6-25
CAUTION:
Adding only plain water to your cooling system
can be dangerous. Plain water, or some other
liquid like alcohol, can boil before the proper
coolant mixture will. Your vehicle's coolant
warning system is set for the proper coolant
mixture. With plain water or the wrong mixture,
your engine could get too hot but you wouldn't
get the overheat warning. Your engine could
catch fire and you or others could be burned.
Use a 50/50 mixture of clean, drinkable water
and DEX
-COOL
coolant.
NOTICE:
If you use an improper coolant mixture, your
engine could overheat and be badly damaged.
The repair cost wouldn't be covered by your
warranty. Too much water in the mixture can
freeze and crack the engine, radiator, heater core
and other parts.
If you have to add coolant more than four times a year,
have your dealer check your cooling system.
NOTICE:
If you use the proper coolant, you don't have to
add extra inhibitors or additives which claim to
improve the system. These can be harmful.

yellowblue
6-26 Checking Coolant
The coolant recovery tank is located on the passenger's
side at the rear corner of the engine compartment.
The vehicle must be on a level surface. When your
engine is cold, the coolant level should be at the COLD
mark, or a little higher. When your engine is warm, the
level should be at the HOT mark, or a little higher.
Adding Coolant
If you need more coolant, add the proper DEX
-COOL

coolant mixture at the coolant recovery tank.
CAUTION:
Turning the radiator pressure cap when the
engine and radiator are hot can allow steam and
scalding liquids to blow out and burn you badly.
With the coolant recovery tank, you will almost
never have to add coolant at the radiator.
Never turn the radiator pressure cap
-- even a
little
-- when the engine and radiator are hot.
Add coolant mixture at the recovery tank, but be careful
not to spill it.
CAUTION:
You can be burned if you spill coolant on hot
engine parts. Coolant contains ethylene glycol,
and it will burn if the engine parts are hot
enough. Don't spill coolant on a hot engine.

yellowblue
6-27
Power Steering Fluid
When to Check Power Steering Fluid
It is not necessary to regularly check power steering
fluid unless you suspect there is a leak in the system or
you hear an unusual noise. A fluid loss in this system
could indicate a problem. Have the system inspected
and repaired.
How to Check Power Steering Fluid
When the engine compartment is cool, wipe the cap and
the top of the reservoir clean, then unscrew the cap and
wipe the dipstick with a clean rag. Replace the cap and
completely tighten it. Then remove the cap again and
look at the fluid level on the dipstick.
The level should be at the FULL COLD mark. If
necessary, add only enough fluid to bring the level up to
the mark.
What to Use
To determine what kind of fluid to use, see
ªRecommended Fluids and Lubricantsº in the
Maintenance Schedule booklet. Always use the proper
fluid. Failure to use the proper fluid can cause leaks and
damage hoses and seals.

yellowblue
6-29
Brakes
Brake Fluid
Your brake master cylinder
reservoir is here. It is filled
with DOT
-3 brake fluid.
There are only two reasons why the brake fluid level in the
reservoir might go down. The first is that the brake fluid
goes down to an acceptable level during normal brake
lining wear. When new linings are put in, the fluid level
goes back up. The other reason is that fluid is leaking out
of the brake system. If it is, you should have your brake
system fixed, since a leak means that sooner or later your
brakes won't work well, or won't work at all.So, it isn't a good idea to ªtop offº your brake fluid.
Adding brake fluid won't correct a leak. If you add fluid
when your linings are worn, then you'll have too much
fluid when you get new brake linings. You should add
(or remove) brake fluid, as necessary, only when work is
done on the brake hydraulic system.
CAUTION:
If you have too much brake fluid, it can spill on
the engine. The fluid will burn if the engine is hot
enough. You or others could be burned, and your
vehicle could be damaged. Add brake fluid only
when work is done on the brake hydraulic system.
Refer to the Maintenance Schedule to determine when to
check your brake fluid. See ªPeriodic Maintenance
Inspectionsº in the Maintenance Schedule booklet.

