2-52
Parade Dimming
This feature prohibits dimming of the digital displays
and backlighting during daylight hours when the key is
in the ignition and the headlamps are on. This feature
operates with the light sensor for the Twilight Sentinel
and is fully automatic. When the light sensor reads
darkness outside and the park lamps are active, the
digital displays can be adjusted by turning the lamp
control knob counterclockwise to dim and clockwise to
brighten lighting.
Reading Lamps
The reading lamps are located on the overhead console
on the ceiling and in the rear door opening. These lamps
come on automatically when any door is opened and it is
dark outside. For manual operation, press the button to
turn them on. Press it again to turn them off.
If the reading lamps are left on, they automatically shut
off 10 minutes after the ignition has been turned off.
Map Lamps
These lamps are located in the front overhead console.
Press the button to turn them on. Press it again to turn
them off.

2-53
Battery Load Management
The battery load management feature is designed to
monitor the vehicle electrical load and determine when
the battery is in a heavy discharge condition. During
times of high electrical loading, the engine may idle at a
higher RPM setting than normal to make sure the battery
charges. High electrical loads may occur when several
of the following are on: headlamps, high beams, fog
lamps, rear window defogger, high blower fan, heated
seats and engine cooling fans.
Inadvertent Power Battery Saver
This feature is designed to protect your vehicle's battery
against drainage from the interior lamps, trunk lamp, glove
box lamp, cigarette lighters or the garage door opener.
When the ignition is turned off, the power to these features
will automatically turn off after 10 minutes (three minutes
if a new car has 15 miles (24 km) or less). Power will be
restored for an additional 10 minutes if any door is
opened, the trunk is opened or the courtesy lamp switch
is turned on.
Mirrors
Electrochromic Day/Night Rearview Mirror
with Compass (If Equipped)
Your vehicle may have an electrochromic inside
rearview mirror with a compass.
By pressing the MIRROR side of the button located at
the bottom of the mirror, the mirror automatically
darkens to reduce the glare from headlamps behind you.
The mirror also includes an eight
-point compass display
in the upper right corner of the mirror face. When on,
the compass automatically calibrates as the vehicle
is driven.

2-54
When cleaning the mirror, use a paper towel or similar
material dampened with glass cleaner. Do not spray
glass cleaner directly on the mirror as that may cause the
liquid cleaner to enter the mirror housing.
Cleaning Photocells
Use a cotton swab and glass cleaner to clean the
photocells when necessary.
Mirror Operation
The right side of the button, located at the bottom of the
mirror, turns the electrochromic mirror on and off. To
turn on the automatic dimming feature, press MIRROR.
To turn off automatic dimming, press MIRROR again.
The green indicator light will be illuminated when this
feature is active.Time Delay
The automatic mirror has a time delay feature which
prevents unnecessary changing from night back to the
day position. This delay prevents rapid changing of the
mirror as you drive under lights and through traffic.
Compass Operation
Press COMPASS once to turn the compass on or off.
When the ignition and the compass feature are on, the
compass will show two character boxes for
approximately two seconds. After two seconds, the
mirror will display the compass heading.
Compass Calibration
If after two seconds the display does not show a
compass heading (ªNº for North, for example), there
may be a strong magnetic field with the compass. Such
interference may be caused by a magnetic antenna
mount, magnetic note pad holder or a similar magnetic
item. If the letter ªCº should ever appear in the compass
window, the mirror needs calibration.
The mirror can be calibrated in one of two ways:

Drive the vehicle in circles at 5 mph (8 km/h) or less
until the display reads a direction, or

Drive the vehicle on your everyday routine.

