CADILLAC DTS 2010 1.G Owners Manual

Console Shift
If the console shift cannot be moved out of P (Park)
1. Apply the regular brakes.
2. Turn the ignition to ON/RUN or ACC/ACCESSORYposition. SeeIgnition Positions on page 3-23formore information.
3. Push the shift lever all the way into P (Park).
4. Then, shift into the desired gear.
If you still cannot move the shift lever from P (Park),consult your dealer/retailer or a professional towingservice.
Column Shift
If the column shift cannot be moved out of P (Park)
1. Apply the regular brakes.
2. Turn the ignition key to the ON/RUN orACC/ACCESSORY position. SeeIgnition Positionson page 3-23for more information.
3. Shift out of the P (Park) position to the N (Neutral)position.
4. Move the column shift to the desired gear.
If you still cannot move the shift lever from P (Park),consult your dealer/retailer or a professional towingservice.
Parking Over Things That Burn
{WARNING:
Things that can burn could touch hot exhaust
parts under the vehicle and ignite. Do not park
over papers, leaves, dry grass, or other things that
can burn.
3-33

Engine Exhaust
{WARNING:
Engine exhaust contains Carbon Monoxide (CO)
which cannot be seen or smelled. Exposure to
CO can cause unconsciousness and even death.
Exhaust may enter the vehicle if:
•The vehicle idles in areas with poor ventilation
(parking garages, tunnels, deep snow thatmay block underbody airflow or tail pipes).
•The exhaust smells or sounds strange or
different.
•The exhaust system leaks due to corrosion
or damage.
•The vehicle’s exhaust system has been
modified, damaged or improperly repaired.
•There are holes or openings in the vehicle
body from damage or after-marketmodifications that are not completely sealed.
WARNING: (Continued)
WARNING: (Continued)
If unusual fumes are detected or if it is suspected
that exhaust is coming into the vehicle:
•Drive it only with the windows
completely down.
•Have the vehicle repaired immediately.
Never park the vehicle with the engine running inan enclosed area such as a garage or a buildingthat has no fresh air ventilation.
3-34

Running the Vehicle While Parked
It is better not to park with the engine running. But if youever have to, here are some things to know.
{WARNING:
Idling a vehicle in an enclosed area with poor
ventilation is dangerous. Engine exhaust may
enter the vehicle. Engine exhaust contains Carbon
Monoxide (CO) which cannot be seen or smelled.
It can cause unconsciousness and even death.
Never run the engine in an enclosed area that has
no fresh air ventilation. For more information, see
Engine Exhaust on page 3-34.
{WARNING:
It can be dangerous to get out of the vehicle if the
automatic transmission shift lever is not fully in
P (Park) with the parking brake firmly set. The
vehicle can roll. Do not leave the vehicle when the
engine is running unless you have to. If you have
left the engine running, the vehicle can move
suddenly. You or others could be injured. To be
sure the vehicle will not move, even when you are
on fairly level ground, always set the parking
brake after you move the shift lever to P (Park).
Follow the proper steps to be sure the vehicle will notmove. SeeShifting Into Park on page 3-31.
If parking on a hill and pulling a trailer, seeTowing aTrailer on page 5-26.
3-35

Mirrors
Automatic Dimming Rearview Mirror
The vehicle has an automatic dimming inside rearviewmirror with a compass display. Automatic dimmingreduces the glare of lights from behind the vehicle.The dimming feature comes on and the indicator lightilluminates each time the vehicle is started.
O(On/Off):Press and holdOfor about three
seconds to turn the dimming feature and compassdisplay on or off.
AUTO3(Vehicles with Intellibeam™):Press and
hold for approximately three seconds to turn thecompass display on or off. SeeExterior Lamps onpage 4-25for more information.
Cleaning the Mirror
Do not spray glass cleaner directly on the mirror. Use asoft towel dampened with water.
Compass
Compass Operation
PressOor AUTO3, depending on the vehicle, to
turn the compass on or off.
When the ignition and the compass feature are on, aftera few seconds, the mirror will display the compassheading. The compass automatically calibrates as thevehicle is driven.
Compass Calibration
If after a few seconds, the display does not show thecorrect direction, (for example, N for North), theremay be a strong magnetic field interfering with thecompass. Interference can be caused by a magneticantenna mount, magnetic note pad holder or asimilar magnetic item.
The compass can be placed in calibration mode
manually by pressing and holdingOor AUTO3,
depending on the vehicle, until a C is shown inthe compass display.
The compass can be calibrated by driving the vehicle incircles at 5 mph (8 km/h) or less until the displayreads a direction.
3-36

