1-2
Seats and Seat Controls
This section tells you about the power seats -- how to
adjust them, and also about the reclining front seatbacks,
memory seats, lumbar adjustments and heated seats.
Power Seats
The power seat controls
are located on the
outboard side of the
front seat cushions.

Move the front of the seat control up or down to
adjust the front portion of the cushion.

Move the rear of the seat control up or down to
adjust the rear portion of the cushion.

Lift up or push down on the center of the seat control
to move the entire seat up or down.

To move the seat forward or rearward, slide the seat
control forward or rearward.
Four Way Power Lumbar Control
(If Equipped)
If you have this feature, the
driver's and passenger's
seatback lumbar support
can be adjusted four ways
by moving a single switch
located on the outboard side
of the seat.
To increase or decrease support, hold the switch forward
or rearward. To move the lumbar up or down, hold the
switch up or down.
Keep in mind that as your seating position changes, as it
may during long trips, so should the position of your
lumbar support. Adjust the seat as needed.

1-5 Memory Seat, Mirrors and Steering
Wheel (Option)
The controls for these
features are located on the
driver's door panel, and are
used to program and recall
memory settings for the
driver's seating positions.
Adjust the driver's seat (including the seatback recliner,
lumbar and shoulder belt height adjustments), both the
outside mirrors and steering wheel to a comfortable
position and then press the MEMORY SET button.
Within five seconds, press button ª1º (for driver 1).A second mirror, seating and steering wheel position
can be programmed by repeating the above steps and
pressing button ª2º (for driver 2). Each time a memory
button is pressed, a single beep will sound. Each time
button 1 or 2 is pressed and released while the vehicle
is in PARK (P), the memory positions will be recalled.
Each time button 1 or 2 is pressed and held while the
vehicle is out of PARK (P), the memory positions will
be recalled.
To stop recall movement of the memory seat and
steering wheel at any time, press one of the power seat,
steering wheel or mirror controls.
Two personalized exit positions can be set by first
recalling the driving position (by pressing 1 or 2),
then positioning the steering wheel and seat in the
desired exit positions and then pressing and releasing
the MEMORY SET button and, within five seconds,
pressing the EXIT button. With the vehicle in PARK (P),
the exit position for either previously set driver can be
recalled by pressing the EXIT button. The mirrors,
power lumbar and shoulder belt height positions will
not be stored or recalled for the exit positions.

2-10
Operation
When you press this
symbol to unlock the
driver's door, the parking
lamps on your vehicle
will flash twice. You can
program your vehicle
so the parking lamps
will not flash.
(For more information,
see ªLock/Unlock
Confirmationº in the Index.)
The parking lamps will also not flash if they have been
turned on manually. Pressing this symbol again within
five seconds will unlock the other doors. Pressing this
symbol will disarm the theft
-deterrent system and turn
on the interior lamps at night.
When you press this symbol to lock the doors,
the parking lamps will flash once and the horn will
sound. The parking lamps will not flash, however, if the
manual parking lamps are left on. (You can program
your vehicle so the parking lamps will not flash and
the horn will not sound. For more information,
see ªLock/Unlock Confirmationº in the Index.)
This arms the theft
-deterrent system.
Press this symbol to open the trunk. (The VALET
lockout switch must be off for this feature to work.)
Your transmitter comes equipped with an
instant panic alarm. To use the alarm, press the horn
symbol with the ignition off. The horn will sound and
the exterior lamps will flash for up to 30 seconds.
To stop the instant panic alarm, press the symbol
again or turn the ignition to ON.
The remote keyless entry transmitter can be used
to recall the memory settings for up to two drivers.
For more information, see ªMemory Seat, Mirrors
and Steering Wheelº in the Index.

2-41
Power Tilt and Telescopic Wheel
(If Equipped)
The power tilt wheel control
is located on the outboard
side of the steering column.
To operate the power tilt feature, push the control up
and the steering wheel will tilt up. Push the control
down and the steering wheel will go down.If the power tilt control is pressed up or down and held
in that position, there will be a slight movement and a
slight pause followed by a continuous movement in the
direction the control is being pressed. This allows very
fine control of the steering wheel position. If the control
is bumped, the steering wheel moves approximately
one degree in the direction commanded.
Push the control forward and the steering wheel moves
toward the front of the vehicle. Push the control
rearward and the steering wheel moves toward the
rear of the vehicle. To set the memory position,
see ªMemory Seat, Mirrors and Steering Wheelº in
the Index.