2-60
Sun Visors
Swing down the primary visor to block out glare. It can
also be detached from the center mount and moved to
the side while the auxiliary sunshade remains to block
the glare from the front. The visors also have
side
-to-side slide capability.
The driver's sunshade is also equipped with a
storage flap.
Lighted Visor Vanity Mirror
Pull the sunshade down and lift the cover. Move the
slide switch up or down to brighten or dim the lamp.
Lighted Rear Vanity Mirror (If Equipped)
Pull the vanity cover down to see the mirror. Move the
slide switch up or down to brighten or dim the lamp.
Coat Hooks
Your vehicle is equipped with flip-out coat hooks. They
are located above the rear doors, behind the rear assist
handles. Return to the stowed position when not in use.
Rear Power Sunshade (If Equipped)
The rear power sunshade helps to reduce the amount of
heat and light entering the rear window.
The rear power sunshade is located in the rear shelf. To
raise the power sunshade, press and release the REAR
SHADE switch located on the front overhead console.
To close the power sunshade, press and release the
REAR SHADE switch again. The rear power sunshade
switch only works when the ignition is on or when the
Retained Accessory Power is active. See ªRetained
Accessory Powerº in the Index.
Also, never store objects on the rear shelf because they
may get caught in the sunshade or be tossed about in
your vehicle.
Manual Rear Side Door Sunshade
(If Equipped)
To use the manual rear side door sunshades, lower the
side windows and hook the top edge of the retractable
sunshades over the edge of the windows and raise the
windows. To remove the shades, lower the windows and
the hooks will disengage automatically.

2-61
Cellular Telephone (Option)
Your vehicle has been prewired for dealer installation of
the Cadillac Communiport
integrated portable cellular
telephone system. The system has steering wheel
telephone controls and information output through the
Driver Information Center (DIC). Voice activation with
remote record and hands
-free operation are standard
features. For more information, contact your dealer. A
user's guide is provided with the telephone.
Accessory Power Outlets (If Equipped)
Your vehicle may be equipped with accessory power
outlets that can be used to power additional devices
designed to operate with vehicle electrical systems. The
accessory power outlets are located in the center storage
compartment of the instrument panel and under each
storage lid of the rear door armrests. When the ignition
is on, or up to 10 minutes after the ignition is turned off,
you can plug in accessories that require electrical power.
Power to the outlets will shut off 10 minutes after the
ignition is turned off to help prevent the battery from
draining. See ªInadvertant Power Battery Saverº in the
Index. Power supply to the accessory power outlets or
cigarette lighters can be changed from 10 minutes to full
time by changing some fuses. See your dealer
for assistance.Leaving an accessory on for an extended period of time
(i.e. airport stay or storage) or if a fuse is in the wrong
place may drain the vehicle's battery.
OnStar System (If Equipped)
OnStar is a vehicle communications service. The
following services are available through subscription
with OnStar and are available 24 hours a day:
Emergency Services

Automatic Notification of Air Bag Deployment

Theft Notification and Stolen Vehicle Tracking

Roadside Assistance with Location

Remote Diagnostics

OnStar MED
-NET

Accident Assist
Convenience Services

Remote Door Unlock

Route Support

Concierge Services

Ride Assist
A complete user's guide is provided with the OnStar
System. For more information contact OnStar at
1
-888-ONSTAR7.

2-62
Assist Handles
A handle above each door can be used when getting out
of your vehicle.
Umbrella Holder
The driver's and passenger's front seat cushion comes
equipped with an umbrella holder. Gently slide the
umbrella into the slot located under the front portion of
the driver's or passenger's seat cushion.
Floor Mats
Your vehicle is equipped with rubber-backed front and
rear floor mats. Keep them clean by vacuuming and
using a spot cleaner, if necessary. Do not machine wash.
Sunroof (Option)
The two control switches to operate the sunroof are
located on the overhead console and include VENT,
open and close.
The control switches work only when the ignition is on
or the Retained Accessory Power (RAP) is active.
See ªRetained Accessory Powerº in the Index.