Compass Variance
The compass is set to zone eight. If you do not live inzone eight or drive out of the area, the compassvariance needs to be changed to the appropriate zone.
To adjust for compass variance:
1. Find the current location and variance zone numberon the following zone map.
2. Press and holdOor AUTO3until a zone
number displays.
3. Once the zone number displays, pressOor
AUTO3repeatedly until the correct zone number
displays. Stop pressing the button and the mirrorwill return to normal operation. If C appears inthe compass window, the compass may needcalibration. See “Compass Calibration” listedpreviously.
Outside Power Foldaway Mirrors
Controls for the outsidepower mirrors are locatedon the driver doorarmrest.
Press the selector switch (A) or (B) to choose either theleft or right outside mirror. Then press the control padto move the mirror to the desired direction.
3-37

Mirror Adjustment
1. Press (C) to unfold the mirrors out to the drivingposition.
2. Press (D) to fold the mirrors toward the vehicle.
Resetting the Power Foldaway Mirrors
Reset the power foldaway mirrors if:
•The mirrors are accidentally obstructed while
folding.
•They are accidentally manually folded/unfolded.
•The mirrors do not stay in the unfolded position.
•The mirrors vibrate at normal driving speeds.
Fold and unfold the mirrors one time using the mirrorcontrols to reset them to their normal position. Anoise may be heard during the resetting of the powerfoldaway mirrors. This sound is normal after a manualfolding operation.
Turn Signal Indicator (If Equipped)
The vehicle may have a turn signal indicator lamp thatis built into the mirror. The turn signal lamp flasheswith the use of the vehicle’s turn signal and hazardflashers.
Outside Automatic Dimming Mirror
If the vehicle has this feature, the driver side mirroradjusts for the glare of headlamps behind you.This feature is controlled by the on and off settings onthe automatic dimming rearview mirror.
Side Blind Zone Alert (SBZA)
If the vehicle has the Side Blind Zone Alert (SBZA)system, seeSide Blind Zone Alert (SBZA) on page 3-43for more information.
3-38

Park Tilt Mirrors
If your vehicle is equipped with memory mirrors, it iscapable of performing the park tilt mirror feature. Thisfeature allows the driver and passenger side mirror to tiltto a factory programmed position when the vehicle is inR (Reverse). This feature may be useful in allowing youto view the curb when you are parallel parking.
When the vehicle is shifted out of R (Reverse) andeither a five-second delay has occurred, or the ignitionis turned to LOCK/OFF, the driver and passengerside mirror will return to its original position.
This feature can be enabled/disabled through the DriverInformation Center (DIC). SeeDIC VehicleCustomization on page 4-80for more information.
Outside Convex Mirror
{WARNING:
A convex mirror can make things, like other
vehicles, look farther away than they really are. If
you cut too sharply into the right lane, you could hit
a vehicle on the right. Check the inside mirror or
glance over your shoulder before changing lanes.
The passenger side mirror is convex shaped. A convexmirror’s surface is curved so more can be seen fromthe driver seat.
Outside Heated Mirrors
=(Rear Window Defogger):Press to heat the
mirrors. See “Rear Window Defogger” underDualClimate Control System on page 4-36for moreinformation.
3-39

