setting has a slightly higher temperature.
10

To turn on the heated seats, press the button
once. The seat will heat to the HI setting. Press the
button again to switch to the LO setting. Pressing
the button a third time turns the system off.
The heated seats can only be used when the
ignition is turned on. When the vehicle is turned
off, the heated seats automatically turn off.
If you wish to have the heated seats on once the
vehicle is restarted, press the button again.
Memory Seat and Mirrors
If your vehicle has the memory feature, you can
program and recall memory settings for the
driver’s seating and outside rearview mirror
driving positions. Different adjustments can be
programmed for two drivers.The buttons for this
feature are located
on the driver’s
door armrest.
Use the following steps to program the buttons:
1. Adjust the driver’s seat including the seatback
recliner and both outside mirrors.
2. Press and hold button 1 for at least
three seconds.
Two beeps will sound to conrm that the seat
and mirror positions have been saved.
3. Repeat the procedure for a second driver
using button 2.
11

If your vehicle has an automatic transmission,
the vehicle must be in PARK (P) to recall
the stored driving positions.
If your vehicle has a manual transmission and the
engine is running, the parking brake must be
set to recall the memory seat driving positions.
The stored driving positions can be recalled
without setting the parking brake if the vehicle
is off.
Press one of the numbered memory buttons to
recall the stored setting. Each time a memory
button is pressed, a single beep will sound.
Three chimes will sound and the setting will not
be recalled if you press button 1 or 2 when
the vehicle is not in PARK (P) on an automatic
transmission or the parking brake is not set on a
manual transmission.If you would like the stored driving positions to be
recalled when unlocking your vehicle with the
Remote Keyless Entry transmitter or after the
key is placed in the ignition, seeDIC Vehicle
Personalization on page 242.
To stop recall movement of the memory feature at
any time, press one of the power seat or mirror
controls.
Two personalized exit positions can also be
programmed. Use the following steps to program
exit positions:
1. Press memory seat button 1 or the unlock
button on the RKE transmitter, that has the
number 1 on the back of it, to recall the
driving position.
2. Adjust the driver’s seat to the desired exit
position.
12

3. Press and hold the exit button located above
buttons 1 and 2 on the driver’s door armrest
for at least three seconds.
Two beeps will sound to conrm that the exit
position has been saved.
4. Repeat the procedure for a second driver
using memory seat button 2 or the RKE
transmitter, that has the number 2 on the
back of it.
To recall the stored exit positions, press and
release the exit button. One beep will sound, and
the seat will move to the stored exit position
for that driver. If an exit position has not been
stored for this driver, the seat will move all the way
back. The position of the outside mirrors does
not change for the exit position.If your vehicle has an automatic transmission,
the vehicle must be in PARK (P) to recall the
exit positions. If your vehicle has a manual
transmission and the engine is running, the parking
brake must be set to recall the stored exit
positions.
Three chimes will sound and the exit setting will
not be recalled if you press the exit button when
the vehicle is not in PARK (P) on an automatic
transmission or the parking brake is not set on a
manual transmission.
If you would like your stored exit position to be
recalled when unlocking the vehicle with the
RKE transmitter, or when the ignition is turned
off and the driver’s door is opened, seeDIC
Vehicle Personalization on page 242.
13

Sun Visors
Swing down the primary visor to block out glare.
It can also be detached from the center mount
and moved to the side to block glare from
that direction.
The driver’s visor may also have buttons for a
built-in garage door opener. SeeUniversal Home
Remote System on page 147for more
information.
Lighted Visor Vanity Mirror
Pull the visor down and lift the cover to access the
mirror. A light comes on when the cover is lifted
and goes out when it is closed.
Theft-Deterrent Systems
Vehicle theft is big business, especially in some
cities. Although your vehicle has a number of
theft-deterrent features, we know that nothing we
put on it can make it impossible to steal.
Theft-Deterrent System
If your vehicle has this
feature, the security
light is located on
the instrument panel
cluster.
If the ignition is off and a door is open, the
security light will ash, reminding you to arm the
theft-deterrent system.
111

Mirrors
Automatic Dimming Rearview Mirror
with OnStar
®
The vehicle may have an automatic dimming
inside rearview mirror with OnStar®controls.
For more information about OnStar®, seeOnStar®
System on page 142.
O(On/Off):The on/off button, located on the
lower left side of the mirror, is used for the
automatic dimming functions of the rearview mirror.
Mirror Operation
The automatic dimming feature comes on each
time the vehicle is started. Automatic dimming
reduces the glare of lights from behind the vehicle.
To turn the automatic dimming feature on or off,
press and release the on/off button. The indicator
light will come on when this feature is on.
Passenger Airbag Indicator
The mirror may have a passenger airbag indicator
on the mirror glass, just above the buttons.
If the vehicle has this feature, the mirror will
display the word ON, or an airbag symbol
in Canada, when the passenger airbag is enabled.
SeePassenger Sensing System on page 82for
more information.
Cleaning the Mirror
When cleaning the mirror, use a paper towel or
similar material dampened with glass cleaner.
Do not spray glass cleaner directly on the mirror
as that may cause the liquid cleaner to enter
the mirror housing.
136