2-60
Power Remote Control Mirror (Heated)
The control on the driver's
door armrest operates both
outside rearview mirrors.
Press (R) on the control
switch to choose the right
mirror or (L) to choose the
left mirror. The center
switch position is off and
will not move the mirrors if
the control pad is touched.
To adjust the mirror, push the arrows on the control pad
in the direction you want the mirror to go. Adjust each
mirror so you can see the side of your vehicle and the
area behind your vehicle.
When you operate the rear window defogger, it also
warms both outside mirrors to help clear them of fog
or ice. See ªRear Window Defoggerº in the Index for
more information.
The mirrors can also be programmed for personalization
if you have the optional memory package. For more
information, see ªMemory Seat and Mirrorsº in
the Index.
Driver's Outside Auto-Dimming
Rearview Mirror
The driver's side outside mirror will adjust for the glare
of headlamps behind you. This feature is controlled by
the on and off settings on the electrochromic mirror.
See ªElectrochromic Day/Night Rearview Mirror with
Compassº in the Index.
Curb View Assist Mirror (If Equipped)
If your vehicle is equipped with memory mirrors,
it will also be capable of performing the curb view assist
mirror feature. This feature will cause the passenger's
mirror to tilt to a preselected position when the vehicle
is in REVERSE (R). This feature may be useful
in allowing you to view the curb when you are
parallel parking.
When the vehicle is shifted out of REVERSE (R) and a
five
-second delay has occurred, the passenger's mirror
will return to its original position.
If further adjustment is needed after the mirror is tilted,
the mirror switch may be used.
This feature can be enabled/disabled through the
Driver Information Center. See ªVehicle Programming
and Personalization Featuresº in the Index for
more information.

2-102
Once the TPM system detects the low or high tire
pressure condition, the message ªCHECK TIRE
PRESSUREº will be displayed whenever you start the
engine or the ignition is in the ON position. To remove
or clear the CHECK TIRE PRESSURE message, you
will need to set the tire(s) to the proper tire pressure.
See ªInflation
-- Tire Pressureº in the Index.
CAUTION:
When the CHECK TIRE PRESSURE message
is displayed on the Driver Information Center
and the tire pressure is low, your vehicle
handling capabilities will be reduced during
severe maneuvers. If you drive too fast, you could
lose control of your vehicle. You or others could
be injured. Don't drive over 55 mph (90 km/h)
when the tire pressure is low. Drive cautiously
and correct the tire pressure as soon as you can.
CHECK WASHER FLUID - 25: This message will
appear to indicate that the washer solvent container
needs refilling.
DRIVER DOOR AJAR
- 140: The driver's door is
open or ajar when this message appears. The ignition
must be in ON and the transaxle not in PARK (P) for
this message to display. A chime will also sound when
the vehicle's speed is greater than 3 mph (5 km/h).
DRIVER NO. X (1 OR 2): This message will be
displayed with the key in ON and while entering Feature
Programming, but only if the vehicle is equipped with
memory seats. The message will show which driver is
activating the personalization feature. It will only stay
on for five seconds. This message can be customized for
you by your dealer.
ENGINE COOLANT HOT, IDLE ENGINE
- 44:
This message will appear when the engine coolant
temperature is over 262
F (128
C). Stop and allow
your vehicle to idle in PARK (P) until it cools down and
the message is removed. Do not increase engine speed
above a normal idle. If it does not cool down, turn off
the engine and have it serviced before driving it again.
Severe engine damage can result from an overheated
engine. See ªEngine Overheatingº in the Index.

2-108
Vehicle Programming and
Personalization Features
(If Equipped)
If your vehicle is equipped with personalization,
you can program certain features to a preferred setting
for up to two people. If your vehicle does not have
personalization then some of the features on your
vehicle have been programmed for all drivers. On all
vehicles, other features such as HVAC settings, radio
preset settings, exterior lighting at unlock, remote lock
and unlock confirmation, and automatic door locks have
already been programmed for your convenience. If the
vehicle is equipped with personalization then the seat
position, steering column position (if equipped) and
outside mirror position can also be programmed.
The Navigation screen preferences (if equipped) will
remain at the last set position.
If your vehicle is equipped with personalization the
driver's preferences are recalled by pressing the unlock
button on the remote keyless entry transmitter or by
pressing the appropriate memory button ª1º or ª2º
located on the driver's door. Certain features can be
programmed not to recall until the key is placed in the
ignition. To change feature preferences you must enter
feature programming (see below).
Entering Feature Programming
To begin programming, the ignition must be in ON,
your vehicle in PARK (P), and if your vehicle has
memory, you must press the appropriate memory button
ª1º or ª2º, located on the driver's door panel, prior to
programming. The display will show either ª1º or ª2º,
depending on which was selected. Press the INFO
button one or more times until the FEATURE
PROGRAMMING prompt appears on the DIC display.
Press the ON/OFF button to enter FEATURE
PROGRAMMING. To exit, press the INFO RESET
or INFO buttons.
Remote Recall Memory (If Equipped)
To enter feature programming, follow the instructions
listed previously, then press the down arrow on the
INFO button one or more times until the REMOTE
RECALL MEMORY prompt appears. To turn the
feature on, press the ON/OFF button until ON is
displayed on the DIC. The seat and mirror memory
settings that have been previously programmed can be
recalled by pressing the unlock button on the remote
keyless entry transmitter. The steering column will
move when the key is inserted in the ignition and turned
to ON. To turn the feature off, press the ON/OFF button
until OFF is displayed.