Object Detection Systems
Ultrasonic Front and Rear Parking
Assist (UFRPA)
For vehicles with the Ultrasonic Front and Rear ParkingAssist (UFRPA) system, it operates at speeds lessthan 8 km/h (5mph), and assists the driver with parkingand avoiding objects. It can determine how closeobjects are to the front bumper, up to 1.2 m (4 ft.) infront of the vehicle and the rear bumper, up to2.5 m (8 ft.) behind the vehicle. The distance sensorsare located on the front and rear bumper.
{WARNING:
The Ultrasonic Front and Rear Park Assist
(UFRPA) system does not replace driver vision.
It cannot detect:
•objects that are below the bumper,
underneath the vehicle, or if they are tooclose or far from the vehicle
•children, pedestrians, bicyclists, or pets.
If you do not use proper care before movingforward and while backing; vehicle damage, injury,or death could occur. Even with UFRPA, alwayscheck in front of the vehicle before moving forwardand behind the vehicle before backing up. Whilemoving forward and backing, be sure to look forobjects and check the vehicle’s mirrors.
3-40

The front display is located on top of the instrumentpanel to the right of the driver. The front display will haveeither three or six lights to provide distance andsystem information. With Adaptive Cruise control (ACC),it will have three lights along with the ACC lights.Without ACC, it will have six lights. High-toned beepsfrom the front speakers are for objects detected near thefront bumper.
The rear display is located near the rear window andcan be seen by looking over your right shoulder.The rear display uses three color-coded lights to providedistance and system information. Low-toned beepsfrom the rear speakers are for the rear bumper.
How the System Works
UFRPA comes on automatically when the shift lever ismoved out of P (Park). The system does not work at aforward or reverse speed greater than 5 mph (8 km/h).
To be detected, objects must be at least 25.4 cm (10 in.)off the ground and below hood or trunk level. Objectsmust also be within 1.2 m (4 ft.) in front of thevehicle and 2.5 m (8 ft.) from the rear bumper. Thisdistance may be less during warmer or humid weather.
When backing up, if objects are detected at thesame time near both the front and rear bumpers, bothcolor-coded light displays will notify you of objects closeto each bumper. If there are objects detected nearboth bumpers, the beeps will only be sounded to notifythat objects are close to the rear bumper. However,if while the vehicle is backing up and an object comeswithin 0.3 m (1 ft.) of the front bumper, and at the sametime there is another object further than 0.3 m (1 ft.)from the rear bumper, then the beeps will only besounded to notify you of the closer object that is nearthe front bumper.
The system can be disabled using the Driver InformationCenter (DIC). See “Parking Assist” underDIC Operationand Displays on page 4-62for more information.
Front Parking AssistDisplay
Rear Parking AssistDisplay
3-41

Moving Forward
When the vehicle is started, the front display will brieflyilluminate to let you know the system is working.
The following describes what will occur with the frontdisplay as you get closer to a object detected in the frontof the vehicle:
DescriptionMetric English
amber/amber lightsACC — one amber light1.2 m4 ft
four amber lightsACC — two amber lights1.0 m40 in
four amber/ two red lightsACC — two amberlights/one red light0.6 m23 in
four amber/ two red lightsflashing and beep forfive secondsACC — two amberlights/one red lightflashing and beep forfive seconds
0.3 m1 ft
Backing
Ultrasonic Rear Parking Assist (URPA) comes onautomatically when the shift lever is moved intoR (Reverse). The rear display will then briefly illuminateto let you know the system is working.
The following describes what will occur with the reardisplay as you get closer to an object detected inthe rear of your vehicle:
DescriptionMetric English
amber light2.5 m8 ft.
amber/amber lights1.0 m40 in.
amber/amber/red lightsand continuous beepingfor five seconds0.6 m23 in.
amber/amber/red lightsflashing and continuousbeeping for five seconds0.3 m1 ft.
The system can be disabled through the DriverInformation Center (DIC). See “Parking Assist” underDIC Operation and Displays on page 4-62for moreinformation.
3-42