2. Press and hold the on/off button until a zone
number appears on the display.
3. Once the zone number appears on the
display, press the on/off button quickly
until you reach the correct zone number.
If C appears in the compass window,
the compass may need calibration. See
“Compass Calibration” listed previously.
Passenger Airbag Indicator
The mirror has a passenger airbag indicator on
the mirror glass, just above the buttons. The mirror
will display the word ON, or an airbag symbol in
Canada, when the passenger airbag is enabled.
SeePassenger Sensing System on page 82
for more information.
Cleaning the Mirror
When cleaning the mirror, use a paper towel or
similar material dampened with glass cleaner.
Do not spray glass cleaner directly on the mirror
as that may cause the liquid cleaner to enter
the mirror housing.
139

The vehicle information usually includes your GPS
location and, in the event of a crash, additional
information regarding the accident that your vehicle
has been involved in (e.g. the direction from
which your vehicle was hit). When you use the
Virtual Advisor feature of OnStar
®Hands-Free
Calling, your vehicle also sends OnStar®your
GPS location so that we can provide you
with location-based services.
OnStar
®service cannot work unless your vehicle
is in a place where OnStar®has an agreement
with a wireless service provider for service in that
area. OnStar
®service also cannot work unless
you are in a place where the wireless service
provider OnStar
®has hired for that area
has coverage, network capacity and reception
when the service is needed, and technology that
is compatible with the OnStar
®service. Not all
services are available everywhere, particularly in
remote or enclosed areas, or at all times.
OnStar
®service that involves location information
about your vehicle cannot work unless GPS
satellite signals are unobstructed and available in
that place as well.Your vehicle must have a working electrical
system (including adequate battery power) for the
OnStar
®equipment to operate. There are other
problems OnStar®cannot control that may prevent
OnStar®from providing OnStar®service to you
at any particular time or place. Some examples are
damage to important parts of your vehicle in an
accident, hills, tall buildings, tunnels, weather
or wireless phone network congestion.
Your Responsibility
You may need to increase the volume of your
radio to hear the OnStar®advisor. If the light next
to the OnStar®buttons is red, this means that
your system is not functioning properly and should
be checked by your dealer/retailer. If the light
appears clear (no light is appearing), your OnStar
®
subscription has expired. You can always press
the OnStar®button to conrm that your OnStar®
equipment is active.
145

Universal Home Remote System
System Identication
Your vehicle may have a Universal Home Remote
System.
Determine which Universal Home Remote your
vehicle has and then read the pages following for
instructions on programming your specic system.
If there is one triangular Light Emitting Diode
(LED) indicator light above the Universal Home
Remote buttons, follow the instructions under
Universal Home Remote System Operation
(With One Triangular LED).If there are three round LED indicator lights above
the Universal Home Remote buttons, follow the
instructions under Universal Home Remote System
Operation (With Three Round LED).
For help or information on the Universal Home
Remote System, call the customer assistance
phone number underCustomer Assistance Offices
on page 486.
146

Universal Home Remote System
Operation (With One Triangular LED)
If there is one triangular Light Emitting Diode
(LED) indicator light above the Universal Home
Remote buttons, follow the instructions below.
Do not use the Universal Home Remote with
any garage door opener that does not have the
stop and reverse feature. This includes any
garage door opener model manufactured before
April 1, 1982. If you have a newer garage
door opener with rolling codes, please be sure
to follow Steps 6 through 8 to complete the
programming of your Universal Home Remote
Transmitter.Read the instructions completely before attempting
to program the Universal Home Remote.
Because of the steps involved, it may be helpful
to have another person available to assist you
in the programming steps
Keep the original hand-held transmitter for use in
other vehicles as well as for future Universal
Home Remote programming. It is also
recommended that upon the sale of the vehicle,
the programmed Universal Home Remote buttons
should be erased for security purposes.
See “Erasing Universal Home Remote Buttons”
later in section.
When programming a garage door, it is advised to
park outside of the garage. Be sure that people
and objects are clear of the garage door or
gate operator you are programming.
It is recommended that a new battery be installed
in your hand-held transmitter for quicker and
more accurate transmission of the radio-frequency
signal.
148
