wiper size CADILLAC DTS 2007 1.G Owners Manual

Service........................................................ 353
Accessories and Modications................... 353
California Proposition 65 Warning.............. 354
Doing Your Own Service Work.................. 354
Adding Equipment to the Outside of
Your Vehicle.......................................... 355
Fuel............................................................. 355
Gasoline Octane........................................ 356
Gasoline Specications.............................. 356
California Fuel........................................... 356
Additives................................................... 357
Fuels in Foreign Countries........................ 358
Filling the Tank......................................... 358
Filling a Portable Fuel Container............... 361
Checking Things Under the Hood.............. 362
Hood Release........................................... 363
Engine Compartment Overview.................. 364
Engine Oil................................................. 365
Engine Oil Life System.............................. 368
Engine Air Cleaner/Filter............................ 370
Automatic Transaxle Fluid......................... 372
Engine Coolant.......................................... 374
Coolant Surge Tank Pressure Cap............ 377
Engine Overheating................................... 377Overheated Engine Protection
Operating Mode..................................... 379
Cooling System......................................... 380
Power Steering Fluid................................. 385
Windshield Washer Fluid........................... 386
Brakes...................................................... 387
Battery...................................................... 390
Jump Starting............................................ 392
Headlamp Aiming........................................ 397
Bulb Replacement....................................... 400
High Intensity Discharge (HID) Lighting..... 400
Windshield Wiper Blade Replacement....... 400
Tires............................................................ 402
Tire Sidewall Labeling............................... 403
Tire Terminology and Denitions............... 408
Ination - Tire Pressure............................. 411
High-Speed Operation............................... 413
Tire Pressure Monitor System................... 414
Tire Inspection and Rotation...................... 418
When It Is Time for New Tires.................. 419
Buying New Tires...................................... 420
Different Size Tires and Wheels................ 422
Uniform Tire Quality Grading..................... 422
Section 5 Service and Appearance Care
351

4. Install the new wiper blade onto the wiper arm
and rmly press down on the clip to snap it
into place.
To remove and replace the wiper blade element
do the following:
1. The wiper blade element has two notches at
one end which are engaged by the bottom
claw set of the wiper blade. At the notched
end of the wiper blade, pull the wiper
blade element from the wiper blade assembly.
2. To replace the element, start at the heel end
of the wiper blade, which is the end nearest to
the base of the wiper arm, and slide the
wiper blade element, notched end last, into
the wiper blade claw sets.
3. To engage the last claw into the notched end
of the wiper blade element, squeeze the wiper
blade element at the notched area, and
push the wiper blade element so the claw ts
into the notch.
4. Be sure the two wiper blade element notches
are engaged by the last claw set, and that all
the other claws are properly engaged in the
slots of the wiper blade element on both sides.A. Correct Installation
B. Incorrect Installation
For the proper type and size windshield wiper
blades, seeNormal Maintenance Replacement
Parts on page 476.
401

W
Warning Lights, Gages and Indicators......... 222
Warnings
DIC Warnings and Messages................... 246
Hazard Warning Flashers......................... 164
Other Warning Devices............................ 164
Safety and Symbols..................................... 4
Vehicle Damage.......................................... 5
Wheels
Alignment and Tire Balance..................... 424
Different Size........................................... 422
Replacement............................................ 424
Where to Put the Restraint............................ 54
Windows..................................................... 108
Power...................................................... 109
Windshield
Rainsense™ II Wipers............................. 173
Washer.................................................... 175
Washer Fluid........................................... 386Windshield (cont.)
Wiper Blade Replacement........................ 400
Wiper Blades, Cleaning............................ 445
Wiper Fuses............................................ 451
Wipers..................................................... 172
Winter Driving............................................. 328
Wiper Activated Headlamps ......................... 197
X
XM Radio Messages................................... 294
XM™ Satellite Radio Antenna
System.................................................... 300
Y
Your Vehicle and the Environment............... 463
518
