CADILLAC ESCALADE 2000 1.G Owners Manual

2-83 Security Light
This light will come on
briefly when you turn the
key to START.
The light will stay on until the engine starts. If the light
flashes, the Passlock

System has entered a tamper
mode. If the vehicle fails to start, see ªPasslockº in
the Index.
If the light comes on continuously while driving and
stays on, there may be a problem with the Passlock
System. Your vehicle will not be protected by Passlock,
and you should see your Cadillac dealer.
Service Four-Wheel Drive Warning Light
Your vehicle is equipped with an automatic
four
-wheel-drive transfer case. It has a computer which
controls the four
-wheel-drive system.
This light should come on
briefly when you turn on the
ignition, as a check to show
you it is working.
If the SERVICE 4WD light comes on, there may be a
problem with the automatic four
-wheel-drive system
and service is required. Malfunctions can be indicated
by the system before any problem is apparent, which
may prevent serious damage to the vehicle. This system
is also designed to assist your service technician in
correctly diagnosing a malfunction.

2-84 Daytime Running Lamps (DRL)
Indicator Light
This light will turn on
whenever the DRL are on.
When it begins to get dark, the DRL indicator light will
turn off and your automatic headlamps will turn on.
Check Gages Light
This light will come on
briefly when you are
starting the engine.
If the light comes on and stays on while you are driving,
it could indicate a problem with your vehicle. It could be
a problem with your oil pressure, coolant temperature,
or some other problem. Check your various gages to see
if they are in the warning zones. If they are, have your
vehicle serviced right away.
Headlamp High-Beam Indicator Light
The high-beam indicator is
on whenever you use your
high
-beam headlamps. For
more details about high
beams, see ªHeadlamp
High/Low
-Beam Changerº
in the Index.
Turn Signal and Lane Change
Indicator Lights
The signal indicator will
come on whenever you
signal a turn or lane change.
See ªTurn and Lane Change
Signalsº in the Index.

2-85 Fuel Gage
When the ignition is on, the
fuel gage tells you about
how much fuel you have
left in your tank.
The gage will first indicate E (Empty) before you are
out of fuel, and you should get more fuel as soon
as possible.Listed are four situations you may experience with your
fuel gage:

At the gas station, the fuel pump shuts off before the
gage reads F (Full).

It takes a little more or less fuel to fill up than the
fuel gage indicated. For example, the gage may have
indicated the tank was half full, but it actually took a
little more or less than half the tank's capacity to fill
the tank.

The gage moves a little when you turn a corner or
speed up.

The gage doesn't go back to E (Empty) when you
turn off the ignition.
None of these indicate a problem with the fuel gage.
For information on how to fill your fuel tank, see ªFuel,
Filling Your Tankº in the Index.
For your fuel tank capacity, see ªFuel, System Capacityº
in the Index.

3-
3-1
Section 3 Comfort Controls and Audio Systems
In this section, you'll find out how to operate the comfort control and audio systems offered with your vehicle.
Be sure to read about the particular systems supplied with your vehicle.
3
-2 Comfort Controls
3
-3 Rear Air Conditioning
3
-4 Air Conditioning
3
-5 Heating
3
-5 Ventilation System
3
-6 Defogging and Defrosting
3
-6 Rear Window Defogger
3
-7 Audio Systems
3
-7 Setting the Clock
3
-8AM-FM Stereo with Cassette Tape Player3
-12 CD Adapter Kits
3
-12 Rear Seat Audio (RSA)
3
-14 Remote Compact Disc Player
3
-16 Console-Mounted CD Changer
3
-18 Theft-Deterrent Feature
3
-20 Understanding Radio Reception
3
-20 Tips About Your Audio System
3
-21 Care of Your Cassette Tape Player
3
-22 Care of Your Compact Discs
3
-22 Fixed Mast Antenna

3-2
Comfort Controls
Heater and Air Conditioning
Control System
Fan Knob
The knob on the left side of the heating system control
panel controls the fan speed. The knob has four speed
positions. To increase airflow, move the knob toward
HI. To decrease airflow, move it toward LO. To turn the
fan off, move the knob to OFF. If you have the air
conditioner on, moving the fan knob to OFF also turns
off the A/C compressor.In OFF, while driving, air will flow through the floor
outlets. The mode knob will not redirect the airflow to
other selected outlet positions. This is normal operation
for the OFF position.
Temperature Knob
The middle knob on the control panel lets you select the
relative temperature of the air flowing into the passenger
area of your vehicle. This knob will allow you to adjust
the relative air temperature independently of the
function knob setting. Move the knob to the right toward
the red area for warmer air. Move the knob to the left
toward the blue area for cooler air.
Mode Knob
The right knob on the control panel allows you to
choose the direction of air delivery. The control knob
can be placed in any position between any two mode
settings to blend the flow of air.
VENT: This setting directs air through the
instrument panel outlets.

3-3
VENT/HEAT: Use this setting to divide airflow
between the floor outlets and instrument panel outlets.
HEATER: This setting directs air through the
floor outlets.
DEFOG: This setting directs air to the heater
outlets and toward the windshield.
DEFROST: This setting directs air toward
the windshield.
Rear Air Conditioning
You can increase and decrease the airflow at the rear vents.
You can also send cooled air to the rear of the vehicle.
Your vehicle has rear air conditioning (without rear
heater). The controls are located above the front and rear
seats. The front and rear overhead controls let you
increase and decrease the airflow at the rear vents.To operate the rear air conditioning system, the front air
conditioning system must be on. With the front air
conditioning system off, the rear system controls can be
used to circulate air in the rear of the vehicle.
FRONT CONTROLS
To operate the rear system using the front control, just
turn the knob to the blower position you want.