yellowblue
6-64 Wheels and Tires
MODEL DESCRIPTION TORQUE
K 1500 6 bolts (14 mm) 140 lb
-ft (190 N´m)
Tire Pressure See the Certification/Tire label on
the rear edge of the driver's door.
Cooling System Capacity (Approximate)
After refill, the level must be rechecked. See ªCooling Systemº in the Index.
ENGINE VIN QTY
ªVORTECº 5700 V8 R 17.5 Quarts (16.5 L)
Crankcase Capacity (Approximate)
After refill, the level must be rechecked. See ªEngine Oilº in the Index.
ENGINE VIN QUANTITY WITH FILTER

ªVORTECº 5700 V8 R 5.0 Quarts (4.8 L)

Oil filter should be changed at every oil change.

yellowblue
7-12
CURRENT PUBLICATIONS FOR 1999 CADILLAC
SERVICE MANUALS
Service Manuals have the diagnosis and repair information
on engines, transmission, axle, suspension, brakes,
electrical, steering, body, etc.
RETAIL SELL PRICE: $90.00
TRANSMISSION, TRANSAXLE, TRANSFER CASE
UNIT REPAIR MANUAL
This manual provides information on unit repair service
procedures, adjustments and specifications for the
1999 GM transmissions, transaxles and transfer cases.
RETAIL SELL PRICE: $50.00
SERVICE BULLETINS
Service Bulletins give technical service information needed
to knowledgeably service General Motors cars and trucks.
Each bulletin contains instructions to assist in the
diagnosis and service of your vehicle.OWNER'S INFORMATION
Owner publications are written directly for Owners and
intended to provide basic operational information about
the vehicle.
In-Portfolio: Includes a Portfolio, Owner's Manual and
Warranty Booklet.
RETAIL SELL PRICE: $20.00
Without Portfolio: Owner's Manual only.
RETAIL SELL PRICE: $15.00
CURRENT & PAST MODEL ORDER FORMS
Service Publications are available for current and past
model GM vehicles. To request an order form, please
specify year and model name of the vehicle.
PLEASE COMPLETE THE ORDER FORM SHOWN ON
THE FOLLOWING PAGE AND MAIL TO:
Helm, Incorporated
P.O. Box 07130
Detroit, MI 48207OR ORDER TOLL FREE: 1-800-551-4123
Monday-Friday 8:00 AM ± 6:00 PM Eastern Time
For Credit Card Orders Only (VISA±MasterCard±Discover)
1999 CADILLAC SERVICE PUBLICATIONS ORDERING INFORMATION
The following publications covering the operation and servicing of your vehicle can be purchased by filling out
the Service Publication Order Form in this book and mailing it in with your check, money order,
or credit card information to Helm, Incorporated (address below.)

