Page 9 of 365
1-3 Power Lumbar Control (Option)
If your vehicle has this
option, the driver's and
passenger's controls are
located on the outboard
sides of the seat cushions.The power lumbar support control can be adjusted the
following ways:
To increase or decrease support, hold the control
forward or rearward.
To move the lumbar up and down, hold the control
up or down.
Keep in mind that as your seating position changes,
as it may during long trips, so should the position of
your lumbar support. Adjust the seat as needed.
If you have the optional personalization package, the
power lumbar control can be programmed for memory
recall. For more information, see ªMemory and
Personalization Featuresº and ªMemory Seat and
Mirrorsº in the Index.
Page 10 of 365
1-4 Memory Seat and Mirrors (If Equipped)
If your vehicle has this
feature, the controls are
located on the driver's
door armrest.
These buttons are used to program and recall memory
settings for the driver's seating and outside rearview mirror
positions. Use the following steps to program each button:
1. Adjust the driver's seat (including lumbar adjustments)
and both outside mirrors to a comfortable position.
2. Press the SET button.
3. Within five seconds, press button 1. A single beep
will sound through the driver's side front speaker to
let you know that the position has been stored.A second mirror and seating position may be
programmed by repeating the above steps and pressing
button 2 instead of button 1. Each time button 1 or 2 is
pressed and released while the vehicle is in PARK (P),
the memory position will be recalled. Each time a
memory button is pressed, a single beep will sound.
You can also recall a seat and mirror position if your
vehicle is not in PARK (P). Press and hold either
the 1 or 2 button until seat and mirror movement is
complete. Releasing the buttons will stop adjustment.
If you use the button with the unlock symbol on the
remote keyless entry transmitter to enter the vehicle, the
preset driver's seat and mirror positions will be recalled.
The numbers on the back of the transmitters, 1 or 2,
correspond to the numbers on the driver's armrest.
If the remote keyless entry transmitter was not used to
enter the vehicle, the last used seat and mirror positions
will be recalled when a key is inserted in the ignition
and is turned to RUN. The vehicle must be previously
programmed to turn this feature on. See ªMemory and
Personalization Featuresº in the Index.
Page 11 of 365
1-5
To stop recall movement of the memory feature at
any time, press one of the power seat controls or
memory buttons.
The EXIT button can be programmed to allow easy exit
for up to two drivers. Adjust the seat to a comfortable
ªexitº position and then press the SET button followed
by the EXIT button. While your vehicle is in PARK (P),
briefly press the EXIT button to recall your programmed
exit position.
Further programming for automatic seat and mirror
movement can be done using the Driver Information
Center (DIC). You can select or not select the following:
Automatic seat and mirror movement when the
vehicle is unlocked with the remote keyless entry
transmitter, or
automatic seat and mirror movement when a key
is placed in the ignition.
For programming information, see ªMemory and
Personalization Featuresº in the Index.Heated Front Seat (Option)
The switch for the heated
front seat is located in the
center console.
Move the switch to LO or HI to turn on the heating
elements in the seat. The LO setting warms the
seatback and cushion until the seat approximates body
temperature. The HI setting heats the seat to a slightly
higher temperature.
A light in the switch is on when the system is in use.
The heated seats can only be used when the ignition
is turned on.
To turn the heated front seat off, move the switch to
the center position.
Page 58 of 365
2-
2-1
Section 2 Features and Controls
Here you can learn about the many standard and optional features on your vehicle, and information on starting,
shifting and braking. Also explained are the instrument panel and the warning systems that tell you if everything is
working properly
-- and what to do if you have a problem.
2
-2 Windows
2
-4 Keys
2
-6 Door Locks
2
-8 Remote Keyless Entry System
2
-12 Trunk
2
-15 Theft
2
-16 Theft-Deterrent System
2
-18 PASS-Key II
2
-19 New Vehicle ªBreak-Inº
2
-19 Ignition Positions
2
-21 Starting Your Engine
2
-22 Engine Coolant Heater (If Equipped)
2
-24 Automatic Transaxle Operation
2
-27 Parking Brake
2
-29 Shifting Into PARK (P)
2
-31 Shifting Out of PARK (P)
2
-31 Parking Over Things That Burn2
-32 Engine Exhaust
2
-32 Running Your Engine While You're Parked
2
-33 Tilt Wheel
2
-34 Turn Signal/Multifunction Lever
2
-42 Exterior Lamps
2
-46 Interior Lamps
2
-48 Mirrors
2
-51 Storage Compartments
2
-53 Sun Visors
2
-54 OnStar System (If Equipped)
2
-57 Sunroof (Option)
2
-58 HomeLink Transmitter (Option)
2
-62 The Instrument Panel -- Your
Information System
2
-66 Warning Lights, Gages and Indicators
2
-78 Driver Information Center (DIC)
Page 327 of 365
6-67
Fuse Usage
RADIO/PHONERadio Receiver, Radio Interface
Module (RIM) (Optional),
Phone, RAP Relay, Trunk Release
Relay, Fuel Door Release Relay,
High/Low
-Beam Relay
CLUSTER Steering Wheel Controls, Cluster
ACC PZM, Electrochromic Mirror,
Rain Sensor (Optional),
Accessory Relay
HTD BACKLT Rear Window Defogger
HTD MIR Right and Left Outside
Heated Mirror
HTD SEAT R Passenger Heated Seat
Relay (Optional)
HTD SEAT L Driver Heated Seat
Relay (Optional)
PULL DOWN Trunk Pull
-Down Motor
SPARE Spare Fuse
ANTENNA Power Mast Antenna
RSS Damper Relay (ETC Only)Fuse Usage
CONVENC Trunk Release Relay, Trunk
Release Solenoid, Fuel Door
Release Relay, Fuel Filler Door
Release Solenoid, Door Lock
Relay, Left and Right Door Motors,
PZM, Door Unlock Relay
BATT Driver and Passenger Seat
Lumbar Switch (Optional),
Driver and Passenger Seat Belt
Comfort Solenoid, Memory Seat
Module (Optional)
RSS Road Sensing Suspension (RSS)
Module (ETC Only)
RT PARK Headlamp Switch, Right Front
Parking Lamp, Right Front
and Rear Sidemarker Lamps,
Right Turn/Stop/Tail Lamps
LT PARK Left Front and Rear Sidemarker
Lamps, Left Front Parking Lamp,
Left Turn/Stop/Tail Lamps,
Right and Left License Lamps,
Underhood Lamp