3-4
REAR CONTROLS
To use the rear control, first turn the front control knob
to REAR CNTL. Then, the rear control can be used to
increase and decrease the airflow.
Air Conditioning
On hot days, open the windows long enough to let hot
air inside escape. This reduces the time it takes for your
vehicle to cool down. Then keep your windows closed
for the air conditioner to work its best.
The recirculation button, between the fan and
temperature knobs, allows the air inside your vehicle
to be recirculated. This setting helps to maximize
your air conditioner's performance and your vehicle's
fuel economy. This setting also cools the air the fastest and can be used
to keep unwanted odors and/or dust from entering the
vehicle. When using the air conditioner, turn off
recirculation after the vehicle reaches a comfortable
interior temperature. When the right knob on the control
panel is between HEATER and DEFROST, the
recirculation feature will not function.
The A/C button allows the air coming into your vehicle
to be cooled. This setting is useful for normal cooling on
hot days. When you use A/C with the recirculation
button pushed in, turn off recirculation as soon as the
vehicle reaches a comfortable interior temperature.
With the A/C on, move the temperature knob to MAX
for maximum cooling. This setting also puts the system
in the recirculation mode and helps to maximize your
air conditioner's performance and your vehicle's fuel
economy. This setting also cools the air the fastest. After
the vehicle's interior reaches a comfortable temperature,
move the temperature knob to the right to place the air
conditioning system in the normal mode.

3-5 Heating
The heater works best if you keep your windows closed
while using it. On cold days, use the HEATER or
VENT/HEAT setting with the temperature knob in
the red area.
If you use the engine coolant heater before starting your
engine in cold weather, 20
F (
-8
C) or lower, your
heating system will produce warmer air faster, to heat
the passenger compartment in cold weather.
The use of an engine coolant heater also reduces the
time it takes for the engine to reach normal operating
temperature, and shortens the time it takes the heater to
reach full output. For more information, see ªEngine
Coolant Heaterº in the Index.
Ventilation System
For mild outside temperatures when little heating or
cooling is needed, use VENT to direct outside air
through your vehicle. Air will flow through the
instrument panel outlets.
The ventilation system supplies outside air to the inside
of your vehicle when it is moving. With the side windows
closed, air will flow into the front air inlet grilles, through
the vehicle, and out the air exhaust valves.Outside air will also enter the vehicle when the heater or
the air conditioning fan is running, unless you have the
recirculation button pushed in. For more information on
the recirculation button, see ªAir Conditioningº earlier
in this section.
Your vehicle has air outlets
in the center and on
the sides of your
instrument panel.
You can move the outlets from side
-to-side or up and
down to direct the flow of air, or close the outlets
altogether. When you close an outlet, it will increase the
flow of air coming out of any outlets that are open.
These outlets do not completely shut off airflow when in
a closed vent position.

3-6
Ventilation Tips

Keep the hood and front air inlet free of ice, snow or
any other obstruction (such as leaves). The heater
and defroster will work far better, reducing the
chance of fogging the inside of your windows.

When you enter a vehicle in cold weather, turn the
blower fan to HI for a few moments before driving.
This helps clear the intake ducts of snow and
moisture, and reduces the chance of fogging the
inside of your windows.

Keep the air path under the front seats clear of
objects. This helps air to circulate throughout
your vehicle.

The use of hood air deflectors may adversely
affect the performance of the heating and air
conditioning system.Defogging and Defrosting
On cool, humid days, use DEFOG to keep the windshield
and side windows clear. Use DEFROST to remove fog or
ice from the windshield in extremely humid or cold
conditions. Use DEFROST with the temperature knob
toward the red area and the fan control toward HI.
Rear Window Defogger
The lines you see running across the rear window, are
the rear window defogger. The lines warm the glass.
To turn on the rear window
defogger, press this button
next to the fan control knob.
The rear window defogger
will only work if the
ignition switch is turned to
RUN. For best results, first
clear the window of as
much snow or ice
as possible.

3-7
The defogger will shut itself off after several minutes.
If you need additional warming time, press the button
again. You can turn the defogger off at any time by
pressing the button.
The rear window defogger button will activate the rear
window defogger and the heated outside rearview mirrors.
Do not attach a temporary vehicle license, tape or decals
across the defogger grid on the rear window.
NOTICE:
Don't use a razor blade or anything else sharp on
the inside of the rear window. If you do, you
could cut or damage the warming grid, and the
repairs wouldn't be covered by your warranty.
Audio Systems
Your audio system has been designed to operate easily
and give years of listening pleasure. You will get the
most enjoyment out of it if you acquaint yourself with it
first. Find out what your audio system can do and how
to operate all its controls, to be sure you're getting the
most out of the advanced engineering that went into it.
Setting the Clock
Press and hold HR until the correct hour appears on the
display. Press and hold MN until the correct minute
appears on the display. To display the clock with the
ignition off, press RECALL or HR/MN and the time
will be displayed for a few seconds. There is an initial
two
-second delay before the clock goes into the
time
-set mode.
