CADILLAC DEVILLE 2002 8.G Owners Manual

3-9
~ TEMP ! (Temperature): Press this switch to
manually adjust the temperature. Press the up arrow to
increase the temperature or the down arrow to decrease
it. The current temperature will appear on the display
above the climate control panel.
The front seat climate control panel has an AUTO
button that can override the climate controls of the rear
seating area automatically. When AUTO is pressed, the
rear automatic mode is selected and the rear air
temperature and mode will readjust to coincide with the
setting selected for the front seating area.
The PASS OFF button on the front climate control panel
allows the settings for the driver to be used for the front
and rear seat areas.Ventilation System
Your vehicle's flow-through ventilation system supplies
outside air into the vehicle when it is moving. Outside
air will also enter the vehicle when the heater or the air
conditioning fan is in operation. See ªRecirculationº
listed previously in this section for more information.
The front outlets are located in the center and at each
side of the instrument panel. You can adjust the
direction of airflow by moving the center control levers
or you can stop the airflow by moving the thumbwheel
located on each outlet downward.

3-10
Ventilation Tips

Keep the hood and front air inlet free of ice, snow or
any other obstruction (such as leaves). The heater
and defroster will work far better, reducing the
chance of fogging the inside of the windows.

Keep the air path under the front seats clear of
objects. This helps circulate air throughout
your vehicle.
Passenger Compartment Air Filter
Passenger compartment air, both outside air and
recirculated air, is routed through a passenger
compartment filter. The filter removes certain
contaminants from the air, including pollen and dust
particles. Reductions in airflow, which may occur more
quickly in dusty areas, indicate that the filter needs to
be replaced early.
The filter should be replaced as part of routine
scheduled maintenance. See ªPassenger Compartment
Air Filterº in the Index for more information on
replacement. See ªMaintenance Scheduleº in the Index
for replacement intervals.
Your vehicle will not be damaged if you choose not to
replace the filter once the old one is removed.HVAC Steering Wheel Controls
(If Equipped)
Some heating and cooling
controls can be adjusted at
the steering wheel. Other
touch controls operate some
audio controls. See ªAudio
Steering Wheel Controlsº in
the Index.
~TEMP! (Temperature): Press the up arrow on the
control to increase the temperature and the down arrow
to decrease temperature manually.
!
~
(Fan): Press the up arrow on the control to
increase the fan speed and the down arrow to decrease
fan speed manually.

3-11 Climate Control Personalization
(If Equipped)
This feature allows two different drivers to store and
recall their own climate control settings. These settings
include the set temperatures for the driver and front
passenger, the air conditioning, the airflow mode and
the fan speed. (This feature does not recall recirculation
or defrost).
Each driver (1 or 2) has a corresponding number located
on the back of the remote keyless entry transmitter.
Settings recalled by the system can be determined by
which transmitter is used to unlock the vehicle. When
the button with the unlock symbol is pressed, the
settings will be automatically recalled for that driver.
The settings can also be recalled when the key is placed
in the ignition. If the settings are recalled this way, the
system will recall the settings of the last driver to use the
vehicle. If these are not the correct settings for you,
press the button with the unlock symbol on remote
keyless entry transmitter that was used when you saved
your settings.The settings can also be recalled by briefly pressing the
corresponding memory button (1 or 2) located on the
driver's door panel.
Further programming for recalling climate control
personalization settings can be done using the DIC.
You can select or not select the following:

Automatic recall of the climate control settings when
the vehicle is unlocked with the remote keyless entry
transmitter, or

Automatic recall of the climate control settings when
a key is placed in the ignition.
For more programming information, see ªMemory and
Personalization Featuresº in the Index.

3-12
Audio Systems
Your audio system has been designed to operate easily
and give years of listening pleasure. You will get the
most enjoyment out of it if you acquaint yourself with it
first. Find out what your audio system can do and how
to operate all of its controls to be sure you're getting the
most out of the advanced engineering that went into it.
Your vehicle has a feature called Retained Accessory
Power (RAP). With RAP, you can play your audio
system even after the ignition is turned off. See
ªRetained Accessory Powerº in the Index.
Setting the Clock
Press and hold HR or MN until the time display begins
to change. Release the button as you get close to the
correct time. The time may be set anytime the clock is
displayed. There is a two
-second delay before the clock
goes into time
-set mode.
AM-FM Stereo with Cassette Tape and
Compact Disc Player
Playing the Radio
PWR (Power): Press this knob to turn the system on
and off.
VOL (Volume): Turn this knob clockwise to increase
volume. Turn it counterclockwise to decrease volume.
HR (Hour) or MN (Minute): Display the time with the
ignition off by pressing one of these buttons.