2-75
Air Bag Readiness Light
There is an air bag readiness light on the instrument
panel, which shows AIR BAG or the symbol of an air
bag. The system checks the air bag's electrical system for
malfunctions. The light tells you if there is an electrical
problem. The system check includes the air bag sensors,
the air bag modules, the wiring and the crash sensing and
diagnostic module. For more information on the air bag
system, see ªAir Bagº in the Index.
United States Canada
This light will come on when you start your vehicle, and
it will flash for a few seconds. Then the light should go
out. This means the system is ready.
If the air bag readiness light stays on after you start the
vehicle or comes on when you are driving, your air bag
system may not work properly. Have your vehicle
serviced right away.
CAUTION:
If the air bag readiness light stays on after you
start your vehicle, it means the air bag system
may not be working properly. The air bags in
your vehicle may not inflate in a crash, or they
could even inflate without a crash. To help avoid
injury to yourself or others, have your vehicle
serviced right away if the air bag readiness light
stays on after you start your vehicle.
The air bag readiness light should flash for a few
seconds when you turn the ignition key to ON. If the
light doesn't come on then, have it fixed so it will be
ready to warn you if there is a problem.

2-76
Charging System Light
When you turn the key to
ON, this light will come on
briefly to show that the
generator and battery
charging systems
are working.
If this light stays on, you need service and you should
take your vehicle to the dealer at once. To save your
battery until you get there, turn off all accessories.
Brake System Warning and Park Brake
Indicator Light
Your vehicle's hydraulic brake system is divided into
two parts. If one part isn't working, the other part can
still work and stop you. For good braking, though, you
need both parts working well.
If the warning light comes on, there is a brake problem.
Have your brake system inspected right away.
This light should come on
briefly when you turn the
ignition key to ON. If it
doesn't come on then, have
it fixed so it will be ready
to warn you if there's
a problem.
If the light comes on while you are driving, pull off the
road and stop carefully. You may notice that the pedal is
harder to push. Or, the pedal may go closer to the floor.
It may take longer to stop. If the light is still on, have the
vehicle towed for service. (See ªTowing Your Vehicleº
in the Index.)

2-77
CAUTION:
Your brake system may not be working properly
if the brake system warning light is on. Driving
with the brake system warning light on can lead
to an accident. If the light is still on after you've
pulled off the road and stopped carefully, have
the vehicle towed for service.
When the ignition is on, the brake system warning light
will also come on when you set your parking brake. The
light will stay on if your parking brake doesn't release
fully. If it stays on after your parking brake is fully
released, it means you have a brake problem.
Anti-Lock Brake System Warning Light
With the anti-lock brake
system, the light(s) will
come on when you start
your engine and may stay
on for several seconds.
That's normal.
If the light stays on, turn the ignition to OFF. Or, if the
light comes on when you're driving, stop as soon as
possible and turn the ignition off. Then start the engine
again to reset the system. If the light still stays on, or
comes on again while you're driving, your vehicle needs
service. If the regular brake system warning light isn't
on, you still have brakes, but you don't have anti
-lock
brakes. If the regular brake system warning light is also
on, you don't have anti
-lock brakes and there's a
problem with your regular brakes. See ªBrake System
Warning Lightº earlier in this section.
The anti
-lock brake system warning light should come
on briefly when you turn the ignition key to ON. If the
light doesn't come on then, have it fixed so it will be
ready to warn you if there is a problem.

2-80
Malfunction Indicator Lamp
(Service Engine Soon Light in the United
States or Check Engine Light in Canada)
United States Canada
Your vehicle is equipped with a computer which
monitors operation of the fuel, ignition and emission
control systems.This system is called OBD II (On
-Board
Diagnostics
-Second Generation) and is intended to
assure that emissions are at acceptable levels for the
life of the vehicle, helping to produce a cleaner
environment. The SERVICE ENGINE SOON or
CHECK ENGINE light comes on and a chime will
sound to indicate that there is a problem and service is
required. Malfunctions often will be indicated by the
system before any problem is apparent. This may
prevent more serious damage to your vehicle. This
system is also designed to assist your service technician
in correctly diagnosing any malfunction.
NOTICE:
If you keep driving your vehicle with this light
on, after a while, your emission controls may not
work as well, your fuel economy may not be as
good and your engine may not run as smoothly.
This could lead to costly repairs that may not be
covered by your warranty.
