CADILLAC DEVILLE 2002 8.G Owners Manual

2-133
Ultrasonic Rear Parking Assist
(URPA) (Option)
Ultrasonic Rear Parking Assist can help you to
determine how close an object is to your rear bumper
within a given area, making parking easier.
The URPA display is
located inside the vehicle,
above the rear window. It
has three color
-coded lights
that can be seen through the
rearview mirror or by
turning around.
How the System Works
URPA comes on automatically when the shift lever is
moved into REVERSE (R) and the vehicle speed is less
than 3 mph (5 km/h). When the system comes on, the
three lights on the display will illuminate to let you
know that the system is working. URPA senses how
close your vehicle is to an object. The distance is
determined by the four ultrasonic sensors located on the
rear bumper. When you shift into REVERSE (R) and an
object is detected, the following will occur in sequence
depending on the distance from the object:

At 5 feet (1.5 m) a chime will sound and one amber
light will be lit;

at 40 inches (1.0 m) both amber lights will be lit;

at 20 inches (0.5 m) a continuous chime will sound
and all three lights (amber/amber/red) will be lit; and

at 1 foot (0.3 m) a continuous chime will sound and
all three lights (amber/amber/red) will flash.

2-134
URPA can detect objects 3 inches (7.6 cm) and wider,
and at least 10 inches (25.4 cm) tall, but it cannot detect
objects that are above trunk level. In order for the rear
sensors to recognize an object, it must be within
operating range.
If the URPA system is not functioning properly, the
display will flash red, indicating that there is a problem.
The light will also flash red while driving if a trailer is
attached to your vehicle, or a bicycle or object is on
the back of, or hanging out of your trunk. The light
will continue to flash until the trailer or the object is
removed and your vehicle is driven forward at
least 15 mph (25 km/h).
It may also flash red if the ultrasonic sensors are not
kept clean. So be sure to keep your rear bumper free of
mud, dirt, snow, ice and slush or materials such as paint
or the system may not work properly. If after cleaning
the rear bumper and driving forward at least 15 mph
(25 km/h), the display continues to flash red, see your
dealer. For cleaning instructions, see ªCleaning, Outside
of Your Vehicleº in the Index.It may also flash red if your vehicle is moving in
REVERSE (R) at a speed greater than 3 mph (5 km/h).
Other conditions that may affect system performance
include things like the vibrations from a jackhammer or
the compression of air brakes on a very large truck.
As always, drivers should use care when backing up a
vehicle. Always look behind you, being sure to check
for other vehicles, obstructions and blind spots.

3-
3-1
Section 3 Comfort Controls and Audio Systems
In this section, you'll find out how to operate the comfort control and audio systems offered with your vehicle.
Be sure to read about the particular systems supplied with your vehicle.
3
-2 Comfort Controls
3
-2 Climate Control Panel
3
-6 Air Conditioning
3
-6 Heating
3
-6 Defogging and Defrosting
3
-7 Rear Window Defogger
3
-9 Ventilation System
3
-10 HVAC Steering Wheel Controls
3
-11 Climate Control Personalization (If Equipped)
3
-12 Audio Systems
3
-12 Setting the Clock
3
-12 AM-FM Stereo with Cassette Tape and
Compact Disc Player
3
-17 AM-FM Stereo with Cassette Tape and
Compact Disc Player with Radio Data
Systems (RDS), Digital Signal Processing
(DSP) and XM
Satellite Radio Service
(If Equipped)3
-27 Navigation/Radio System (Option)
3
-28 Glovebox-Mounted CD Changer (Option)
3
-30 Radio Personalization with Home and Away
Feature (If Equipped)
3
-31 Theft-Deterrent Feature
3
-32 Audio Steering Wheel Controls
3
-32 Understanding Radio Reception
3
-33 Tips About Your Audio System
3
-34 Care of Your Cassette Tape Player
3
-35 Care of Your Compact Discs
3
-35 Care of Your Compact Disc Player
3
-36 Diversity Antenna System
3
-36 XM Satellite Radio Antenna System
(If Equipped)

