jump start CADILLAC ELDORADO 1999 10.G Owners Manual

5-
yellowblue
5-1
Section 5 Problems on the Road
Here you'll find what to do about some problems that can occur on the road.
5
-2 Hazard Warning Flashers
5
-3 Other Warning Devices
5
-3 Jump Starting
5
-9 Towing Your Vehicle
5
-10 Engine Overheating5
-13 Cooling System
5
-19 If a Tire Goes Flat
5
-20 Changing a Flat Tire
5
-31 Compact Spare Tire
5
-32 If You're Stuck: In Sand, Mud, Ice or Snow

yellowblue
5-3
Pull out on the collar to turn the flashers off. When the
hazard warning flashers are on, the turn signals won't
work since they are already flashing.
Other Warning Devices
If you carry reflective triangles, you can set one up at
the side of the road about 300 feet (100 m) behind
your vehicle.
Jump Starting
If your battery has run down, you may want to use
another vehicle and some jumper cables to start your
vehicle. Please follow the steps below to do it safely.
CAUTION:
Batteries can hurt you. They can be
dangerous because:

They contain acid that can burn you.

They contain gas that can explode or ignite.

They contain enough electricity to
burn you.
If you don't follow these steps exactly, some or all
of these things can hurt you.

yellowblue
5-4
NOTICE:
Ignoring these steps could result in costly damage
to your vehicle that wouldn't be covered by
your warranty.
The ACDelco Freedom
battery in your vehicle
has a built
-in hydrometer. Do not charge, test or
jump start the battery if the hydrometer looks
clear or light yellow. Replace the battery when
there is a clear or light yellow hydrometer and a
cranking complaint.
Trying to start your vehicle by pushing or pulling
it won't work, and it could damage your vehicle.
1. Check the other vehicle. It must have a 12-volt
battery with a negative ground system.
NOTICE:
If the other system isn't a 12-volt system with a
negative ground, both vehicles can be damaged.
2. Get the vehicles close enough so the jumper cables
can reach, but be sure the vehicles aren't touching
each other. If they are, it could cause a ground
connection you don't want. You wouldn't be able to
start your vehicle, and the bad grounding could
damage the electrical systems.
3. Turn off the ignition on both vehicles. Unplug
unnecessary accessories plugged into the cigarette
lighter. Turn off all lamps that aren't needed as well
as radios. This will avoid sparks and help save both
batteries. In addition, it could save your radio!
4. Open the hoods and locate the batteries. Find
the positive (+) and negative (
-) terminals on
each battery.

yellowblue
6-32 Replacing Brake System Parts
The braking system on a vehicle is complex. Its many
parts have to be of top quality and work well together if
the vehicle is to have really good braking. Your vehicle
was designed and tested with top
-quality GM brake
parts. When you replace parts of your braking
system
-- for example, when your brake linings wear
down and you have to have new ones put in
-- be sure
you get new approved GM replacement parts. If you
don't, your brakes may no longer work properly. For
example, if someone puts in brake linings that are wrong
for your vehicle, the balance between your front and
rear brakes can change
-- for the worse. The braking
performance you've come to expect can change in many
other ways if someone puts in the wrong replacement
brake parts.
Battery
Your new vehicle comes with an ACDelco Freedom

battery. When it's time for a new battery, we
recommend an ACDelco Freedom battery. Get one that
has the replacement number shown on the original
battery's label.
Vehicle Storage
If you're not going to drive your vehicle for 25 days
or more, remove the black, negative (
-) cable from
the battery. This will help keep your battery from
running down.
CAUTION:
Batteries have acid that can burn you and gas
that can explode. You can be badly hurt if you
aren't careful. See ªJump Startingº in the Index
for tips on working around a battery without
getting hurt.
Contact your dealer to learn how to prepare your vehicle
for longer storage periods.
Also, for your audio system, see ªTheft
-Deterrent
Featureº in the Index.

yellowblue
7-6
Each technician travels with a specially equipped
service vehicle complete with the necessary Cadillac
parts and tools required to handle most roadside repairs.
Cadillac Roadside Service can be reached by dialing
1
-800-882-1112, 24 hours a day, 365 days a year.
This service is provided at no charge for any
warranty
-covered situation and for a nominal charge
if the Cadillac is no longer under warranty. Roadside
Service is available only in the United States
and Canada.
Cadillac Owner Privileges
Roadside Service provides several Cadillac
Owner Privileges at ªno charge,º throughout
your 1999 Cadillac Warranty Period
-- 48 months/
50,000 miles (80 000 km).
Emergency Road Service is performed on site for the
following situations:

Towing Service

Battery Jump Starting

Lock Out Assistance

Fuel Delivery

Flat Tire Change (Covers change only)