yellowblue
8-5
Flat Tire, Changing 5-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid Capacities 6-64, 6-65 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid Leak Check 6-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fog Lamps 2-49, 6-36, 6-62 . . . . . . . . . . . . . . . . . . . . . . . . . .
Folding the Rear Seat 1-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Foreign Countries, Fuel 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Four-Wheel Drive 2-29, 6-21 . . . . . . . . . . . . . . . . . . . . . . . . .
Four-Wheel Drive, Automatic Transfer Case 2-29, 6-21 . . . .
Freeway Driving 4-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
French Language Manual ii. . . . . . . . . . . . . . . . . . . . . . . . . . .
Front
Axle 6
-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Axle Locking Feature 2-29 . . . . . . . . . . . . . . . . . . . . . . . . . .
Park/Turn Signal Bulb Replacement 6-35, 6-62 . . . . . . . . .
Sidemarker Lamp Bulb Replacement 6-35, 6-62 . . . . . . . .
Towing 5-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel 6-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Canada 6-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Filling a Portable Container 6-8 . . . . . . . . . . . . . . . . . . . . . .
Filling Your Tank 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gage 2-82 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
In Foreign Countries 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . .
System Capacity 6-65 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuses and Circuit Breakers 6-57 . . . . . . . . . . . . . . . . . . . . . . .
Gages
Engine Coolant Temperature 2-76 . . . . . . . . . . . . . . . . . . . .
Engine Oil Pressure 2-79 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel 2-82 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Speedometer 2
-71 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tachometer 2-71 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Voltmeter 2-74 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GAWR 4-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gear Positions, Automatic Transmission 2-26 . . . . . . . . . . . . .
Glove Box 2-56 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GM Mobility Program for Persons with Disabilities 7-5 . . . . .
GM Vehicle Care/Appearance Materials 6-54 . . . . . . . . . . . . .
Gross Axle Weight Rating 4-41 . . . . . . . . . . . . . . . . . . . . . . . .
Gross Vehicle Weight Rating 4-41 . . . . . . . . . . . . . . . . . . . . . .
Guide en Fran†ais ii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GVWR 4
-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Halogen Bulbs 6-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hazard Warning Flashers 5-2 . . . . . . . . . . . . . . . . . . . . . . . . . .
Head Restraints 1-5, 1-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlamp Delay 2-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlamps 2-47, 6-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bulb Replacement 6-34, 6-62 . . . . . . . . . . . . . . . . . . . . . . .
High/Low Beam Changer 2-42 . . . . . . . . . . . . . . . . . . . . . .
On Reminder 2-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiring 6-56 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hearing Impaired, Customer Assistance 7-3 . . . . . . . . . . . . . .
Heated Front Seats 1-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Heated Rear Seats 1-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Heating 3-2, 3-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
High-Beam Headlamps 2-42 . . . . . . . . . . . . . . . . . . . . . . . . . .
Highway Hypnosis 4-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hill and Mountain Roads 4-34 . . . . . . . . . . . . . . . . . . . . . . . . .
Hitches, Trailer 4-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

yellowblue
8-6
Hood
Checking Things Under 6-8 . . . . . . . . . . . . . . . . . . . . . . . . .
Release 6-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Horn 2-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hydroplaning 4-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ignition Positions 2-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inflation, Tire 6-39 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inside Rearview Mirror 2-52 . . . . . . . . . . . . . . . . . . . . . . . . . .
Instrument Panel 2-68 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brightness Control 2-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning 6-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cluster 2-70 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuse Block 6-57 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior Lamps 2-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Jack, Tire 5-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Jump Starting 5-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Keyless Entry System 2-6 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Keys 2-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Labels
Certification/Tire 4-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service Parts Identification 6-55 . . . . . . . . . . . . . . . . . . . . .
Tire-Loading Information 4-41 . . . . . . . . . . . . . . . . . . . . . .
Vehicle Identification Number 6-55 . . . . . . . . . . . . . . . . . . . Lamps 2
-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic 2-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning Exterior 6-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Delay 2-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dome 2-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exterior 2-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fog 2-49, 6-36, 6-62 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior 2-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
On Reminder 2-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Leaving Your Vehicle 2-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Leaving Your Vehicle with the Engine Running 2-35 . . . . . . .
Lighter 2-62 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lights
Air Bag Readiness 1
-25, 2-73 . . . . . . . . . . . . . . . . . . . . . . .
Anti-Lock Brake System Warning 2-75, 4-7 . . . . . . . . . . . .
Brake System Warning 2-74 . . . . . . . . . . . . . . . . . . . . . . . . .
Charging Warning System 2-73 . . . . . . . . . . . . . . . . . . . . . .
Check Gages 2-81 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Daytime Running Lamps Indicator 2-81 . . . . . . . . . . . . . . .
Headlamp High-Beam Indicator 2-81 . . . . . . . . . . . . . . . . .
Safety Belt Reminder 1-9, 2-72 . . . . . . . . . . . . . . . . . . . . . .
Security 2-80 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service Engine Soon 2-76 . . . . . . . . . . . . . . . . . . . . . . . . . .
Service Four-Wheel Drive 2-80 . . . . . . . . . . . . . . . . . . . . . .
Turn Signal and Lane Change Indicator 2-82 . . . . . . . . . . .
Loading Your Vehicle 4-41 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Loading Your Vehicle for Off-Road Driving 4-14 . . . . . . . . . .
Lockout Prevention 2-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
