towing capacity CADILLAC ESCALADE 1999 1.G Owners Manual

yellowblue
4-44
NOTICE:
Pulling a trailer improperly can damage your
vehicle and result in costly repairs not covered by
your warranty. To pull a trailer correctly, follow
the advice in this part, and see your dealer for
important information about towing a trailer
with your vehicle.
Your vehicle may be able to tow a trailer. To identify
what the vehicle trailering capacity is for your vehicle,
you should read the information in ªWeight of the
Trailerº that appears later in this section.
If yours was built with trailering options, as many are,
it's ready for heavier trailers. But trailering is different
than just driving your vehicle by itself. Trailering means
changes in handling, durability and fuel economy.
Successful, safe trailering takes correct equipment, and
it has to be used properly.
That's the reason for this part. In it are many
time
-tested, important trailering tips and safety rules.
Many of these are important for your safety and that of
your passengers. So please read this section carefully
before you pull a trailer.
If You Do Decide To Pull A Trailer
If you do, here are some important points:

There are many different laws, including speed limit
restrictions, having to do with trailering. Make sure
your rig will be legal, not only where you live but
also where you'll be driving. A good source for this
information can be state or provincial police.

Consider using a sway control if your trailer will
weigh less than the capacity stamped on your step
bumper. You should always use a sway control if
your trailer will weigh more than the capacity
stamped on your step bumper. You can ask a hitch
dealer about sway controls.

Don't tow a trailer at all during the first 500 miles
(800 km) your new vehicle is driven. Your engine,
axle or other parts could be damaged.

Then, during the first 500 miles (800 km) that you
tow a trailer, don't drive over 50 mph (80 km/h) and
don't make starts at full throttle. This helps your
engine and other parts of your vehicle wear in at the
heavier loads.

yellowblue
8-5
Flat Tire, Changing 5-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid Capacities 6-64, 6-65 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid Leak Check 6-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fog Lamps 2-49, 6-36, 6-62 . . . . . . . . . . . . . . . . . . . . . . . . . .
Folding the Rear Seat 1-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Foreign Countries, Fuel 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Four-Wheel Drive 2-29, 6-21 . . . . . . . . . . . . . . . . . . . . . . . . .
Four-Wheel Drive, Automatic Transfer Case 2-29, 6-21 . . . .
Freeway Driving 4-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
French Language Manual ii. . . . . . . . . . . . . . . . . . . . . . . . . . .
Front
Axle 6
-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Axle Locking Feature 2-29 . . . . . . . . . . . . . . . . . . . . . . . . . .
Park/Turn Signal Bulb Replacement 6-35, 6-62 . . . . . . . . .
Sidemarker Lamp Bulb Replacement 6-35, 6-62 . . . . . . . .
Towing 5-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel 6-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Canada 6-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Filling a Portable Container 6-8 . . . . . . . . . . . . . . . . . . . . . .
Filling Your Tank 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gage 2-82 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
In Foreign Countries 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . .
System Capacity 6-65 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuses and Circuit Breakers 6-57 . . . . . . . . . . . . . . . . . . . . . . .
Gages
Engine Coolant Temperature 2-76 . . . . . . . . . . . . . . . . . . . .
Engine Oil Pressure 2-79 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel 2-82 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Speedometer 2
-71 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tachometer 2-71 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Voltmeter 2-74 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GAWR 4-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gear Positions, Automatic Transmission 2-26 . . . . . . . . . . . . .
Glove Box 2-56 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GM Mobility Program for Persons with Disabilities 7-5 . . . . .
GM Vehicle Care/Appearance Materials 6-54 . . . . . . . . . . . . .
Gross Axle Weight Rating 4-41 . . . . . . . . . . . . . . . . . . . . . . . .
Gross Vehicle Weight Rating 4-41 . . . . . . . . . . . . . . . . . . . . . .
Guide en Fran†ais ii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GVWR 4
-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Halogen Bulbs 6-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hazard Warning Flashers 5-2 . . . . . . . . . . . . . . . . . . . . . . . . . .
Head Restraints 1-5, 1-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlamp Delay 2-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlamps 2-47, 6-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bulb Replacement 6-34, 6-62 . . . . . . . . . . . . . . . . . . . . . . .
High/Low Beam Changer 2-42 . . . . . . . . . . . . . . . . . . . . . .
On Reminder 2-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiring 6-56 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hearing Impaired, Customer Assistance 7-3 . . . . . . . . . . . . . .
Heated Front Seats 1-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Heated Rear Seats 1-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Heating 3-2, 3-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
High-Beam Headlamps 2-42 . . . . . . . . . . . . . . . . . . . . . . . . . .
Highway Hypnosis 4-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hill and Mountain Roads 4-34 . . . . . . . . . . . . . . . . . . . . . . . . .
Hitches, Trailer 4-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