2-109
Key in Recall Memory (If Equipped)
To enter feature programming, follow the instructions
listed previously, then press the down arrow on the
INFO button one or more times until the KEY IN
RECALL MEMORY prompt appears on the DIC
display. To turn the feature on, press the ON/OFF button
until ON appears. The seat and mirror memory settings
that have been previously programmed will be recalled
when the key is inserted in the ignition. The steering
column will move when the key is turned to ON.
To turn the feature off, press the ON/OFF button until
OFF appears.
Auto Exit Seat (If Equipped)
To enter feature programming, follow the instructions
listed previously, then press the down arrow on the
INFO button one or more times until the AUTO EXIT
SEAT prompt shows on the DIC display. This feature
will move the seat to the driver's exit position that was
previously programmed when the ignition is turned off
and the driver's door is opened. To turn this feature on,
press the ON/OFF button until ON appears on the DIC.
To turn this feature off, press the ON/OFF button until
OFF shows.
Auto Exit Steering Wheel (If Equipped)
Press the down arrow on the INFO button one or more
times until the AUTO EXIT STRG WHEEL prompt
appears on the DIC display. This feature will move the
column to the driver's previously stored exit position
when the ignition is turned off and the driver's door
is opened.
Lights Flash at Unlock
To enter feature programming follow the instructions
listed previously, then press the down arrow on the
INFO button one or more times until the LIGHTS
FLASH AT UNLOCK prompt appears. To turn this
feature on, press the ON/OFF button until ON is
displayed on the DIC. If all the doors are closed, the
parking lamps will flash twice when the unlock button
on the remote keyless entry transmitter is pressed.
The lamps will not flash if the manual parking lamps or
headlamps are active. To turn the feature off, press the
ON/OFF button until the OFF prompt appears.

3-10 HVAC Steering Wheel Controls
(If Equipped)
Some heating and cooling
controls can be adjusted at
the steering wheel. Other
touch controls operate some
audio controls. See ªAudio
Steering Wheel Controlsº in
the Index.
FAN SPEED: Press the up arrow lever to
increase the fan speed and the down arrow lever to
decrease fan speed.
TEMP: Press the up arrow lever to increase
the temperature and the down arrow lever to
decrease temperature.
Climate Control Personalization
(If Equipped)
With this feature, your vehicle will recall the latest
climate control settings as adjusted the last time your
vehicle was operated. This feature allows two different
drivers to store and recall their own climate control
settings. The settings recalled by the climate control
system are determined by which remote keyless entry
transmitter (ª1º or ª2º) was used to enter the vehicle.
The number on the back of the remote keyless entry
transmitter corresponds to driver 1 or to driver 2. After
the unlock button is pressed on the remote keyless entry
transmitter or the ignition key is placed in the ignition
(the ignition must be turned to OFF), the climate control
settings will automatically adjust to where they were
last set. The settings can also be changed by briefly
pressing the memory seat buttons 1 or 2 located on the
driver's door.

3-44 Radio Personalization with Home and Away
Feature (If Equipped)
If DRIVER 1 (HOME or AWAY) PRESETS or
DRIVER 2 (HOME or AWAY) PRESETS appears in the
display when the radio is first turned on, your vehicle is
equipped with this feature.
With this feature, your vehicle will recall the latest radio
settings as adjusted the last time your vehicle was
operated. This feature allows two different drivers to
store and recall their own radio settings. The settings
recalled by the radio are determined by which RKE
transmitter (ª1º or ª2º) was used to enter the vehicle.
The number on the back of the RKE transmitter
corresponds to driver 1 or to driver 2. The radio settings
will automatically adjust to where they were last set by
the identified driver. The settings can also be recalled by
briefly pressing the MEMORY seat buttons 1 or 2
located on the driver's door.
Your radio can store home and away presets. Home and
away presets allow you to use one set of preset radio
settings in the area where you live, and another set when
you go out of town. That way, you will not need to
reprogram your presets every time you travel. With the
radio off and the clock displayed, use FF and RW to
select home or away presets. To select the away presets,
press and hold FF for five counts until you hear a beep.The next time the radio comes on, the away presets will
be active. To select the home presets, press and hold RW
for five counts until you hear a beep. The next time the
radio comes on, the home presets will be active.
When battery power is removed and later applied, you
will not have to reset your home radio presets because
the radio remembers them. However, you will have to
reset your away radio presets.
Theft-Deterrent Feature
THEFTLOCK
is designed to discourage theft of your
radio. Your vehicle has a ªbuilt
-inº theft-deterrent
feature on each radio that is automatic
-- there is no
programming required. The radio in your vehicle cannot
be used in any other vehicle. When the radio was
originally installed in your vehicle at the factory, it
stored the Vehicle Identification Number (VIN). Each
time the ignition is turned on, the VIN is verified. If the
vehicle's VIN does not match the VIN stored in the
radio, THEFTLOCK will be activated and the audio
system will not play. If the radio is removed from your
vehicle, the original VIN in the radio can be used to
trace the radio back to your vehicle.