3-13
SOURCE: Press this button to select a source, either
cassette or compact disc. The audio source must be
loaded to play. Available loaded sources are shown on
the display. If a source is being used, it will be
underlined on the display. If none of the audio sources
are loaded, NO SOURCE LOADED will appear on the
display. Press this button again or press BAND to switch
back to the radio.
Finding a Station
BAND: Press this button to select AM, FM1 or FM2.
~' TUNE SEEK !': When this button is pressed it
has two positions. Press this button to the first position
to manually tune to the next or previous stations. If this
button is held at the first position for a few seconds, the
radio will continue tuning until this button is released.
Press this button to the second position and release it to
seek to the next or previous radio station.
SCAN: Press this button for less than two seconds
to scan radio stations and associated tone settings.
The radio will go to a station, play for five seconds,
then go on to the next station. Press this button again
to stop scanning.To scan preset stations, press and hold SCAN for more
than two seconds until you hear a beep. The radio will
go to the first preset station stored on your pushbuttons,
play for five seconds, then go on to the next preset
station. Press SCAN again to stop scanning. The radio
will scan preset stations with a strong signal only.
Setting Preset Stations
The six numbered pushbuttons let you return to
your favorite stations. You can set up to 18 stations
(six AM, six FM1 and six FM2), by performing the
following steps:
1. Turn the radio on.
2. Press BAND to select AM, FM1 or FM2.
3. Tune in the desired station.
4. Press and hold one of the six numbered pushbuttons
for more than two seconds until you hear a beep.
5. Repeat the steps for each pushbutton. Whenever
you press that numbered pushbutton for less than
two seconds, the station you set will return.
When battery power is removed and later applied, you
will not have to reset your radio presets because the
radio remembers them.

3-14
Setting the Tone (Bass/Treble)
TONE: Press and release this button until the desired
tone control (bass, treble or midrange) is found. The
radio keeps separate tone settings for each band, each
preset and each source.
- LEVEL +: After selecting the desired tone control,
press the plus or minus symbol on this button to select
the desired level.
To save the tone settings for your presets, press and hold
the numbered pushbutton for the desired preset for more
than two seconds until you hear a beep.
Adjusting the Speakers (Balance/Fade)
(Speaker): Press and release this button until the
desired control (balance or fade) is found.
- LEVEL +: After selecting the desired control, press
the plus or minus symbol on this button to select the
desired level.
PTY (Program
-Type): This button is inoperable on
this radio.Playing a Cassette Tape
With the radio on, insert a cassette tape. The tape will
begin playing as soon as it is inserted. When one side of
your cassette tape is done playing, auto reverse plays the
other side of your cassette tape. A cassette tape may be
loaded with the radio off but it will not start playing
until the radio is on. If you want to insert a cassette tape
when the ignition is off, first press the eject button.
While the tape is playing, use the VOL, TONE, LEVEL,
and speaker controls just as you do for the radio. Other
controls may have different functions when a tape is
inserted. The display will show an underlined tape
symbol. TAPE PLAY will appear on the display when a
tape is playing, with an arrow to indicate which side of
the tape is playing.
Your cassette tape player automatically reduces
background noise. Dolby Noise Reduction is manufactured
under a license from Dolby Laboratories Licensing
Corporation. Dolby and the double
-D symbol are
trademarks of Dolby Laboratories Licensing Corporation.
Auto CrO
2 allows the cassette tape player to adjust to
the type of cassette tape for clearer sound for CrO
2cassette tapes.
If an error appears on the display, see ªCassette Tape
Messagesº later in this section.

3-15

RW (Rewind): Press the left arrow to rewind the
tape rapidly. The radio will play while the tape rewinds.
You may use your station pushbuttons to tune to another
radio station while in rewind. Press the left arrow again
to return to playing speed.
FF
 (Fast Forward): Press the right arrow to fast
forward to another part of the tape. The radio will play
while the tape advances. You may use your station
pushbuttons to tune to another radio station while in fast
forward. Press the right arrow again to return to playing
speed.
~' TUNE SEEK !': When this button is pressed it
has two positions. Press this button to the first position
to manually tune to the next or previous stations. If this
button is held at the first position for a few seconds, the
radio will continue tuning until this button is released.
Press this button to the second position and release it to
seek to the next or previous radio station.
SCAN: Press this button to listen to selections for a few
seconds. The tape will go to a selection, play for a few
seconds, then go on to the next selection. Press this
button again to stop scanning.
SIDE: Press this button to change the side of the tape
that is playing.
(Eject): Press this button to the right of the
cassette tape player to remove a tape. The radio will
play. Eject may be activated with the radio off and/or
the ignition off.
Cassette Tape Messages
If an error occurs while trying to play a cassette tape, it
could be for one of the following reasons:

The cassette tape is tight and the cassette player
cannot turn the hubs of the tape. Hold the cassette
tape with the open end down and try turning the right
hub counterclockwise with a pencil. Flip the tape
over and repeat. If the hubs do not turn easily, your
cassette tape may be damaged and should not be
used in the player. Try a new tape to be sure your
player is working properly.