3-2
Comfort Controls
This section tells you how to make your air system work
for you.
Climate Control Panel
Your vehicle is equipped with an electronic climate
control system. This system can automatically adjust
and control temperature, fan speed, air delivery mode,
air conditioning operation and air intake. You can use
the AUTO (automatic) setting or override the automatic
operation by manually adjusting the controls. If your
vehicle is equipped with the climate control
personalization feature, you will be able to recall your
preferred climate control settings using your remote
keyless entry transmitter. See ªClimate Control
Personalizationº in the Index.Manual Operation
To turn the system on, press the knob located on the left
side of the climate control panel.
~MODE!: Press MODE to deliver air through the
floor, instrument panel or windshield outlets. The
system will stay in the selected mode until MODE is
pressed again. The current mode is displayed on the
climate control panel when MODE is pressed. Press the
up or down arrow to cycle through the following modes:


(Upper): This setting directs the airflow
through the instrument panel outlets.


(Bi-Level): This setting directs airflow into
your vehicle in two ways. Cooler air is directed to
the upper portion of your body through the four
instrument panel outlets while warmer air is directed
to the floor.


(Floor/Defrost): This setting directs airflow to
the floor outlets and toward the windshield.


(Floor): This setting directs airflow through
the floor outlets. Some air is diverted to the
windshield to minimize fogging.

3-3
!~(Fan): This switch adjusts the fan speed. Press the
up arrow to increase fan speed and the down arrow to
decrease it.
(Recirculation): Press this button to limit the
amount of outside air entering your vehicle. This is
helpful when you are trying to cool the air quickly or
limit odors entering your vehicle. Press this button again
to turn off the recirculation feature. If you notice the
windows fogging, turn off the recirculation feature.
Recirculation is not available in the defrost mode.
FRONT (Defrost): Press this button to quickly
remove fog or frost from the windshield. This setting
sends most of the airflow to the windshield with only a
small amount to the floor outlets. The air conditioning
compressor will operate in this mode.
A/C (Air Conditioning): Press this button to turn the
air conditioning compressor on and off. The system will
cool and dehumidify the air inside the vehicle. A/C
cannot be turned off in defrost mode.PASS OFF (Passenger's Climate Control): Pressing
this button will turn off or on the climate controls for the
passengers. When this feature is active, the driver's
climate control settings are used for both the front and
rear seating areas.
Driver's Temperature Knob: The knob located on the
left side of the climate control panel is used to adjust the
air temperature coming through the system for the
driver's side of the vehicle while the passenger's side
controls are active. Turn the knob clockwise to increase
the temperature displayed on the climate control panel,
or turn the knob counterclockwise to decrease the
temperature. Press the knob to turn the climate control
system off.
~PASS TEMP! (Passenger's Temperature): This
switch is used to increase or decrease the temperature of
the air for the right front passenger independent of the
driver's setting.
Press the up arrow to increase the temperature setting or
the down arrow to decrease it.

3-4
Automatic Operation
AUTO: This button is used to select the automatic
operation of the climate control system. When the
automatic operation is active, AUTO will appear on
the display.
A sensor will control the air delivery mode. Air will
come from the floor, the instrument panel or windshield
outlets. The fan speed and use of air conditioning
will vary as the system maintains the selected
temperature setting.
Do not cover the electronic solar sensor located on top
of the instrument panel near the windshield. The sensor
is used by the automatic system to regulate temperature.
See ªElectronic Solar Sensorº later in this section for
more information.
To find your comfort zone, start with the 75
F (24
C)
setting and allow about 30 minutes for the system to
regulate. Turn the driver's temperature knob to adjust
the temperature if necessary. If you choose 60
F
(16
C), the system will remain at that maximum cooling
setting and will not regulate fan speed. If you choose
90
F (32
C), the system will remain at that maximum
heating setting and will not regulate fan speed. Choosing
either maximum setting will not cause the system to heat
or cool any faster.In cold weather, when the system senses the need for
heat, the airflow will be directed out of the floor outlets.
As the interior temperature approaches the desired
setting, the fan speed will decrease. To maintain interior
comfort, the airflow may move to the instrument panel
air outlets and floor outlets (bi
-level mode). On bright
sunny days in cold weather, the airflow may come out of
the instrument panel outlets in A/C mode to maintain
comfort and prevent stuffiness.
When the automatic setting is active, the air
conditioning compressor cycles when needed to cool the
air. If your vehicle is sitting out on a hot day and AUTO
is active, the air will first flow out of the floor outlets for
a few seconds. This is normal. This is to remove hot air
from the air outlets. As the air is cooled, the airflow will
move through the instrument panel outlets. If you start
your vehicle with the fan setting on HI, it will skip the
air conditioning purge and the system will be in
manual mode.