yellowblue
8-2
Battery 6-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Charging System Indicator Light 2-62 . . . . . . . . . . . . . . . . .
Jump Starting 5-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Not Charge Message 2-72 . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacement, Remote Keyless Entry 2-7 . . . . . . . . . . . . . . .
Voltage High Message 2-72 . . . . . . . . . . . . . . . . . . . . . . . . .
Voltage Low Message 2-72 . . . . . . . . . . . . . . . . . . . . . . . . .
Warnings 5-3, 5-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Battery Savers 2-43, 2-44 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BBB Auto Line 7-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Better Business Bureau Mediation 7-3 . . . . . . . . . . . . . . . . . . .
Blade Replacement, Windshield Wipers 6-39 . . . . . . . . . . . . .
Blizzard 4-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake
Adjustment 6
-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid 6-29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Master Cylinder 6-29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parking 2-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pedal Travel 6-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing System Parts 6-32 . . . . . . . . . . . . . . . . . . . . . . . .
System Warning Light 2-62 . . . . . . . . . . . . . . . . . . . . . . . . .
Trailer 4-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transaxle Shift Interlock (BTSI) 2-29 . . . . . . . . . . . . . . . . .
Vacuum Problem Message 2-72 . . . . . . . . . . . . . . . . . . . . . .
Wear 6-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brakes, Anti-Lock 4-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Braking 4-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Braking in Emergencies 4-10 . . . . . . . . . . . . . . . . . . . . . . . . . .
Break-In, New Vehicle 2-17 . . . . . . . . . . . . . . . . . . . . . . . . . .
Brightness Control 2-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . BTSI 2
-29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bulb Replacement 6-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Center High-Mounted Stoplamp 6-36 . . . . . . . . . . . . . . . . .
Front Turn Signal Lamps 6-39 . . . . . . . . . . . . . . . . . . . . . . .
Headlamps 6-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear Turn Signal Lamp 6-38 . . . . . . . . . . . . . . . . . . . . . . . .
Taillamps 6-38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Capacities and Specifications 6-65 . . . . . . . . . . . . . . . . . . . .
Carbon Monoxide 2-30, 4-28, 4-34 . . . . . . . . . . . . . . . . . . . .
Carpet Cleaning 6-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cassette Tape Player Care 3-30 . . . . . . . . . . . . . . . . . . . . . . . .
Cassette Tape Players 3-12, 3-19 . . . . . . . . . . . . . . . . . . . . . . .
CD Adapter Kits 3-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CD Changer, Trunk-Mounted 3-23 . . . . . . . . . . . . . . . . . . . . .
Cellular Telephone 2-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Center Console Storage 2-49 . . . . . . . . . . . . . . . . . . . . . . . . . .
Center High-Mounted Stoplamp Bulb Replacement 6-36 . . . .
Center Passenger Position 1-31 . . . . . . . . . . . . . . . . . . . . . . . .
Central Door Unlocking System 2-4 . . . . . . . . . . . . . . . . . . . .
Certification Label 4-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chains, Safety 4-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chains, Tire 6-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Change Engine Oil Message 2-72 . . . . . . . . . . . . . . . . . . . . . .
Change Trans Fluid Message 2-72 . . . . . . . . . . . . . . . . . . . . . .
Changing a Flat Tire 5-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Charging System Indicator Light 2-62 . . . . . . . . . . . . . . . . . . .
Check Brake Fluid Message 2-84 . . . . . . . . . . . . . . . . . . . . . .
Check Coolant Level Message 2-84 . . . . . . . . . . . . . . . . . . . . .

yellowblue
8-7
Ice Possible Message 2-75 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ignition Positions 2-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Illuminated Entry 2-44 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inadvertent Power Battery Saver 2-44 . . . . . . . . . . . . . . . . . . .
Indicator, Oil Life 2-84 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inflation, Tire Pressure 6-40 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Instrument Panel 2-56 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning the Top 6-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cluster 2-58 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Intensity/Brightness Control 2-43 . . . . . . . . . . . . . . . . . . . .
Interior Lamps 2-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Jack, Tire 5-21, 5-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Jump Starting 5-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Keyless Entry System, Remote 2-6 . . . . . . . . . . . . . . . . . . . .
Keys 2-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Labels
Certification 4-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service Parts Identification 6-55 . . . . . . . . . . . . . . . . . . . . .
Tire-Loading Information 4-29 . . . . . . . . . . . . . . . . . . . . . .
Vehicle Identification Number 6-55 . . . . . . . . . . . . . . . . . . .
Lamps
Cornering 2
-42 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Daytime Running Lamps 2-41 . . . . . . . . . . . . . . . . . . . . . . .
Exterior 2-40 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Fog 2
-42 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Instrument Panel Intensity/Brightness Control 2-43 . . . . . .
Interior 2-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
On Reminder 2-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parking 2-40 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Reading 2-44 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Underhood 6-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Latches, Seatback 1-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Leaving Your Vehicle 2-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Leaving Your Vehicle with the Engine Running 2-28 . . . . . . .
Light Sensor 2-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lighted Visor Vanity Mirrors 2-51 . . . . . . . . . . . . . . . . . . . . . .
Lighter 2-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lights
Air Bag Readiness 1
-22, 2-62 . . . . . . . . . . . . . . . . . . . . . . .
Anti-Lock Brake System Warning 2-64, 4-7 . . . . . . . . . . . .
Brake System Warning 2-62 . . . . . . . . . . . . . . . . . . . . . . . . .
Charging System Indicator 2-62 . . . . . . . . . . . . . . . . . . . . . .
Engine Coolant Temperature Warning 2-65 . . . . . . . . . . . . .
Oil Pressure 2-68 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parking Brake Indicator 2-63 . . . . . . . . . . . . . . . . . . . . . . . .
Safety Belt Reminder 1-7, 2-61 . . . . . . . . . . . . . . . . . . . . . .
Service Engine Soon 2-66 . . . . . . . . . . . . . . . . . . . . . . . . . .
Traction Control System Warning 2-64, 4-9 . . . . . . . . . . . .
Limiter, Engine Speed 2-60 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Limiter, Vehicle Speed 2-60 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Loading Your Vehicle 4-29 . . . . . . . . . . . . . . . . . . . . . . . . . . .