The cassette tape is broken. (Check to see if your
tape is broken. Try a new tape.)
CLEAN TAPE: If this message appears on the display,
the cassette tape player needs to be cleaned. It will still
play tapes, but you should clean it as soon as possible to
prevent damage to the tapes and player. See ªCare of
Your Cassette Tape Playerº in the Index.
If any error occurs repeatedly or if an error can't be
corrected, contact your dealer.

3-16
Playing a Compact Disc
Insert a disc partway into the slot, label side up. The
player will pull it in. If the ignition and the radio are on
and the underlined compact disc symbol appears on the
display, the disc will begin playing. Compact discs may
be loaded with the radio off but they will not start
playing until the radio is on. If you want to insert a disc
when the ignition is off, first press the eject button.
The integral CD player can play the smaller 8 cm
compact discs. Full
-size compact discs and the smaller
compact discs are loaded in the same manner.
If an error appears on the display, see ªCompact Disc
Messagesº later in this section.

RW (Rewind): Press and hold the left arrow to
reverse the compact disc. Release it to return to playing
speed.
FF
 (Fast Forward): Press and hold the right arrow
to fast forward to another part of the compact disc.
Release it to return to playing speed.
~' TUNE SEEK !': When this button is pressed, it
has two positions. This button works the same, whether
it is pressed to the first or second position. Press this
button to seek to the next or previous track on the
compact disc.
SCAN: Press this button to listen to tracks for a few
seconds. The compact disc will go to a track, play for a
few seconds, then go on to the next track. Press this
button again to stop scanning.
RDM (Random): Press this button to hear the tracks in
random, rather than sequential, order. Press RDM again
to turn off random play.
(Eject): Press this button, located to the right of the
CD slot, to stop a CD when it is playing or to eject a CD
when it is not playing. Eject may be activated with the
radio off and/or the ignition off.

3-17
Compact Disc Messages
If the disc comes out, it could be for one of the
following reasons:

If you're driving on a very rough road. When the
road becomes smooth the disc should play.

If it's very hot. When the temperature returns to
normal, the disc should play.

The disc is upside down.

It is dirty, scratched or wet.

The air is very humid. (If so, wait about an hour and
try again.)

If the CD is not playing correctly, for any other
reason, try a known good CD.
If any error occurs repeatedly or if an error can't be
corrected, contact your dealer.AM-FM Stereo with Cassette Tape and
Compact Disc Player with Radio Data
Systems (RDS), Digital Signal Processing
(DSP) and XM Satellite Radio Service
(If Equipped)
Playing the Radio
PWR (Power): Press this knob to turn the system on
and off.
VOL (Volume): Turn this knob clockwise to increase
volume. Turn it counterclockwise to decrease volume.

3-18
AVC (Automatic Volume Control): With AVC, your
audio system monitors the noise in the vehicle. Then,
AVC adjusts the volume level so that it always sounds
the same to you. To use AVC, press and hold the TONE
button until AUTO VOLUME CONTROL OFF appears
on the display. Then press the LEVEL plus symbol.
AUTO VOLUME CONTROL ON will appear on the
display. AVC VOLUME will appear on the display any
time you adjust the volume while AVC is on. To turn
AVC off, press and hold the TONE button until AUTO
VOLUME CONTROL ON appears on the display. Then
press the LEVEL minus symbol. AUTO VOLUME
CONTROL OFF will appear on the display.
HR (Hour) or MN (Minute): Display the time with the
ignition off by pressing one of these buttons.
SOURCE: Press this button to select a source, either
cassette or compact disc. The audio source must be
loaded to play. Available loaded sources are shown on
the display. If a source is being used, it will be
underlined on the display. If none of the audio sources
are loaded, NO SOURCE LOADED will appear on the
display. Press this button again or press BAND to switch
back to the radio.Finding a Station
BAND: Press this button to select AM, FM1 or FM2,
weather or XM1 or XM2 if your radio is equipped with
XM
Satellite Radio Service.
~' TUNE SEEK !': When this button is pressed it
has two positions. Press this button to the first position
to manually tune to the next or previous stations. If this
button is held at the first position for a few seconds, the
radio will continue tuning until this button is released.
Press this button to the second position and release it to
seek to the next or previous radio station.
SCAN: Press this button for less than two seconds to
scan radio stations. The radio will go to a station, play
for five seconds, then go on to the next station. Press
this button again to stop scanning.
To scan preset stations, press and hold SCAN for more
than two seconds until you hear a beep. The radio will
go to the first preset station stored on your pushbuttons,
play for five seconds, then go on to the next preset
station. Press SCAN again to stop scanning. The radio
will scan preset stations with a strong signal only.