3-5
To avoid blowing cold air in cold weather, the system
will start at reduced fan speeds until warm air is
available. The length of reduction depends on the
outside air temperature, engine coolant temperature
or the time since the engine was last started. As the
coolant warms up, the fan speed will gradually increase
and air will flow from the floor outlets, with some
airflow to the windshield to prevent fogging under most
normal conditions.
If you select defrost mode or a fan speed, this function
will be skipped and the system will be in manual mode.
If you leave your vehicle, the system will recall the
control setting the next time you start your engine,
except for recirculation and defrost.Electronic Solar Sensor
The sensor monitors the sun's solar radiation. It is located
on top of the instrument panel near the windshield.
When the climate control system is in AUTO, the system
uses this information to automatically make the necessary
temperature and airflow adjustments to maintain your
comfort. The climate control system may supply cooler air
to one side of your vehicle, if that side is facing the sun.
Be sure not to cover the sensor on top of the instrument
panel. If you do, it will not work properly.

3-6 Air Conditioning
On hot days, open the windows long enough to let hot
inside air escape. This reduces the time it takes for your
vehicle to cool down. Then keep your windows closed
for the air conditioner to work its best.
Press the driver's temperature knob to turn the system
on manually. You may also need to adjust the
temperature and fan speed. The system will cool and
dehumidify the air inside the vehicle.
When the system is in AUTO, it will use recirculation as
necessary to cool the air.
Heating
Press MODE to select floor. Adjust the interior
temperature manually to a comfortable level. If the fan
speed needs adjustment, press the up or down arrow.
Outside air will be brought in, warmed and sent through
the floor, instrument panel outlets. The heater works
best if you keep your windows closed while using it.
In AUTO, the fan will not run at high speed to minimize
warm
-up time.
Defogging and Defrosting
Use FRONT on cool and humid days to keep the
windshield and side windows clear. This setting will
remove fog or ice from the windshield quickly in
extremely humid or cold conditions. If you desire to
have more air on your feet, turn the control to the
floor/defrost mode.
Press FRONT to activate the defrost mode. Adjust the
fan speed by pressing the up or down arrow on the fan
button. You may also adjust the temperature by turning
the driver's temperature knob. If you select floor/defrost
from AUTO, the system will control the fan speed and
temperature for you.
Recirculation is not available in the defrost mode, and
the A/C system cannot be turned off in this mode.

3-7 Rear Window Defogger
The grid lines you see on the rear window warm the
glass. When the rear window defogger is turned on,
the rear window and both outside rearview mirrors are
heated to remove snow and ice from the surface of
the glass.
REAR (Rear Window
Defogger): The rear
window defogger button is
located on the climate
control panel near the
bottom left corner.
Press the button to turn on the rear defogger. Press the
button again to turn the system off.The system will automatically shut off after 10 minutes
unless your vehicle is traveling more than 30 mph
(48 km/h). If further defogging is desired once the
system is off, press the button again. The system will
automatically shut off after five minutes for any cycles
after the initial activation.
NOTICE:
Don't use a razor blade or something else sharp
on the inside of the rear window. If you do, you
could cut or damage the warming grid or the
integrated rear window antenna, and the repairs
wouldn't be covered by your warranty.
The lines along the top of the window are for the
diversity antenna and are not intended to defog the
rear window.
Do not attach a temporary vehicle license, tape or decals
across the defogger grid on the rear window.

3-8 Rear Climate Control
Your vehicle is equipped with a rear climate control.
With this system, the rear passengers can control the
temperature of the air flow for his/her own zones.The rear climate control has three switches:
~ MODE !: Press this switch to select the direction
of the airflow. Press the up or down arrow to cycle
through the available modes. The current mode appears
on the display above the climate control panel. If you
press the down arrow until AUTO is displayed,
automatic mode will be active. The automatic mode
selects the airflow mode for you.
See ªManual Operationº previously in this section for
more information on the modes available.
!
~
(Fan): Press this switch to manually adjust the fan
speed. Press the up arrow to increase the speed or the
down arrow to decrease it. The current speed will appear
on the display above the climate control panel. You can
turn the system off by pressing the down arrow until
OFF appears on the display.
